INFINITI QX56 2011 Factory Service Manual

SRC-38
< BASIC INSPECTION >
DIAGNOSIS AND REPAIR WORK FLOW
Repair or replace the malfunctioning part.>> GO TO 10.
10.FINAL CHECK
Check self diagnostic result and air bag warning lamp operation in the user mode.
Is the malfunction repaired?
YES >> INSPECTION END
NO >> GO TO 2.
Revision: 2010 May2011 QX56

INSPECTION AND ADJUSTMENTSRC-39
< BASIC INSPECTION >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
INSPECTION AND ADJUSTMENT
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT
ADDITIONAL SERVICE WHEN REPL ACING CONTROL UNIT : Description
INFOID:0000000006219959
When replacing or removing and installing passenger seat, always perform zero point reset so that Occupant
Detection System is activated normally.
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT : Special Repair Re-
quirement
INFOID:0000000006219960
WORK PROCEDURE WHEN REPLACING CONTROL UNIT
1.PERFORM ZERO POINT RESET
Perform zero point reset. Refer to SRC-39, "
ZERO POINT RESET : Special Repair Requirement".
>> END
ZERO POINT RESET
ZERO POINT RESET : DescriptionINFOID:0000000006219961
Zero point reset is an initializing procedure for occupant detection sensor that must be performed when replac-
ing or removing and installing passenger seat.
If zero point reset is not performed, the initializati on is incomplete and Occupant Detection System does not
operate normally.
NOTE:
 When replacing passenger seat with a NISSAN genuine part, air bag warning lamp blinks if zero point reset
is incomplete.
 When zero point reset is performed once after removal and installation of passenger seat, CONSULT-III dis-
plays “complete” and air bag warning does not blink.
 When reinstalling passenger seat after removal, the initial value for occupant detection sensor changes, and
Occupant Detection System does not operate normally.
 Always perform zero point reset after performing the work as per the following.
- Reinstallation of passenger seat
- Replacement of passenger seat with a seat that is zero point reset complete.
ZERO POINT RESET : Special Repair RequirementINFOID:0000000006219962
1.PERFORM ZERO POINT RESET
1. Perform zero point reset. NOTE:
When performing zero point reset, be careful of the items described as per the following.
 Perform zero point reset after installing passenger seat to the vehicle
 Do not put any objects on passenger seat
 Do not apply excessive vibration to the vehicle
 Do not touch the vehicle
 Do not tilt the vehicle
2. Select start on “Zero point reset function” scr een from, WORK SUPPORT of CONSULT-III “OCCUPANT
DETECTION”.
3. “Zero point reset” starts.
>> GO TO 2.
2.CONFIRMATION OF SETTING
1. Proceed to “Zero point reset function” screen fr om work support of CONSULT-III “OCCUPANT DETEC-
TION”.
2. Check that “Complete” or “Incomplete” is displayed on “Zero point reset status”.
CAUTION:
Revision: 2010 May2011 QX56

SRC-40
< BASIC INSPECTION >
INSPECTION AND ADJUSTMENT
 “Complete” is displayed on “zero point reset current status” if the seat is reinstalled by seat removal
and installation, or “zero poin t reset” is already performed.
 “Zero point reset current status” displays “Incompl ete” if a new seat is installed. When turning key
switch ON without performing zero point reset, air bag warning lamp blinks. When zero point reset is
performed, air bag wa rning lamp turns OFF.
 Air bag warning lamp blinks in user mode only.
 Air bag sensor unit does not record whethe r or not zero point reset is performed.
Is condition
“ALREADY PERFORMED”?
YES >> Print out “ZERO POINT RESET CURRENT STATUS” screen, and inspection end.
NO >> Check condition as per the following, and perform zero point reset again.  Passenger seat is occupied by an object.
 Excessive vibration is applied while performing zero point reset.
 Occupant detection system is malfunctioning.NOTE:
If “Incomplete” is displayed on “zero point reset cu rrent status”, zero point reset is not completed
normally. Check the condition as per the following and perform zero point reset again.
 Passenger seat is occupied by an object.
 Excessive vibration is applied while performing zero point reset.
 Occupant detection system is malfunctioning.
Revision: 2010 May2011 QX56

