8W-30 FUEL/IGNITION SYSTEM
Component Page
A/C Compressor Clutch.............. 8Wa-30-34
A/C Compressor Clutch Relay..... 8Wa-30-34, 2, 3
A/C High Pressure Switch............ 8Wa-30-29
A/C Low Pressure Switch.......... 8Wa-30-8, 29
A/C Pressure Transducer....... 8Wa-30-11, 23, 12
Accelerator Pedal Position Sensor...... 8Wa-30-27
Auto Shut Down Relay . . 8Wa-30-13, 14, 15, 24, 28,
31, 16, 17, 2
Battery Temperature Sensor........ 8Wa-30-30, 7
Blower Motor Relay................. 8Wa-30-31
Body Control Module.............. 8Wa-30-8, 33
Boost Pressure Sensor............ 8Wa-30-26, 28
Brake Lamp Switch............ 8Wa-30-8, 32, 33
Cabin Heater...................... 8Wa-30-34
Cabin Heater Relay................. 8Wa-30-34
Camshaft Position Sensor....... 8Wa-30-10, 9, 28
Capacitor...................... 8Wa-30-19, 17
Clockspring..................... 8Wa-30-33, 7
Clutch Switch Override Relay.... 8Wa-30-13, 8, 32
Coil On Plug No. 1................. 8Wa-30-19
Coil On Plug No. 2................. 8Wa-30-20
Coil On Plug No. 3................. 8Wa-30-19
Coil On Plug No. 4................. 8Wa-30-20
Coil On Plug No. 5................. 8Wa-30-19
Coil On Plug No. 6................. 8Wa-30-20
Coil Rail......................... 8Wa-30-17
Controller Antilock Brake............ 8Wa-30-33
Crankshaft Position Sensor...... 8Wa-30-10, 9, 27
Data Link Connector.............. 8Wa-30-25, 6
Diagnostic Junction Port........... 8Wa-30-25, 6
EGR Solenoid..................... 8Wa-30-30
Engine Control Module . . 8Wa-30-24, 25, 26, 27, 28,
29, 30, 31, 32, 33, 34, 35, 36
Engine Coolant Temperature Sensor . 8Wa-30-11, 28,
12
Engine Oil Pressure Sensor..... 8Wa-30-11, 28, 12
Evap/Purge Solenoid................. 8Wa-30-2
Fuel Heater....................... 8Wa-30-31
Fuel Heater Relay.................. 8Wa-30-31
Fuel Injector No. 1............... 8Wa-30-18, 36
Fuel Injector No. 2............... 8Wa-30-18, 36
Fuel Injector No. 3............... 8Wa-30-18, 36
Fuel Injector No. 4............... 8Wa-30-18, 36
Fuel Injector No. 5................. 8Wa-30-18
Fuel Injector No. 6................. 8Wa-30-18
Fuel Pressure Sensor............... 8Wa-30-36
Fuel Pressure Solenoid.............. 8Wa-30-31
Fuel Pump Module............. 8Wa-30-30, 4, 5
Fuel Pump Relay.............. 8Wa-30-4, 2, 3, 5
Fuse 2........................... 8Wa-30-23
Fuse 6................... 8Wa-30-24, 28, 31, 2Component Page
Fuse 10.......................... 8Wa-30-35
Fuse 11.......................... 8Wa-30-35
Fuse 12....................... 8Wa-30-31, 33
Fuse 15...................... 8Wa-30-25, 2, 3
Fuse 16...... 8Wa-30-13, 14, 15, 24, 30, 34, 35, 16
Fuse 21.......................... 8Wa-30-34
Fuse 24...................... 8Wa-30-31, 2, 3
Fuse 26.................. 8Wa-30-18, 24, 17, 2
Fuse 28.......................... 8Wa-30-13
G100.................... 8Wa-30-19, 27, 17, 3
G101............................ 8Wa-30-23
G103................. 8Wa-30-15, 23, 31, 34, 16
G104............................ 8Wa-30-27
