8W-12 JUNCTION BLOCK
Component Page
A/C Compressor Clutch Relay...............8Wa-12-19
A/C-Heater Control.................8Wa-12-26, 28, 35
Airbag Control Module.................8Wa-12-18, 25
Antenna Module.....................8Wa-12-23, 24
Ash Receiver Lamp......................8Wa-12-35
Auto Shut Down Relay...................8Wa-12-19
Back-Up Lamp Switch....................8Wa-12-28
Blend Door Actuator.....................8Wa-12-26
Blower Motor Relay.....................8Wa-12-25
Body Control Module . 8Wa-12-9, 10, 11, 13, 14, 15, 18, 21 22, 23
, 24, 27, 28, 30, 31, 32, 33, 34
Brake Lamp Switch.....................8Wa-12-16
Brake Pressure Switch....................8Wa-12-25
Cargo Lamp........................8Wa-12-30, 34
Center High Mounted Stop Lamp.............8Wa-12-16
Cigar Lighter.......................8Wa-12-23, 24
Circuit Breaker No. 1....................8Wa-12-29
Circuit Breaker No. 3 (JB)...............8Wa-12-23, 24
Clockspring...........................8Wa-12-9
Compass Mini-Trip Computer.............8Wa-12-18, 30
Controller Antilock Brake...............8Wa-12-16, 25
Data Link Connector.....................8Wa-12-29
Daytime Running Lamp Relay...............8Wa-12-27
Defogger Relay........................8Wa-12-28
Dome Lamp........................8Wa-12-30, 34
Door Lock Relay........................8Wa-12-11
Driver Door Unlock Relay..................8Wa-12-11
Engine Control Module...................8Wa-12-20
EVAP/Purge Solenoid....................8Wa-12-19
Front Fog Lamp Relay.................8Wa-12-21, 22
Front Wiper Motor......................8Wa-12-32
Fuel Pump Relay.......................8Wa-12-19
Fuse 1..............................8Wa-12-9
Fuse 2..............................8Wa-12-10
Fuse 3..............................8Wa-12-9
Fuse 4..............................8Wa-12-10
Fuse 5..............................8Wa-12-10
Fuse 6..............................8Wa-12-11
Fuse 7..............................8Wa-12-16
Fuse 9....................8Wa-12-13, 14, 15, 21, 22
Fuse 11.............................8Wa-12-17
Fuse 12.............................8Wa-12-16
Fuse 13.............................8Wa-12-18
Fuse 15...........................8Wa-12-19, 20
Fuse 16...........................8Wa-12-21, 22
Fuse 17...........................8Wa-12-21, 22
Fuse 18...........................8Wa-12-21, 22
Fuse 19...........................8Wa-12-21, 22
Fuse 20...........................8Wa-12-23, 24
Fuse 22...........................8Wa-12-23, 24
Fuse 23........................8Wa-12-13, 14, 15
Fuse 24.............................8Wa-12-25
Fuse 25.............................8Wa-12-26
Fuse 26.............................8Wa-12-27
Fuse 27.............................8Wa-12-27
Fuse 29.............................8Wa-12-17
Fuse 30.............................8Wa-12-28
Fuse 31...........................8Wa-12-23, 24
Fuse 32...........................8Wa-12-23, 24
Fuse 33.............................8Wa-12-29
Fuse 34.............................8Wa-12-30
Fuse 36.............................8Wa-12-18
Fuse 37.............................8Wa-12-25
Fuse 38.............................8Wa-12-25
Fuse 39.............................8Wa-12-28
G202...................8Wa-12-11, 13, 14, 15, 27, 32
Hazard Switch/Combination Flasher......8Wa-12-17, 28, 35
Headlamp Leveling Switch...............8Wa-12-14, 15
Heated Seat Module.....................8Wa-12-17
