C1155 BRAKE FLUID LEVEL SWITCHBRC-103
< DTC/CIRCUIT DIAGNOSIS > [WITH VDC]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
C1155 BRAKE FLUID LEVEL SWITCH
DTC LogicINFOID:0000000006222625
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK DTC DETECTION
With CONSULT-III.
1. Turn the ignition switch OFF to ON, and then wait 1 minute or more.
2. Perform self-diagnosis for “ABS”.
Is DTC
“C1155” detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-103, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006222626
1.CHECK BRAKE FLUID LEVEL
1. Turn the ignition switch OFF.
2. Check brake fluid level. Refer to BR-10, "
Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Refill brake fluid. Refer to BR-11, "
Refilling".
2.CHECK BRAKE FLUID LEVEL SWITCH HARNESS
1. Disconnect brake fluid level switch harness connector.
2. Disconnect ABS actuator and electric unit (control unit) harness connector.
3. Check continuity between brake fluid level switch harness connector and ABS actuator and electric unit
(control unit) harness connector.
4. Check continuity between brake fluid level switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace error-detected parts.
3.CHECK BRAKE FLUID LEVEL SWITCH GROUND
Check continuity between brake fluid level switch harness connector and ground.
DTC Display Item Malfunction detected condition Possible causes
C1155 BR FLUID LEVEL LOW  When brake fluid level low signal is detected.
 When an open circuit is detected in brake fluid level
switch circuit.  Harness or connector
 ABS actuator and electric unit
(control unit)
 Brake fluid level switch
Brake fluid level switch ABS actuator and electric unit (control unit) Continuity
Connector Terminal Connector Terminal
E47 1 E36 13 Existed
Brake fluid level switch —Continuity
Connector Terminal
E47 1 Ground Not existed
Revision: 2010 May2011 QX56

BRC-104
< DTC/CIRCUIT DIAGNOSIS >[WITH VDC]
C1155 BRAKE FLUID LEVEL SWITCH
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace error-detected parts.
4.CHECK BRAKE FLUID LEVEL SWITCH
Check brake fluids level witch. Refer to BRC-104, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace reservoir tank. Refer to BR-30, "
Disassembly and Assembly".
5.CHECK TERMINAL
 Check brake fluid level switch pin terminals for damage or loose connection with harness connector.
 Check ABS actuator and electric unit (control unit) pin terminals for damage or loose connection with har-
ness connector.
Is the inspection result normal?
YES >> Replace ABS actuator and electr ic unit (control unit). Refer to BRC-137, "Removal and Installa-
tion".
NO >> Repair or replace error-detected parts.
Component InspectionINFOID:0000000006222627
1.CHECK BRAKE FLUID LEVEL SWITCH
1. Turn the ignition switch OFF.
2. Disconnect brake fluid level switch harness connector.
3. Check resistance between terminals of brake fluid level switch.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace reservoir tank. Refer to BR-30, "
Disassembly and Assembly".
Brake fluid level switch
—Continuity
Connector Terminal
E47 2 Ground Existed
Brake fluid level switch Condition Resistance
Te r m i n a l
1 – 2 When brake fluid level in reservoir tank is within the specified level. 1.9 – 2.1 k
Ω
When brake fluid level in reservoir tank is less than the specified
level. 1.0
Ω or less
Revision: 2010 May2011 QX56

BRC-106
< DTC/CIRCUIT DIAGNOSIS >[WITH VDC]
C1164, C1165 CV SYSTEM
C1164, C1165 CV SYSTEM
DTC LogicINFOID:0000000006222630
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK DTC DETECTION
With CONSULT-III.
1. Turn the ignition switch OFF to ON.
2. Perform self-diagnosis for “ABS”.
Is DTC
“C1164” or “C1165” detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-106, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006222631
1.CHECK CUT VALVE POWER SUPPLY
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) harness connector.
3. Check voltage between ABS actuator and electr ic unit (control unit) harness connector and ground.
4. Turn the ignition switch ON. CAUTION:
Never start engine.
5. Check voltage between ABS actuator and electr ic unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK CUT VALVE POWER SUPPLY CIRCUIT
1. Turn the ignition switch OFF.
2. Check 30A fusible link (L).
3. Check continuity and short circui t between ABS actuator and electric unit (control unit) harness connector
terminal (1) and 30A fusible link (L).
Is the inspection result normal?
YES >> Perform trouble diagnosis for battery power supply. Refer to PG-11, "Wiring Diagram - BATTERY
POWER SUPPLY -".
NO >> Repair or replace error-detected parts.
3.CHECK CUT VALVE GROUND CIRCUIT
DTC Display Item Malfunction detected condition Possible causes
C1164 CV 1 When a malfunction is detected in cut valve 1.  Harness or connector  ABS actuator and electric unit
(control unit)
 Fusible link
 Battery power supply system
C1165 CV 2 When a malfunction is detected in cut valve 2.
ABS actuator and electric
unit (control unit)
—Voltage
Connector Terminal
E36 1 Ground Battery voltage
ABS actuator and electric unit (control unit) —Voltage
Connector Terminal
E36 1 Ground Battery voltage
Revision: 2010 May2011 QX56