G111 ............................ 8Wa-30-31
G112 .......................... 8Wa-30-8, 23
G320........................... 8Wa-30-4, 5
Generator.................. 8Wa-30-24, 4, 3, 5
Glow Plug Assembly................ 8Wa-30-35
Glow Plug Relay No. 1.............. 8Wa-30-35
Glow Plug Relay No. 2.............. 8Wa-30-35
Idle Air Control Motor............ 8Wa-30-21, 22
Ignition Switch.................... 8Wa-30-32
Intake Air Temperature Sensor..... 8Wa-30-11, 12
Junction Block........... 8Wa-30-25, 31, 33, 2, 3
Knock Sensor...................... 8Wa-30-8
Leak Detection Pump.............. 8Wa-30-4, 5
Left Speed Control Switch.......... 8Wa-30-33, 7
Manifold Absolute Pressure Sensor . . 8Wa-30-11, 12
Oxygen Sensor 1/1 Upstream...... 8Wa-30-14, 15
Oxygen Sensor 1/2 Downstream . 8Wa-30-13, 14, 15
Oxygen Sensor 2/1 Upstream......... 8Wa-30-16
Oxygen Sensor 2/2 Downstream.... 8Wa-30-13, 16
Oxygen Sensor Downstream Relay . . 8Wa-30-13, 15,
16
Power Distribution Center . . 8Wa-30-13, 14, 15, 23,
24, 28, 30, 31, 34, 35, 16, 17, 2, 3
Power Steering Pressure Switch....... 8Wa-30-23
Powertrain Control Module . . . 8Wa-30-10, 13, 20, 8,
11, 14, 15, 18, 19, 21, 9, 23, 4, 12, 16, 17, 2, 22, 3,
6, 7, 5
Radiator Fan Motor................. 8Wa-30-23
Radiator Fan Relay................. 8Wa-30-23
Right Speed Control Switch......... 8Wa-30-33, 7
Shifter Assembly................. 8Wa-30-8, 32
Speed Control Servo................. 8Wa-30-8
Starter Motor Relay................ 8Wa-30-13
Throttle Position Sensor.......... 8Wa-30-21, 22
Transfer Case Position Sensor.... 8Wa-30-9, 23, 32
Transmission Control Module . . 8Wa-30-10, 8, 22, 6
Transmission Solenoid/Trs Assembly.... 8Wa-30-10
Water In Fuel Sensor............... 8Wa-30-29
KJ8W-30 FUEL/IGNITION SYSTEM8Wa-30-1

8W-31 TRANSMISSION CONTROL SYSTEM
Component Page
A/C Compressor Clutch Relay.......... 8Wa-31-3
Auto Shut Down Relay............... 8Wa-31-3
Back-Up Lamp Switch............... 8Wa-31-4
Brake Lamp Switch................. 8Wa-31-5
Crankshaft Position Sensor............ 8Wa-31-6
Data Link Connector................. 8Wa-31-6
Diagnostic Junction Port.............. 8Wa-31-3
Engine Control Module............... 8Wa-31-6
Fuel Pump Relay................... 8Wa-31-3
Fuse 5............................ 8Wa-31-2
Fuse 15........................... 8Wa-31-3
Fuse 28........................... 8Wa-31-3
Fuse 38........................... 8Wa-31-5
Fuse 39........................... 8Wa-31-4
G102........................... 8Wa-31-7, 9
G111 ............................. 8Wa-31-2
G301............................. 8Wa-31-5
Input Speed Sensor.................. 8Wa-31-9Component Page
Instrument Cluster.................. 8Wa-31-5
Junction Block.................. 8Wa-31-3, 4, 5
Left Tail/Stop Lamp................. 8Wa-31-4
Line Pressure Sensor................ 8Wa-31-9
Output Speed Sensor................ 8Wa-31-9
Power Distribution Center.......... 8Wa-31-2, 3
Powertrain Control Module........ 8Wa-31-3, 5, 6
Right Tail/Stop Lamp................ 8Wa-31-4
