warning INFINITI QX60 2023 Owners Manual

SYSTEM TEMPORARILY
UNAVAILABLE
When radar blockage is detected, the system
will be deactivated automatically. The “Un-
available: Side Radar Obstruction” warning
message will appear in the vehicle informa-
tion display.
The systems are not available until the condi-
tions no longer exist.
The radar sensors may be blocked by tempo-
rary ambient conditions such as splashing
water, mist or fog.
The blocked condition may also be caused by
conditions such as ice, snow, frost or dirt
obstructing the radar sensors.
NOTE:
If the BSW system stops working, the RCTA
and BSI systems (if so equipped) will also
stop working.
Action to take
When the above conditions no longer exist,
the system will resume automatically.
LSD4412
For vehicles with the 7 inch (18 cm) display
5-80Starting and driving

Malfunction
When the RCTA system malfunctions, it will
turn off automatically. The system malfunc-
tion warning message will appear in the ve-
hicle information display.
NOTE:
If the BSW system stops working, the RCTA
and BSI systems (if so equipped) will also
stop working.
Action to take
Stop the vehicle in a safe location, push the
park button to engage the P (Park) position,
turn the engine off and restart the engine. If
the message continues to appear, have the
system checked. It is recommended that you
visit an INFINITI retailer for this service.
LSD4413
For vehicles with the 12.3 inch (31.2 cm) display
Starting and driving5-81

PRECAUTIONS ON CRUISE
CONTROL
1. ACCEL/RES switch
2. COAST/SET switch
3. CANCEL switch
4. ON/OFF switch
• If the cruise control system malfunctions, itwill cancel automatically. The SET indicator
in the vehicle information display will blink
to warn the driver.
• If the engine coolant temperature becomes excessively high, the cruise control system
will be canceled automatically. • If the SET indicator blinks, turn the ON/
OFF switch off and have the system
checked. It is recommended that you visit
an INFINITI retailer for this service.
• The SET indicator may sometimes blink when the ON/OFF switch is turned on
while pushing the ACCEL/RES, COAST/
SET or CANCEL switch. To properly set
the cruise control system, perform the
steps below.
WARNING
Do not use the cruise control when driving
under the following conditions:
• When it is not possible to keep the ve-
hicle at a set speed
• In heavy traffic or in traffic that varies in
speed
• On winding or hilly roads
• On slippery roads (rain, snow, ice, etc.)
• In very windy areas
Doing so could cause a loss of vehicle con-
trol and result in an accident.
CRUISE CONTROL OPERATIONS
The cruise control allows driving at a speed
between 25 - 89 mph (40 - 144 km/h) with-
out keeping your foot on the accelerator
pedal.
To turn on the cruise control, push the cruise
control ON/OFF switch on. The
indica-
tor (white) in the vehicle information display
will illuminate.
To set cruising speed, accelerate the vehicle
to the desired speed, push the SET- switch
and release it. The
indicator (green) in
the vehicle information display will illuminate.
Take your foot off the accelerator pedal.
Your vehicle maintains the set speed.
• To pass another vehicle, depress the accel-
erator pedal. When you release the pedal,
the vehicle returns to the previously set
speed.
• The vehicle may not maintain the set speed when going up or down steep hills. If this
happens, drive without the cruise control.
To cancel the preset speed, use one of the
following three methods:
• Push the CANCEL switch; the
indica-
tor (green) in the vehicle information display
goes out.
LSD4169
CRUISE CONTROL (if so equipped)
Starting and driving5-83

• Tap the brake pedal; theindicator
(green) goes out.
• Push the cruise control ON/OFF switch off. The
indicator in the vehicle infor-
mation display go out.
The cruise control is automatically canceled
and the
indicator (green) in the vehicle
information display goes out if:
• You depress the brake pedal while pushing the RES+ or SET- switch. The preset speed
is deleted from memory.
• The vehicle slows down more than 8 mph (13 km/h) below the set speed.
• You move the shift lever to N (Neutral).
To reset at a faster cruising speed, use one of
the following three methods:
• Depress the accelerator pedal. When the vehicle attains the desired speed, push and
release the SET- switch.
• Push and hold the RES+ switch. When the vehicle attains the speed you desire, release
the switch.
• Push and release the RES+ switch. Each time you do this, the set speed increases by
about 1 mph (1.6 km/h). To reset at a slower cruising speed,
use one
of the following three methods:
• Lightly tap the brake pedal. When the ve- hicle attains the desired speed, push the
SET- switch and release it.
• Push and hold the SET- switch. Release the switch when the vehicle slows to the de-
sired speed.
• Push and release the SET- switch. Each time you do this, the set speed decreases by
about 1 mph (1.6 km/h).
To resume the preset speed, push and re-
lease the RES+ switch. The vehicle returns to
the last set cruising speed when the vehicle
speed is over 25 mph (40 km/h).
WARNING
Failure to follow the warnings and instruc-
tions for proper use of the ProPILOT Assist
system could result in serious injury or
death.
• ProPILOT Assist is not a self-driving
system. Within the limits of its capabili-
ties, as described in this manual, it helps
the driver with certain driving activities.
• The ProPILOT Assist system is not a re-
placement for proper driving procedures
and is not designed to correct careless,
inattentive or absent-minded driving.
ProPILOT Assist will not always steer
the vehicle to keep it in the lane. The Pro-
PILOT Assist system is not designed to
prevent loss of control. It is the driver’s
responsibility to stay alert, drive safely,
keep the vehicle in the traveling lane, and
be in control of the vehicle at all times.
• There are limitations to the ProPILOT
Assist system capability. The ProPILOT
Assist system does not function in all
driving, traffic, weather, and road condi-
tions. It is the driver’s responsibility to
stay alert, drive safely, keep the vehicle
in the traveling lane, and be in control of
the vehicle at all times.
PROPILOT ASSIST (if so equipped)
5-84Starting and driving