B1001, B1002, B1003, B1004, B1005 DIAGNOSIS SENSOR UNIT
SRC-41
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
DTC/CIRCUIT DIAGNOSIS
B1001, B1002, B1003, B1004, B 1005 DIAGNOSIS SENSOR UNIT
DTC LogicINFOID:0000000006219963
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-41, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006219964
WARNING:
 Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal, and wait 3 minutes
or more. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connectors.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-41, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
DTC Display contents of
CONSULT-III DTC detecting condition Possible cause
B1001
B1002
B1003
B1004
B1005 CONTROL UNIT Air bag diagnosis sensor unit is malfunctioning Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

SRC-42
< DTC/CIRCUIT DIAGNOSIS >
B1006, B1007, B1008, B1009, B1010 DIAGNOSIS SENSOR UNIT
B1006, B1007, B1008, B1009, B1010 DIAGNOSIS SENSOR UNIT
DTC LogicINFOID:0000000006219965
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-42, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006219966
WARNING:
 Before servicing, turn ignition switch OFF, disco nnect battery negative terminal, and wait 3 minutes
or more. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connectors.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation"
2. Perform DTC confirmation procedure. Refer to SRC-42, "DTC Logic"
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
DTCDisplay contents of
CONSULT-III DTC detecting condition Possible cause
B1006
B1007
B1008
B1009
B1010 CONTROL UNIT Air bag diagnosis sensor unit is malfunctioning Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

B1011, B1012, B1013, B1014, B1015 DIAGNOSIS SENSOR UNIT
SRC-43
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
B1011, B1012, B1013, B1014, B1015 DIAGNOSIS SENSOR UNIT
DTC LogicINFOID:0000000006219967
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “Self Diagnostic Result” mode of “AIR BAG” using CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter the diagnosis mode if no malfunction is detected in the user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-43, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006219968
WARNING:
 Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal, and wait 3 minutes
or more. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
1.CHECK HARNESS CONNECTOR
Check the harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connectors.
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation"
2. Perform DTC confirmation procedure. Refer to SRC-43, "DTC Logic"
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
DTCDisplay contents of
CONSULT-III DTC detecting condition Possible cause
B1011
B1012
B1013
B1014
B1015 CONTROL UNIT Air bag diagnosis sensor unit is malfunctioning Malfunction in air bag diagnosis sensor unit
Revision: 2010 May2011 QX56

SRC-44
< DTC/CIRCUIT DIAGNOSIS >
B1017, B1020, B1021 OCCUPANT SENS C/U
B1017, B1020, B1021 OCCUPANT SENS C/U
DescriptionINFOID:0000000006219969
Suppresses the deployment of front passenger air bag when the condition of passenger seat is empty or occu-
pied with a child and child-seat. Also illuminates front passenger air bag OFF indicator lamp when the condi-
tion of passenger seat is occupied with a child-seat and ch ild. In case of malfunction the blinking of the air bag
warning lamp reports the malfunction to driver, and by the on board self-diagnosis system or CONSULT-III can
detect the cause.
OPERATION
This unit classifies occupant in passenger seat and detec ts electrical malfunctions in Occupant Detection Sys-
tem, and transmits malfunction information to air bag control unit.
STRUCTURE
It is integrated into the seat sensor mat and detects the occupants with Occupant Detection System control
unit that classifies the occupants.
INSTALLATION
Occupant Detection System control unit is installed in the passenger seat cushion.
DTC LogicINFOID:0000000006219970
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter diagnosis mode if no malfunction is detected in user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-44, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006219971
WARNING:
 Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
DIAGNOSTIC PROCEDURE
1.CHECK HARNESS CONNECTOR
Check the connection of harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connectors.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1017
B1020
B1021 OCCUPANT SENS C/U
[UNIT FAIL]
Trouble occurs in Occupant Detection
System control unit  Disconnection of wiring harness
 Malfunction in Occupant Detection
System control unit
 Malfunction in air bag diagnosis sen-
sor unit
Revision: 2010 May2011 QX56

