INFINITI QX56 2011 Factory Service Manual

A/C UNIT ASSEMBLYHA-45
< REMOVAL AND INSTALLATION >
C
DE
F
G H
J
K L
M A
B
HA
N
O P
CAUTION:
 Replace O-rings with new ones. Then apply compressor oil to them when installing.
 Check for leakages when recharging refrigerant. Refer to HA-18, "
Leak Test".
Revision: 2010 May2011 QX56

HA-46
< REMOVAL AND INSTALLATION >
REAR A/C UNIT
REAR A/C UNIT
Exploded ViewINFOID:0000000006276187
REMOVAL
DISASSEMBLY
1. Roof duct RH 2. Rear ventilator outlet grille A RH 3. Rear ventilator base RH
4. Rear ventilator garnish A RH 5. Rear ventilator outlet grille B RH 6. Rear ventilator grille RH
7. Rear ventilator garnish B RH 8. Rear A/C unit assembly 9. Rear ventilator duct lower
10. Luggage side finisher RH 11. Rear ventilator garnish A LH 12. Rear ventilator base LH
13. Rear ventilator outlet grille A LH 14. Rear ventilator garnish B LH 15. Rear ventilator grille LH
16. Rear ventilator outlet grille B LH 17. Roof duct LH Roof duct center
19. Rear ventilator duct upper
JMIIA0643ZZ
Revision: 2010 May2011 QX56

REAR A/C UNITHA-47
< REMOVAL AND INSTALLATION >
C
DE
F
G H
J
K L
M A
B
HA
N
O P
REAR A/C UNIT ASSEMBLY
REAR A/C UNIT ASSEMBLY : Removal and InstallationINFOID:0000000006276188
REMOVAL
1. Use a refrigerant collecting equipment (for HF C-134a) to discharge the refrigerant. Refer to HA-22, "Per-
form Lubricant Return Operation".
2. Drain engine coolant from cooling system. Refer to HA-22, "
Perform Lubricant Return Operation".
3. Remove rear ventilator duct upper. Refer to VTL-12, "
REAR VENTILATOR DUCT UPPER : Removal and
Installation".
4. Remove rear ventilator duct lower. Refer to VTL-12, "
REAR VENTILATOR DUCT LOWER : Removal and
Installation".
5. Remove mounting bolt, and then disconnect rear cooler unit pipe assembly from rear cooler pipe assem-
bly.
1. Rear blower harness 2. Rear blower motor 3. Rear A/C unit case RH
4. Rear evaporator pipe assembly 5. O-ring 6. Rear expantion valve assembly
7. Rear A/C cooler pipe assembly 8. Pipe bracket 9. Grommet
10. Rear cooler pipe 11. Rear heater outlet tube assembly 12. Blind cap
13. Rear heater inlet tube assembly 14. Clamp 15. Clamp
16. Shild plate 17. Bracket 18. Rear A/C unit case LH
19. Rear evapolator 20. Drain hose 21. Rear air mix door
22. Rear heater core 23. Rear heater pipe clamp 24. Rear A/C unit upper case (front)
25. Rear mode door 26. Rear A/C unit upper case (rear) 27. Air mix door harness
28. Rear intake sensor 29. Packing
Refer to GI-4, "
Components" for symbols in the figure.
JMIIA0641GB
Revision: 2010 May2011 QX56

