DAS-346
< DTC/CIRCUIT DIAGNOSIS >[LDW & LDP]
C1A01 POWER SUPPLY CIRCUIT 1,
C1A02 POWER SUPPLY CIRCUIT 2
C1A01 POWER SUPPLY CIRCUIT 1, C1A02 POWER SUPPLY CIRCUIT 2
DTC LogicINFOID:0000000006223741
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the LDP system ON.
3. Perform “All DTC Reading” with CONSULT-III.
4. Check if the “C1A01” or “C1A02” is detected as t he current malfunction in “Self Diagnostic Result” of “ICC/
ADAS”.
Is
“C1A01” or “C1A02” detected as the current malfunction?
YES >> Refer to DAS-346, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006223742
1.CHECK ADAS CONTROL UNIT POWER SUPPLY AND GROUND CIRCUIT
Check power supply and ground circuit of ADAS control unit. Refer to DAS-387, "
ADAS CONTROL UNIT :
Diagnosis Procedure".
Is the inspection result normal?
YES >> Replace the ADAS control unit. Refer to DAS-63, "Removal and Installation".
NO >> Repair or replace the malfunctioning parts.
DTC
(On board dis-
play) Trouble diagnosis
name DTC detecting condition Possible causes
C1A01 (1) POWER SUPPLY
CIR The battery voltage sent to ADAS control unit re-
mains less than 7.9 V for 5 seconds
 Connector, harness, fuse
 ADAS control unit
C1A02
(2) POWER SUPPLY
CIR 2 The battery voltage sent to ADAS control unit re-
mains more than 19.3 V for 5 seconds
Revision: 2010 May2011 QX56

DAS
C1A03 VEHICLE SPEED SENSORDAS-347
< DTC/CIRCUIT DIAGNOSIS > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
C1A03 VEHICLE SPEED SENSOR
DTC LogicINFOID:0000000006223743
DTC DETECTION LOGIC
NOTE:
If DTC “C1A03” is detected along with DTC “U1000” or “C1A04”, first diagnose the DTC “U1000” or “C1A04”.
 Refer to DAS-374, "
ADAS CONTROL UNIT : DTC Logic" for DTC “U1000”.
 Refer to DAS-348, "
DTC Logic" for DTC “C1A04”.
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the LDP system ON.
3. Drive the vehicle at 30 km/h (19 MPH) or more. CAUTION:
Always drive safely.
4. Stop the vehicle.
5. Perform “All DTC Readi ng” with CONSULT-III.
6. Check if the “C1A03” is detected as the current malfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A03” detected as the current malfunction?
YES-1 (Lane departure warning lamp: ON)>>Refer to DAS-347, "Diagnosis Procedure".
YES-2 (Lane departure warning lamp: OFF)>>Refer to CCS-87, "
Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006223744
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “C1A04” or “U1000” is detected other than “C1A03” in “Self Diagnostic Result” of “ICC/ADAS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
DAS-310, "
DTC Index".
NO >> GO TO 2.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (C ONTROL UNIT) SELF-DIAGNOSIS RESULTS
Check if any DTC is detected in “Self Diagnostic Result” of “ABS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
BRC-51, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board
display) Trouble diagnosis
name DTC detecting condition Possible causes
C1A03 (3) VHCL SPEED SE
CIRC If the vehicle speed signal (wheel speed) from
ABS actuator and electric unit (control unit) re-
ceived by the ADAS control unit via CAN com-
munication, are inconsistent  Wheel speed sensor
 ABS actuator and electric unit (control
unit)
 ADAS control unit
Revision: 2010 May2011 QX56

DAS-348
< DTC/CIRCUIT DIAGNOSIS >[LDW & LDP]
C1A04 ABS/TCS/VDC SYSTEM
C1A04 ABS/TCS/VDC SYSTEM
DTC LogicINFOID:0000000006228186
DTC DETECTION LOGIC
NOTE:
If DTC “C1A04” is detected along with DTC “U
1000”, first diagnose the DTC “U1000”. Refer to DAS-374,
"ADAS CONTROL UNIT : DTC Logic".
Diagnosis ProcedureINFOID:0000000006228187
1.CHECK SELF-DIAGNOSIS RESULTS
1. Perform “All DTC Reading” with CONSULT-III.
2. Check if the “U1000” is detected other than “C1A 04” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communication system inspecti on. Repair or replace the malfunctioning parts.
Refer to DAS-374, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS RESULTS
Check if any DTC is detected in “Self Diagnostic Result” of “ABS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
BRC-51, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board dis-
play) Trouble diagnosis
name DTC detecting condition Possible causes
C1A04 (4) ABS/TCS/VDC CIRC
If a malfunction occu
rs in the VDC/TCS/ABS
system ABS actuator and electric unit (control
unit)
Revision: 2010 May2011 QX56

