NORMAL OPERATING CONDITIONBRC-147
< SYMPTOM DIAGNOSIS > [BRAKE ASSIST (WITH PREVIEW FUNCTION)]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
SYMPTOM DIAGNOSIS
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000006228295
PRECAUTIONS FOR PREVIEW FUNCTION
 This system is only an aid to assist braking operation and is not a collision warning or avoidance device. It is
the driver ′s responsibility to stay alert, drive safely and be in control of the vehicle at all times.
 As there is a performance limit to the Preview Function, never rely solely on this system. This system does
not correct careless inattentive or absent-minded driving, or overcome poor visibility in rain, fog, or other bad
weather. Reduce vehicle speed by depressing the brake pedal , in order to maintain a safe distance between
vehicles.
 The system may not detect a vehicle ahead, depending on road or weather conditions. While the vehicle still
travels and the Brake Assist Syst em operates under normal conditions, the Preview Function may operate
improperly under the following conditions:
- When rain, snow or dirt adhere to the system sensor
- When strong light (for example, at sunrise or sunset ) is directly shining on the front of the vehicle
- Winding or hilly roads may cause the sensor to tem porarily not detect a vehicle in the same lane or may
detect objects or vehicles in other lanes.
- Vehicle position in the lane may cause the sensor to te mporarily not detect a vehicle in the same lane or may
detect objects or vehicles in other lanes.
 The system will not detect:
- Pedestrians or objects in the roadway
- Oncoming vehicles in the same lane
- Motorcycles traveling offset in the travel lane as illustrated
 When the Preview Function operates, the brake pedal may move slightly and may make a small noise. This is not a system malfunc-
tion.
JSFIA0390ZZ
Revision: 2010 May2011 QX56

BRC-152
< SYSTEM DESCRIPTION >[INTELLIGENT BRAKE ASSIST]
SYSTEM
SYSTEM
INTELLIGENT BRAKE ASSIST
INTELLIGENT BRAKE ASSIST : System DescriptionINFOID:0000000006228299
FUNCTION DESCRIPTION
Intelligent Brake Assist (IBA) syst
em warns the driver by a vehicle ahead detection indicator and chime when
there is a risk of a collision with the vehicle ahead in the traveling lane and the driver must take avoidance
action immediately. The system helps reduce the rear -end collision speed by applying the brakes when it
judges a collision can not be avoided.
CAUTION:
The IBA system is a not collision avoidance system. It is the driver ′s responsibility to stay alert, drive
safely and be in control of the vehicle at all times. As there is a performance limit, it may not provide a
warning or brake in certain conditions.
NOTE:
 The IBA system shares component parts and diagnosis wi th the Intelligent Cruise Control (ICC) system.
New parts added to the IBA system is the IBA OFF indica tor lamp in the combination meter and the IBA OFF
switch on the instrument driver lower panel.
 The ICC sensor integrated unit shares the parts with the ICC, but the IBA system will operate even when the
ICC system is turned to OFF.
OPERATION DESCRIPTION
The IBA system uses an ICC sensor located below t he front bumper to measure the distance to a vehicle
ahead. When the system judges that the distance gets shorter, the vehicle ahead detection indicator on the
combination meter blinks and the warning chime sounds.
To turn the system OFF/ON, push and hold the IBA OFF switch after starting the engine for more than 1 sec-
ond.
NOTE:
 The system ON/OFF condition will be memorized even if the ignition switch turns OFF.
 The IBA system operates under the following conditions.
- The IBA system will function when the vehicle is driv en at speeds of approximately 15 km/h (10 MPH) and
above, and when the vehicle ′s speed is approximately 15 km/h (10 MPH) faster than that of the vehicle
ahead.
Switch and Indicators
Temporary unavailable indication
1. IBA OFF switch 2. Vehicle ahead detection indicator 3. IBA OFF indicator lamp
A. Under side of Instrument lower panel
(LH) B. On the combination meter
JSFIA0445ZZ
Revision: 2010 May2011 QX56

NORMAL OPERATING CONDITIONBRC-157
< SYMPTOM DIAGNOSIS > [INTELLIGENT BRAKE ASSIST]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000006228304
PRECAUTIONS FOR INTELLIGENT BRAKE ASSIST
 The IBA system is a not collision avoidance system. It is the driver′s responsibility to stay alert, drive safely
and be in control of the vehicle at all times.
