trip computer INFINITI QX56 2011 Factory Service Manual

MWI-2
DIAGNOSIS SYSTEM (COMBINATION
METER) ..............................................................
29
On Board Diagnosis Function .............................. ...29
CONSULT-III Function ...........................................30
ECU DIAGNOSIS INFORMATION ..............35
COMBINATION METER ................................. ...35
Reference Value .................................................. ...35
Fail-Safe .................................................................42
DTC Index ..............................................................43
IPDM E/R ...........................................................44
List of ECU Reference ......................................... ...44
WIRING DIAGRAM .....................................45
METER SYSTEM ............................................ ...45
Wiring Diagram .................................................... ...45
CLOCK ...............................................................55
Wiring Diagram .................................................... ...55
BASIC INSPECTION ...................................57
DIAGNOSIS AND REPAIR WORKFLOW
(METER SYSTEM ) .......................................... ...
57
Work flow ............................................................. ...57
DTC/CIRCUIT DIAGNOSIS ...................... ...59
U1000 CAN COMM CIRCUIT ......................... ...59
Description ........................................................... ...59
DTC Logic ...............................................................59
Diagnosis Procedure .............................................59
U1010 CONTROL UNIT (CAN) .........................60
Description ........................................................... ...60
DTC Logic ...............................................................60
Diagnosis Procedure ..............................................60
B2205 VEHICLE SPEED ...................................61
Description ........................................................... ...61
DTC Logic ...............................................................61
Diagnosis Procedure .............................................61
B2267 ENGINE SPEED .....................................62
Description ........................................................... ...62
DTC Logic ...............................................................62
Diagnosis Procedure ..............................................62
B2268 WATER TEMP ........................................63
Description ........................................................... ...63
DTC Logic ...............................................................63
Diagnosis Procedure ..............................................63
POWER SUPPLY AND GROUND CIRCUIT .....64
COMBINATION METER ........................................ ...64
COMBINATION METER : Diagnosis Procedure ....64
TRIP RESET AND ILLUMINATION CON-
TROL SWITCH SIGNAL CIRCUIT ....................
65
Diagnosis Procedure ............................................ ...65
Component Inspection ............................................66
TRIP COMPUTER SWITCH SIGNAL CIRCUIT
...
67
Diagnosis Procedure ............................................ ...67
Component Inspection ............................................68
FUEL LEVEL SENSOR SIGNAL CIRCUIT .......69
Component Function Check ................................ ...69
Diagnosis Procedure ..............................................69
Component Inspection ............................................70
OIL PRESSURE SWITCH SIGNAL CIRCUIT ...71
Component Function Check ...................................71
Diagnosis Procedure ...............................................71
Component Inspection ............................................71
WASHER LEVEL SWITCH SIGNAL CIRCUIT ...73
Diagnosis Procedure ............................................ ...73
Component Inspection ............................................73
A/C AUTO AMP. CONNECTION RECOGNI-
TION SIGNAL CIRCUIT ....................................
74
Diagnosis Procedure ........................................... ...74
SYMPTOM DIAGNOSIS ............................75
THE FUEL GAUGE INDICATOR DOES NOT
OPERATE ....................................................... ...
75
Description ........................................................... ...75
Diagnosis Procedure ...............................................75
THE TRIP RESET AND ILLUMINATION CON-
TROL SWITCH IS INOPERATIVE ....................
76
Description ........................................................... ...76
Diagnosis Procedure ...............................................76
THE TRIP COMPUTER SWITCH IS INOPER-
ATIVE .................................................................
77
Description ........................................................... ...77
Diagnosis Procedure ...............................................77
THE OIL PRESSURE WARNING LAMP
DOES NOT TURN ON .................................... ...
78
Description ........................................................... ...78
Diagnosis Procedure ...............................................78
THE OIL PRESSURE WARNING LAMP
DOES NOT TURN OFF .................................. ...
79
Description ........................................................... ...79
Diagnosis Procedure ...............................................79
THE PARKING BRAKE RELEASE WARNING
CONTINUES DISPLAYING, OR DOES NOT
DISPLAY ............................................................
80
Description ........................................................... ...80
Diagnosis Procedure ...............................................80
Revision: 2010 May2011 QX56