Shifter Assembly.................... 8Wa-31-5
Starter Motor Relay................. 8Wa-31-8
Throttle Position Sensor.............. 8Wa-31-5
Trailer Tow Connector................ 8Wa-31-4
Transfer Case Position Sensor.......... 8Wa-31-5
Transmission Control Module . . 8Wa-31-2, 3, 5, 6, 7,
8, 9
Transmission Control Relay....... 8Wa-31-2, 7, 8
Transmission Solenoid/Trs Assembly . . 8Wa-31-2, 4,
7, 8, 9
KJ8W-31 TRANSMISSION CONTROL SYSTEM8Wa-31-1

8W-35 ANTILOCK BRAKES
Component Page
Body Control Module................ 8Wa-35-3
Brake Lamp Switch................. 8Wa-35-3
Brake Pressure Switch............... 8Wa-35-2
Controller Antilock Brake......... 8Wa-35-2, 3, 4
Data Link Connector................. 8Wa-35-2
Diagnostic Junction Port.............. 8Wa-35-2
Fuse 4............................ 8Wa-35-2
Fuse 12........................... 8Wa-35-3
Fuse 25........................... 8Wa-35-2
Fuse 38........................... 8Wa-35-2Component Page
G110 ............................. 8Wa-35-2
Junction Block.................... 8Wa-35-2, 3
Left Front Wheel Speed Sensor......... 8Wa-35-4
Power Distribution Center............ 8Wa-35-2
Powertrain Control Module............ 8Wa-35-3
Rear Wheel Speed Sensor............. 8Wa-35-4
Right Front Wheel Speed Sensor....... 8Wa-35-4
Shifter Assembly.................. 8Wa-35-2, 3
Speed Control Servo................. 8Wa-35-3
KJ8W-35 ANTILOCK BRAKES8Wa-35-1

Component Page
C316 (Built-Up-Export).............. 8Wa-80-46
C316 (Built-Up-Export).............. 8Wa-80-46
C317 (Except Built-Up-Export)........ 8Wa-80-47
C317 (Except Built-Up-Export)........ 8Wa-80-47
Cabin Heater (Diesel)............... 8Wa-80-47
Camshaft Position Sensor (2.4L)....... 8Wa-80-47
Camshaft Position Sensor (3.7L)....... 8Wa-80-47
Camshaft Position Sensor (Diesel)...... 8Wa-80-48
Capacitor......................... 8Wa-80-48
Cargo Lamp (Except Base)........... 8Wa-80-48
CD Changer...................... 8Wa-80-48
Center High Mounted Stop Lamp...... 8Wa-80-49
Cigar Lighter..................... 8Wa-80-49
Clockspring C1.................... 8Wa-80-49
Clockspring C2.................... 8Wa-80-49
Clockspring C3.................... 8Wa-80-49
Clutch Interlock Switch (M/T)......... 8Wa-80-50
Coil On Plug No. 1 (3.7L)............ 8Wa-80-50
Coil On Plug No. 2 (3.7L)............ 8Wa-80-50
Coil On Plug No. 3 (3.7L)............ 8Wa-80-50
Coil On Plug No. 4 (3.7L)............ 8Wa-80-50
Coil On Plug No. 5 (3.7L)............ 8Wa-80-51
Coil On Plug No. 6 (3.7L)............ 8Wa-80-51
Coil Rail (2.4L).................... 8Wa-80-51
Compass Mini-Trip Computer
(Premium)...................... 8Wa-80-51
Controller Antilock Brake............ 8Wa-80-52
Crankshaft Position Sensor (2.4L)...... 8Wa-80-52
Crankshaft Position Sensor (3.7L)...... 8Wa-80-52
Crankshaft Position Sensor (Diesel).... 8Wa-80-53
Data Link Connector................ 8Wa-80-53
Diagnostic Junction Port............. 8Wa-80-53
Dome Lamp (Base)................. 8Wa-80-54
Driver Airbag Squib 1............... 8Wa-80-54