 As there is a performance limit, it may not prov ide a warning or brake in certain conditions.
 The system will not detect the following objects:
- Pedestrians, animals, or obstacles in the roadway
- Oncoming vehicles in the same lane
 The system will not detect under the following conditions:
- When the sensor gets dirty and it is impossibl e to detect the distance from the vehicle ahead.
- When driving into a strong light (i.e. sunlight)
 The sensor generally detects the signals returned from the reflectors on a vehicle ahead. Therefore, the sys-
tem may not function properly under the following conditions:
- When the reflectors of the vehicle ahead are positioned high or close each other (including a small vehicle
such as motorcycles).
- When the sensor gets dirty or and it is impossi ble to detect the distance from the vehicle ahead.
- When the reflectors on the vehicle ahead is missing, damaged or covered.
- When the reflector of the vehicle ahead is covered with dirt, snow and road spray.
- When visibility is low (such as rain, fog, snow, etc.).
- When snow or road spray from traveling vehicles are raised up.
- When dense exhaust or other smoke (black smoke) fr om vehicles reduces the sensor visibility.
- When excessively heavy baggage is loaded in the rear seat or the luggage room of vehicle.
- When abruptly accelerating or decelerating.
- On steep downhill or roads with sharp curves.
- When there is a highly reflective object near the vehicle ahead (i.e. very close to other vehicle, signboard,
etc.).
- While towing a trailer or other vehicle.
 Depending on certain road conditions (curved, beginning of a curve), vehicle conditions (steering position,
vehicle position), or preceding vehicle ′s conditions (position in lane, etc. ), the system may not function prop-
erly.
 The system may not function in offset conditions.
 The system may not function when the distanc e to the vehicle ahead is extremely close.
 The system detect highly reflective objects such as reflectors, signs, white markers, and other stationary objects on the road or
near the traveling lane, and when in extreme conditions, detection
of these objects may caus e the system to function.
 The system is designed to automatically check the sensor ′s func-
tionality. If the sensor is covered with ice, a transparent or translu-
cent plastic bag, etc., the system may not detect them. In these
instances the system may not be able to warn properly. Be sure to
check and clean the sensor regularly.
 Excessive noise will interfere with the warning chime sound, and the chime may not be heard.
 Never step in under the brake pedal to avoid an accident when IBA
system turns ON.
 Sudden appearance of the vehicle in front (i.e. it abrupt ly cuts in) may not be detected and the system may
not warn soon enough.
 The system will be cancelled automatically with a beep sound and the IBA OFF indicator lamp will illuminate
under the following conditions:
- When the sensor window is dirty
- When the system malfunctions
JSFIA0385ZZ
Revision: 2010 May2011 QX56

CCS
HANDLING PRECAUTIONCCS-27
< SYSTEM DESCRIPTION > [ICC]
C
D
E
F
G H
I
J
K L
M B
N P A
HANDLING PRECAUTION
Precautions for Vehicle-to-V ehicle Distance Control ModeINFOID:0000000006224276
 ICC system is only an aid to assist the driver and is not a collision warning or avoidance device. It is the\
driver's responsibility to stay alert, drive safe ly and be in control of the vehicle at all times.
 The system is primarily intended for use on straight, dry, open roads with light traffic. It is not advisable to
use the system in city traffic or congested areas.
 This system will not adapt automatically to road condi tions. This system should be used in evenly flowing
traffic. Do not use the system on roads with sharp curves, or on icy roads, in heavy rain or in fog.
 The ICC sensor will not detect under most conditions.
- Stationary and slow moving vehicles.
- Pedestrians or objects in the roadway.
- Oncoming vehicles in the some lane.
- Motorcycles traveling offset in the travel lane.
 As there is a performance limit to the distance contro l function, never rely solely on the ICC system. This
system does not correct careless, inattentive or absent -minded driving, or overcome poor visibility in rain,
fog, or other bad weather. Decelerate the vehicle speed by depressing the brake pedal, depending on the
distance to the vehicle ahead and the surrounding circumstances in order to maintain a safe distance
between vehicles.
