< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0460 FUEL LEVEL SENSOR
P0460 FUEL LEVEL SENSOR
DTC LogicINFOID:0000000006288328
DTC DETECTION LOGIC
NOTE:

If DTC P0460 is displayed with DTC UXXXX, first perform the tr ouble diagnosis for DTC UXXXX.
 If DTC P0460 is displayed with DTC P0607, first pe rform the trouble diagnosis for DTC P0607. Refer
to EC-378, "
DTC Logic".
When the vehicle is parked, the fuel level in the fuel tank is naturally stable. It means that output signal of the
fuel level sensor does not change. If ECM senses sloshi ng signal from the sensor, fuel level sensor malfunc-
tion is detected.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and wait maximum of 2 consecutive minutes.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-352, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006288329
1.CHECK DTC WITH “COMBINATION METER”
Refer to MWI-30, "
CONSULT-III Function".
Is any DTC detected?
YES >> Perform trouble diagnosis of detected DTC.
NO >> GO TO 2.
2.CHECK FUEL LEVEL SENSOR SIGNAL CIRCUIT
Check fuel level sensor signal circuit. Refer to MWI-69, "
Component Function Check".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> Perform trouble diagnosis of fuel level sensor signal circuit. Refer to MWI-69,
"DiagnosisProcedure".
DTC No.Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0460 FUEL LEV SEN SLOSH
(Fuel level sensor circuit
noise) Even though the vehicle is parked, a
signal being varied is sent from the
fuel level sensor to ECM.  Harness or connectors
(The CAN communication line is open or shorted)
 Harness or connectors (The sensor circuit is open or shorted)
 Combination meter
 Fuel level sensor
Revision: 2010 May2011 QX56

P0461 FUEL LEVEL SENSOREC-353
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0461 FUEL LEVEL SENSOR
DTC LogicINFOID:0000000006288330
DTC DETECTION LOGIC
NOTE:

If DTC P0461 is displayed with DTC UXXXX, first perform the tr ouble diagnosis for DTC UXXXX.
 If DTC P0461 is displayed with DT C P0607, first perform the trouble diagnosis for DTC P0607. Refer
to EC-378, "
DTC Logic".
Driving long distances naturally affect fuel gauge level.
This diagnosis detects the fuel gauge malfunction of the gauge not moving even after a long distance has
been driven.
DTC CONFIRMATION PROCEDURE
1.PERFORM COMPONENT FUNCTION CHECK
Perform Component Function Check. Refer to EC-353, "
Component Function Check".
Use component function check to check the overall function of the fuel level sensor. During this check, a 1st
trip DTC might not be confirmed.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to EC-354, "
Diagnosis Procedure".
Component Function CheckINFOID:0000000006288331
1.PRECONDITIONING
WARNING:
When performing the following procedure, alw ays observe the handling of the fuel. Refer to FL-2,
"General Precautions".
TESTING CONDITION:
Before starting component function check, preparation of draining fuel and refilling fuel is required.
>> GO TO 2.
2.PERFORM COMPONENT FUNCTION CHECK
NOTE:
Start from step 8, if it is possible to confirm that the fuel cannot be drained by 30 (7-7/8 US gal, 6-5/8
Imp gal) in advance.
1. Prepare a fuel container and a spare hose.
2. Release fuel pressure from fuel line. Refer to EC-153, "
Work Procedure".
3. Remove the fuel feed hose on the fuel level sensor unit. Refer to FL-5, "
Removal and Installation".
4. Connect a spare fuel hose where the fuel feed hose was removed.
5. Turn ignition switch ON.
6. Drain fuel by 30 (7-7/8 US gal, 6-5/8 Imp gal) from the fuel tank using proper equipment.
7. Confirm that the fuel gauge indication varies.
8. Fill fuel into the fuel tank for 30 (7-7/8 US gal, 6-5/8 Imp gal).
9. Confirm that the fuel gauge indication varies.
Is the inspection result normal?
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0461 FUEL LEVEL SENSOR
(Fuel level sensor circuit
range/performance) The output signal of the fuel level sensor
does not change within the specified
range even though the vehicle has been
driven a long distance.  Harness or connectors
(The CAN communication line is open or short-
ed)
 Harness or connectors (The sensor circuit is open or shorted)
 Combination meter
 Fuel level sensor
Revision: 2010 May2011 QX56

EC-354
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0461 FUEL LEVEL SENSOR
YES >> INSPECTION END
NO >> Proceed to
EC-354, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006288332
1.CHECK DTC WITH “COMBINATION METER”
Refer to MWI-30, "
CONSULT-III Function".
Is any DTC detected?
YES >> Perform trouble diagnosis of detected DTC.
NO >> GO TO 2.
2.CHECK FUEL LEVEL SENSOR SIGNAL CIRCUIT
Check fuel level sensor signal circuit. Refer to MWI-69, "
Component Function Check".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> Perform trouble diagnosis of fuel level sensor signal circuit. Refer to MWI-69,
"DiagnosisProcedure".
Revision: 2010 May2011 QX56