•The ProPILOT Assist system is only an
aid to assist the driver and is not a colli-
sion warning or avoidance device.
• The ProPILOT Assist system is for high-
way use only and is not intended for city
driving. Failure to apply the brakes or
steer the vehicle when necessary may re-
sult in a serious accident.
• Always observe posted speed limits and
do not set the speed over them.
• Never take your hands off the steering
wheel when driving. Always keep your
hands on the steering wheel and drive
your vehicle safely.
• Never unfasten your safety belt when
using ProPILOT Assist. Doing so auto-
matically cancels the ProPILOT Assist
system.
• The ProPILOT Assist system does not
react to stationary and slow moving
vehicles. •
Always drive carefully and attentively
when using the ProPILOT Assist system.
Read and understand the Owner’s
Manual thoroughly before using the
ProPILOT Assist system. To avoid seri-
ous injury or death, do not rely on the
system to prevent accidents or to control
the vehicle’s speed in emergency situa-
tions. Do not use the ProPILOT Assist
system except in appropriate road and
traffic conditions.
The ProPILOT Assist system is intended to
enhance the operation of the vehicle when
following a vehicle traveling in the same lane
and direction.
The ProPILOT Assist system uses a multi-
sensing front camera
OAinstalled behind the
windshield and a radar sensor located on the
front of the vehicle
OBto measure the distance
to the vehicle ahead in the same lane and to
monitor the lane markers. If the vehicle detects
a slower moving vehicle ahead, the system will
reduce the vehicle speed so that your vehicle
follows the vehicle in front at the selected dis-
tance. The system will also help keep the ve-
hicle centered in the traveling lane when clear
lane markings are detected.
LSD4514
Starting and driving5-85

• Steering Assist indicator (gray): SteeringAssist standby
• Steering Assist indicator (green): Steer- ing Assist active
4. Set distance indicator
Displays the selected distance
5. Lane marker indicator
Indicates whether the system detects lane
markers
• No lane markers displayed: Steering Assist is turned off
• Lane marker indicator (gray): No lane markers detected
•
Lane marker indicator (green): Lane mark-
ers detected, Steering Assist is active
• Lane marker indicator (yellow): Lane de- parture is detected 6.
ProPILOT Assist status indicator
Indicates the status of the ProPILOT As-
sist system by the color of the indicator
– ProPILOT Assist status indicator (white): ProPILOT Assist is on but in
standby.
– ProPILOT Assist status indicator (blue): ProPILOT Assist active
7. Steering Assist status indicator/warning
Displays the status of the Steering Assist
by the color of the indicator/warning
• No Steering Assist status indicator dis- played: Steering Assist is turned off
• Steering Assist indicator (gray): Steering Assist standby
• Steering Assist indicator (green): Steer- ing Assist active
• Steering Assist indicator (yellow): Steer- ing Assist malfunction 8.
Speed control status indicator/set dis-
tance indicator/lane marker indicator
(
)
Displays the status of speed control by
the color of the indicator, and displays the
selected distance by the number of hori-
zontal bars shown
• Speed control status indicator (white): ICC standby
• Speed control status indicator (green): ICC (distance control mode) is active
– Green vehicle icon displayed: Vehicle detected ahead
– No vehicle icon shown: No vehicle de- tected ahead (Your vehicle maintains the
driver-selected set speed.)
• Speed control status indicator (orange): Indicates an ICC malfunction
For the lane marker indicator, see “Steering
Assist display and indicators” (P. 5-112).
9. Set vehicle speed indicator
Indicates the set vehicle speed
Starting and driving5-89