Driver Airbag Squib 2............... 8Wa-80-54
Driver Seat Belt Switch............. 8Wa-80-54
Driver Seat Belt Tensioner........... 8Wa-80-54
EGR Solenoid (Diesel)............... 8Wa-80-55
Engine Control Module C1........... 8Wa-80-55
Engine Control Module C2........... 8Wa-80-56
Engine Coolant Level Sensor (Diesel) . . . 8Wa-80-57
Engine Coolant Temp Sensor (Diesel) . . . 8Wa-80-57
Engine Coolant Temperature
Sensor (Gas).................... 8Wa-80-58
Engine Oil Pressure Sensor........... 8Wa-80-58
Evap/Purge Solenoid................ 8Wa-80-58
Flip-Up Glass Release Motor.......... 8Wa-80-58
Flip-Up Glass Release Switch......... 8Wa-80-58
Front Wiper Motor................. 8Wa-80-59
Fuel Heater (Diesel)................ 8Wa-80-59
Fuel Injector No. 1 (Diesel)........... 8Wa-80-59
Fuel Injector No. 1 (Gas)............. 8Wa-80-59
Fuel Injector No. 2 (Diesel)........... 8Wa-80-59
Fuel Injector No. 2 (Gas)............. 8Wa-80-60Component Page
Fuel Injector No. 3 (Diesel)........... 8Wa-80-60
Fuel Injector No. 3 (Gas)............. 8Wa-80-60
Fuel Injector No. 4 (Diesel)........... 8Wa-80-60
Fuel Injector No. 4 (Gas)............. 8Wa-80-60
Fuel Injector No. 5 (3.7L)............ 8Wa-80-61
Fuel Injector No. 6 (3.7L)............ 8Wa-80-61
Fuel Pressure Sensor (Diesel)......... 8Wa-80-61
Fuel Pressure Solenoid (Diesel)........ 8Wa-80-61
Fuel Pump Module................. 8Wa-80-61
G202............................ 8Wa-80-61
Generator........................ 8Wa-80-62
Glow Plug Assembly (Diesel).......... 8Wa-80-62
Hazard Switch/Combination Flasher.... 8Wa-80-62
Headlamp Leveling Switch
(Built-Up-Export)................ 8Wa-80-63
Heated Seat Module (Highline)........ 8Wa-80-63
High Note Horn.................... 8Wa-80-63
Hood Ajar Switch (Except Base)....... 8Wa-80-63
Idle Air Control Motor............... 8Wa-80-64
Ignition Switch.................... 8Wa-80-64
Input Speed Sensor (3.7L)............ 8Wa-80-64
Instrument Cluster................. 8Wa-80-64
Intake Air Temperature Sensor (Gas) . . . 8Wa-80-65
Intrusion Sensor (Built-Up-Export)..... 8Wa-80-65
Junction Block Body Control Module-JB . 8Wa-80-65
Junction Block C1.................. 8Wa-80-66
Junction Block C2.................. 8Wa-80-67
Junction Block C3.................. 8Wa-80-68
Knock Sensor (3.7L)................ 8Wa-80-69
Leak Detection Pump............... 8Wa-80-69
Left Courtesy Lamp................ 8Wa-80-69
Left Curtain Airbag................. 8Wa-80-69
Left Cylinder Lock Switch (Except Base) . 8Wa-80-69
Left Door Lock Switch (Except Base) . . . 8Wa-80-70
Left Fog Lamp..................... 8Wa-80-70
Left Front Door Ajar Switch (Base)..... 8Wa-80-70
Left Front Door Lock Motor/Ajar Switch
(Except Base)................... 8Wa-80-70
Left Front Door Speaker (Base)........ 8Wa-80-70
Left Front Door Speaker (Premium).... 8Wa-80-71
Left Front Impact Sensor............ 8Wa-80-71
Left Front Park/Turn Signal Lamp..... 8Wa-80-71
Left Front Power Window Motor
(Midline/Highline)................ 8Wa-80-71
