sensor JEEP LIBERTY 2002 KJ / 1.G Workshop Manual

HEADLAMP LEVELING SWITCH (BUILT-UP-EXPORT)-4WAY
CAV CIRCUIT FUNCTION
1 L13 18BR/YL HEADLAMP ADJUST SIGNAL
2 L78 18DG/YL FUSED PARK LAMP RELAY OUTPUT
3 Z12 18BK/TN GROUND
4- -
HEATED SEAT MODULE (HIGHLINE) - GREEN 14 WAY
CAV CIRCUIT FUNCTION
1 P133 20TN/DG LEFT SEAT HEATER SWITCH MUX
2 P86 20PK/BK HEATED SEAT TEMPERATURE SENSOR SIGNAL
3 F98 16RD/WT PASSENGER HEATED SEAT FEED
4 A3 16RD/WT FUSED B(+)
5 F99 16RD/YL DRIVER HEATED SEAT FEED
6 A3 16RD/WT FUSED B(+)
7 P142 20TN/DB PASSENGER HEATED SEAT TEMPERATURE SENSOR
GROUND
8 P141 20TN/LB DRIVER HEATED SEAT TEMPERATURE SENSOR
GROUND
9 P134 20TN/LG RIGHT SEAT HEATER SWITCH MUX
10 P138 20VT/LG RIGHT SEAT LOW HEAT LED DRIVER
11 P140 20VT/BK RIGHT SEAT HIGH HEAT LED DRIVER
12 P137 20VT/DG LEFT SEAT LOW HEAT LED DRIVER
13 Z238 16BK/WT GROUND
14 P139 20VT/WT LEFT SEAT HIGH HEAT LED DRIVER
HIGH NOTE HORN - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 X2 18DG/RD HORN RELAY OUTPUT
2 Z141 18BK GROUND
HOOD AJAR SWITCH (EXCEPT BASE)-2WAY
CAV CIRCUIT FUNCTION
1 G70 18BR/TN HOOD AJAR SWITCH SENSE
2 Z142 18BK/WT GROUND
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-63

IDLE AIR CONTROL MOTOR - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 K59 18VT/BK IDLE AIR CONTROL MOTOR NO. 4 DRIVER
2 K40 18BR/WT IDLE AIR CONTROL MOTOR NO. 1 DRIVER
3 K60 18YL/BK IDLE AIR CONTROL MOTOR NO. 2 DRIVER
4 K39 18GY/RD IDLE AIR CONTROL MOTOR NO. 3 DRIVER
IGNITION SWITCH - BLACK 10 WAY
CAV CIRCUIT FUNCTION
1 A1 12RD FUSED (+)
2 A21 12RD/DB IGNITION SWITCH OUTPUT (RUN-START)
3 F81 12TN IGNITION SWITCH OUTPUT (RUN-ACC)
4 A25 12DB FUSED B(+)
5 G26 20LB KEY-IN IGNITION SWITCH SENSE
6 A41 12YL IGNITION SWITCH OUTPUT (START)
7 A31 12BK/WT IGNITION SWITCH OUTPUT (RUN-ACC)
8 A22 12BK/OR IGNITION SWITCH OUTPUT (RUN)
9 A2 12PK/BK FUSED B (+)
10 Z232 16BK/LB GROUND
INPUT SPEED SENSOR (3.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 T52 18RD/BK INPUT SPEED SENSOR SIGNAL
2 T13 18DB/BK SPEED SENSOR GROUND
INSTRUMENT CLUSTER - BLACK 20 WAY
CAV CIRCUIT FUNCTION
1 Z105 20BK/LG GROUND
2- -
3 Y98 20GY/DB INSTRUMENT CLUSTER WAKE UP SIGNAL
4- -
5 G18 20PK/BK LOW COOLANT FLUID LEVEL SENSE
6 L63 20DG/RD LEFT TURN SIGNAL
7 G9 20GY/BK PARK BRAKE SWITCH SENSE
8 G69 20BK/OR VTSS INDICATOR DRIVER
9- -
10 M1 20PK FUSED B(+)
11 L78 20DG/YL FUSED PARK LAMP RELAY OUTPUT
12 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
13 - -
14 D25 20YL/VT/RD PCI BUS
15 - -
8Wa - 80 - 64 8W-80 CONNECTOR PIN-OUTSKJ