B1017, B1020, B1021 OCCUPANT SENS C/U
SRC-45
< DTC/CIRCUIT DIAGNOSIS >
C
D E
F
G
I
J
K L
M A
B
SRC
N
O P
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE OCCUPANT DETECTION SYSTEM CONTROL UNIT
1. Replace occupant detection system control unit. Refer to SR-30, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-44, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE OCCUPANT DETECTION SYSTEM SEAT SENSOR
1. Replace seat cushion frame. Refer to SE-105, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-44, "
DTC Logic".
Is DTC detected?
YES >> GO TO 5.
NO >> INSPECTION END
5.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-44, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
Revision: 2010 May2011 QX56

SRC-46
< DTC/CIRCUIT DIAGNOSIS >
B1018 OCCUPANT SENS
B1018 OCCUPANT SENS
DescriptionINFOID:0000000006219972
Suppresses the deployment of front passenger air bag when the condition of passenger seat is empty or occu-
pied with a child and child-seat. Also illuminates front passenger air bag OFF indicator lamp when the condi-
tion of passenger seat is occupied with a child-seat and ch ild. In case of malfunction the blinking of the air bag
warning lamp reports the malfunction to driver, and by the on board self-diagnosis system or CONSULT-III can
detect the cause.
OPERATION
The unit classifies occupant in passenger seat and trans mits it to Occupant Detection System control unit.
STRUCTURE
Multiple sensors are installed in the sensor mat to prevent incorrect sensing induced by the sitting position.
INSTALLATION
Occupant Detection System sensor is installed in the passenger seat cushion.
DTC LogicINFOID:0000000006219973
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAG RESULT
With CONSULT-III
1. Turn ignition switch ON.
2. Perform “AIR BAG” Self Diagnostic Result CONSULT-III.
Without CONSULT-III
1. Turn ignition switch ON.
2. Check the air bag warning lamp status. Refer to SRC-14, "
On Board Diagnosis Function".
NOTE:
SRS does not enter diagnosis mode if no malfunction is detected in user mode.
Is malfunctioning part detected?
YES >> Refer to SRC-46, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006219974
WARNING:
 Before servicing, turn ignition sw itch OFF, disconnect battery negative terminal and wait at least 3
minutes. (To discharge backup capacitor.)
 Never use unspecified tester or other measuring device.
DIAGNOSTIC PROCEDURE
1.CHECK HARNESS CONNECTOR
Check the connection of harness connector.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace harness connectors.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
B1018 OCCUPANT SENS [UNIT FAIL] Malfunction occurs in Occupant Detec-
tion System sensor  Disconnection of wiring harness
 Malfunction in Occupant Detection
System sensor
 Malfunction in Occupant Detection System control unit
 Malfunction in air bag diagnosis sen-
sor unit
Revision: 2010 May2011 QX56

B1018 OCCUPANT SENSSRC-47
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G
I
J
K L
M A
B
SRC
N
O P
2.CHECK WIRING HARNESS
Check the wiring harness externals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace wiring harness.
3.REPLACE OCCUPANT DETECTION SYSTEM CONTROL UNIT
1. Replace occupant detection system control unit. Refer to SR-30, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-44, "
DTC Logic".
Is DTC detected?
YES >> GO TO 4.
NO >> INSPECTION END
4.REPLACE OCCUPANT DETECTION SYSTEM SEAT SENSOR
1. Replace seat cushion frame. Refer to SE-105, "
Exploded View".
2. Perform DTC confirmation procedure. Refer to SRC-44, "
DTC Logic".
Is DTC detected?
YES >> GO TO 5.
NO >> INSPECTION END
5.REPLACE AIR BAG DIAGNOSIS SENSOR UNIT
1. Replace air bag diagnosis sensor unit. Refer to SR-26, "
Removal and Installation".
2. Perform DTC confirmation procedure. Refer to SRC-46, "
DTC Logic".
Is DTC detected?
YES >> GO TO 1.
NO >> INSPECTION END
Revision: 2010 May2011 QX56