Left Front Wheel Speed Sensor (ABS) . . . 8Wa-80-72
Left Headlamp (Built-Up-Export)...... 8Wa-80-72
Left Headlamp (Except Built-Up-Export) . 8Wa-80-72
Left Heated Seat Assembly (Highline) . . . 8Wa-80-72
Left Heated Seat Switch (Highline)..... 8Wa-80-72
Left Instrument Panel Speaker........ 8Wa-80-73
Left Leveling Motor (Built-Up-Export) . . 8Wa-80-73
Left Position Lamp (Built-Up-Export) . . . 8Wa-80-73
Left Power Mirror (Except Base)....... 8Wa-80-73
8Wa - 80 - 2 8W-80 CONNECTOR PIN-OUTSKJ

Component Page
Left Power Seat Motors
(Midline/Highline)................ 8Wa-80-74
Left Power Seat Switch
(Midline/Highline)................ 8Wa-80-74
Left Rear Door Ajar Switch (Base)..... 8Wa-80-74
Left Rear Door Lock Motor/Ajar Switch
(Except Base)................... 8Wa-80-74
Left Rear Door Speaker.............. 8Wa-80-75
Left Rear Power Window Motor
(Midline/Highline)................ 8Wa-80-75
Left Remote Radio Switch (Premium) . . . 8Wa-80-75
Left Side Impact Airbag Control
Module (LSIACM)................ 8Wa-80-75
Left Side Marker Lamp (Except
Built-Up-Export)................. 8Wa-80-76
Left Side Repeater Lamp
(Built-Up-Export)................ 8Wa-80-76
Left Speed Control Switch (Except Base) . 8Wa-80-76
Left Tail/Stop Lamp................ 8Wa-80-76
Left Visor/Vanity Lamp (Except Base) . . . 8Wa-80-76
License Lamp (Built-Up-Export)....... 8Wa-80-77
License Lamp (Except Built-Up-Export) . 8Wa-80-77
Line Pressure Sensor (3.7L).......... 8Wa-80-77
Low Note Horn.................... 8Wa-80-77
Manifold ABSolute Pressure Sensor.... 8Wa-80-77
Multi-Function Switch C1............ 8Wa-80-78
Multi-Function Switch C2............ 8Wa-80-78
Output Speed Sensor (3.7L).......... 8Wa-80-78
Overhead Map/Reading Lamp
(Except Base)................... 8Wa-80-78
Oxygen Sensor 1/1 Upstream......... 8Wa-80-79
Oxygen Sensor 1/2 Downstream....... 8Wa-80-79
Oxygen Sensor 2/1 Upstream (3.7L).... 8Wa-80-79
Oxygen Sensor 2/2 Downstream (3.7L) . . 8Wa-80-79
Passenger Airbag................... 8Wa-80-79
Passenger Seat Belt Switch........... 8Wa-80-80
Power Mirror Switch (Except Base)..... 8Wa-80-80
Power Outlet...................... 8Wa-80-80
Power Steering Pressure Switch....... 8Wa-80-80
Power Window Master Switch
(Midline/Highline)................ 8Wa-80-81
Powertrain Control Module-C1 (2.4L) . . . 8Wa-80-81
Powertrain Control Module-C1 (3.7L) . . . 8Wa-80-82
Powertrain Control Module-C2 (Gas) . . . 8Wa-80-82
Powertrain Control Module-C3 (Gas) . . . 8Wa-80-83
Radiator Fan Motor................. 8Wa-80-84
Radiator Fan Relay................. 8Wa-80-84
Radio C1......................... 8Wa-80-84
Radio C2......................... 8Wa-80-85
Radio C3......................... 8Wa-80-85
Radio Choke (Premium)............. 8Wa-80-85
Rear Power Outlet.................. 8Wa-80-85
Rear Power Window Switch
(Midline/Highline)................ 8Wa-80-86
Rear Wheel Speed Sensor............ 8Wa-80-86Component Page
Rear Wiper Motor.................. 8Wa-80-86
Red Brake Warning Indicator Switch . . . 8Wa-80-86
