diagram INFINITI QX56 2011 Factory Service Manual

DLK-74
< WIRING DIAGRAM >
AUTOMATIC BACK DOOR SYSTEM
JCKWM4453GB
Revision: 2010 May2011 QX56

INTEGRATED HOMELINK TRANSMITTER SYSTEMDLK-75
< WIRING DIAGRAM >
C
DE
F
G H
I
J
L
M A
B
DLK
N
O P
INTEGRATED HOMELINK TRANSMITTER SYSTEM
Wiring Diagram - INTEGRATED HOMELINK TRANSMITTER SYSTEM -INFOID:0000000006256147
JCKWM4454GB
Revision: 2010 May2011 QX56

DLK-76
< WIRING DIAGRAM >
INTEGRATED HOMELINK TRANSMITTER SYSTEM
JCKWM4455GB
Revision: 2010 May2011 QX56

DLN-1
TRANSMISSION & DRIVELINE
CEF
G H
I
J
K L
M
SECTION DLN
A
B
DLN
N
O P
CONTENTS
DRIVELINE
TRANSFER: ATX90A
PRECAUTION ................ ...............................
6
PRECAUTIONS .............................................. .....6
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
6
Precaution Necessary for Steering Wheel Rota-
tion after Battery Disconnect .....................................
6
Service Notice or Precautions for Transfer ...............7
PREPARATION ............................................8
PREPARATION .............................................. .....8
Special Service Tools .......................................... ......8
Commercial Service Tools ........................................8
SYSTEM DESCRIPTION .............................10
COMPONENT PARTS ................................... ....10
Component Parts Location .................................. ....10
Component Description ...........................................11
Transfer Control Unit ...............................................11
Transfer Control Actuator ........................................11
Transfer Hi-Lo Position Sensor ...............................12
Transfer Rotary Position Sensor .............................12
Transfer Lock Position Sensor ................................12
Transfer Fluid Temperature Sensor ........................12
STRUCTURE AND OPERATION .......................13
Sectional View ..................................................... ....13
Torque Split Mechanism .........................................13
SYSTEM .............................................................18
4WD SYSTEM ...........................................................18
4WD SYSTEM : System De scription ......................18
4WD SYSTEM : Fail-Safe ......................... ..............20
DIAGNOSIS SYSTEM (TRANSFER CON-
TROL UNIT) .................................................... ....
21
CONSULT-III Function ........................................ ....21
ECU DIAGNOSIS INFORMATION ..............24
TRANSFER CONTROL UNIT ...........................24
Reference Value .................................................. ....24
Fail-Safe ..................................................................28
DTC Inspection Priority Chart ..................................29
DTC Index ...............................................................29
WIRING DIAGRAM ......................................31
4WD SYSTEM .. ................................ .................31
Wiring Diagram .................................................... ....31
BASIC INSPECTION ...................................38
DIAGNOSIS AND REPAIR WORK FLOW .......38
Work Flow ............................................................ ....38
Diagnostic Work Sheet ............................................39
ADDITIONAL SERVICE WHEN REPLACING
TRANSFER CONTROL UNIT ...........................
41
Description ...............................................................41
Work Procedure .......................................................41
ADDITIONAL SERVICE WHEN REPLACING
TRANSFER ASSEMBLY ..................................
42
Description ...............................................................42
Work Procedure .......................................................42
TRANSFER LOCK POSITION SENSOR
LEARNING ....................................... .................
44
Description ........................................................... ....44
Work Procedure .......................................................44
TRANSFER ROTARY POSITION SENSOR
LEARNING ....................................... .................
46
Description ........................................................... ....46
Work Procedure .......................................................46
TRANSFER FLUID VISCOSITY LEARNING ....47
Description ...............................................................47
Revision: 2010 May2011 QX56