C1164, C1165 CV SYSTEMBRC-107
< DTC/CIRCUIT DIAGNOSIS > [WITH VDC]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
1. Turn the ignition switch OFF.
2. Check continuity between ABS actuator and electr ic unit (control unit) harness connector and the ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace error-detected parts.
4.CHECK TERMINAL
Check ABS actuator and electric unit (control unit) pin terminals for damage or loose connection with harness
connector.
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-137, "Removal and Installa-
tion".
NO >> Repair or replace error-detected parts.
ABS actuator and electric unit (control unit) —Continuity
Connector Terminal
E36 2
Ground Existed
3
E37 48
Revision: 2010 May2011 QX56

BRC-108
< DTC/CIRCUIT DIAGNOSIS >[WITH VDC]
C1166, C1167 SV SYSTEM
C1166, C1167 SV SYSTEM
DTC LogicINFOID:0000000006222632
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK DTC DETECTION
With CONSULT-III.
1. Turn the ignition switch OFF to ON.
2. Perform self-diagnosis for “ABS”.
Is DTC
“C1166” or “C1167” detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-108, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006222633
1.CHECK SUCTION VALVE POWER SUPPLY
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) harness connector.
3. Check voltage between ABS actuator and electr ic unit (control unit) harness connector and ground.
4. Turn the ignition switch ON. CAUTION:
Never start engine.
5. Check voltage between ABS actuator and electr ic unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK SUCTION VALVE POWER SUPPLY CIRCUIT
1. Turn the ignition switch OFF.
2. Check 30A fusible link (L).
3. Check continuity and short circui t between ABS actuator and electric unit (control unit) harness connector
terminal (1) and 30A fusible link (L).
Is the inspection result normal?
YES >> Perform trouble diagnosis for battery power supply. Refer to PG-11, "Wiring Diagram - BATTERY
POWER SUPPLY -".
NO >> Repair or replace error-detected parts.
3.CHECK SUCTION VALVE GROUND CIRCUIT
DTC Display Item Malfunction detected condition Possible causes
C1166 SV 1 When a malfunction is detected in suction valve 1.  Harness or connector  ABS actuator and electric unit
(control unit)
 Fusible link
 Battery power supply system
C1167 SV 2 When a malfunction is detected in suction valve 2.
ABS actuator and electric
unit (control unit)
—Voltage
Connector Terminal
E36 1 Ground Battery voltage
ABS actuator and electric unit (control unit)
—Voltage
Connector Terminal
E36 1 Ground Battery voltage
Revision: 2010 May2011 QX56

C1166, C1167 SV SYSTEMBRC-109
< DTC/CIRCUIT DIAGNOSIS > [WITH VDC]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
1. Turn the ignition switch OFF.
2. Check continuity between ABS actuator and electr ic unit (control unit) harness connector and the ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace error-detected parts.
4.CHECK TERMINAL
Check ABS actuator and electric unit (control unit) pin terminals for damage or loose connection with harness
connector.
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-137, "Removal and Installa-
tion".
NO >> Repair or replace error-detected parts.
ABS actuator and electric unit (control unit)
—Continuity
Connector Terminal
E36 2
Ground Existed
3
E37 48
Revision: 2010 May2011 QX56

POWER SUPPLY AND GROUND CIRCUITBRC-113
< DTC/CIRCUIT DIAGNOSIS > [WITH VDC]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
POWER SUPPLY AND GROUND CIRCUIT
DescriptionINFOID:0000000006222641
ABS actuator and electric uni t (control unit) power supply
Diagnosis ProcedureINFOID:0000000006222642
1.CHECK ABS ACTUATOR AND ELECTRIC UNIT (C ONTROL UNIT) IGNITION POWER SUPPLY (1)
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) harness connector.
3. Check voltage between ABS actuator and electr ic unit (control unit) harness connector and ground.
4. Turn the ignition switch ON CAUTION:
Never start engine.
5. Check voltage between ABS actuator and electr ic unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CON TROL UNIT) IGNITION POWER SUPPLY CIRCUIT
(1)
1. Turn the ignition switch OFF.
2. Check 10A fuse (#57).
3. Disconnect IPDM E/R harness connector.
4. Check continuity between ABS actuator and electr ic unit (control unit) harness connector and IPDM E/R
harness connector.
5. Check for continuity between ABS actuator and el ectric unit (control unit) harness connector and the
ground.
Is the inspection result normal?
YES >> Perform trouble diagnosis for ignition power supply. Refer to PG-89, "Wiring Diagram - IGNITION
POWER SUPPLY -".
NO >> Repair or replace error-detected parts.
3.CHECK ABS ACTUATOR AND ELECTRIC UNIT (C ONTROL UNIT) IGNITION POWER SUPPLY (2)
1. Check voltage between ABS actuator and electr ic unit (control unit) harness connector and ground.
ABS actuator and electric unit (control unit)
—Voltage
Connector Terminal
E36 18 Ground Approx. 0 V
ABS actuator and electric unit (control unit) —Voltage
Connector Terminal
E36 18 Ground 10 − 16 V
ABS actuator and electric unit (control unit) IPDM E/R
Continuity
Connector Terminal Connector Terminal
E3618E1559Existed
ABS actuator and electric unit (control unit) —Continuity
Connector Terminal
E36 18 Ground Not existed
Revision: 2010 May2011 QX56