Remote Keyless Entry Module
(Except Base)................... 8Wa-80-86
Right Courtesy Lamp............... 8Wa-80-87
Right Curtain Airbag................ 8Wa-80-87
Right Cylinder Lock Switch
(Except Base)................... 8Wa-80-87
Right Door Lock Switch (Except Base) . . 8Wa-80-87
Right Fog Lamp................... 8Wa-80-87
Right Front Door Ajar Switch (Base).... 8Wa-80-88
Right Front Door Lock Motor/Ajar Switch
(Except Base)................... 8Wa-80-88
Right Front Door Speaker (Base)...... 8Wa-80-88
Right Front Door Speaker (Premium) . . . 8Wa-80-88
Right Front Impact Sensor........... 8Wa-80-88
Right Front Park/ Turn Signal Lamp . . . 8Wa-80-89
Right Front Power Window Motor
(Midline/Highline)................ 8Wa-80-89
Right Front Wheel Speed Sensor (ABS) . 8Wa-80-89
Right Headlamp (Built-Up-Export)..... 8Wa-80-89
Right Headlamp (Except Built-Up-Export). 8Wa-80-89
Right Heated Seat Assembly (Highline) . 8Wa-80-90
Right Heated Seat Switch (Highline) . . . 8Wa-80-90
Right Instrument Panel Speaker....... 8Wa-80-90
Right Leveling Motor (Built-Up-Export) . 8Wa-80-90
Right Position Lamp (Built-Up-Export) . . 8Wa-80-91
Right Power Mirror (Except Base)...... 8Wa-80-91
Right Power Seat Motors
(Midline/Highline)................ 8Wa-80-91
Right Power Seat Switch
(Midline/Highline)................ 8Wa-80-91
Right Rear Door Ajar Switch (Base).... 8Wa-80-92
Right Rear Door Lock Motor/Ajar Switch
(Except Base)................... 8Wa-80-92
Right Rear Door Speaker............ 8Wa-80-92
Right Rear Power Window Motor
(Midline/Highline)................ 8Wa-80-92
Right Remote Radio Switch (Premium) . . 8Wa-80-92
Right Side Impact Airbag Control Module
(RSIACM)...................... 8Wa-80-93
Right Side Marker Lamp
(Except Built-Up-Export)........... 8Wa-80-93
Right Side Repeater Lamp
(Built-Up-Export)................ 8Wa-80-93
Right Speed Control Switch
(Except Base)................... 8Wa-80-93
Right Tail/Stop Lamp............... 8Wa-80-93
Right Visor/Vanity Lamp (Except Base) . 8Wa-80-94
Sentry Key Immobilizer Module
(Except Base)................... 8Wa-80-94
Shifter Assembly................... 8Wa-80-94
Siren (Built-Up-Export).............. 8Wa-80-94
Speed Control Servo................ 8Wa-80-94
Sunroof Motor..................... 8Wa-80-95
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-3

BODY CONTROL MODULE C1 - GRAY 26 WAY
CAV CIRCUIT FUNCTION
16 D19 20VT/OR BODY CONTROL MODULE FLASH ENABLE
17 P101 20OR/PK FLIP-UP GLASS RELEASE SWITCH SENSE
18 - -
19 - -
20 B22 18LG/YL VEHICLE SPEED OUTPUT
21 G69 20BK/OR VTSS INDICATOR DRIVER
22 - -
23 C79 20VT/BK REAR WINDOW DEFOGGER CONTROL
24 C19 18BR A/C ON/OFF CONTROL
25 Z3 16BK/OR GROUND
26 P100 18OR/BR FLIP-UP GLASS RELEASE MOTOR DRIVER
BODY CONTROL MODULE C2 - GRAY 22 WAY
CAV CIRCUIT FUNCTION
1 Y66 20GY (EXCEPT BASE) RKE ANTENNA
2 G910 20VT/BR TAILGATE SWITCH GROUND
3- -
4 L80 20WT/DG HEADLAMP SWITCH RETURN
5 L307 20LG/OR HEADLAMP SWITCH MUX
6 G72 18DG/OR (LHD PREMIUM) RIGHT CYLINDER LOCK SWITCH MUX