High Beam Relay.......................8Wa-12-27Component Page
High Note Horn.........................8Wa-12-9
Horn Relay...........................8Wa-12-9
Horn Switch...........................8Wa-12-9
Instrument Cluster..........8Wa-12-13, 14, 15, 18, 30, 35
Intrusion Sensor.......................8Wa-12-30
Junction Block . 8Wa-12-2, 3, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18,
19, 20, 21, 22, 23, 24, 25, 26, 27, 28, 30, 31, 32, 33, 34, 35,
Left Courtesy Lamp...................8Wa-12-30, 34
Left Cylinder Lock Switch.................8Wa-12-33
Left Door Lock Switch.............8Wa-12-23, 24, 31, 33
Left Fog Lamp......................8Wa-12-21, 22
Left Front Door Lock Motor/Ajar Switch.......8Wa-12-11, 12
Left Front Park/Turn Signal Lamp............8Wa-12-13
Left Headlamp......................8Wa-12-10, 27
Left Heated Seat Switch...................8Wa-12-26
Left Position Lamp....................8Wa-12-14, 15
Left Power Mirror......................8Wa-12-28
Left Power Seat Switch...................8Wa-12-29
Left Rear Door Lock Motor/Ajar Switch.........8Wa-12-12
Left Side Impact Airbag Control Module.........8Wa-12-18
Left Side Marker Lamp...................8Wa-12-13
Left Tail/Stop Lamp..............8Wa-12-13, 14, 15, 16
Left Visor/Vanity Lamp...................8Wa-12-30
Left Visor/Vanity Lamp...................8Wa-12-31
License Lamp.....................8Wa-12-13, 14, 15
Low Beam Relay.......................8Wa-12-10
Low Note Horn.........................8Wa-12-9
Multi-Function Switch...............8Wa-12-23, 24, 27
Overhead Map/Reading Lamp...........8Wa-12-30, 31, 34
Park Lamp Relay..................8Wa-12-13, 14, 15
Passenger Door Unlock Relay...............8Wa-12-11
Power Distribution Center........8Wa-12-16, 21, 22, 31, 32
Power Mirror Switch.....................8Wa-12-26
Power Outlet..........................8Wa-12-9
Powertrain Control Module.................8Wa-12-19
Radio Choke........................8Wa-12-21, 22
Radio.......................8Wa-12-23, 24, 30, 35
Rear Fog Lamp Relay....................8Wa-12-10
Rear Power Outlet....................8Wa-12-21, 22
Rear Window Defogger....................8Wa-12-28
Rear Wiper Motor....................8Wa-12-21, 22
Right Courtesy Lamp..................8Wa-12-30, 34
Right Cylinder Lock Switch.................8Wa-12-33
Right Door Lock Switch............8Wa-12-23, 24, 31 33
Right Fog Lamp.....................8Wa-12-21, 22
Right Front Door Lock Motor/Ajar Switch......8Wa-12-11, 12
Right Front Park/Turn Signal Lamp...........8Wa-12-13
Right Headlamp.....................8Wa-12-10, 27
Right Heated Seat Switch..................8Wa-12-26
Right Position Lamp...................8Wa-12-14, 15
Right Power Mirror......................8Wa-12-28
Right Power Seat Switch..................8Wa-12-29
Right Rear Door Lock Motor/Ajar Switch........8Wa-12-12
Right Side Impact Airbag Control Module........8Wa-12-18
Right Side Marker Lamp..................8Wa-12-13
Right Tail/Stop Lamp...........8Wa-12-10, 13, 14, 15, 16
Right Visor/Vanity Lamp................8Wa-12-30, 31
Sentry Key Immobilizer Module.........8Wa-12-19, 20, 29
Shifter Assembly.....................8Wa-12-25, 35
Siren...............................8Wa-12-30
Sunroof Motor.......................8Wa-12-23, 24
Tailgate Lock Motor/Ajar Switch..............8Wa-12-32
Trailer Tow Brake Lamp Relay..........8Wa-12-16, 21, 22
Trailer Tow Connector...............8Wa-12-13, 14, 15