 If the vehicle ahead comes to a stop, the vehicle decelerat es to a standstill within the limitations of the sys-
tem. The system will cancel once it judges that the vehicle has come to a standstill and sound a warning
chime. To prevent the vehicle from movi ng, the driver must depress the brake pedal.
 The system may not detect the vehicle in front of the dr iver in certain road or weather conditions. To avoid
accidents, never use the ICC syst em under the following conditions:
- On roads where the traffic is heavy or there are sharp curves.
- On slippery road surfaces such as on ice or snow, etc.
- On off-road surfaces such as on sand or rock, etc.
- During bad weather (rain, fog, snow, etc.)
- When the windshield wipers are operating at high speed. The ICC system may cancel when the wipers are
set to the AUTO position.
- When strong light (for example, at sunrise or sunset ) is directly shining on the front of the vehicle.
- When rain, snow or dirt adhere to the system sensor.
- On steep downhill roads (the vehicle may go beyond the set vehicle speed and frequent braking may result in overheating the brakes).
- On repeated uphill and downhill roads.
- When traffic conditions make it difficult to keep a proper distance between vehicles because of frequent acceleration or deceleration.
- When towing a trailer or other vehicle
 In some road or traffic conditions, a vehicle or object can unexpectedly come into the sensor detection zone and cause automatic braking. The driver may need to c ontrol the distance from other vehicles using the
accelerator pedal. Always stay alert and avoid using t he ICC system when it is not recommended in this sec-
tion.
 The vehicle-to-vehicle distance control mode uses a sensor located on the front of the vehicle to detect vehi-
cles traveling ahead. The sensor generally detects t he signals returned from the reflectors on a vehicle
ahead. Therefore, if the sensor c annot detect the reflector on the v ehicle ahead, the ICC system may not
maintain the selected distance.
 The following are some conditions in which the sensor cannot detect the signals:
- When the reflector of the vehicle ahead is positioned high on the vehicle (trailer, etc.).
- When the reflector on the vehicle ahead is missing, damaged or covered.
- When the reflector of the vehicle ahead is covered with dirt, snow and road spray.
- When the snow or road spray from traveling vehicles reduces the sensor's visibility.
- When dense exhaust or other smoke (black smoke) fr om vehicles reduces the sensor's visibility.
- When excessively heavy baggage is loaded in the rear seat or the luggage room of own vehicle.
- When the vehicle is towing a trailer, etc.
 The ICC system is designed to automatic ally check the sensor's operation within the limitation of the system.
When the sensor is covered with dirt or is obstruct ed, the system will automatically be canceled. If the sen-
sor is covered with ice, a transparent or translucent vinyl bag, etc., the ICC system may not detect them. In
these instances, the vehicle-to-vehicle distance control mode may not cancel and may not be able to main-
tain the selected following distance from the vehicle ahead. Be sure to check and clean the sensor regularly.
Revision: 2010 May2011 QX56

CCS
C1A13 STOP LAMP RELAYCCS-97
< DTC/CIRCUIT DIAGNOSIS > [ICC]
C
D
E
F
G H
I
J
K L
M B
N P A
C1A13 STOP LAMP RELAY
DTC LogicINFOID:0000000006224323
DTC DETECTION LOGIC
NOTE:
If DTC “C1A13” is detected along with DTC “U 1000”, first diagnose the DTC “U1000”. Refer to CCS-145,
"ADAS CONTROL UNIT : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE (1)
1. Start the engine.
2. Perform the active test item “STOP LAMP” with CONSULT-III.
3. Perform “All DTC Reading”.
4. Check if the “C1A13” is detected as the current malfunction in the “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A13” detected as the current malfunction?
YES >> Refer to CCS-97, "Diagnosis Procedure".
NO >> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE (2)
1. Drive at the vehicle speed of 40 km/h (25 MPH) or more for approximately 60 seconds or more without the
brake pedal depressed.
CAUTION:
Always drive safely.
NOTE:
If it is outside the above condition, repeat step 1.