DAS
C1A05 BRAKE SW/STOP LAMP SWDAS-349
< DTC/CIRCUIT DIAGNOSIS > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
C1A05 BRAKE SW/STOP LAMP SW
DTC LogicINFOID:0000000006228188
DTC DETECTION LOGIC
NOTE:
If DTC “C1A05” is detected along with DTC “U1000”, first diagnose the DTC “U1000”. Refer to DAS-374,
"ADAS CONTROL UNIT : DTC Logic".
Diagnosis ProcedureINFOID:0000000006228189
1.CHECK SELF-DIAGNOSIS RESULTS
1. Perform “All DTC Readi ng” with CONSULT-III.
2. Check if the “U1000” is detect ed other than “C1A05” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communicati on system inspection. Repair or replace the malfunctioning parts.
Refer to DAS-374, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK STOP LAMP SWIT CH AND ICC BRAKE SWITCH
Check that “STOP LAMP SW” and “BRAKE SW” operate normally in “DATA MONITOR” of “ICC/ADAS”.
Is the inspection result normal?
YES >> GO TO 3.
NO-1 >> When “BRAKE SW” operation is malfunctioning: GO TO 4.
NO-2 >> When “STOP LAMP SW” operation is malfunctioning: GO TO 9.
3.CHECK STOP LAMP SWITCH
Check that “STOP LAMP SW” operate no rmally in “DATA MONITOR” of “ABS”.
Is the inspection result normal?
YES >> GO TO 14.
NO >> GO TO 9.
4.CHECK ICC BRAKE SWITCH INSTALLATION
1. Turn ignition switch OFF.
2. Check ICC brake switch for correct installation. Refer to BR-7, "
Inspection and Adjustment".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Adjust ICC brake switch installation. Refer to BR-7, "
Inspection and Adjustment".
5.ICC BRAKE SWITCH INSPECTION
1. Disconnect ICC brake switch connector.
2. Check ICC brake switch. Refer to DAS-352, "
Component Inspection (ICC Brake Switch)".
Is the inspection result normal?
DTC
(On board dis-
play) Trouble diagnosis
name DTC detecting condition Possible causes
C1A05 (5) BRAKE SW/STOP L
SW A mismatch between a stop lamp switch signal
and a ICC brake switch signal received from
ECM and a stop lamp signal received from the
ABS actuator and electric
unit (control unit) con-
tinues for 10 seconds or more with vehicle
speeds at approximately 40 km/h or more  Stop lamp switch circuit
 ICC brake switch circuit
 Stop lamp switch
 ICC brake switch
 Incorrect stop lamp switch installa-
tion
 Incorrect ICC brake switch installa- tion
ECM
 ABS actuator and electric unit (con-
trol unit)
Revision: 2010 May2011 QX56

DAS-352
< DTC/CIRCUIT DIAGNOSIS >[LDW & LDP]
C1A05 BRAKE SW/STOP LAMP SW
14.PERFORM SELF-DIAGNOSIS OF ECM
1. Connect all connectors again if the connectors are disconnected.
2. Turn ignition switch ON.
3. Perform “All DTC Reading”.
4. Check if any DTC is detected in “Self Diagnostic Result” of “ENGINE”. Refer to EC-98, "
DTC Index".
Is any DTC detected?
YES >> Repair or replace the malfunctioning part s identified by the self-diagnosis result.
NO >> GO TO 15.
15.PERFORM SELF-DIAGNOSIS OF ABS ACTUAT OR AND ELECTRIC UNIT (CONTROL UNIT)
Check if any DTC is detected in “Sel f Diagnostic Result” of “ABS”. Refer to BRC-51, "
DTC Index".
Is any DTC detected?
YES >> Repair or replace the malfunctioning part s identified by the self-diagnosis result.
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
Component Inspection (ICC Brake Switch)INFOID:0000000006228190
1.CHECK ICC BRAKE SWITCH
Check for continuity between ICC brake switch terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace ICC brake switch.
Component Inspection (Stop Lamp Switch)INFOID:0000000006228191
1.CHECK STOP LAMP SWITCH
Check for continuity between stop lamp switch terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace stop lamp switch.
Terminal Condition Continuity
12 When brake pedal is depressed
Not exist-
ed
When brake pedal is released Existed
Terminal Condition Continuity
12 When brake pedal is depressed Existed
When brake pedal is released
Not exist-
ed
34 When brake pedal is depressed Existed
When brake pedal is released
Not exist-
ed
Revision: 2010 May2011 QX56