Trailer Tow Relay.......................8Wa-12-26
Transmission Control Module...............8Wa-12-19
Transmission Solenoid/TRS Assembly..........8Wa-12-28
Wiper On/Off Relay...............8Wa-12-23, 24, 31, 32
KJ8W-12 JUNCTION BLOCK8Wa-12-1

8W-15 GROUND DISTRIBUTION
Component Page
A/C Compressor Clutch...................8Wa-15-6
A/C Low Pressure Switch.................8Wa-15-3
A/C- Heater Control...................8Wa-15-7, 8
Airbag Control Module...................8Wa-15-7
Ash Receiver Lamp.....................8Wa-15-8
Battery.............................8Wa-15-2
Blend Door Actuator.....................8Wa-15-8
Blower Motor Relay.....................8Wa-15-4
Body Control Module....................8Wa-15-8
Brake Lamp Switch.....................8Wa-15-8
Cabin Heater.........................8Wa-15-6
Capacitor............................8Wa-15-2
Center High Mounted Stop Lamp...........8Wa-15-14
Cigar Lighter.........................8Wa-15-8
Compass Mini-Trip Computer..............8Wa-15-14
Controller Antilock Brake.................8Wa-15-2
Data Link Connector....................8Wa-15-2
Engine Control Module...................8Wa-15-7
Engine Coolant Level Sensor...............8Wa-15-6
Flip-Up Glass Release Motor..............8Wa-15-14
Front Wiper Motor......................8Wa-15-3
Fuel Heater..........................8Wa-15-6
Fuel Heater Relay......................8Wa-15-4
Fuel Pump Module.....................8Wa-15-15
G100.............................8Wa-15-2, 7
G101...............................8Wa-15-6
G102...............................8Wa-15-2
G103...............................8Wa-15-6
G104...............................8Wa-15-7
G105...............................8Wa-15-2
G106...............................8Wa-15-2
G110...............................8Wa-15-2
G111 .............................8Wa-15-3, 4
G112...............................8Wa-15-3
G200...............................8Wa-15-7
G201...............................8Wa-15-7
G202...............................8Wa-15-8
G300............................8Wa-15-9, 11
G301............................8Wa-15-9, 10
G302............................8Wa-15-9, 12
G310.........................8Wa-15-13, 14, 15
G311 ..............................8Wa-15-14
G312..............................8Wa-15-14
G320..............................8Wa-15-15
Hazard Switch/Combination Flasher..........8Wa-15-8
Headlamp Leveling Switch................8Wa-15-8
Heated Seat Module....................8Wa-15-10
High Note Horn.......................8Wa-15-3
Hood Ajar Switch.......................8Wa-15-4
Ignition Switch........................8Wa-15-8
Instrument Cluster.....................8Wa-15-8
Intrusion Sensor......................8Wa-15-14
Junction Block........................8Wa-15-8
Left Door Lock Switch...................8Wa-15-11
Left Fog Lamp........................8Wa-15-5
Left Front Door Ajar Switch...............8Wa-15-11
Left Front Door Lock Motor/Ajar Switch.......8Wa-15-11
Left Front Door Speaker..................8Wa-15-7
Left Front Park/Turn Signal Lamp...........8Wa-15-5
Left Headlamp........................8Wa-15-3
Left Heated Seat Assembly...............8Wa-15-10
Left Heated Seat Switch.................8Wa-15-10Component Page
Left Leveling Motor.....................8Wa-15-3
Left Position Lamp.....................8Wa-15-3
Left Power Mirror.....................8Wa-15-11
Left Power Seat Switch..................8Wa-15-10