MWI
MWI-3
C
DE
F
G H
I
J
K L
M B
A
O P
THE LOW WASHER FLUID WARNING CON-
TINUES DISPLAYING, or DOES NOT DIS-
PLAY .............................................................. ....
81
Description .......................................................... ....81
Diagnosis Procedure ...............................................81
THE DOOR OPEN WARNING CONTINUES
DISPLAYING, OR DOES NOT DISPLAY ..........
82
Description .......................................................... ....82
Diagnosis Procedure ...............................................82
THE AMBIENT TEMPERATURE DISPLAY IS
INCORRECT .......................................................
83
Description .......................................................... ....83
Diagnosis Procedure ...............................................83
NORMAL OPERATING CONDITION .................84
INFORMATION DISPLAY ..................................... ....84
INFORMATION DISPLAY : Description ..................84
REMOVAL AND INSTALLATION ...............85
COMBINATION METER ...................................85
Exploded View ..................................................... ....85
Removal and Installation .........................................85
Disassembly and Assembly .....................................85
TRIP RESET AND ILLUMINATION CON-
TROL SWITCH ..................................................
86
Exploded View .........................................................86
Removal and Installation .........................................86
TRIP COMPUTER SWITCH ..............................87
Exploded View .........................................................87
Removal and Installation .........................................87
CLOCK ..............................................................88
Exploded View .........................................................88
Removal and Installation .........................................88
Revision: 2010 May2011 QX56

MWI-6
< SYSTEM DESCRIPTION >
COMPONENT PARTS
SYSTEM DESCRIPTION
COMPONENT PARTS
METER SYSTEM
METER SYSTEM : Component Parts LocationINFOID:0000000006221690
1.IPDM E/R
Refer to
PCS-4, "Component Parts
Location". 2.
ECM
Refer to
EC-16, "
Component Parts
Location". 3. Washer level switch
4. Oil pressure switch
Refer to
EM-57, "
Exploded View".5. Ambient sensor 6. A/C auto amp.
Refer to
HAC-6, "
FRONT AUTO-
MATIC AIR CONDITIONING SYS-
TEM : Component Parts Location".
7. TCM
Refer to
TM-10, "
A/T CONTROL
SYSTEM : Componen t Parts Loca-
tion". 8.ABS actuator and electric unit (con-
trol unit)
Refer to
BRC-10, "
Component Parts
Location". 9.BCM
Refer to
BCS-4, "
BODY CONTROL
SYSTEM : Component Parts Loca-
tion".
10. Fuel level sensor unit 11. Trip computer switch 12. Combination meter
13. Trip reset and illumination control
switch 14. Parking brake switch
A. Under of left side second seat
JSNIA3157ZZ
Revision: 2010 May2011 QX56

MWI
COMPONENT PARTSMWI-7
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
J
K L
M B A
O P
METER SYSTEM : Com ponent DescriptionINFOID:0000000006221691
CLOCK
Unit Description
Combination meter Controls the following with the signals received from each unit via CAN communication and the sig-
nals from switches and sensors.
 Speedometer
 Tachometer
 Engine coolant temperature gauge
 Fuel gauge
 Engine oil pressure gauge
 Voltmeter
 Warning lamps
 Indicator lamps
 Meter illumination control
 Meter effect function
 Information display
Trip computer switch Transmits the following signals to the combination meter.
 Enter switch signal
 Select switch signal
Trip reset and illumination con-
trol switch Transmits the following signals to the combination meter.
 Trip reset switch signal
 Illumination control switch signal (+)
 Illumination control switch signal (
−)
ECM Transmits the following signals to the combination meter via CAN communication.
 Engine speed signal
 Engine coolant temperature signal
 Engine status signal
 Fuel consumption monitor signal
ABS actuator and electric unit
(control unit) Transmits the vehicle speed signal to the combination meter via CAN communication.
IPDM E/R Transmits the oil pressure switch signal to the BCM via CAN communication.
BCM Transmits the following signals to the combination meter via CAN communication.
 Oil pressure switch signal
 Position light request signal
 Dimmer signal
 Door switch signal
 Meter ring illumination request signal
 Starter relay status signal
TCM Transmits the shift position signal to the combination meter via CAN communication.
A/T shift selector Transmits the following signals to the combination meter.
 Manual mode signal
 Non-manual mode signal
 Manual mode shift up signal
 Manual mode shift down signal
Fuel level sensor unit Transmits the fuel level sensor signal to the combination meter.
Oil pressure switch Transmits the oil pressure switch signal to the IPDM E/R.
Ambient sensor Transmits the ambient sensor signal to the combination meter.
A/C auto amp. Transmits the A/C auto amp. connection recognition signal to the combination meter.
Parking brake switch Transmits the parking brake switch signal to the combination meter.
Washer level switch Transmits the washer level switch signal to the combination meter.
Revision: 2010 May2011 QX56

