To attach a child restraint tether strap:
For rearward facing infant seats secured in the
center seat position with the vehicle seat belts,
the rear center seat position has an armrest
tether that secures the arm rest in the upward
position. To access the center seat arm rest
tether first lower the arm rest. The tether is
located behind the armrest and hooked onto
the plastic seat backing.
Pull down on the tether to unhook it from the
plastic seat backing, then raise the armrest and
attach the tether hook to the strap located on
the front of the arm rest.For center seating position route the tether
strap over the seatback and headrest then
attach the hook to the tether anchor located on
the back of the outboard seats. For the out-
board seating positions, route the tether under
the head restraints, and attach the hook to the
top tether anchor located on the back of the
seat. To access the top tether strap anchor-
ages behind the rear seat, pull the carpeted
floor panel away from the seat back, this will
expose the top tether strap anchorages.
Center Seat Position Arm Rest Tether
Center Seat Position Arm Rest Tether AttachedPulling Down The Carpet Floor Panel To
Access Top Tether Strap
Top Tether Strap Anchorage(Located on Seatback)
54

NOTE:
•The head restraints should only be re-
moved by qualified technicians, for ser-
vice purposes only. If either of the head
restraints require removal, see your au-
thorized dealer.
• In the event of deployment of an Active
Head Restraint, refer to “Occupant
Restraints/Resetting Active Head Re-
straints (AHR)” in “Things to Know Be-
fore Starting Your Vehicle” for further in-
formation.
WARNING!
•Do not place items over the top of the
Active Head Restraint, such as coats, seat
covers or portable DVD players. These
items may interfere with the operation of
the Active Head Restraint in the event of a
collision and could result in serious injury or
death.
(Continued)
WARNING!(Continued)
• Active Head Restraints may be deployed if
they are struck by an object such as a
hand, foot or loose cargo. To avoid acci-
dental deployment of the Active Head Re-
straint ensure that all cargo is secured, as
loose cargo could contact the Active Head
Restraint during sudden stops. Failure to
follow this warning could cause personal
injury if the Active Head Restraint is de-
ployed.
Head Restraints — Rear Seats
The head restraints on the outboard seats are
not adjustable. They automatically fold forward
when the rear seat is folded to a load floor
position but do not return to their normal posi-
tion when the rear seat is raised. After returning
either seat to its upright position, raise the head
restraint until it locks in place. The outboard
headrests are not removable.
Active Head Restraint (Normal Position)
Active Head Restraint (Tilted)
99

Cavity Car-tridgeFuse Mini
Fuse Description
J01 40 Amp Green Air Suspension
J02 30 Amp Pink Power Liftgate
Module
J03 30 Amp Pink Trailer Tow
J04 25 Amp Natural Driver Door
Node
J05 25 Amp Natural Passenger Door
Node
J06 40 Amp Green Antilock Brakes
Pump/Stability
Control System
J07 30 Amp Pink Antilock Brakes
Valve/Stability
Control System
J08 40 Amp Green Power Seat
J09 30 Amp Pink E-Brake
J10 30 Amp Pink Headlamp Wash
Relay ContactCavity Car-
tridgeFuse Mini
Fuse Description
J11 30 Amp Pink Drive Train Con-
trol Module
J12 30 Amp Pink Rear Defroster
J13 60 Amp Yellow Main Ignition Off
Draw (IOD)
J14 20 Amp Blue Trailer Tow
Lamps/Park
Lamps
J15 40 Amp Green Front Cabin Fan/
Blower
J17 40 Amp Green Starter Motor
Solenoid
J18 20 Amp Blue Powertrain Con-
trol Module/
Powertrain Con-
trol Module
Transmission
RangeCavity Car-
tridgeFuse Mini
Fuse Description
J19 60 Amp Yellow Radiator Fan
Motor HI/
Radiator Fan
Motor Low
J20 30 Amp Pink Front Wiper
J21 20 Amp Blue Front/Rear
Washer Control
J22 25 Amp Natural Sunroof Module
M1 15 Amp
Blue Stop Lamps
M2 20 Amp
Yellow Electronic Limit
Slip Differential/
Air Suspension
M3 20 Amp
Yellow Liftgate/Headrest
M5 25 Amp
Natural 115V AC Power
Inverter
M6 20 Amp
Yellow Cigar Lighter