P0462, P0463 FUEL LEVEL SENSOR
EC-355
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0462, P0463 FUEL LEVEL SENSOR
DTC LogicINFOID:0000000006288333
DTC DETECTION LOGIC
NOTE:

If DTC P0462 or P0463 is displayed with DTC UXXXX, first perform the trouble diagnosis for DTC
UXXXX.
 If DTC P0462 or P0463 is displayed with DTC P0607, first perform the trouble diagnosis for DTC
P0607.Refer to EC-378, "
DTC Logic".
This diagnosis indicates the former, to detect open or short circuit malfunction.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at ignition
switch ON.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON and wait at least 5 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-355, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006288334
1.CHECK DTC WITH “COMBINATION METER”
Refer to MWI-30, "
CONSULT-III Function".
Is any DTC detected?
YES >> Perform trouble diagnosis of detected DTC.
NO >> GO TO 2.
2.CHECK FUEL LEVEL SENSOR SIGNAL CIRCUIT
Check fuel level sensor signal circuit. Refer to MWI-69, "
Component Function Check".
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-40, "Intermittent Incident".
NO >> Perform trouble diagnosis of fuel level sensor signal circuit. Refer to MWI-69,
"DiagnosisProcedure".
DTC No.Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0462 FUEL LEVL SEN/CIRC
(Fuel level sensor circuit low
input) An excessively low voltage from the
sensor is sent to ECM.
 Harness or connectors
(The CAN communication line is open or shorted)
 Harness or connectors (The sensor circuit is open or shorted)
 Combination meter
 Fuel level sensor
P0463 FUEL LEVL SEN/CIRC
(Fuel level sensor circuit high
input) An excessively high voltage from
the sensor is sent to ECM.
Revision: 2010 May2011 QX56

P0500 VSSEC-357
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O4. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to
EC-357, "Diagnosis Procedure".
NO >> INSPECTION END
4.PERFORM COMPONENT FUNCTION CHECK
WITH GST
Perform Component Function Check. Refer to EC-357, "
Component Function Check".
Use Component Function Check to check the overall func tion of the vehicle speed signal circuit. During this
check, a 1st trip DTC might not be confirmed.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-357, "
Diagnosis Procedure".
Component Function CheckINFOID:0000000006217859
1.PERFORM COMPONENT FUNCTION CHECK
WITH GST
1. Lift up drive wheels.
2. Start engine.
3. Read vehicle speed signal in Service $01 with GST. The vehicle speed signal on GST should be able to ex ceed 10 km/h (6 MPH) when rotating wheels with
suitable gear position.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-357, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006217860
1.CHECK DTC WITH “ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)”
Refer to BRC-40, "
CONSULT-III Function".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace malfunctioning part.
2.CHECK DTC WITH “COMBINATION METER”
Refer to MWI-30, "
CONSULT-III Function".
>> INSPECTION END
B/FUEL SCHDL 5.5 - 31.8 msec
Selector lever Except P or N position
PW/ST SIGNAL OFF
Revision: 2010 May2011 QX56

EC-362
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P050E COLD START CONTROL
P050E COLD START CONTROL
DescriptionINFOID:0000000006288336
ECM controls ignition timing and engine idle speed when engine is started with pre-warming up condition.
This control promotes the activation of three way ca
talyst by heating the catalyst and reduces emissions.
DTC LogicINFOID:0000000006288337
DTC DETECTION LOGIC
NOTE:
If DTC P050E is displayed with other DTC, first perform the trouble diagnosis for other DTC.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE-I
WITH CONSULT-III
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Select “DATA MONITOR” mode with CONSULT-III.
4. Check the indication of “COOLAN TEMP/S”.
WITH GST
Follow the procedure “With CONSULT-III” above.
Is the value of
“COOLAN TEMP/S” between 5°C (41°F) and 36°C (97°F)?
YES >> GO TO 3.
NO-1 [If it is below 5 °C (41 °F)]>>Warm up the engine until the val ue of “COOLAN TEMP/S” reaches 5°C
(41 °F) or more. Retry from step 1.
NO-2 [If it is above 36 °C (97 °F)]>>Cool engine down to less than 36 °C (97 °F). Retry from step 1.
3.PERFORM DTC CONFIRMATION PROCEDURE-II
WITH CONSULT-III
1. Set the select lever in N range.
2. Start the engine and warm up in idle with the value of “COOLAN TEMP/S” between 5 °C (41 °F) and 40 °C
(104 °F) for more than 15 seconds.
3. Check 1st trip DTC.
WITH GST
Follow the procedure “With CONSULT-III” above.
Is 1st trip DTC detected?
YES >> Proceed to EC-362, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006288338
1.PERFORM IDLE AIR VOLUME LEARNING
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P050E Cold start engine exhaust temper-
ature too low The temperature of the catalyst inlet does not
rise to the proper temperature when the engine
is started with pre-warming up condition.  Lack of intake air volume
 Fuel injection system
ECM
Revision: 2010 May2011 QX56

