Back door INFINITI QX56 2011 Factory Service Manual

DLK-262
< REMOVAL AND INSTALLATION >
AUTOMATIC BACK DOOR CONTROL MODULE
AUTOMATIC BACK DOOR CONTROL MODULE
Removal and InstallationINFOID:0000000006226129
REMOVAL
1. Remove the luggage side finisher lower LHD. Refer to INT-36, "LUGGAGE SIDE LOWER FINISHER :
Removal and Installation".
2. Remove the automatic back door control unit bra cket mounting bolt and nats, and then remove the auto-
matic back door control unit bracket.
3. Remove the automatic back door control unit m ounting bolt, and then remove the automatic back door
control unit.
INSTALLATION
Install in the reverse order of removal.
NOTE:
After installing back door control unit, perform additional service when replace control unit. Refer to DLK-80,
"ADDITIONAL SERVICE WHEN REPLACING (AUTOMATIC BACK DOOR CONTROL MODULE) : Work Pro-
cedure".
Revision: 2010 May2011 QX56

AUTOMATIC BACK DOOR WARNING BUZZERDLK-263
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
L
M A
B
DLK
N
O P
AUTOMATIC BACK DOOR WARNING BUZZER
Removal and InstallationINFOID:0000000006226130
REMOVAL
1. Remove the back door finisher inner. Refer to INT-39, "Removal and Installation".
2. Remove the automatic back door warning buzzer mounting nut, and then remove the automatic back door
warning buzzer.
INSTALLATION
Install in the reverse order of removal.
Revision: 2010 May2011 QX56

DLK-264
< REMOVAL AND INSTALLATION >
AUTOMATIC BACK DOOR MAIN SWITCH
AUTOMATIC BACK DOOR MAIN SWITCH
Removal and InstallationINFOID:0000000006226131
REMOVAL
1. Remove the instrument driver lower panel LH. Refer to IP-14, "Removal and Installation".
2. Widen the pawl, and remove the automatic ba ck door main switch from switch bracket.
INSTALLATION
Install in the reverse order of removal.
Revision: 2010 May2011 QX56

AUTOMATIC BACK DOOR CLOSE SWITCHDLK-265
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
L
M A
B
DLK
N
O P
AUTOMATIC BACK DOOR CLOSE SWITCH
Removal and InstallationINFOID:0000000006226132
REMOVAL
1. Remove the automatic back door close switch finisher.
2. Widen the pawl, and remove the automatic back door close switch (1) from automatic back door close
switch finisher (2).
INSTALLATION
Install in the reverse order of removal. :
Pawl
JMKIA1847ZZ
Revision: 2010 May2011 QX56

DLK-266
< REMOVAL AND INSTALLATION >
AUTOMATIC BACK DOOR SWITCH
AUTOMATIC BACK DOOR SWITCH
Removal and InstallationINFOID:0000000006226133
REMOVAL
1. Remove the instrument driver lower panel. Refer to IP-14, "Removal and Installation".
2. Widen the pawl, and remove the automatic back door s witch from automatic back door switch finisher.
INSTALLATION
Install in the reverse order of removal.
Revision: 2010 May2011 QX56