10.Vehicle set speed indicator (if so
equipped) ()
Indicates the vehicle set speed
11. Road information indicator (if so
equipped) (
,)
Indicates the detected road information.
For additional information, see “Speed
Adjust by Route - a feature of ProPILOT
Assist with Navi-link” (P. 5-104).
12. Detected speed limit indicator (if so
equipped) (
)
Indicates the currently detected speed
limit.
For additional information, see “Speed
Limit Assist - a feature of ProPILOT As-
sist with Navi-link” (P. 5-102).
13. Speed Limit Assist indicator (if so
equipped) (A,
,)
Indicates the Speed Limit Assist activa-
tion mode or system operation.
For additional information, see “Speed
Limit Assist - a feature of ProPILOT As-
sist with Navi-link” (P. 5-102).
TURNING THE CONVENTIONAL
(fixed speed) CRUISE CONTROL
MODE ON
NOTE:
ProPILOT Assist provides no approach
warnings, automatic braking, or steering as-
sist in the conventional (fixed speed) cruise
control mode.
To choose the conventional (fixed speed)
cruise control mode, push and hold the Pro-
PILOT Assist switch for longer than approxi-
mately 1.5 seconds. For additional informa-
tion, see “Conventional (fixed speed) cruise
control mode” (P. 5-117).
OPERATING PROPILOT ASSIST
When the driving aids are enabled:
Zone Driving Aid Display
For-
ward Forward Emergency
Braking (FEB) with
Pedestrian Detection
Outline
Predictive Forward
Collision Warning
(PFCW)
LSD4318
Example (all enabled)
5-90Starting and driving

Zone Driving AidDisplay
Lane Lane Departure
Warning (LDW)
Outline
Lane Departure Pre-
vention (LDP) Shaded
Blind
Spot Blind Spot Warning
(BSW)
Outline
Blind Spot Intervention
(BSI) Shaded
1. Push the ProPILOT Assist switch
OA. This
turns on the ProPILOT Assist system.
• The ProPILOT Assist status indicator
OBilluminates in white.
2. A screen is displayed for a period of time that indicates the status of the driving aid
functions.
• When any of the “Warning” systems are enabled, the “
” is shown in each zone.
• When any of the “Intervention” systems are enabled, the “
” mark is shown in each
zone.
• When no system is enabled, “OFF” is shown in each zone. To change the status of the driving aids, use
the
O1orO2button to navigate
the settings screen. For additional informa-
tion, see “How to use the vehicle information
display” (P. 2-44).
LSD4210LSD4211
Starting and driving5-91

WARNING
When the accelerator pedal is depressed
and you are approaching the vehicle ahead,
the ICC system will neither control the
brake nor warn the driver with the chime
and display. The driver must manually con-
trol the vehicle speed to maintain a safe
distance to the vehicle ahead. Failure to do
so could result in severe personal injury or
death.
NOTE:
When you accelerate by depressing the ac-
celerator pedal or decelerate by pushing the
SET- switch and the vehicle travels faster
than the speed set by the driver, the set
speed vehicle indicator will blink.
How to change the set distance to
the vehicle ahead
The distance to the vehicle ahead can be
selected at any time.
Each time the DISTANCE switch
OAis
pushed, the set distance will change to long,
middle, short and back to long again in that
sequence.
LSD4216
5-94Starting and driving

NOTE:
• When the Cruise screen is displayed on thevehicle information display, press the OK
button on the steering wheel to call up the
“Driving Aids” setting display.
• When enabling/disabling the system through the vehicle information display or
when pushing the Steering Assist switch,
the system retains the current settings
even if the engine is restarted.
How to cancel the ProPILOT Assist
system
To cancel the ProPILOT Assist system, use
one of the following methods:
• Push the CANCEL switch.
• Tap the brake pedal (except at a standstill).
• Push the ProPILOT Assist switch to turnthe system off. The ProPILOT Assist status
indicator will go out.
When the ProPILOT Assist system is canceled
while the vehicle is stopped, the electronic
parking brake is automatically activated.
WARNING
To prevent the vehicle from moving or roll-
ing unexpectedly, which could result in se-
rious personal injury or property damage,
before exiting the vehicle make sure to
push the ProPILOT Assist switch to turn
the system off, press the park button to
shift to the P (Park) position, and turn the
engine off.
INTELLIGENT CRUISE CONTROL
(ICC) (for vehicles with ProPILOT
Assist)
WARNING
Failure to follow the warnings and instruc-
tions for proper use of the ICC system
could result in serious injury or death.
• The ICC system is only an aid to assist the
driver and is not a collision warning or
avoidance device. It is recommended for
highway use only and it is not intended
for city driving. It is the driver’s respon-
sibility to stay alert, drive safely, and be
in control of the vehicle at all times. •
There are limitations to the ICC system
capability. The ICC system does not
function in all driving, traffic, weather,
and road conditions. It is the driver’s re-
sponsibility to stay alert, drive safely,
keep the vehicle in the traveling lane, and
be in control of the vehicle at all times.
• Always observe posted speed limits and
do not set the speed over them.
• The ICC system does not react to sta-
tionary and slow moving vehicles.
• Always drive carefully and attentively
when using the ICC system. Read and
understand the Owner’s Manual thor-
oughly before using the ICC system. To
avoid serious injury or death, do not rely
on the system to prevent accidents or to
control the vehicle’s speed in emergency
situations. Do not use the ICC system
except in appropriate road and traffic
conditions.
Starting and driving5-97