BRC-114
< DTC/CIRCUIT DIAGNOSIS >[WITH VDC]
POWER SUPPLY AND GROUND CIRCUIT
2. Turn the ignition switch ON
CAUTION:
Never start engine.
3. Check voltage between ABS actuator and electr ic unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 4.
4.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CON TROL UNIT) IGNITION POWER SUPPLY CIRCUIT
(2)
1. Turn the ignition switch OFF.
2. Check 10A fuse (#74).
3. Check continuity and short circui t between ABS actuator and electric unit (control unit) harness connector
terminal (49) and 10A fuse (#74).
Is the inspection result normal?
YES >> Perform trouble diagnosis for ignition power supply. Refer to PG-89, "Wiring Diagram - IGNITION
POWER SUPPLY -".
NO >> Repair or replace error-detected parts.
5.CHECK MOTOR AND MOTOR RE LAY POWER SUPPLY CIRCUIT
1. Turn the ignition switch OFF.
2. Check voltage between ABS actuator and electr ic unit (control unit) harness connector and ground.
3. Turn the ignition switch ON. CAUTION:
Never start engine.
4. Check voltage between ABS actuator and electr ic unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 6.
6.CHECK MOTOR AND MOTOR RE LAY POWER SUPPLY CIRCUIT
1. Turn the ignition switch OFF.
2. Check 50A fusible link (M).
3. Check continuity and short circui t between ABS actuator and electric unit (control unit) harness connector
terminal (4 and 47) and 50A fusible link (M).
ABS actuator and electric unit (control unit) —Voltage
Connector Terminal
E37 49 Ground Approx. 0 V
ABS actuator and electric unit (control unit) —Voltage
Connector Terminal
E37 49 Ground 10 − 16 V
ABS actuator and electric unit (control unit)
—Voltage
Connector Terminal
E36 4 Ground Battery voltage
E37 47
ABS actuator and electric unit (control unit)
—Voltage
Connector Terminal
E36 4 Ground Battery voltage
E37 47
Revision: 2010 May2011 QX56

POWER SUPPLY AND GROUND CIRCUITBRC-115
< DTC/CIRCUIT DIAGNOSIS > [WITH VDC]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Is the inspection result normal?
YES >> Perform trouble diagnosis for battery power supply. Refer to PG-11, "Wiring Diagram - BATTERY
POWER SUPPLY -".
NO >> Repair or replace error-detected parts.
7.CHECK ACTUATOR RELAY, ABS IN VALVE, ABS OUT VALVE, ANS CUT VALVE, SUCTION VALVE POW-
ER SUPPLY
1. Turn the ignition switch OFF.
2. Check voltage between ABS actuator and electr ic unit (control unit) harness connector and ground.
3. Turn the ignition switch ON CAUTION:
Never start engine.
4. Check voltage between ABS actuator and electr ic unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 9.
NO >> GO TO 8.
8.CHECK ACTUATOR RELAY, ABS IN VALVE, ABS OUT VALVE, ANS CUT VALVE, SUCTION VALVE POW-
ER SUPPLY CIRCUIT 1. Turn the ignition switch OFF.
2. Check 30A fusible link (L).
3. Check continuity and short circuit between ABS act uator and electric unit (control unit) harness connector
terminal (1) and 30A fusible link (L).
Is the inspection result normal?
YES >> Perform trouble diagnosis for battery power supply. Refer to PG-11, "Wiring Diagram - BATTERY
POWER SUPPLY -".
NO >> Repair or replace error-detected parts.
9.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT
Check for continuity between ABS actuator and elec tric unit (control unit) harness connector and the ground.
Is the inspection result normal?
YES >> GO TO 10.
NO >> Repair or replace error-detected parts.
10.CHECK TERMINAL
 Check ABS actuator and electric unit (control unit) pin terminals for damage or loose connection with har-
ness connector.
 Check IPDM E/R pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> INSPECTION END
ABS actuator and electric unit (control unit)
—Voltage
Connector Terminal
E36 1 Ground Battery voltage
ABS actuator and electric unit (control unit)
—Voltage
Connector Terminal
E36 1 Ground Battery voltage
ABS actuator and electric unit (control unit) —Continuity
Connector Terminal
E36 2
Ground Existed
3
E37 48
Revision: 2010 May2011 QX56

BRC-116
< DTC/CIRCUIT DIAGNOSIS >[WITH VDC]
POWER SUPPLY AND GROUND CIRCUIT
NO >> Repair or replace error-detected parts.
Revision: 2010 May2011 QX56