INSTRUMENT CLUSTER - BLACK 20 WAY
CAV CIRCUIT FUNCTION
16 L62 20BR/RD RIGHT TURN SIGNAL
17 G11 20WT/BK RED BRAKE WARNING INDICATOR DRIVER
18 G29 20BK/TN LOW WASHER FLUID SENSE
19 F87 20TN/BK FUSED IGNITION SWITCH OUTPUT (RUN-START)
20 - -
INTAKE AIR TEMPERATURE SENSOR (GAS) - GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 K4 18BK/LB SENSOR GROUND
2 K21 18BK/RD INTAKE AIR TEMPERATURE SENSOR SIGNAL
INTRUSION SENSOR (BUILT-UP-EXPORT) - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 Z2 20BK/LG GROUND
2- -
3 X75 20DG SIREN SIGNAL CONTROL
4- -
5 D25 20YL/VT PCI BUS
6 M1 20PK FUSED B(+)
JUNCTION BLOCK BODY CONTROL MODULE-JB - 26 WAY
CAV CIRCUIT FUNCTION
1 X3 (PREMIUM) HORN RELAY CONTROL
2 P334 DOOR UNLOCK RELAY CONTROL
3 L308 PARK LAMP RELAY CONTROL
4 L96 (PREMIUM) REAR FOG LAMP RELAY CONTROL
5 P109 (EXCEPT BASE) DRIVER DOOR UNLOCK RELAY CONTROL
6 C80 REAR WINDOW DEFOGGER RELAY CONTROL
7- -
8 Z300 GROUND
9 F35 FUSED B(+)
10 L309 HIGH BEAM RELAY CONTROL
11 P31 TAILGATE UNLOCK DRIVER
12 P37 DOOR LOCK SWITCH GROUND
13 L94 LOW BEAM RELAY CONTROL
14 F89 FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
15 M1 FUSED B(+)
16 F87 FUSED IGNITION SWITCH OUTPUT (RUN-START)
17 L26 (EXCEPT BASE) FRONT FOG LAMP RELAY CONTROL
18 P333 DOOR LOCK RELAY CONTROL
19 V16 FRONT WIPER HIGH/LOW RELAY CONTROL
20 V55 FRONT WIPER PARK SWITCH SENSE
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-65

KNOCK SENSOR (3.7L) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 K4 18BK/LB SENSOR GROUND
2 K42 18DB/LB KNOCK SENSOR NO. 1 SIGNAL
3 K4 18BK/LB SENSOR GROUND
4 K142 18GY/BK KNOCK SENSOR NO. 2 SIGNAL
LEAK DETECTION PUMP - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1- -
2 K125 18WT/DB GENERATOR SOURCE
3 K106 18WT/DG LEAK DETECTION PUMP SOLENOID CONTROL
4 K107 18OR LEAK DETECTION PUMP SWITCH SENSE
LEFT COURTESY LAMP - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 M1 20PK FUSED B(+)
2 M2 20YL COURTESY LAMP DRIVER
LEFT CURTAIN AIRBAG - YELLOW 2 WAY
CAV CIRCUIT FUNCTION
1 R77 18YL/RD LEFT CURTAIN SQUIB LINE 2
2 R75 18YL/BK LEFT CURTAIN SQUIB LINE 1
LEFT CYLINDER LOCK SWITCH (EXCEPT BASE) - LT. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 P37 18LG DOOR LOCK SWITCH GROUND
2 G73 18LG/OR (LHD) LEFT CYLINDER LOCK SWITCH MUX
2 G72 18DG/OR (RHD) LEFT CYLINDER LOCK SWITCH MUX
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-69

LEFT FRONT DOOR SPEAKER (PREMIUM) - BLACK 10 WAY
CAV CIRCUIT FUNCTION
1 X53 18DG LEFT FRONT SPEAKER (+)
2 X55 18BR/RD LEFT FRONT SPEAKER (-)
3 Z9 16BK GROUND
4 X81 18YL/BK AMPLIFIED HIGH LEFT FRONT SPEAKER (-)
5 X91 18WT/BK AMPLIFIED LOW LEFT REAR SPEAKER (-)
6 X57 18BR/LB LEFT REAR SPEAKER (-)
7 X51 18BR/YL LEFT REAR SPEAKER (+)
8 X13 16BK/RD RADIO CHOKE OUTPUT
9 X83 18YL/RD AMPLIFIED HIGH LEFT FRONT SPEAKER (+)
10 X93 18WT/RD AMPLIFIED LOW LEFT REAR SPEAKER (+)
LEFT FRONT IMPACT SENSOR - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3 R47 18DB/LB LEFT FRONT IMPACT SENSOR GROUND
4 R49 18LB LEFT FRONT IMPACT SENSOR SIGNAL
LEFT FRONT PARK/TURN SIGNAL LAMP - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 L63 18DG/RD LEFT TURN SIGNAL
2 L77 18BK/YL (EXCEPT BUILT-UP-EX-
PORT)PARK LAMP RELAY OUTPUT
3 Z141 18BK GROUND
LEFT FRONT POWER WINDOW MOTOR (MIDLINE/HIGHLINE) - LT. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 Q21 16WT LEFT FRONT WINDOW DRIVER DOWN
2 Q11 16LB LEFT FRONT WINDOW DRIVER UP
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-71