EXL-3
C
DE
F
G H
I
J
K
M A
B
EXL
N
O P
EXTERIOR LAMP FUSE ................................ ....85
Diagnosis Procedure ........................................... ....85
HEADLAMP (HI) CIRCUIT .................................86
Component Function Check ................................ ....86
Diagnosis Procedure ...............................................86
HEADLAMP (LO) CIRCUIT ................................88
Component Function Check ................................ ....88
Diagnosis Procedure ...............................................88
XENON HEADLAMP ..........................................90
Diagnosis Procedure ........................................... ....90
HEADLAMP LEVELIZER CIRCUIT ...................91
Component Function Check ................................ ....91
Diagnosis Procedure ...............................................91
HEADLAMP AIMING SYSTEM (MANUAL) .......93
Component Inspection ........................................ ....93
FRONT FOG LAMP CIRCUIT ............................94
Component Function Check ................................ ....94
Diagnosis Procedure ...............................................94
PARKING LAMP CIRCUIT ............................. ....96
Component Function Check ................................ ....96
Diagnosis Procedure ...............................................96
FRONT SIDE MARKER LAMP CIRCUIT ...........98
Component Function Check ................................ ....98
Diagnosis Procedure ...............................................98
TURN SIGNAL LAMP CIRCUIT .........................99
Component Function Check ................................ ....99
Diagnosis Procedure ...............................................99
OPTICAL SENSOR ..........................................102
Component Function Check ................................ ..102
Diagnosis Procedure .............................................102
HAZARD SWITCH .......................................... ..105
Component Function Check ................................ ..105
Diagnosis Procedure .............................................105
AFS SWITCH ....................................................107
Component Function Check ................................ ..107
Diagnosis Procedure .............................................107
Component Inspection ..........................................108
TAIL LAMP CIRCUIT .......................................109
BODY SIDE ........................................................... ..109
BODY SIDE : Component Function Check ...........109
BODY SIDE : Diagnosis Procedure ......................109
BACK DOOR SIDE ................................................ ..110
BACK DOOR SIDE : Component Function Check ..110
BACK DOOR SIDE : Diagnosis Procedure ...........111
LICENSE PLATE LAMP CIRCUIT ...................112
Component Function Check ................................ ..112
Diagnosis Procedure .............................................112
SYMPTOM DIAGNOSIS ............................113
EXTERIOR LIGHTING SYSTEM SYMPTOMS .113
Symptom Table ................................................... ..113
NORMAL OPERATING CONDITION .............116
Description .............................................................116
BOTH SIDE HEADLAMPS DO NOT SWITCH
TO HIGH BEAM ..............................................
117
Description .............................................................117
Diagnosis Procedure .............................................117
BOTH SIDE HEADLAMPS (LO) ARE NOT
TURNED ON ...................................................
118
Description ........................................................... ..118
Diagnosis Procedure .............................................118
PARKING, LICENSE PLATE, SIDE MARKER
AND TAIL LAMPS ARE NOT TURNED ON ...
119
Description .............................................................119
Diagnosis Procedure .............................................119
BOTH SIDE FRONT FOG LAMPS ARE NOT
TURNED ON ...................................................
120
Description ........................................................... ..120
Diagnosis Procedure .............................................120
PERIODIC MAINTENANCE ......................121
HEADLAMP AIMING ADJUSTMENT .............121
description ........................................................... ..121
Aiming Adjustment Procedure ...............................122
FRONT FOG LAMP AIMING ADJUSTMENT .123
Description .............................................................123
Aiming Adjustment Procedure ...............................123
REMOVAL AND INSTALLATION .............125
FRONT COMBINATION LAMP ......................125
Exploded View ..................................................... ..125
Removal and Installation .......................................125
Replacement .........................................................126
Disassembly and Assembly ...................................127
FRONT FOG LAMP ........................................128
Exploded View .......................................................128
Removal and Installation .......................................128
Replacement .........................................................128
SIDE TURN SIGNAL LAMP ............................130
Exploded View .......................................................130
Removal and Installation .......................................130
OPTICAL SENSOR .........................................131
Exploded View .......................................................131
Removal and Installation .......................................131
LIGHTING & TURN SIGNAL SWITCH ...........132
Exploded View .......................................................132
Revision: 2010 May2011 QX56