MWI
SYSTEMMWI-11
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
J
K L
M B A
O P
ARRANGEMENT OF COMBINATION METER
Information
display Odo/trip meter Displays mileage.
MWI-20, "
INFOR-
MATION DIS-
PLAY : System
Description"
Shift position indicator Displays shift position.
Trip computerCurrent fuel consumption Displays current fuel consumption.
Average fuel consumption Displays average fuel consumption.
Distance to empty Displays distance to empty.
Average vehicle speed Displays average vehicle speed.
Travel time Displays travel time.
Travel distance Displays mileage.
Ambient temperature Displays ambient temperature.
Interrupt indi-
cation Warning
Door open
warning
Warns when a door is open.
Parking brake
release warning Warns if traveling when the parking brake is
under operating condition.
Low fuel warn-
ing Warns when being low on fuel.
Low washer flu-
id warning Displayed/Hidden, depending on washer
fluid level.
Alert Travel time
Causes an interrupt when exceeding ran-
domly set time.
Low ambient
temperature Causes an interrupt when ambient tempera-
ture reaches below 3
°C (37 °F).
Maintenance Tire
Causes an interrupt when exceeding ran-
domly set distance.
Oil filter Causes an interrupt when exceeding ran-
domly set distance.
Engine oil Causes an interrupt when exceeding ran-
domly set distance.
Other Causes an interrupt when exceeding ran-
domly set distance.
Meter illumination level Indicates the brightness of the meter illumi-
nation in stages.
Setting Alert
Timer
Allows the user to set a display time for
“Travel time”.
ICY Allows the ON/OFF setting of the low ambi-
ent temperature (alert) function.
Maintenance Tire
Alerts when reaching mileage set in “SET-
TING”.
Filter Alerts when reaching mileage set in “SET-
TING”.
Oil Alerts when reaching mileage set in “SET-
TING”.
Other Alerts when reaching mileage set in “SET-
TING”.
Options Language
Allows the user to set language for informa-
tion display.
Unit Allows unit settings.
Effects Allows the ON/OFF setting of the engine-
start effect function.
System Description Reference
Revision: 2010 May2011 QX56

MWI-20
< SYSTEM DESCRIPTION >
SYSTEM
INFORMATION DISPLAY : System Description
INFOID:0000000006221717
DESCRIPTION
 The combination meter receives signals necessary for controlling the operation of the information display from each unit, sensor and switch.
 The combination meter incorporates a trip computer t hat displays the warning/information according to the
information received from each unit, sensor and switch.
 The combination meter shows the following functions on the information display.
- Odo/trip meter
- Shift position indicator
- Trip computer
- Interrupt indication
- Warning check indication
- Setting
ODO/TRIP METER
 The ABS actuator and electric unit (control unit) r eads the rectangular wave signal provided by the wheel
sensor and transmits the vehicle speed signal to the combination meter via CAN communication.
 The combination meter converts the vehicle speed signal received via CAN communication to mileage, and it displays the accumulated mileage on the information display.
SHIFT POSITION INDICATOR
MANUAL MODE
 The combination meter receives the following signal and transmits the signal to TCM via CAN communica-tion.
 TCM judges a shift position, manual mode, and manual mode information, based on a signal received from
the combination meter via CAN communication and transmi ts the following signals to the combination meter
via CAN communication.
 The combination meter activates the shift position indicator, and manual mode information, based on signals received from TCM via CAN communication.
NOTE:
When receiving a manual mode shift refusal signal from TCM via CAN communication, the combination meter
blinks the shift position indicator lamp and allows the integrated buzzer to ring a beep tone. For further infor-
mation, refer to TM-54, "
SHIFT PATTERN CONTROL : System Description".
NON-MANUAL MODE
 Combination meter inputs non-manual mode signal from A/T shift selector (manual mode switch), and trans-
mits the signals to TCM with CAN communication line.
 TCM transmits shift position signal to combination meter with CAN communication line.
 Combination meter indicates shift position when receiving shift position signal.
TRIP COMPUTER
Current Fuel Consumption
The combination meter calculates current fuel cons umption based on the following signals, and the calculated
value is displayed on the information display.
Signal name Signal path
Manual mode signal
A/T shift selector Combination meter TCM
Non-manual mode signal
Manual mode shift up signal
Manual mode shift down signal
Signal name Signal path
Shift position signal TCM Combination meter
Manual mode shift refusal signal
Revision: 2010 May2011 QX56