STRUCTURE AND OPERATIONDLN-13
< SYSTEM DESCRIPTION > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
STRUCTURE AND OPERATION
Sectional ViewINFOID:0000000006222222
Torque Split MechanismINFOID:0000000006222223
CONTROL DIAGRAM
1. Rear companion flange 2. Main shaft 3. Rear case
4. Ball ramp lever 5. Ball lamp lever 6. Piston
7. Clutch 8. Sprocket 9. Lock sleeve
10. Hi-Lo sleeve 11. Sun gear 12. Front case
13. Planetary carrier assembly 14. Internal gear 15. Shift fork
16. Transfer rotary position sensor 17. Front shaft flange 18. Drive chain
19. Actuator shaft 20. Cam 21. Transfer control actuator
JPDIE0277ZZ
Revision: 2010 May2011 QX56

DLN-14
< SYSTEM DESCRIPTION >[TRANSFER: ATX90A]
STRUCTURE AND OPERATION
DESCRIPTION
 Ball ramp lever operates in the direction of main shaft axis according to rotation of actuator shaft and
presses piston. Pressure is applied to each clutch and torque is transmitted.
 Shift fork operates in the direction of main shaft axis according to rotation of actuator shaft and performs
engagement and disengagement to Hi-Lo sleeve and lock sleev e of main shaft. Mode is switched between
4H ⇔4L.
AUTO MODE
 The optimum torque distribution is electronically performed for front and rear wheels according to road con-
ditions.
 Stable start without wheel spin is possible on slippery road conditions, such as on a snowy road.
 When road condition does not require 4WD driving, the st atus becomes close to rear wheel drive, which
results in better fuel efficiency and prov ides FR-like steering characteristics.
 The vehicle cornering status is judged according to information from each sensor, and the optimum torque is
distributed to front wheels for prev enting tight-corner braking symptom.
NOTE:
When there is a difference of revolution speed between the front and rear wheel the shift occasionally changes
to direct 4-wheel driving conditions aut omatically. This is not a malfunction.
4H MODE
 Torque distribution for front and rear wheels is fixed and stable start is achieved while driving on an rough,
sandy or snowy road.
4L MODE
 Large traction force is obtained due to low gear. High running ability and escaping ability are achieved.
 Switching from 4H mode to 4L mode is not possible w hen the vehicle is not stopped and A/T shift selector is
not in the neutral position.
TORQUE DISTRIBUTION DIAGRAM
JPDIE0256GB
Revision: 2010 May2011 QX56

DLN-18
< SYSTEM DESCRIPTION >[TRANSFER: ATX90A]
SYSTEM
SYSTEM
4WD SYSTEM
4WD SYSTEM : System DescriptionINFOID:0000000006222224
 In AUTO mode, distribution of traction force is cont
rolled from 2WD status (0:100) to 4WD status (50:50)
according to signal from each sensor and switch.
 In accordance with fail-safe function, when system is malfunctioning, 4WD warning lamp on combination meter turns ON and 4WD control stops. For fail-safe function, refer to DLN-20, "
4WD SYSTEM : Fail-Safe".
 When a high load status continues for transfer assembly (transfer control actuator or transfer fluid), 4WD
control temporarily becomes 4H or 2WD status, according to protection function.
NOTE:
4WD system is not malfunctioning.
SYSTEM DIAGRAM
INPUT/OUTPUT SIGNAL
It transmits/receives each signal from the followi ng transfer control unit via CAN communication line.
JPDIE0272GB
Component parts Control signal
ABS actuator and electric unit (control unit) Transmits the following signals via CAN communication line to transfer control unit.
 Vehicle spee
d signal (ABS)
 Stop lamp switch signal (brake signal)
 ABS operation signal
 VDC operation signal
 TCS operation signal
ECM Transmits the following signals via CAN communication line to transfer control unit.
 Accelerator pedal position signal
 Engine speed signal
 Engine torque signal
Revision: 2010 May2011 QX56

4WD SYSTEMDLN-31
< WIRING DIAGRAM > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
WIRING DIAGRAM
4WD SYSTEM
Wiring DiagramINFOID:0000000006222231
JCDWM1069GB
Revision: 2010 May2011 QX56

DLN-32
< WIRING DIAGRAM >[TRANSFER: ATX90A]
4WD SYSTEM
JCDWM1070GB
Revision: 2010 May2011 QX56

4WD SYSTEMDLN-33
< WIRING DIAGRAM > [TRANSFER: ATX90A]
C
EF
G H
I
J
K L
M A
B
DLN
N
O P
JCDWM1071GB