COMPONENT PARTSEXL-7
< SYSTEM DESCRIPTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
*1: With headlamp aiming control system (manual) models
*2: With AFS system models
EXTERIOR LIGHTING SYSTEM : Component DescriptionINFOID:0000000006213888
1. Combination meter 2. BCM
Refer to BCS-4, "
BODY CONTROL
SYSTEM : Compon ent Parts Loca-
tion"
3. Optical sensor
4. IPDM E/R Refer to PCS-4, "
Component Parts
Location"
5. ECM
Refer to EC-16, "
Component Parts
Location"
6. Parking lamp
7. Front turn signal lamp 8. Front fog lamp 9. Headlamp
10. Front side marker lamp 11. Combination switch 12. Headlamp aiming switch*
1
13. Front door switch (driver side) 14.
Steering angle sensor*2
Refer to BRC-10, "Component Parts
Location"
15. License plate lamp
16. Tail lamp 17. Rear turn signal lamp 18. Rear side marker lamp
19. Hazard switch 20. Side turn signal lamp 21. Headlamp swivel actuator
22. Headlamp aiming motor 23. AFS switch*
224.Rear height sensor*2
25.AFS control unit*226.Front height sensor*2
A. Front combination lamp (back) B. View with instrument driver lower
panel (LH)C. Rear suspension member (RH)
D. View with instrument lower cover E. Front suspension arm (RH)
Part Description
BCM Controls the exterior lighting system.
ECM*
1Transmits engine speed signal to AFS control unit. (via CAN communication)
TCM*
1Transmits Shift position signal to AFS control unit. (via CAN communication)
IPDM E/R Controls the integrated relay, and supplies voltage to the load according to the request
from BCM (via CAN communication).
AFS control unit*
1AFS control unit judges the vehicle condition from each signal. AFS control unit con-
trols AFS function and the headlamp aiming.
Combination meter  Outputs the vehicle speed signal (8-pulse) to AFS control unit.
 Blinks the turn signal indicator lamp and outputs the turn signal operating sound with
integrated buzzer according to the request from BCM (via CAN communication).
 Turns the tail lamp indicator lamp and high beam indicator lamp ON according to the
request from BCM (via CAN communication).
 Turns the AFS OFF indicator lamp ON/OFF /blinking according to the request from
AFS control unit (via CAN communication).
Headlamp assembly Xenon bulb Refer to
EXL-8, "
FRONT COMBINATION LAMP : Xenon Headlamp".
HID control unit Refer to EXL-9, "
FRONT COMBINATION LAMP : HID control unit".
High beam solenoid Refer to EXL-9, "
FRONT COMBINATION LAMP : High Beam Solenoid".
Aiming motor Refer to EXL-9, "
FRONT COMBINATION LAMP : Aiming Motor".
Swivel actuator*
1Refer to EXL-9, "FRONT COMBINATION LAMP : Swivel Actuator".
Height sensor*
1
 The height sensor is installed to the front suspension member and rear suspension member.
 The height sensor detects the suspension arm displacement as the vehicle height change.
 The height sensor transmits the height sensor signal to AFS control unit.
NOTE:
The sensor angle of the unloaded vehicle position is the reference value.
Optical sensor Optical sensor converts the outside brightness (lux) to voltage and transmits the opti-
cal sensor signal to BCM.
Revision: 2010 May2011 QX56

EXL-22
< SYSTEM DESCRIPTION >[XENON TYPE]
DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT-III Fu
nction (BCM - COMMON ITEM)INFOID:0000000006368037
APPLICATION ITEM
CONSULT-III performs the following functions via CAN communication with BCM.
SYSTEM APPLICATION
BCM can perform the following functions for each system.
NOTE:
It can perform the diagnosis modes except the following for all sub system selection items.
×: Applicable item
*: This item is indicated, but not used.
FREEZE FRAME DATA (FFD)
The BCM records the following vehicle condition at the time a particular DTC is detected, and displays on
CONSULT-III.
Diagnosis mode Function Description
Work Support Changes the setting for each system function.
Self Diagnostic Result Displays the diagnosis results judged by BCM. Refer to BCS-57, "
DTCIndex".
CAN Diag Support Monitor Monitors the reception status of CAN communication viewed from BCM. Refer to CONSULT-III opera-
tion manual.
Data Monitor The BCM input/output signals are displayed.
Active Test The signals used to activate ea ch device are forcibly supplied from BCM.
Ecu Identification The BCM part number is displayed.
Configuration  Read and save the vehicle specification.
 Write the vehicle specification when replacing BCM.
System Sub system selection item Diagnosis mode
Work Support Data Monitor Active Test
Door lock DOOR LOCK ×××
Rear window defogger REAR DEFOGGER ××
Warning chime BUZZER ××
Interior room lamp timer INT LAMP ×××
Exterior lamp HEAD LAMP ×××
Wiper and washer WIPER ×××
Turn signal and hazard warning lamps FLASHER ×××
— AIR CONDITONER* ××
 Intelligent Key system
 Engine start system INTELLIGENT KEY
×××
Combination switch COMB SW ×
Body control system BCM ×
IVIS IMMU ×××
Interior room lamp battery saver BATTERY SAVER ×××
Back door TRUNK ×
Vehicle security system THEFT ALM ×××
RAP system RETAINED PWR ×
Signal buffer system SIGNAL BUFFER ××
Revision: 2010 May2011 QX56

