width JEEP GRAND CHEROKEE 2012 Owner handbook (in English)

on the Navigation/Multimedia radio display
screen along with a caution note to “check
entire surroundings” across the top of the
screen. After five seconds this note will disap-
pear. The ParkViewcamera is located on the
rear of the vehicle above the rear License plate. When the vehicle is shifted out of REVERSE, the
rear camera mode is exited and the navigation
or audio screen appears again.
When displayed, static grid lines will illustrate
the width of the vehicle while a dashed center-
line will indicate the center of the vehicle toassist with aligning to a hitch/receiver. The
static grid lines will show separate zones that
will help indicate the distance to the rear of the
vehicle. The following table shows the approxi-
mate distances for each zone:
Zone
Distance to the rear of the vehicle
Red 0-1ft(0-30cm)
Yellow 1 ft-3ft(30cm-1m)
Green 3 ft or greater (1 m or greater)
WARNING!
Drivers must be careful when backing up even
when using the ParkViewRear Back Up
Camera. Always check carefully behind your
vehicle, and be sure to check for pedestrians,
animals, other vehicles, obstructions, or blind
spots before backing up. You are responsible
for the safety of your surroundings and must
continue to pay attention while backing up.
Failure to do so can result in serious injury or
death.CAUTION!
• To avoid vehicle damage, ParkView
should only be used as a parking aid. The
ParkView camera is unable to view every
obstacle or object in your drive path.
• To avoid vehicle damage, the vehicle must
be driven slowly when using ParkView to
be able to stop in time when an obstacle is
seen. It is recommended that the driver
look frequently over his/her shoulder when
using ParkView. NOTE:
If snow, ice, mud, or any foreign substance
builds up on the camera lens, clean the lens,
rinse with water, and dry with a soft cloth. Do
not cover the lens.
137

Frontal Area
The frontal area is the maximum height multi-
plied by the maximum width of the front of a
trailer.
Breakaway Cable AttachmentEuropean braking regulations for braked trail-
ers up to 7,700 lbs (3 500 kg), require trailers to
be fitted with either a secondary coupling or
breakaway cable.The recommended location for attaching the
normal trailer’s breakaway cable is in the
stamped slot located on the sidewall of the
hitch receiver.
With Attachment Point
•
For detachable tow bar pass the cable
through the attachment point and clip it back
onto itself or attach the clip directly to the
designated point.
Detachable Ball Clip Loop Method
268