6 G73 18LG/OR (RHD) RIGHT CYLINDER LOCK SWITCH MUX
7 L27 20WT/TN (EXCEPT BASE) FRONT FOG LAMP SWITCH SENSE
8 E21 20OR/RD PANEL LAMPS DIMMER SWITCH MUX
9 G72 18DG/OR (RHD) LEFT CYLINDER LOCK SWITCH MUX
9 G73 18LG/OR (LHD PREMIUM) LEFT CYLINDER LOCK SWITCH MUX
10 V52 20DG/RD FRONT WIPER SWITCH MUX
11 X10 20RD/DB (EXCEPT BASE) RADIO CONTROL MUX RETURN
12 Y66 20GY (EXCEPT BASE) RKE ANTENNA
13 - -
14 - -
15 G32 20DB/OR (EXCEPT BASE) AMBIENT TEMPERATURE SENSOR RETURN
16 - -
17 G71 18VT/YL TAILGATE CYLINDER LOCK SWITCH MUX
18 G31 20VT/LG (EXCEPT BASE) AMBIENT TEMPERATURE SENSOR SIGNAL
19 L324 20WT/LG HIGH BEAM SWITCH SENSE
20 F512 18PK/OR VEHICLE SPEED SENSOR SUPPLY
21 B12 18DG/OR VEHICLE SPEED SIGNAL
22 X20 20RD/BK (EXCEPT BASE) RADIO CONTROL MUX
BODY CONTROL MODULE C3 (PREMIUM)-6WAY
CAV CIRCUIT FUNCTION
1 Y60 RKE DATA
2 Y62 RKE SUPPLY
3 Y61 RKE PROGRAM
4 Y63 RKE GROUND
5 Y64 RKE ANTENNA (+)
6 Y65 RKE ANTENNA (-)
8Wa - 80 - 10 8W-80 CONNECTOR PIN-OUTSKJ

BOOST PRESSURE SENSOR (DIESEL)-4WAY
CAV CIRCUIT FUNCTION
1 K4 18BK/LB SENSOR GROUND
2 K21 18BK/RD INTAKE AIR TEMPERATURE SENSOR SIGNAL
3 K6 18VT/WT SENSOR REFERENCE VOLTAGE B
4 K37 20DB/YL BOOST PRESSURE SENSOR SIGNAL
BRAKE LAMP SWITCH - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 F32 18PK/DB FUSED B(+)
2 L50 18WT/TN (GAS) BRAKE LAMP SWITCH OUTPUT
2 L50 18WT/TN (DIESEL) PRIMARY BRAKE SWITCH SIGNAL
3 V30 18DB/RD SPEED CONTROL BRAKE SWITCH OUTPUT
4 V32 18YL/RD SPEED CONTROL SUPPLY
5 Z3 18BK/OR GROUND
6 K29 18WT/PK (GAS) BRAKE SWITCH SENSE
6 K29 18WT/PK (DIESEL) SECONDARY BRAKE SWITCH SIGNAL
BRAKE PRESSURE SWITCH (ABS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 F22 18DB/PK FUSED IGNITION SWITCH OUTPUT (RUN)
2 S43 18LB/YL FLUID PRESSURE SWITCH SIGNAL
C100 (RHD) - GRAY (INSTRUMENT PANEL SIDE)
CAV CIRCUIT
1 L43 18VT
2 F1 20DB
3 M1 18PK
4 B22 18LG/YL
5 L44 18VT/RD
6 V16 18VT/YL
7 V55 16TN/RD
8 G32 20DB/OR
9 D20 20LG
10 D25 18YL/VT/BR
11 V14 18RD/VT
12 L13 18BR/YL
13 G70 20BR/TN
14 G11 20WT/BK
15 K4 20BK/LB
16 L50 18WT/TN
17 L62 18BR/RD
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-11

CENTER HIGH MOUNTED STOP LAMP - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 L50 18WT/TN BRAKE LAMP SWITCH OUTPUT
2 Z309 18BK GROUND
CIGAR LIGHTER - RED 3 WAY
CAV CIRCUIT FUNCTION
1 F30 16RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
2- -
3 Z3 16BK/OR GROUND
CLOCKSPRING C1 - WHITE 6 WAY
CAV CIRCUIT FUNCTION
1- -
2 X3 20BK/RD HORN RELAY CONTROL
3 X20 20RD/BK (PREMIUM) RADIO CONTROL MUX
4 X10 20RD/DB (PREMIUM) RADIO CONTROL MUX RETURN
5 K4 20BK/LB SENSOR GROUND
6 V37 20RD/LG SPEED CONTROL SWITCH SIGNAL
CLOCKSPRING C2 - YELLOW 4 WAY
CAV CIRCUIT FUNCTION
1 R45 18DG/LB DRIVER SQUIB 1 LINE 2
2 R43 18BK/LB DRIVER SQUIB 1 LINE 1
3 R63 18TN/LB DRIVER SQUIB 2 LINE 2
4 R61 18OR/LB DRIVER SQUIB 2 LINE 1
CLOCKSPRING C3 - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1- -
2 X3 20BK/RD HORN RELAY CONTROL
3 X20 20RD/BK (PREMIUM) RADIO CONTROL MUX