DAS
C1A06 OPERATION SWDAS-353
< DTC/CIRCUIT DIAGNOSIS > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
C1A06 OPERATION SW
DTC LogicINFOID:0000000006228192
DTC DETECTION LOGIC
NOTE:
If DTC “C1A06” is detected along with DTC “U1000”, first diagnose the DTC “U1000”. Refer to DAS-374,
"ADAS CONTROL UNIT : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Wait for approximately 5 minutes after turning the LDP system ON.
3. Perform “All DTC Readi ng” with CONSULT-III.
4. Check if the “C1A06” is detected as the current malfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A06” detected as the current malfunction?
YES >> Refer to DAS-353, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228193
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected other than “C1A06” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communicati on system inspection. Repair or replace the malfunctioning parts.
Refer to DAS-374, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK ICC STEERING SWITCH
1. Turn the ignition switch OFF.
2. Disconnect the ICC steering switch connector.
3. Check the ICC steering switch. Refer to DAS-354, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace the steering wheel.
3.CHECK HARNESS BETWEEN SP IRAL CABLE AND ECM
1. Disconnect the ECM connector.
2. Check for continuity between the spiral cable harness connector and ECM harness connector.
3. Check for continuity between spiral cable harness connector and ground.
DTC
(On board dis-
play) Trouble diagnosis
name DTC detecting condition Possible causes
C1A06 (6) OPERATION SW
CIRC  Any switch of the ICC steering switch is de-
tected as “ON” continuously for 60 seconds
 An ON/OFF state judgment of the ICC differs
between ECM and ADAS control unit, and the
state continues for 2 seconds or more  ICC steering switch circuit
 ICC steering switch
ECM
Spiral cable ECM
Continuity
Connector Terminal Connector Terminal
M33 25
E80 128
Existed
32 130
Revision: 2010 May2011 QX56

DAS
C1A14 ECMDAS-355
< DTC/CIRCUIT DIAGNOSIS > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
C1A14 ECM
DTC LogicINFOID:0000000006228195
DTC DETECTION LOGIC
NOTE:
If DTC “C1A14” is detected along with DTC “U1000”, first diagnose the DTC “U1000”. Refer to DAS-374,
"ADAS CONTROL UNIT : DTC Logic".
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Operate the ICC system and drive. CAUTION:
Always drive safely.
3. Stop the vehicle.
4. Perform “All DTC Readi ng” with CONSULT-III.
5. Check if the “C1A14” is detected as the current malfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A14” detected as the current malfunction?
YES >> Refer to DAS-355, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228196
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected other than “C1A14” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communicati on system inspection. Repair or replace the malfunctioning parts.
Refer to DAS-374, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.PERFORM SELF-DIAGNOSIS OF ECM
Check if any DTC is detected in “S elf Diagnostic Result” of “ENGINE”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
EC-98, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board dis-
play) Trouble diagnosis name DTC detecting condition Possible causes
C1A14 (14) ECM CIRCUIT If ECM is malfunctioning  Accelerator pedal position sensor
ECM
 ADAS control unit
Revision: 2010 May2011 QX56

DAS-356
< DTC/CIRCUIT DIAGNOSIS >[LDW & LDP]
C1A15 GEAR POSITION
C1A15 GEAR POSITION
DescriptionINFOID:0000000006228197
ADAS control unit judges the gear pos
ition based on the following signals.
 Current gear position signal transmitt ed from TCM via CAN communication.
 Value of gear ratio calculated from input speed signal transmitted from TCM via CAN communication.
 Value of gear ratio calculated from the vehicle speed signal transmitted from ABS actuator and electric unit
(control unit) via CAN communication.
DTC LogicINFOID:0000000006228198
DTC DETECTION LOGIC
NOTE:
If DTC “C1A15” is detected along with DTC “U1000”, “C1A03”, or “C1A04”, first diagnose the DTC “U1000”,
“C1A03”, or “C1A04”.
 Refer to DAS-374, "
ADAS CONTROL UNIT : DTC Logic" for DTC “U1000”.
 Refer to DAS-347, "
DTC Logic" for DTC “C1A03”.
 Refer to DAS-348, "
DTC Logic" for DTC “C1A04”.
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the LDP system ON.
3. Drive the vehicle at 10 km/h (6 MPH) or faster for approximately 15 minutes or more.
CAUTION:
Always drive safely.
4. Stop the vehicle.
5. Perform “All DTC Reading” with CONSULT-III.
6. Check if “C1A15” is detected as the current malf unction in the “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A15” detected as the current malfunction?
YES >> Refer to DAS-356, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228199
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “C1A03”, “C1A04”, or “U1000” is detected ot her than “C1A15” in “Self Diagnostic Result” of “ICC/
ADAS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
DAS-310, "
DTC Index".
NO >> GO TO 2.
2.CHECK VEHICLE SPEED SIGNAL
Check that “VHCL SPEED SE” operates norma lly in “DATA MONITOR” of “ICC/ADAS”.
CAUTION:
Be careful of the vehicle speed.
Is the inspection result normal?
DTC
(On board dis- play) Trouble diagnosis
name DTC detecting condition Possible causes
C1A15 (15) GEAR POSITION A mismatch between an current gear posi-
tion signal transmitted from TCM via CAN
communication and a gear position calculat-
ed by the ADAS control unit continues for
approximately 11 minutes or more  Input speed sensor
 Vehicle speed sensor A/T (output speed
sensor)
TCM
Revision: 2010 May2011 QX56

