•Unstored Messages Until RUN
These messages deal primarily with the Re-
mote Start feature. This message type is dis-
played until the ignition is in the RUN state.
Examples of this message type are "Remote
Start Aborted - Door Ajar" and"Press Brake
Pedal and Push Button to Start".
• Five Second Unstored Messages
When the appropriate conditions occur, this
type of message takes control of the main
display area for five seconds and then returns to
the previous screen. Examples of this message
type are "Memory System Unavailable - Not in
Park" and"Automatic High Beams On".
The Reconfigurable Telltales section is divided
into the white telltales area on the right, amber
telltales in the middle, and red telltales on the left.
When the appropriate conditions exist, the
EVIC displays the following messages:
•Vehicle Not In Park
• Key Left Vehicle
• Key Not Detected •
Service Keyless System
• Service Tire Pressure System
• Service Park Assist System
• Park Assist System Blinded
• Park Assist Disabled
• Front Sensor Blinded
• Rear Sensor Blinded
• Keyfob Battery Low
• Liftglass Open
• Left Front Turn Signal Lamp Out
• Right Front Turn Signal Lamp Out
• Left Rear Turn Signal Lamp Out
• Right Rear Turn Signal Lamp Out
• Check Tire Pressure
• ESC System Off
• Service Blind Spot System
• Blind Spot Detection Unavailable
• Blind Spot System Off •
Blind Spot System Unavailable Sensor
Blocked
• Blind Spot System Unavailable Astronomy
Zone — When the Blind Spot Module senses
a tower on the same frequency that it is
interfering with, it will automatically turn the
Blind Spot System off.
• Normal Cruise Ready — When Adaptive
Cruise Control (ACC) system is turned off
and Normal (Fixed Speed) Cruise Control
mode is available. Refer to “Adaptive Cruise
Control (ACC)” in “Understanding The Fea-
tures Of Your Vehicle” (if equipped).
• Adaptive Cruise Off — When the Adaptive
Cruise Control (ACC) system is turned off.
Refer to “Adaptive Cruise Control (ACC)” in
“Understanding The Features Of Your Ve-
hicle” (if equipped).
• ACC Ready — When the ACC system is
activated. Refer to “Adaptive Cruise Control
(ACC)” in “Understanding The Features Of
Your Vehicle” (if equipped).
170

Cav-ity Car-
tridge Fuse Mini
Fuse Description
J04
25
Amp
NaturalDriver Door Node
J05
25
Amp
NaturalPassenger
Door Node
J06 40 Amp
Green Antilock
Brakes Pump/ Stability Con- trol System
J07 30 AmpPink Antilock
Brakes Valve/ Stability Con- trol System
J08 40 Amp
Green Power Seat
J09 30 AmpPink E-Brake
Cav-
ity Car-
tridge Fuse Mini
Fuse Description
J10 30 AmpPink Headlamp
Wash Relay Contact
J11 30 AmpPink Drive Train
Control Module
J12 30 AmpPink Rear Defroster
J13 60 Amp
Yellow Main Ignition
Off Draw (IOD)
J14 20 AmpBlue Trailer Tow
Lamps/Park Lamps
J15 40 Amp
Green Front Cabin
Fan/Blower
J17 40 Amp
Green Starter Motor
SolenoidCav-ity Car-
tridge Fuse Mini
Fuse Description
J18 20 AmpBlue Powertrain
Control
Module/
Powertrain Control
Module/
Transmission Range
J19 60 Amp
Yellow Radiator Fan
Motor HI/
Radiator Fan Motor Low
J20 30 AmpPink Front Wiper
J21 20 AmpBlue
Front/Rear
Washer Control
J2225
Amp
Natural Sunroof Module
332

Cav-ity Car-
tridge Fuse Mini
Fuse Description
M1 15
Amp Blue Stop Lamps
M2 20
Amp
Yellow Electronic
Limit Slip
Differential/Air Suspension
M3 20
Amp
Yellow Liftgate/
Headrest
M5
25
Amp
Natu- ral115V AC
Power Inverter
M6 20
Amp
Yellow Cigar Lighter
M7 20
Amp
Yellow Power Outlet
#2 (Switch- able)
Cav-ity Car-
tridge Fuse Mini
Fuse Description
M8 20
Amp
Yellow Front Heated
Seat & Steer- ing Wheel
M9 20
Amp
Yellow Rear Heated
Seats
M10 15
Amp Blue Video/
Universal
Garage Door Opener
M11 10
Amp Red Heating, Venti-
lation & Air
Conditioning
(Climate Con- trol System)
M12 30
Amp
Green Radio/Amplifier
M13 20
Amp
Yellow Instrument
ClusterCav-ity Car-
tridge Fuse Mini
Fuse Description
M14 20
Amp
Yellow Back Up
Camera – If Equipped
M15 20
Amp
Yellow Power Seat
Module(s)/ Adaptive
Cruise Control/ Audio
Telematics/ Daytime
Running Lights Relay/Air
Suspension Module/
Instrument Cluster
M16 10
Amp Red Occupant
Restraint
Controller
M18 15
Amp Blue Stop Lamp
333