4 X10 20RD/DB (PREMIUM) RADIO CONTROL MUX RETURN
5 K4 20BK/LB (EXCEPT BASE) SENSOR GROUND
6 V37 20RD/LG (EXCEPT BASE) SPEED CONTROL SWITCH SIGNAL
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-49

CONTROLLER ANTILOCK BRAKE - LT.GRAY 24 WAY
CAV CIRCUIT FUNCTION
1 Z101 12BK/OR GROUND
2- -
3- -
4- -
5 D25 18YL/VT PCI BUS
6 B6 18WT/DB RIGHT FRONT WHEEL SPEED SENSOR SIGNAL
7 B7 18WT RIGHT FRONT WHEEL SPEED SENSOR 12 VOLT
SUPPLY
8 D24 18WT/DG FLASH ABS
9 A20 12RD/DB FUSED B(+)
10 F22 18DB/PK FUSED IGNITION SWITCH OUTPUT (RUN)
11 - -
12 - -
13 B12 18DG/OR VEHICLE SPEED SIGNAL
14 - -
15 - -
16 Z102 12BK/OR GROUND
17 S43 18LB/YL FLUID PRESSURE SWITCH SIGNAL
18 L50 18WT/TN BRAKE LAMP SWITCH OUTPUT
19 B1 18YL/DB REAR WHEEL SPEED SENSOR SIGNAL
20 B2 18YL REAR WHEEL SPEED SENSOR 12 VOLT SUPPLY
21 - -
22 B8 18RD/DB LEFT FRONT WHEEL SPEED SENSOR SIGNAL
23 B9 18RD LEFT FRONT WHEEL SPEED SENSOR 12 VOLT SUP-
PLY
24 A10 12RD/DG FUSED B(+)
CRANKSHAFT POSITION SENSOR (2.4L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K24 18GY/BK CRANKSHAFT POSITION SENSOR SIGNAL
2 K4 18BK/LB SENSOR GROUND
3 K7 18OR 5 VOLT SUPPLY
CRANKSHAFT POSITION SENSOR (3.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K24 18GY/BK CRANKSHAFT POSITION SENSOR SIGNAL
2 K4 18BK/LB SENSOR GROUND
3 K7 18OR 5 VOLT SUPPLY
8Wa - 80 - 52 8W-80 CONNECTOR PIN-OUTSKJ

EGR SOLENOID (DIESEL)-2WAY
CAV CIRCUIT FUNCTION
1 A71 18DG/RD FUSED AUTO SHUT DOWN RELAY OUTPUT
2 K35 18GY/YL EGR SOLENOID CONTROL
ENGINE CONTROL MODULE C1 (DIESEL) - BLACK 81 WAY
CAV CIRCUIT FUNCTION
1 Z108 14BK/DG GROUND
2 Z108 14BK/DG GROUND
3 K20 18DG GENERATOR FIELD CONTROL
4 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
5 A142 14DG/OR AUTO SHUT DOWN RELAY OUTPUT
6- -
7 D25 20VT/YL PCI BUS
8 K944 20BK/LB CAMSHAFT POSITION SENSOR GROUND
9 K44 20TN/YL CAMSHAFT POSITION SENSOR SIGNAL
10 - -
11 K37 20DB/YL BOOST PRESSURE SENSOR SIGNAL
12 - -
13 K78 20GY FUEL PRESSURE SENSOR SIGNAL
14 - -
15 K81 20VT/TN ACCELERATOR PEDAL POSITION SENSOR SIGNAL
16 K80 20BK/VT FUEL PRESSURE SENSOR GROUND
17 - -
18 - -
19 F92 20YL/BR BATTERY SENSE (+)
20 Z109 20BK/DB BATTERY SENSE (-)
21 K4 20BK/LB SENSOR GROUND
22 F1 20DB FUSED IGNITION SWITCH OUTPUT (RUN-START)
23 K6 20VT/WT SENSOR REFERENCE VOLTAGE B
24 K3 20LB/BK CRANKSHAFT POSITION SENSOR SIGNAL 2
25 - -
26 - -
27 - -
28 - -
29 K77 20BR/WT TRANSFER CASE POSITION SENSOR INPUT
30 G60 20GY/YL ENGINE OIL PRESSURE SENSOR SIGNAL
31 G123 20DG/WT WATER IN FUEL SENSOR SIGNAL
32 K118 20PK/YL BATTERY TEMPERATURE SENSOR SIGNAL
33 - -
34 K255 20WT/DG ACCELERATOR PEDAL POSITION SENSOR GROUND
35 K852 20VT/WT ACCELERATOR PEDAL POSITION SENSOR 5 VOLT
SUPPLY
36 - -
37 - -
38 V37 20RD/LG SPEED CONTROL SWITCH SIGNAL
39 K226 20DB/WT FUEL LEVEL SENSOR SIGNAL
40 K2 20TN/BK ENGINE COOLANT TEMPERATURE SENSOR SIGNAL
41 K21 18BK/RD INTAKE AIR TEMPERATURE SENSOR SIGNAL
42 Y101 20BK/OR CRANKSHAFT POSITION SENSOR SHIELD
43 K24 20GY/BK CRANKSHAFT POSITION SENSOR SIGNAL 1
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-55