2. Perform “All DTC Reading”.
3. Check if the “C1A13” is detected as the current malfunction in the “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A13” detected as the current malfunction?
YES >> Refer to CCS-97, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006224324
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected other than “C1A13” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communicati on system inspection. Repair or replace the malfunctioning parts.
Refer to CCS-145, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK STOP LAMP SWITCH
Check that “STOP LAMP SW” operate normally in “DATA MONITOR” of “ICC/ADAS”.
DTC
(On board dis-
play) Trouble diagnosis name DTC detecting condition Possible causes
C1A13 (13) STOP LAMP RLY FIX  Stop lamp inactive state continues for 0.3
seconds or more despite the outputting of
an ICC sensor ICC brake hold relay drive
signal
 The stop lamp remains ON for 60 seconds or more under the following conditions:
- Driving at 40 km/h or more
- No stop lamp drive signal output from ICC
sensor
- No brake operation  Stop lamp switch circuit
 ICC brake switch circuit
 ICC brake hold relay circuit
 Stop lamp switch
 ICC brake switch
 ICC brake hold relay
 Incorrect stop lamp switch installation
 Incorrect ICC brake switch installation
ECM
 ABS actuator and elec
tric unit (control
unit)
Revision: 2010 May2011 QX56

CCS
NORMAL OPERATING CONDITIONCCS-173
< SYMPTOM DIAGNOSIS > [ICC]
C
D
E
F
G H
I
J
K L
M B
N P A
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000006224457
PRECAUTIONS FOR VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE
 ICC system is only an aid to assist the driver and is not a collision warning or avoidance device. It is the\
driver's responsibility to stay alert, drive safe ly and be in control of the vehicle at all times.
 The system is primarily intended for use on straight, dry, open roads with light traffic. It is not advisable to
use the system in city traffic or congested areas.
 This system will not adapt automatically to road condi tions. This system should be used in evenly flowing
traffic. Do not use the system on roads with sharp curves, or on icy roads, in heavy rain or in fog.
 The ICC sensor will not detect under most conditions.
- Stationary and slow moving vehicles.
- Pedestrians or objects in the roadway.
- Oncoming vehicles in the some lane.
- Motorcycles traveling offset in the travel lane.
 As there is a performance limit to the distance contro l function, never rely solely on the ICC system. This
system does not correct careless, inattentive or absent -minded driving, or overcome poor visibility in rain,
fog, or other bad weather. Decelerate the vehicle speed by depressing the brake pedal, depending on the
distance to the vehicle ahead and the surrounding circumstances in order to maintain a safe distance
between vehicles.
 If the vehicle ahead comes to a stop, the vehicle decelerat es to a standstill within the limitations of the sys-
tem. The system will cancel once it judges that the vehicle has come to a standstill and sound a warning
chime. To prevent the vehicle from movi ng, the driver must depress the brake pedal.
 The system may not detect the vehicle in front of the dr iver in certain road or weather conditions. To avoid
accidents, never use the ICC syst em under the following conditions:
- On roads where the traffic is heavy or there are sharp curves.
- On slippery road surfaces such as on ice or snow, etc.
- On off-road surfaces such as on sand or rock, etc.
- During bad weather (rain, fog, snow, etc.)
- When the windshield wipers are operating at high speed. The ICC system may cancel when the wipers are
set to the AUTO position.
- When strong light (for example, at sunrise or sunset ) is directly shining on the front of the vehicle.
- When rain, snow or dirt adhere to the system sensor.
- On steep downhill roads (the vehicle may go beyond the set vehicle speed and frequent braking may result
in overheating the brakes).
- On repeated uphill and downhill roads.
- When traffic conditions make it difficult to keep a proper distance between vehicles because of frequent
acceleration or deceleration.
- When towing a trailer or other vehicle
 In some road or traffic conditions, a vehicle or object can unexpectedly come into the sensor detection zone
and cause automatic braking. The driver may need to c ontrol the distance from other vehicles using the
accelerator pedal. Always stay alert and avoid using t he ICC system when it is not recommended in this sec-
tion.