HA-48
< REMOVAL AND INSTALLATION >
REAR A/C UNIT
CAUTION:
Cap or wrap the joint of the A/C piping with suitable material such as vinyl tape to avoid the entry
of air.
6. Remove clamps, and then disconnect rear heater pipe from rear cooler pipe assembly.
7. Remove jack from the vehicle.
8. Remove mounting bolts and nuts, and then remove rear A/C unit assembly.
INSTALLATION
Note the following items, and install in the reverse order of removal.
CAUTION:
 Replace O-rings with new ones. Then apply compressor oil to them when installing.
 Check for leakages when recharging refrigerant. Refer to HA-18, "
Leak Test".
EVAPORATOR
EVAPORATOR : Removal and InstallationINFOID:0000000006276189
REMOVAL
1. Remove rear A/C unit assembly. Refer to HA-47, "REAR A/C UNIT ASSEMBLY : Removal and Installa-
tion".
2. Disassemble rear A/C unit, and then remove rear evaporator assembly.
3. Remove mounting bolt, and then remove rear evaporator from rear evaporator assembly.
INSTALLATION
Note the following items, and install in the reverse order of removal.
CAUTION:
 Replace O-rings with new ones. Then apply compressor oil to them when installing.
 Check for leakages when recharging refrigerant. Refer to HA-18, "
Leak Test".
EVAPORATOR PIPE ASSEMBLY
EVAPORATOR PIPE ASSEMBLY : Removal and InstallationINFOID:0000000006276190
REMOVAL
1. Remove rear evaporator assembly. Refer to HA-48, "EVAPORATOR : Removal and Installation".
2. Remove mounting bolts, and then rear expansion valve from rear evaporator assembly. CAUTION:
Cap or wrap the joint of the A/C piping and rear expansion valve with suitable material such as
vinyl tape to avoid the entry of air.
3. Remove mounting bolts, and then remove evaporat or pipe assembly from evaporator assembly.
INSTALLATION
Note the following items, and install in the reverse order of removal.
CAUTION:
 Replace O-rings with new ones. Then apply compressor oil to them when installing.
 Check for leakages when recharging refrigerant. Refer to HA-18, "
Leak Test".
HEATER CORE
HEATER CORE : Removal and InstallationINFOID:0000000006276191
REMOVAL
1. Remove rear A/C unit assembly. Refer to HA-47, "REAR A/C UNIT ASSEMBLY : Removal and Installa-
tion"
2. Remove grommet from pipe bracket.
3. Remove mounting screws and then remove pipe bracket.
4. Remove mounting screw, and then heater pipe clamp.
Revision: 2010 May2011 QX56

REAR A/C UNITHA-49
< REMOVAL AND INSTALLATION >
C
DE
F
G H
J
K L
M A
B
HA
N
O P
5. Pull out heater core (1) from rear A/C unit assembly.
INSTALLATION
Note the following item, and install in the reverse order of removal.
NOTE:
Refer to CO-9, "
Refilling" when filling radiator with engine coolant.
EXPANSION VALVE
EXPANSION VALVE : Removal and InstallationINFOID:0000000006276192
REMOVAL
1. Remove rear A/C unit assembly. Refer to HA-47, "REAR A/C UNIT ASSEMBLY : Removal and Installa-
tion".
2. Disassembly rear A/C unit assembly.
3. Remove mounting bolts, and then disconnect rear exp ansion valve assembly from rear evaporator pipe
assembly and rear cooler pipe assembly.
INSTALLATION
Note the following items, and install in the reverse order of removal.
CAUTION:
 Replace O-rings with new ones. Then apply compressor oil to them when installing.
 Check for leakages when recharging refrigerant. Refer to HA-18, "
Leak Test".
JMIIA0685ZZ
Revision: 2010 May2011 QX56

HA-50
< SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
CompressorINFOID:0000000006276197
LubricantINFOID:0000000006276198
RefrigerantINFOID:0000000006276199
Engine Idling SpeedINFOID:0000000006276200
Refer to EC-538, "Idle Speed".
Belt TensionINFOID:0000000006276201
Refer to EM-20, "TensionAdjustment".
Model VALEO THERMAL SYSTEMS JAPAN make
DSK-17D
Ty p e Fixation displacement swash plate
Displacement
cm
3 (cu in)/rev Maximum 175 (10.7)
Direction of rotation Clockwise (viewed from clutch)
Drive belt Poly V
Disc to pulley clearance
mm (in) Standard 0.3 – 0.6 (0.012 – 0.024)
Name
UV Luminaus Oil Type S (DH-PS)
Capacity
m (Imp fl oz) Total in system 210 (7.1)
Compressor (service part) charging
amount
210 (7.1)
Ty p e
HFC-134a (R-134a)
Capacity
kg (lb) 1.05 (2.32)
Revision: 2010 May2011 QX56