MWI-28
< SYSTEM DESCRIPTION >
OPERATION
OPERATION
Switch Name and FunctionINFOID:0000000006221718
JSNIA2978ZZ
Switch name Operation Description
Trip reset and illumi-
nation control switch Trip reset switch (1)
Press The trip meter can be switched between A and B.
 Trip meter A/B can be reset by pressing and holding the
trip reset switch.
Illumination control switch (+) (2) An illuminance level of the back light of the combination
meter can be adjusted.
Illumination control switch ( −) (3)
Trip computer
switch Enter switch (4)  The information display screen can be switched.
 The item indicated on the information display can be con-
firmed.
 An indicated value of the trip computer can be reset by
pressing and holding the enter switch.
Select switch (5) When plural items are shown on the information display, a
selected item can be changed to the other item.
Revision: 2010 May2011 QX56

MWI
TRIP COMPUTER SWITCH SIGNAL CIRCUITMWI-67
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
J
K L
M B A
O P
TRIP COMPUTER SWITCH SIGNAL CIRCUIT
Diagnosis ProcedureINFOID:0000000006221746
1.CHECK COMBINATION METER INPUT SIGNAL
1. Turn ignition switch ON.
2. Measure voltage between the following terminals of the combination meter.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.CHECK TRIP COMPUTER SWITCH SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect combination meter connector and trip computer switch connector.
3. Check continuity between combination meter harnes s connector and trip computer switch harness con-
nector.
4. Check continuity between combination meter harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK TRIP COMPUTER SWITCH GROUND CIRCUIT
Check continuity between trip computer switch connector and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair harness or connector.
(+) ( −)
Condition Voltag e
(Approx.)
Combination meter
Ground
Connector Terminals
M34 11
When enter switch is pressed 0 V
Other than the above 5 V
12 When select switch is pressed 0 V
Other than the above 5 V
Te r m i n a l s
Continuity
Combination meter Trip computer switch
Connector Terminal Connector Terminal
M34 11
M84 3
Existed
12 4
Combination meter GroundContinuity
Connector Terminal
M34 11
Not existed
12
Trip computer switch
GroundContinuity
Connector Terminal
M84 6 Existed
Revision: 2010 May2011 QX56

MWI-68
< DTC/CIRCUIT DIAGNOSIS >
TRIP COMPUTER SWITCH SIGNAL CIRCUIT
Component Inspection
INFOID:0000000006221747
1.CHECK TRIP COMPUTER SWITCH
1. Turn ignition switch OFF.
2. Disconnect trip computer switch connector.
3. Check trip computer switch.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace trip computer switch. Refer to MWI-87, "
Removal and Installation".
Te r m i n a l s
Condition Continuity
Trip computer switch
3 6When enter switch is pressed Existed
Other than the above Not existed
4 When select switch is pressed Existed
Other than the above Not existed
Revision: 2010 May2011 QX56

MWI
THE TRIP COMPUTER SWITCH IS INOPERATIVEMWI-77
< SYMPTOM DIAGNOSIS >
C
DE
F
G H
I
J
K L
M B A
O P
THE TRIP COMPUTER SW ITCH IS INOPERATIVE
DescriptionINFOID:0000000006221761
If any of the following malfunctions is f ound for the trip computer switch operation.
 All switches are inoperative
 The specified switch cannot be operated
Diagnosis ProcedureINFOID:0000000006221762
1.CHECK TRIP COMPUTER SWITCH SIGNAL CIRCUIT
Check the trip computer switch signal circuit. Refer to MWI-67, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK TRIP COMPUTER SWITCH
Perform a unit check for the trip computer switch. Refer to MWI-68, "
Component Inspection".
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-85, "Removal and Installation".
NG >> Replace trip computer switch. Refer to MWI-87, "
Removal and Installation".
Revision: 2010 May2011 QX56