 The vehicle-to-vehicle distance control mode uses a sensor located on the front of the vehicle to detect vehi-
cles traveling ahead. The sensor generally detects t he signals returned from the reflectors on a vehicle
ahead. Therefore, if the sensor c annot detect the reflector on the v ehicle ahead, the ICC system may not
maintain the selected distance.
 The following are some conditions in which the sensor cannot detect the signals:
- When the reflector of the vehicle ahead is positioned high on the vehicle (trailer, etc.).
- When the reflector on the vehicle ahead is missing, damaged or covered.
- When the reflector of the vehicle ahead is covered with dirt, snow and road spray.
- When the snow or road spray from traveling vehicles reduces the sensor's visibility.
- When dense exhaust or other smoke (black smoke) fr om vehicles reduces the sensor's visibility.
- When excessively heavy baggage is loaded in the rear seat or the luggage room of own vehicle.
- When the vehicle is towing a trailer, etc.
 The ICC system is designed to automatic ally check the sensor's operation within the limitation of the system.
When the sensor is covered with dirt or is obstruct ed, the system will automatically be canceled. If the sen-
sor is covered with ice, a transparent or translucent vinyl bag, etc., the ICC system may not detect them. In
these instances, the vehicle-to-vehicle distance control mode may not cancel and may not be able to main-
tain the selected following distance from the vehicle ahead. Be sure to check and clean the sensor regularly.
Revision: 2010 May2011 QX56

CHG
POWER GENERATION VOLTAGE VARIABLE CONTROL SYSTEM OPERATION
INSPECTION
CHG-17
< BASIC INSPECTION >
C
DE
F
G H
I
J
K L
B A
O P
N
POWER GENERATION VOLTAGE VA
RIABLE CONTROL SYSTEM OPER-
ATION INSPECTION
Inspection ProcedureINFOID:0000000006274867
CAUTION:
When performing this inspection, always use a charged battery that has completed the battery inspec-
tion. (When the charging rate of the battery is low, the response speed of the voltage change will
become slow. This can cause an incorrect inspection.)
1.CHECK ECM (CONSULT-III)
Perform ECM self-diagnosis with CONSULT-III. Refer to EC-63, "
CONSULT-III Function".
Self
-diagnostic results content
No malfunction detected>> GO TO 2.
Malfunction detected>> Check applicable parts, and repair or replace corresponding parts.
2.CHECK OPERATION OF POWER GENERATION VOLTAGE VARIABLE CONTROL SYSTEM
1. Connect CONSULT-III and start the engine.
2. shift the selector lever to “P” or “N” position and turn off all of the electric loads and A/C, etc.
3. Select “ALTERNATOR DUTY” at “Active Test” of “ENGINE”, and then check the value of “BATTERY
VOLT” monitor when DUTY value of “ALTERNATOR DUTY” is set to 40.0 %.
4. Check the value of “BATTERY VOLT” monitor when DUTY value of “ALTERNATOR DUTY” is set to 80.0%.
Is the measurement value within the specification?
YES >> INSPECTION END
NO >> GO TO 3.
3.CHECK IPDM E/R (CONSULT-III)
Perform IPDM E/R self-diagnosis with CONSULT-III. Refer to PCS-12, "
CONSULT-III Function (IPDM E/R)".
Self
-diagnostic results content
No malfunction detected>> GO TO 4.
Malfunction detected>> Check applicable parts, and repair or replace corresponding parts.
4.CHECK HARNESS BETWEEN ALTE RNATOR AND IPDM E/R
1. Turn ignition switch OFF.
2. Disconnect alternator harness connec tor and IPDM E/R harness connector.
3. Check continuity between alternator har ness connector and IPDM E/R harness connector.
4. Check continuity between alte rnator harness connector and ground.
“BATTERY VOLT”
2 seconds after setting the
DUTY value of “ALTERNA-
TOR DUTY” to 40.0 %
: 12 - 13.6 V
“BATTERY VOLT”
20 seconds after setting
the DUTY value of “ALTER-
NATOR DUTY” to 80.0 % : +0.5 V or more against
the value of “BATTERY
VOLT” monitor when
DUTY value is 40.0 %
Alternator IPDM E/R
Continuity
Connector Terminal Connector Terminal
E205 5 E13 33 Existed
Revision: 2010 May2011 QX56

ENGINE COOLANTCO-9
< PERIODIC MAINTENANCE >
C
DE
F
G H
I
J
K L
M A
CO
NP
O
3. Check drained engine coolant for contaminants such as rust, corrosion or discoloration.
If contaminated, flush the engine cooling system. Refer to CO-10, "
Flushing".