DIAGNOSIS SYSTEM (BCM)EXL-25
< SYSTEM DESCRIPTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
ACTIVE TEST
*: Only models for Canada display this item.
FLASHER
FLASHER : CONSULT-III F unction (BCM - FLASHER)INFOID:0000000006213912
WORK SUPPORT
DOOR SW-DR
[On/Off] The switch status input from front door switch (driver side)
DOOR SW-AS
[On/Off] The switch status input from front door switch (passenger side)
DOOR SW-RR
[On/Off] The switch status input from rear door switch RH
DOOR SW- RL
[On/Off] The switch status input from rear door switch LH
DOOR SW-BK
[On/Off] The switch status input from back door switch
OPTICAL SENSOR
[On/Off] The sensor status input from optical sensor
OPTI SEN (DTCT)
[V] The value of outside brightness voltage input from the optical sensor
OPTI SEN (FILT)
[V] The value of outside brightness voltage filtered by BCM
Monitor item
[Unit] Description
Test item Operation Description
TAIL LAMP On
Transmits the position light request signal to IPDM E/R via CAN commu-
nication to turn the tail lamp ON
Off Stops the tail lamp request signal transmission
HEAD LAMP Hi
Transmits the high beam request signal via CAN communication to turn
the headlamp (HI)
Lo Transmits the low beam request signal via CAN communication to turn
the headlamp (LO)
Off Stops the high & low beam request signal transmission
FR FOG LAMP On
Transmits the front fog lights request signal to IPDM E/R via CAN com-
munication to turn the front fog lamp ON
Off Stops the front light request signal transmission
RR FOG LAMP On
NOTE:
This item is indicated, but can not tested
Off
DAYTIME RUNNING LIGHT* On
Transmits the front fog lights request signal to IPDM E/R via CAN com-
munication to turn the front fog lamp ON (daytime running light system)
Off Stops the front light request signal transmission (daytime running light
system)
ILL DIM SIGNAL On Transmits the dimmer signal to combination meter via CAN communi-
cation and dims combination meter
 Transmits the dimmer signal to AV control unit and dims display
Off Stops the dimmer signal transmission
Revision: 2010 May2011 QX56

EXL-26
< SYSTEM DESCRIPTION >[XENON TYPE]
DIAGNOSIS SYSTEM (BCM)
*: Factory setting
DATA MONITOR
ACTIVE TEST
Service item Setting item Setting
HAZARD ANSWER
BACK Lock Only With locking only
Sets the hazard warning lamp answer back function
when the door is lock/unlock with the request switch or
the key fob.
Unlk Only With unlocking only
Lock&Unlk
*With locking/unlocking
Off Without the function
Monitor item [Unit] Description
REQ SW-DR
[On/Off] The switch status input from the request switch (driver side)
REQ SW-AS
[On/Off] The switch status input from the request switch (passenger side)
PUSH SW
[On/Off] The switch status input from the push-button ignition switch
TURN SIGNAL R
[On/Off] Each switch status that BCM detects from the combination switch reading function
TURN SIGNAL L
[On/Off]
HAZARD SW
[On/Off] The switch status input from the hazard switch
RKE-LOCK
[On/Off] Lock signal status received from the remote keyless entry receiver
RKE-UNLOCK
[On/Off] Unlock signal status received from the remote keyless entry receiver
RKE-PANIC
[On/Off] Panic alarm signal status received from the remote keyless entry receiver
Test item Operation Description
FLASHER RH Outputs the voltage to blink the right side turn signal lamps.
LH Outputs the voltage to blink the left side turn signal lamps.
Off Stops the voltage to turn the turn signal lamps OFF.
Revision: 2010 May2011 QX56
