INFINITI QX60 2014 Navigation Manual

12. Speak the house number.“How to speak numbers”
(page 9-14)
INFO:
If the house number is not known, speak
“No house number”.
13. To confirm the destination location onthe map, speak “Show Map” .To
calculate a route, speak “Calculate
Route”.
2. Getting started
2-33

2. Getting started
2-34
COMMAND LISTS
CategoryCommand Action
Phone Operates the Phone function.
Navigation Operates the Navigation function.
Information Displays the Vehicle Information function.
Audio Operates the Audio function.
Help Displays the User Guide.
Navigation Command Action
Destination Home Sets a route to the home location that is stored in the Address book.
Address Searches for a location by the street address specified, and sets a route (for continental U.S.
and Canada only).
Places Sets a route to a facility near the current vehicle location.
Address Book Searches for information stored in the Address Book.
Previous Destinations Sets a route to a previous destination.
Phone Command
Action
Dial Number Makes a call to a spoken phone number up to 10 digits.
Quick Dial Makes a call to a contact that is stored in the Quick Dial.
Phonebook Makes a call to a phone number stored in a mobile phone.
Call History Incoming Calls Makes a call to an incoming call number.
Outgoing Calls Makes a call to a dialed number.
Missed Calls Makes a call to a missed calls number.
International Call Makes an international call by allowing more than 10 digits to be spoken.

InformationCommand
Action
Fuel Economy Displays fuel economy information.
Trip Computer (if so equipped) Displays trip information.
Maintenance Displays maintenance information.
Where am I? Displays GPS information.
Traffic Information Turns the traffic information system on and off.
Audio Command
Action
AM Turns to the AM band, selecting the station last played.
FM Turns to the FM band, selecting the station last played.
XM Turns to the SiriusXM Satellite Radio band, selecting the channel last played.
CD Starts to play a CD.
General Command
Action
Go back Corrects the last recognition result to return to the previous screen.
Exit Cancels Voice Recognition.
INFO:
Refer to the vehicle Owner’s Manual for the operations related to phone, information and audio.
2. Getting started
2-35

2. Getting started
2-36 MEMO

3 Map settings
Map types ........................................................... 3-22D map ........................................................... 3-2
Birdview
TM(3D) map ....................................... 3-3
Building graphics ............................................ 3-3
Displaying current vehicle location ...................... 3-4 Operating with control panel ........................... 3-4
Operating with touch panel operation ............. 3-5
Moving map ........................................................ 3-5 2D map ........................................................... 3-5
Birdview
TM(3D) map ....................................... 3-7
Changing scale of map ........................................ 3-8
Operating with ZOOM buttons (if
so equipped) ................................................... 3-8
Operating with center dial ............................... 3-9
Operating with touch panel operation ........... 3-10
Map scale ..................................................... 3-10 Changing map view........................................... 3-11
Other settings.............................................. 3-12
Map view settings ............................................. 3-13 Basic operation............................................ 3-13
Setting map orientation ............................... 3-14
Settings long range map view...................... 3-15
Setting map color ........................................ 3-16
Changing Birdview
TMangle .......................... 3-16
Setting left screen display ........................... 3-17
Looking at information on map ......................... 3-18 Displaying map icons................................... 3-18
Map scrolling information ............................ 3-19
Map symbols ............................................... 3-21
Road color ................................................... 3-22
Traffic information on map ........................... 3-22

3. Map settings
3-2
MAP TYPES
Two types of map views are available: 2D
map and BirdviewTM(3D) map.
2D MAP
The 2D map displays the map in a 2-
dimensional environment similar to a road
map.
Screen information
*1Vehicle icon:
Indicates the current vehicle location
and the direction of travel.
*2Guide point:
Indicates a guide point on the route.
*3Remaining time and distance to
the destination:
Indicates the approximate remaining
time and distance to the destination or
waypoint. This indicator will appear
when a destination or waypoint is set
and route guidance is started.
When the vehicle is not driven on the
suggested route, the screen displays
the direction to the destination and the
distance to the destination from the
current vehicle position.
“Switching estimated arrival time
display” (page 5-29)
*4Suggested route:
Appears in bold yellow during route
guidance.
*5/Direction indicator:
Indicates the directional setting of the
map. Touch the icon to change the
setting.
: North always pointing up.