RefillingINFOID:0000000006289659
1. Install reservoir tank if removed, and radiator drain plug.
CAUTION:
Be sure to clean drain plug and install with new O-ring. Refer to CO-13, "
Exploded View".
If water drain plug on cylinder block is removed, close and tighten it. Refer to EM-107, "
Disassem-
bly and Assembly".
2. Check that each hose clamp is firmly tightened.
3. Remove air relief plug (1) on heater hose.
4. Fill radiator, and reservoir tank, to specified level. Pour engine coolant through engine coolant filler neck
slowly of less than 3 (2-5/8 lmp qt) a minute to allow air
in system to escape.
 Use Genuine NISSAN Long Li fe Antifreeze/Coolant or
equivalent mixed with water (dis tilled or demineralized).
Refer to MA-10, "
Fluids and Lubricants".
5. When engine coolant overflows air relief hole on heater hos e, install air relief plug with clamp. Then refill
radiator with engine coolant.
6. Install radiator cap.
7. Install reservoir tank cap.
8. Warm up engine until opening thermostat less than 3,000 rpm.  Check thermostat opening condition by touching radiat or hose (lower) to see a flow of warm water.
CAUTION: : 1.96 N·m (0.2 kg-m, 17 in-lb)
2. Engine cover
: Vehicle front
JPBIA3429ZZ
Engine coolant capacity : Refer to CO-23,
"PeriodicalMaintenanceS
pecification".
(With reservoir tank at
“MAX” level)JPBIA0412ZZ
Reservoir tank engine
coolant capacity :Refer to
CO-23,
"PeriodicalMaintenanceSp
ecification".
(At “MAX” level)
A : MAX
B: MIN
JPBIA0102ZZ
Revision: 2010 May2011 QX56

DAS-76
< SYSTEM DESCRIPTION >[DCA]
HANDLING PRECAUTION
HANDLING PRECAUTION
Precautions for Distance Control AssistINFOID:0000000006223505
 If the vehicle ahead comes to a stop, the vehicle deceler
ates to a standstill within the limitations of the sys-
tem. The system will cancel once it judges that the vehi cle has come to a standstill with a warning chime. To
prevent the vehicle from moving, t he driver must depress the brake pedal.
 The DCA system will not apply brake control while the driver is depressing the accelerator pedal.
 This system is only an aid to assist the driver and is not a collision warning or avoidance device. It is the
driver's responsibility to stay alert, drive safe ly and be in control of the vehicle at all times.
 This system will not adapt automatically to road condi tions. Do not use the system on roads with sharp
curves, or on icy roads, in heavy rain or in fog.
 The distance sensor will not detect under most conditions.
- Stationary and slow moving vehicles
- Pedestrians or objects in the roadway
- Oncoming vehicles in the same lane
- Motorcycles traveling offset in the travel lane
 As there is a performance limit to the distance contro l function, never rely solely on the DCA system. This
system does not correct careless, inat tentive or absent-minded driving, or overcome poor visibility in rain,
fog, or other bad weather. Decelerate the vehi cle speed by depressing the brake pedal, depending on the
distance to the vehicle ahead and the surrounding circumstances in order to maintain a safe distance
between vehicles.
 The system may not detect the vehicle in front of own v ehicle in certain road or weather conditions. To avoid
accidents, never use the DCA system under the following conditions.
- On roads with sharp curves
- On slippery road surfaces such as on ice or snow, etc.
- On off-road surfaces such as on sand or rock, etc.
- During bad weather (rain, fog, snow, etc.)
- When strong light (for example, at sunrise or sunset) is directly shining on the front of the vehicle
- When rain, snow or dirt adhere to the system sensor
- On steep downhill roads (frequent braking may result in overheating the brakes)
- On repeated uphill and downhill roads
- When towing a trailer or other vehicle
 In some road or traffic conditions, a vehicle or objec t can unexpectedly come into the sensor detection zone
and cause automatic braking. Driver may need to control the distance from other vehicles using the acceler-
ator pedal. Always stay alert and avoid using the DCA system when it is not recommended in this section.