LEFT FRONT WHEEL SPEED SENSOR (ABS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 B9 18RD LEFT FRONT WHEEL SPEED SENSOR 12 VOLT SUP-
PLY
2 B8 18RD/DB LEFT FRONT WHEEL SPEED SENSOR SIGNAL
LEFT HEADLAMP (BUILT-UP-EXPORT)-3WAY
CAV CIRCUIT FUNCTION
1 L33 18LG/BR FUSED LEFT HIGH BEAM OUTPUT
2 L43 18VT FUSED LEFT LOW BEAM OUTPUT
3 Z141 18BK GROUND
LEFT HEADLAMP (EXCEPT BUILT-UP-EXPORT) - BLUE 3 WAY
CAV CIRCUIT FUNCTION
A L43 18VT FUSED LEFT LOW BEAM OUTPUT
B Z141 18BK GROUND
C L33 18LG/BR FUSED LEFT HIGH BEAM OUTPUT
LEFT HEATED SEAT ASSEMBLY (HIGHLINE) - LT. GRAY 4 WAY
CAV CIRCUIT FUNCTION
1 F99 16RD/YL DRIVER HEATED SEAT FEED
2 Z238 16BK/WT GROUND
3 P86 20PK/BK HEATED SEAT TEMPERATURE SENSOR SIGNAL
4 P141 20TN/LB DRIVER HEATED SEAT TEMPERATURE SENSOR
GROUND
LEFT HEATED SEAT SWITCH (HIGHLINE) - BLACK 8 WAY
CAV CIRCUIT FUNCTION
1 V23 20BR/PK FUSED IGNITION SWITCH OUTPUT (RUN)
2 P139 20VT/WT LEFT SEAT HIGH HEAT LED DRIVER
3 P133 20TN/DG LEFT SEAT HEATER SWITCH MUX
4 P137 20VT/DG LEFT SEAT LOW HEAT LED DRIVER
5 Z238 20BK/WT GROUND
6- -
7- -
8- -
8Wa - 80 - 72 8W-80 CONNECTOR PIN-OUTSKJ

LEFT SIDE MARKER LAMP (EXCEPT BUILT-UP-EXPORT) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 L77 18BK/YL FUSED PARK LAMP RELAY OUTPUT
2 L63 18DG/RD LEFT TURN SIGNAL
LEFT SIDE REPEATER LAMP (BUILT-UP-EXPORT) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 L63 18DG/RD LEFT TURN SIGNAL
2 Z141 18BK GROUND
LEFT SPEED CONTROL SWITCH (EXCEPT BASE) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1- -
2 K4 20BK/LB SENSOR GROUND
3 V37 20RD/LG SPEED CONTROL SWITCH SIGNAL
4- -
LEFT TAIL/STOP LAMP - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 L38 18BR/WT (BUILT-UP-EXPORT) REAR FOG LAMP RELAY OUTPUT
2 L77 18BK/YL FUSED PARK LAMP RELAY OUTPUT
3 L50 18WT/TN BRAKE LAMP SWITCH OUTPUT
4 L10 18BR/LG BACK-UP LAMP FEED
5 Z151 18BK/WT GROUND
6 L63 18DG/RD LEFT TURN SIGNAL
LEFT VISOR/VANITY LAMP (EXCEPT BASE) - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 M1 20PK FUSED B(+)
2 M20 20BR COURTESY LAMP LOAD SHED
8Wa - 80 - 76 8W-80 CONNECTOR PIN-OUTSKJ

LICENSE LAMP (BUILT-UP-EXPORT)-2WAY
CAV CIRCUIT FUNCTION
1 L77 18BK/YL FUSED LEFT INBOARD TAIL LAMP
2 Z235 18BK GROUND
LICENSE LAMP (EXCEPT BUILT-UP-EXPORT) - LT. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 L77 18BR/YL FUSED PARK LAMP RELAY OUTPUT
2 Z151 18BK/WT GROUND
LINE PRESSURE SENSOR (3.7L) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 Z112 18BK GROUND
2 T39 18GY/LB 5 VOLT SUPPLY
3 T38 18VT/TN LINE PRESSURE SENSOR SIGNAL
4- -
LOW NOTE HORN - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 X2 18DG/RD HORN RELAY OUTPUT
2 Z141 18BK GROUND
MANIFOLD ABSOLUTE PRESSURE SENSOR - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K1 18DG/RD MANIFOLD ABOLUTE PRESSURE SENSOR SIGNAL
2 K4 18BK/LB SENSOR GROUND
3 K7 18OR 5 VOLT SUPPLY
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-77