P050E COLD START CONTROLEC-363
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Perform
EC-148, "Work Procedure".
Is Idle Air Volume Learning carried out successfully?
YES >> GO TO 2.
NO >> Follow the instruction of Idle Air Volume Learning.
2.CHECK INTAKE SYSTEM
Check for the cause of intake air volume lacking. Refer to the following.
 Crushed intake air passage
 Intake air passage clogging
 Clogging of throttle body
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace malfunctioning part
3.CHECK FUEL INJECTION SYSTEM FUNCTION
Perform DTC Confirmation Procedure for DTC P0171, P0174. Refer to EC-263, "
DTC Logic".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Proceed to EC-264, "
Diagnosis Procedure" for DTC P0171, P0174.
4.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Erase DTC.
3. Perform DTC Confirmation Procedure. See EC-362, "
DTC Logic".
Is the 1st trip DTC P050E displayed again?
YES >> GO TO 5.
NO >> INSPECTION END
5.REPLACE ECM
Replace ECM. Refer to EC-535, "
Removal and Installation".
>> INSPECTION END
Revision: 2010 May2011 QX56

P0527 COOLING FAN SPEED SENSOREC-367
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0527 COOLING FAN SPEED SENSOR
DTC LogicINFOID:0000000006217867
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is 11 V or more at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and warm it up to the normal operating temperature.
2. Keep the engine speed approximately 1,000 rpm at no load.
3. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-367, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217868
1.CHECK COOLING FAN SPEED SENSOR POWER SUPPLY CIRCUIT-I
1. Turn ignition switch OFF.
2. Disconnect electrically-controlled c ooling fan coupling harness connector.
3. Turn ignition switch ON.
4. Check the voltage between electrically-controlled cooling fan coupling harness connector terminals.
Is inspection result normal?
YES >> GO TO 6.
NO >> GO TO 2.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0527 Cooling fan speed sen-
sor circuit range/perfor-
mance The number of fan speed signals is 16 rpm or
less during engine rev.  Harness or connectors
(The Fuel rail pressure sensor circuit is
open or shorted.)
(The Power steering pressure sensor cir-
cuit is open or shorted)
(The Electrically-controlled cooling fan
coupling circuit is open or shorted)
 Fuel rail pressure sensor
 Power steering pressure sensor
 Cooling fan speed sensor
 Electrically-controlled cooling fan cou- pling
 Cooling fan
 IPDM E/R
Electrically-controlled cooling fan coupling Vo l ta g e
(Approx.)
Connector +
−
terminal
F39 2 4 5 V
Revision: 2010 May2011 QX56

EC-368
< DTC/CIRCUIT DIAGNOSIS >[VK56VD]
P0527 COOLING FAN SPEED SENSOR
2.CHECK COOLING FAN SPEED SENSOR POWER SUPPLY CIRCUIT-II
1. Check the voltage between electrically-controlled cooling fan coupling harness connector and the ground.
Is inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK SENSOR POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check harness connector for short to power and short to ground, between the following terminals.
Is inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit. Refer to EC-168, "Diagnosis Procedure".
NO >> Repair or replace error-detected parts.
4.CHECK COOLING FAN SPEED SENSOR GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between electrically-contro lled cooling fan coupling harness connector and ECM har-
ness connector.
Is inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace error-detected parts.
5.CHECK ECM GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between ECM harness connector and the ground.
+
−Vol tag e
(Approx.)
Electrically-controlled cooling fan coupling
Connector terminalF39 2 Ground 5 V
ECM Sensor
Connector Terminal Name Connector Terminal
F 111 27Low fuel pressure sensor F25 3
Power steering pressure sensor F35 1
Cooling fan speed sensor F39 2
28 FRP sensor F26 1
+ −
Continuity
Electrically-controlled cooling fan
coupling ECM
Connector Terminal Connector Terminal F 3 9 4 F 111 4 5 E x i s t e d
Revision: 2010 May2011 QX56

P0550 PSP SENSOREC-371
< DTC/CIRCUIT DIAGNOSIS > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P0550 PSP SENSOR
DTC LogicINFOID:0000000006217870
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for at least 5 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-371, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006217871
1.CHECK POWER STEERING PRESSURE SENSOR POWER SUPPLY CIRCUIT-I
1. Turn ignition switch OFF.
2. Disconnect power steering pressure (PSP) sensor harness connector.
3. Turn ignition switch ON.
4. Check the voltage between PSP sensor harness connector terminals.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 2.
2.CHECK POWER STEERING PRESSURE SENSOR POWER SUPPLY CIRCUIT-II
1. Check the voltage between PSP sensor harness connector and the ground.
DTC No. Trouble diagnosis name
(Trouble diagnosis content) DTC detecting condition Possible cause
P0550 PW ST P SEN/CIRC
(Power steering pressure
sensor circuit) An excessively low or high voltage from the
sensor is sent to ECM.  Harness or connectors
(The Fuel rail pressure sensor circuit is
open or shorted.)
(The Power steering pressure sensor cir-
cuit is open or shorted)
(The Electrically-controlled cooling fan
coupling circuit is open or shorted)
 Fuel rail pressure sensor
 Power steering pressure sensor
 Electrically-controlled cooling fan cou- pling
PSP sensor Vo l ta g e
(Approx.)
Connector +
−
terminal
F35 1 3 5 V
Revision: 2010 May2011 QX56