 The following are some conditions in which the sensor cannot detect the signals.
- When the reflector of the vehicle ahead is positioned high on the vehicle (trailer, etc.)
- When the reflector on the vehicle ahead is missing, damaged or covered
- When the reflector of the vehicle ahead is covered with dirt, snow and road spray
- When the snow or road spray from traveling vehicles reduces the sensor's visibility
- When dense exhaust or other smoke (black smoke) fr om vehicles reduces the sensor's visibility
- When excessively heavy baggage is loaded in the rear seat or the luggage room of own vehicle
 The DCA system is designed to autom atically check the sensor's operation. When the sensor is covered
with dirt or is obstructed, the system will automatically be canceled. If the sensor is covered with ice, a trans-
parent or translucent vinyl bag, etc., the DCA syste m may not detect them. In these instances, the DCA sys-
tem may not be able to decelerate the vehicle properly. Be sure to check and clean the sensor regularly.
 The DCA system is designed to help assist the driver to maintain a following distance from the vehicle
ahead. The system will decelerate as necessary and if the vehicle ahead comes to a stop, the vehicle decel-
erates to standstill. However, the DCA system can only apply up to 25% of the vehicles total braking power.
If a vehicle moves into the traveling lane ahead or if a vehicle traveling ahead rapidly decelerates, the dis-
tance between vehicles may become closer because t he DCA system cannot decelerate the vehicle quickly
enough. If this occurs, the DCA system will sound a warn ing chime and blink the system display to notify the
driver to take necessary action.
 The DCA system does not control vehicle speed or warn when driver approach stationary and slow moving
vehicles. Driver must pay attention to vehicle operat ion to maintain proper distance from vehicles ahead.
Revision: 2010 May2011 QX56

DAS
C1A13 STOP LAMP RELAYDAS-141
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
C1A13 STOP LAMP RELAY
DTC LogicINFOID:0000000006228076
DTC DETECTION LOGIC
NOTE:
If DTC “C1A13” is detected along with DTC “U1000”, first diagnose the DTC “U1000”. Refer to DAS-182,
"ADAS CONTROL UNIT : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE (1)
1. Start the engine.
2. Perform the active test item “STOP LAMP” with CONSULT-III.
3. Perform “All DTC Reading”.
4. Check if the “C1A13” is detected as the current malfunction in the “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A13” detected as the current malfunction?
YES >> Refer to DAS-141, "Diagnosis Procedure".
NO >> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE (2)
1. Drive at the vehicle speed of 40 km/h (25 MPH) or more for approximately 60 seconds or more without the
brake pedal depressed.
CAUTION:
Always drive safely.
NOTE:
If it is outside the above condition, repeat step 1.
2. Perform “All DTC Reading”.
3. Check if the “C1A13” is detected as the current malfunction in the “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A13” detected as the current malfunction?
YES >> Refer to DAS-141, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228077
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected other than “C1A13” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communicati on system inspection. Repair or replace the malfunctioning parts.
Refer to DAS-182, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK STOP LAMP SWITCH
Check that “STOP LAMP SW” operate normally in “DATA MONITOR” of “ICC/ADAS”.
DTC
(On board dis-
play) Trouble diagnosis name DTC detecting condition Possible causes
C1A13 (13) STOP LAMP RLY FIX  Stop lamp inactive state continues for 0.3
seconds or more despite the outputting of
an ICC sensor ICC brake hold relay drive
signal
 The stop lamp remains ON for 60 seconds or more under the following conditions:
- Driving at 40 km/h or more
- No stop lamp drive signal output from ICC
sensor
- No brake operation  Stop lamp switch circuit
 ICC brake switch circuit
 ICC brake hold relay circuit
 Stop lamp switch
 ICC brake switch
 ICC brake hold relay
 Incorrect stop lamp switch installation
 Incorrect ICC brake switch installation
ECM
 ABS actuator and elec
tric unit (control
unit)
Revision: 2010 May2011 QX56