Left Rear Door Ajar Switch...............8Wa-15-11
Left Rear Door Lock Motor/Ajar Switch.......8Wa-15-11
Left Side Impact Airbag Control Module........8Wa-15-9
Left Side Repeater Lamp..................8Wa-15-5
Left Tail/Stop Lamp....................8Wa-15-15
License Lamp........................8Wa-15-15
Line Pressure Sensor....................8Wa-15-2
Low Note Horn........................8Wa-15-3
Multi- Function Switch...................8Wa-15-8
Oxygen Sensor 1/2 Downstream.............8Wa-15-6
Oxygen Sensor 2/2 Downstream.............8Wa-15-6
Power Mirror Switch.................8Wa-15-11, 12
Power Outlet.........................8Wa-15-8
Power Steering Pressure Switch.............8Wa-15-6
Power Window Master Switch.............8Wa-15-10
Powertrain Control Module................8Wa-15-2
Radiator Fan Motor.....................8Wa-15-3
Radiator Fan Relay.....................8Wa-15-3
Radio..............................8Wa-15-7
Radio Choke..........................8Wa-15-9
Rear Power Outlet.....................8Wa-15-15
Rear Window Defogger..................8Wa-15-14
Rear Wiper Motor.....................8Wa-15-14
Red Brake Warning Indicator Switch..........8Wa-15-4
Right Door Lock Switch..................8Wa-15-12
Right Fog Lamp.......................8Wa-15-5
Right Front Door Ajar Switch..............8Wa-15-12
Right Front Door Lock Motor/Ajar Switch......8Wa-15-12
Right Front Door Speaker.................8Wa-15-7
Right Front Park/Turn Signal Lamp..........8Wa-15-5
Right Headlamp.......................8Wa-15-4
Right Heated Seat Assembly..............8Wa-15-10
Right Heated Seat Switch................8Wa-15-10
Right Leveling Motor....................8Wa-15-4
Right Position Lamp....................8Wa-15-4
Right Power Mirror....................8Wa-15-12
Right Power Seat Switch.................8Wa-15-10
Right Rear Door Ajar Switch..............8Wa-15-12
Right Rear Door Lock Motor/Ajar Switch......8Wa-15-12
Right Side Impact Airbag Control Module.......8Wa-15-9
Right Side Repeater Lamp.................8Wa-15-5
Right Tail/Stop Lamp...................8Wa-15-15
Sentry Key Immobilizer Module.............8Wa-15-8
Shifter Assembly.......................8Wa-15-9
Siren...............................8Wa-15-4
Speed Control Servo.....................8Wa-15-3
Starter Motor Relay.....................8Wa-15-4
Sunroof Motor........................8Wa-15-14
Tailgate Flip-Up Ajar Switch..............8Wa-15-14
Trailer Tow Brake Lamp Relay.............8Wa-15-13
Trailer Tow Connector...................8Wa-15-13
Trailer Tow Left Turn Relay...............8Wa-15-13
Trailer Tow Relay......................8Wa-15-13
Trailer Tow Right Turn Relay..............8Wa-15-13
Transmission Control Module...............8Wa-15-2
Transmission Control Relay................8Wa-15-4
Washer Fluid Level Switch................8Wa-15-3
KJ8W-15 GROUND DISTRIBUTION8Wa-15-1

8W-18 BUS COMMUNICATIONS
Component Page
Airbag Control Module............... 8Wa-18-2
Body Control Module............. 8Wa-18-2, 5, 6
Compass Mini-Trip Computer.......... 8Wa-18-2
Controller Antilock Brake....... 8Wa-18-3, 4, 5, 6
Data Link Connector............. 8Wa-18-2, 5, 6
Diagnostic Junction Port........ 8Wa-18-2, 4, 5, 6
Engine Control Module............. 8Wa-18-4, 6
Fuse 33......................... 8Wa-18-5, 6
G100........................... 8Wa-18-5, 6Component Page
Instrument Cluster.................. 8Wa-18-2