: Direction of the vehicle always
pointing up.
“Setting map orientation”
(page 3-14)
*6Scale indicator:
Indicates the scale of the map. Touch
the icon to display the scale bar.
The map scale can be adjusted using
the scale bar.
“Operating with touch panel op-
eration” (page 3-10)
*7Arrow:
Indicates the distance to the next
guide point and the turning direction
at that guide point.
*8Stored location (orange):
Displays the locations that are stored
in the Address Book. Icons can be
changed according to personal prefer-
ences.
“Storing location” (page 6-2)
*9Avoid Area (green or blue):
Displays the areas to avoid that are
stored in the Address Book with green
or blue icons. During the route search,
the route guidance is performed by
searching for a route that avoids those areas.
“Storing avoid area”
(page 6-7)
*10Street name:
Displays the name of the street the
vehicle is currently driving on.
*11Traffic indicator:
Displays the reception condition of the
traffic information transmitted from
the provider.
Green: Reception condition is good.
Gray: Reception condition is not good.
No mark: Subscription to NavTraffic
service is not detected.
BirdviewTM(3D) MAP
BirdviewTMdisplays the map from an
elevated perspective. In BirdviewTM,itis
easy to recognize an image of the route
because it provides a panoramic view over
a long distance.
INFO:
Note the following items about the BirdviewTM
display..“BirdviewTM” is a registered trademark of
Clarion Co., Ltd.
.The map in BirdviewTMalways appears with
the current forward direction facing up.
BUILDING GRAPHICS
In an area where the building graphics are
stored in the map data, the building
graphics are displayed when the map is
zoomed in. On the 2D map display, these
are called “Building footprint graphics”,
and on the Birdview
TMdisplay, these are
called “3D building graphics”.
The method to look at the map is the same
for the 2D and Birdview
TMmaps.
3. Map settings
3-3

3. Map settings
3-4
Building footprint graphics (2D map)
3D building graphics (BirdviewTMmap)
INFO:
In an area where the building graphics are not
stored in the map data, the normal map is
displayed even when the map is zoomed in.
DISPLAYING CURRENT VEHICLE LOCA-
TION
OPERATING WITH CONTROL PANEL
The basic map screen displays the current
location (the position where the vehicle
mark is located). Push

OPERATING WITH TOUCH PANEL
OPERATION
After moving the map, touch [BACK] on the
map screen to display the current location
map screen.
MOVING MAP
The operations for moving across the map
are different between the 2D and Bird-
view
TMmaps.
2D MAP
Screen information:
*1Cross pointer
*2Distance from the current location to
the cross pointer
*3Street name
Operating with INFINITI controller
Push one of the directional buttons or the
slide switch. Press and hold a directional
button or the slide switch to move con-
tinuously across the map in a direction.
While moving across the map, the cross
pointer appears.
If the map scale is set to 1/8 mile (200 m)
or less, the street indicated by the cross
3. Map settings
3-5

3. Map settings
3-6
pointer will blink in pink and the street
name will be displayed.
Operating with touch operation
1. Touch the screen.The cross pointer is displayed, and the
touched position is set as the center of
the screen.
2. Touch the direction to move to. The mapcontinues to scroll while the screen is
touched.
INFO:
While driving, one touch continuous scrolling is
disabled. Touch the screen again to scroll
further.
If the map screen is set to the building footprint
graphics, the map cannot be scrolled while
driving.
Fine-tuning the cursor position:
1. Touch [Slow].
The 8-directional key is displayed.
2. Touch the 8-directional key to adjustthe cross pointer position. Touch
[BACK] to complete the adjustment.
INFO:
Fine-tuning the cursor position is not possible
while driving.