MULTI-FUNCTION SWITCH C1 - GRAY 10 WAY
CAV CIRCUIT FUNCTION
1 E21 20OR/RD PANEL LAMPS DIMMER SWITCH MUX
2 L27 20WT/TN (EXCEPT BASE) FRONT FOG LAMP SWITCH SENSE
3- -
4 L80 20WT/DG HEADLAMP SWITCH RETURN
5 L307 20LG/OR HEADLAMP SWITCH MUX
6 L305 20LB/WT LEFT TURN SWITCH SENSE
7 L309 20LG/WT HIGH BEAM RELAY CONTROL
8 Z12 18BK/TN GROUND
9 L324 20WT/LG HIGH BEAM SWITCH SENSE
10 L302 20LB/YL RIGHT TURN SWITCH SENSE
MULTI-FUNCTION SWITCH C2 - GRAY 8 WAY
CAV CIRCUIT FUNCTION
1 V21 20DB/RD REAR WIPER ON DRIVER
2 V22 20BR/YL REAR WIPER INTERMITTENT DRIVER
3 V20 18BK/WT WASHER MOTOR SENSE
4 V52 20DG/RD FRONT WIPER SWITCH MUX
5 F88 20BR/RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
6- -
7 V10 18BR WASHER PUMP DRIVER
8- -
OUTPUT SPEED SENSOR (3.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 T14 18LG/WT OUTPUT SPEED SENSOR SIGNAL
2 T13 18DB/BK SPEED SENSOR GROUND
OVERHEAD MAP/READING LAMP (EXCEPT BASE) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 M1 20PK FUSED B(+)
2 M2 20YL REAR COURTESY LAMP CONTROL
3 M20 20BR COURTESY LAMPS LOAD SHEED
8Wa - 80 - 78 8W-80 CONNECTOR PIN-OUTSKJ

OXYGEN SENSOR 1/1 UPSTREAM - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 A71 18DG/RD FUSED AUTO SHUT DOWN RELAY OUTPUT
2 K99 18BR/OR OXYGEN SENSOR 1/1 HEATER CONTROL
3 K4 18BK/LB SENSOR GROUND
4 K41 18BK/DG OXYGEN SENSOR 1/1 SIGNAL
OXYGEN SENSOR 1/2 DOWNSTREAM - NATURAL 4 WAY
CAV CIRCUIT FUNCTION
1 A71 18DG/RD (2.4L) FUSED AUTO SHUT DOWN RELAY OUTPUT
1 F18 18LG/BK (3.7L) OXYGEN SENSOR DOWNSTREAM RELAY
2 K299 18BR/WT (2.4L) OXYGEN SENSOR 1/2 HEATER CONTROL
2 Z186 18BK/OR (3.7L) GROUND
3 K4 18BK/LB SENSOR GROUND
4 K141 18TN/WT OXYGEN SENSOR 1/2 SIGNAL
OXYGEN SENSOR 2/1 UPSTREAM (3.7L) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 A71 18DG/RD FUSED AUTO SHUT DOWN RELAY OUTPUT
2 K299 18BR/WT OXYGEN SENSOR 2/1 HEATER CONTROL
3 K4 18BK/LB SENSOR GROUND
4 K241 18LG/RD OXYGEN SENSOR 2/1 SIGNAL
OXYGEN SENSOR 2/2 DOWNSTREAM (3.7L) - NATURAL 4 WAY
CAV CIRCUIT FUNCTION
1 F18 18LG/BK OXYGEN SENSOR DOWNSTREAM RELAY OUTPUT
2 Z186 18BK/OR GROUND
3 K4 18BK/LB SENSOR GROUND
4 K341 18TN/WT OXYGEN SENSOR 2/2 SIGNAL
PASSENGER AIRBAG - YELLOW 4 WAY
CAV CIRCUIT FUNCTION
1 R62 18OR/YL PASSENGER SQUIB 2 LINE 2
2 R64 18TN/YL PASSENGER SQUIB 2 LINE 1
3 R42 18BK/YL PASSENGER SQUIB 1 LINE 1
4 R44 18DG/YL PASSENGER SQUIB 1 LINE 2
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-79