Intrusion Sensor.................... 8Wa-18-2
Junction Block.................... 8Wa-18-5, 6
Left Side Impact Airbag Control Module . . 8Wa-18-2
Powertrain Control Module.......... 8Wa-18-2, 5
Radio............................. 8Wa-18-2
Right Side Impact Airbag Control Module . 8Wa-18-2
Sentry Key Immobilizer Module...... 8Wa-18-2, 4
Transmission Control Module........ 8Wa-18-3, 5
KJ8W-18 BUS COMMUNICATIONS8Wa-18-1

8W-39 VEHICLE THEFT SECURITY SYSTEM
Component Page
Body Control Module......... 8Wa-39-2, 3, 4, 5, 9
Clockspring........................ 8Wa-39-5
Clutch Switch Override Relay.......... 8Wa-39-2
Compass Mini-Trip Computer.......... 8Wa-39-8
Diagnostic Junction Port............ 8Wa-39-6, 8
Flip-Up Glass Release Switch.......... 8Wa-39-4
Fuse 3............................ 8Wa-39-5
Fuse 7............................ 8Wa-39-2
Fuse 13......................... 8Wa-39-2, 8
Fuse 14........................... 8Wa-39-2
Fuse 15........................... 8Wa-39-6
Fuse 28........................... 8Wa-39-2
Fuse 32........................... 8Wa-39-2
Fuse 33........................... 8Wa-39-6
Fuse 34....................... 8Wa-39-2, 7, 8
G111 ........................... 8Wa-39-5, 7
G202............................. 8Wa-39-6
G300............................. 8Wa-39-3
G302............................. 8Wa-39-3
G311 ............................. 8Wa-39-8
High Note Horn.................... 8Wa-39-5Component Page
Hood Ajar Switch................... 8Wa-39-5
Horn Relay........................ 8Wa-39-5
Horn Switch....................... 8Wa-39-5
Ignition Switch..................... 8Wa-39-2
Intrusion Sensor.................. 8Wa-39-7, 8
Junction Block............ 8Wa-39-2, 5, 6, 7, 8, 9
Left Cylinder Lock Switch............. 8Wa-39-9
Left Door Lock Switch................ 8Wa-39-9
Left Front Door Lock Motor/Ajar Switch . . 8Wa-39-3
Left Rear Door Lock Motor/Ajar Switch . . 8Wa-39-3
Low Note Horn..................... 8Wa-39-5
Power Distribution Center............ 8Wa-39-2
Right Cylinder Lock Switch........... 8Wa-39-9
Right Door Lock Switch.............. 8Wa-39-9
Right Front Door Lock Motor/Ajar Switch . 8Wa-39-3
Right Rear Door Lock Motor/Ajar Switch . 8Wa-39-3
Sentry Key Immobilizer Module........ 8Wa-39-6
Siren............................. 8Wa-39-7
Starter Motor Relay................. 8Wa-39-2
Tailgate Cylinder Lock Switch......... 8Wa-39-4
Tailgate Lock Motor/Ajar Switch........ 8Wa-39-4
KJ8W-39 VEHICLE THEFT SECURITY SYSTEM8Wa-39-1

8W-45 BODY CONTROL MODULE
Component Page
A/C- Heater Control................. 8Wa-45-5
Ambient Temperature Sensor.......... 8Wa-45-7
Body Control Module . 8Wa-45-10, 11, 2, 3, 4, 5, 6, 7,
8, 9
Brake Lamp Switch................. 8Wa-45-2
Cargo Lamp..................... 8Wa-45-4, 8
Clockspring........................ 8Wa-45-5
Controller Antilock Brake............. 8Wa-45-5
Data Link Connector............. 8Wa-45-10, 11
Defogger Relay..................... 8Wa-45-3
Diagnostic Junction Port.............. 8Wa-45-6
Door Lock Relay.................... 8Wa-45-4
Driver Door Unlock Relay............. 8Wa-45-3
Engine Control Module............... 8Wa-45-5
Flip-Up Glass Release Motor........... 8Wa-45-8
Flip-Up Glass Release Switch.......... 8Wa-45-8
Front Fog Lamp Relay............... 8Wa-45-4
Fuse 3............................ 8Wa-45-7
Fuse 6............................ 8Wa-45-3
Fuse 13........................... 8Wa-45-2
Fuse 32........................... 8Wa-45-2