DAS-358
< DTC/CIRCUIT DIAGNOSIS >[LDW & LDP]
C1A24 NP RANGE
C1A24 NP RANGE
DTC LogicINFOID:0000000006228200
DTC DETECTION LOGIC
NOTE:
If DTC “C1A24” is detected along with DTC “U
1000”, first diagnose the DTC “U1000”. Refer to DAS-374,
"ADAS CONTROL UNIT : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.CHECK DTC REPRODUCE (1)
1. Start the engine.
2. Turn the LDP system ON.
3. Wait for approximately 5 minutes or more afte r shifting the selector lever to “P” position.
4. Perform “All DTC Reading” with CONSULT-III.
5. Check if the “C1A24” is detected as the current malfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A24” detected as the current malfunction?
YES >> Refer to DAS-358, "Diagnosis Procedure".
NO >> GO TO 2.
2.CHECK DTC REPRODUCE (2)
1. Wait for approximately 5 minutes or more after shifting the selector lever to “N” position.
2. Perform “All DTC Reading”.
3. Check if the “C1A24” is detected as the current malfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A24” detected as the current malfunction?
YES >> Refer to DAS-358, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228201
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected ot her than “C1A24” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communication system inspecti on. Repair or replace the malfunctioning parts.
Refer to DAS-374, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK NP POSITION SWITCH SIGNAL
Check that “NP RANGE SW” operates normally in “DATA MONITOR” of “ICC/ADAS”.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
3.CHECK TCM DATA MONITOR
Check that “SLCT LVR POSI” operates normally in “DATA MONITOR” of “TRANSMISSION”.
Is the inspection result normal?
YES >> Replace the ADAS control unit. Refer to DAS-63, "Removal and Installation".
NO >> GO TO 4.
DTC
(On board dis-
play) Trouble diagnosis name DTC detecting condition Possible causes
C1A24 (24) NP RANGE A mismatch between a shift position signal
transmitted from TCM via CAN communica-
tion and an current gear position signal contin-
ues for 60 seconds or more TCM
 Transmission range switch
Revision: 2010 May2011 QX56

DAS-360
< DTC/CIRCUIT DIAGNOSIS >[LDW & LDP]
C1A50 ADAS CONTROL UNIT
C1A50 ADAS CONTROL UNIT
DTC LogicINFOID:0000000006223761
DTC DETECTION LOGIC
NOTE:
If DTC “C1A50” is detected along with DTC “U
1000”, first diagnose the DTC “U1000”. Refer to DAS-374,
"ADAS CONTROL UNIT : DTC Logic".
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the LDP system ON.
3. Perform “All DTC Reading” with CONSULT-III.
4. Check if the “C1A50” is detected as the current malfunction in “Self Diagnostic Result” of “LANE CAM-
ERA”.
Is
“C1A50” detected as the current malfunction?
YES >> Refer to DAS-360, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006223762
1.CHECK LANE CAMERA UNIT SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected other than “C1A50” in “Self Diagnostic Result” of “LANE CAMERA”.
Is
“U1000” detected?
YES >> Perform the CAN communication system inspecti on. Repair or replace the malfunctioning parts.
Refer to DAS-374, "
LANE CAMERA UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK ADAS CONTROL UNIT SE LF-DIAGNOSIS RESULTS
Check if any DTC is detected in “S elf Diagnostic Result” of “ICC/ADAS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
DAS-310, "
DTC Index".
NO >> Replace the lane camera unit. Refer to DAS-403, "
Removal and Installation".
DTC Trouble diagnosis name DTC detecting condition Possible cause
C1A50 ADAS MALFUNCTION If ADAS control unit is malfunctioning ADAS control unit
Revision: 2010 May2011 QX56