Cav-ity Car-
tridge Fuse Mini
Fuse Description
M19
25
Amp
Natu- ralAutomatic
Shutdown 1 and 2
M20 15
Amp Blue Instrument
Cluster
M21 20
Amp
Yellow Automatic
Shutdown 3
M22 10
Amp Red Horns (Low/
High) – Right
M23 10
Amp Red Horns (Low/
High) – Left
M24 25
Amp
Natu- ral Rear Wiper
Cav-
ity Car-
tridge Fuse Mini
Fuse Description
M25 20
Amp
Yellow Fuel Pump
Motor Output/ Diesel Lift
Pump (Export Only)
M26 10
Amp Red Driver Door
Switch Bank
M27 10
Amp Red Ignition Switch/
Wireless Con- trol Module/
Keyless Entry Module
M28 15
Amp Blue Powertrain
Controller/
Transmission Controller
M29 10
Amp Red Tire Pressure
Monitor – IfEquippedCav- ity Car-
tridge Fuse Mini
Fuse Description
M30 15
Amp Blue J1962 Diag
Connector
M31 20
Amp
Yellow Backup Lamps
M32 10
Amp Red Occupant
Restraint
Controller
M33 10
Amp Red Powertrain
Controller/
Transmission Controller
M34 10
Amp Red
Park Assist
Module/Climate Control System Module/Infra
Red Sensor/ CompassModule
334

Cav-ity Car-
tridge Fuse Mini
Fuse Description
M35 15
Amp Blue Left Rear
Parklamps
M36 20
Amp
Yellow Power Outlet
M37 10
Amp Red Antilock
Brakes/Stability
Control System Module
M38 25
Amp
Natu- ral All Door Lock
&UnlockCAUTION!
•When installing the totally integrated
power module cover, it is important to
ensure the cover is properly positioned
and fully latched. Failure to do so may
allow water to get into the totally integrated
power module and possibly result in a
electrical system failure.
• When replacing a blown fuse, it is impor-
tant to use only a fuse having the correct
amperage rating. The use of a fuse with a
rating other than indicated may result in a
dangerous electrical system overload. If a
properly rated fuse continues to blow, it
indicates a problem in the circuit that must
be corrected.VEHICLE STORAGE
If you are leaving your vehicle dormant for more
than 21 days you may want to take steps to
protect your battery. You may:
• Remove fuse #J13 in the Totally Integrated
Power Module (TIPM) labeled Main Ignition-
Off Draw (IOD).
• Or, disconnect the negative cable from the
battery.
• Anytime you store your vehicle, or keep it out
of service (i.e. vacation) for two weeks or
more, run the air conditioning system at idle
for about five minutes in the fresh air and
high blower setting. This will ensure ad-
equate system lubrication to minimize the
possibility of compressor damage when the
system is started again.
335

Gas Cap (Fuel Filler Cap) . . . .276, 278, 312
Gasoline, Clean Air..............274
Gasoline (Fuel) ................273
Conserving ................178
Gauges Coolant Temperature ..........167
Fuel ....................167
Speedometer ..............166
Tachometer ...............162
Gear Ranges ..............227, 231
Gear Select Lever Override .........304
General Information ......16, 21, 130, 272
Glass Cleaning ................331
Gross Axle Weight Rating ..........278
Gross Vehicle Weight Rating ........278
Hands-Free Phone (Uconnect®) .......72
Hazard Warning Flasher ...........294
Headlights ...................336
Bulb Replacement ............337
Cleaning .................330
On With Wipers .............107
Passing ..................112
Replacing ................337
Heated Mirrors ..............72, 154
High Beam Indicator .............163 Hill Descent Control
.............257
Hill Descent Control Indicator ........163
Hill Start Assist ................256
Holder, Cup ................. .149
Hood Release ................105
Ignition .....................13
Key ..................12, 13
Ignition Key Removal .............13
Illuminated Entry ................18
Immobilizer (Sentry Key) ...........15
Infant Restraint ..............50, 53
Information Center, Vehicle .........168
Inside Rearview Mirror ............70
Instrument
Cluster..............162
Instrument Panel and Controls .......160
Instrument Panel Lens Cleaning ......331
Integrated Power Module (Fuses) ......331
Interior Appearance Care ..........330
Intermittent Wipers (Delay Wipers) .....113
Introduction ...................4
Jacking Instructions .............296
Jack Location ................ .295
Jack Operation ................296
Jump Starting ................ .300Key-In Reminder
................14
Keyless Enter-N-Go ...........23, 221
Keyless Entry System .............19
Keyless Go ................12, 181
Key, Programming ...............16
Key, Replacement ...............15
Keys ......................12
Key, Sentry (Immobilizer) ...........15
Lane Change Assist .............112
Lap/Shoulder Belts ..............33
Latches .....................61
LATCH (Lower Anchors and Tether for CHildren) ................54, 55
Lead Free Gasoline .............273
Leaks, Fluid ..................61
Life of Tires ................. .264
Liftgate .....................28
Liftgate Flipper Glass .............28
Liftgate Window Wiper/Washer .......154
Light Bulbs ...................61
Lights ...................61, 106
Airbag ............45, 49, 60, 162
Anti-Lock .................166
Automatic Headlights ..........107
Back-Up .................338