Fuse 34........................... 8Wa-45-2
G111 ............................. 8Wa-45-7
G202........................... 8Wa-45-2, 6
G300............................. 8Wa-45-9
G302............................. 8Wa-45-9
Hazard Switch/Combination Flasher..... 8Wa-45-5
High Beam Relay................... 8Wa-45-3
Hood Ajar Switch................... 8Wa-45-7
Horn Relay........................ 8Wa-45-7
Ignition Switch..................... 8Wa-45-6
Instrument Cluster.................. 8Wa-45-6Component Page
Junction Block.............. 8Wa-45-2, 3, 4, 7, 8
Left Courtesy Lamp................. 8Wa-45-4
Left Cylinder Lock Switch....... 8Wa-45-10, 11, 4
Left Door Lock Switch.............. 8Wa-45-4, 7
Left Front Door Ajar Switch........... 8Wa-45-9
Left Front Door Lock Motor/Ajar
Switch...................... 8Wa-45-10, 11
Left Rear Door Ajar Switch............ 8Wa-45-9
Left Visor/Vanity Lamp............... 8Wa-45-3
Low Beam Relay.................... 8Wa-45-3
Multi- Function Switch........... 8Wa-45-3, 5, 6
Overhead Map/Reading Lamp........ 8Wa-45-3, 4
Park Lamp Relay................... 8Wa-45-3
Passenger Door Unlock Relay.......... 8Wa-45-3
Powertrain Control Module............ 8Wa-45-5
Rear Fog Lamp Relay................ 8Wa-45-2
Rear Wiper Motor................. 8Wa-45-6, 8
Remote Keyless Entry Module......... 8Wa-45-8
Right Courtesy Lamp................ 8Wa-45-4
Right Cylinder Lock Switch...... 8Wa-45-10, 11, 4
Right Door Lock Switch............ 8Wa-45-4, 7
Right Front Door Ajar Switch.......... 8Wa-45-9
Right Front Door Lock Motor/Ajar
Switch...................... 8Wa-45-10, 11
Right Rear Door Ajar Switch........... 8Wa-45-9
Right Remote Radio Switch............ 8Wa-45-5
Right Visor/Vanity Lamp.............. 8Wa-45-3
Tailgate Cylinder Lock Switch.... 8Wa-45-10, 11, 8
Tailgate Lock Motor/Ajar Switch...... 8Wa-45-7, 8
Washer Pump...................... 8Wa-45-6
Wiper High/Low Relay............... 8Wa-45-4
Wiper On/Off Relay.................. 8Wa-45-4
KJ8W-45 BODY CONTROL MODULE8Wa-45-1

Component Page
Left Power Seat Motors
(Midline/Highline)................ 8Wa-80-74
Left Power Seat Switch
(Midline/Highline)................ 8Wa-80-74
Left Rear Door Ajar Switch (Base)..... 8Wa-80-74
Left Rear Door Lock Motor/Ajar Switch
(Except Base)................... 8Wa-80-74
Left Rear Door Speaker.............. 8Wa-80-75
Left Rear Power Window Motor
(Midline/Highline)................ 8Wa-80-75
Left Remote Radio Switch (Premium) . . . 8Wa-80-75
Left Side Impact Airbag Control
Module (LSIACM)................ 8Wa-80-75
Left Side Marker Lamp (Except
Built-Up-Export)................. 8Wa-80-76
Left Side Repeater Lamp
(Built-Up-Export)................ 8Wa-80-76
Left Speed Control Switch (Except Base) . 8Wa-80-76
Left Tail/Stop Lamp................ 8Wa-80-76
Left Visor/Vanity Lamp (Except Base) . . . 8Wa-80-76
License Lamp (Built-Up-Export)....... 8Wa-80-77
License Lamp (Except Built-Up-Export) . 8Wa-80-77
Line Pressure Sensor (3.7L).......... 8Wa-80-77
Low Note Horn.................... 8Wa-80-77
Manifold ABSolute Pressure Sensor.... 8Wa-80-77
Multi-Function Switch C1............ 8Wa-80-78
Multi-Function Switch C2............ 8Wa-80-78
Output Speed Sensor (3.7L).......... 8Wa-80-78
Overhead Map/Reading Lamp
(Except Base)................... 8Wa-80-78
Oxygen Sensor 1/1 Upstream......... 8Wa-80-79
Oxygen Sensor 1/2 Downstream....... 8Wa-80-79
Oxygen Sensor 2/1 Upstream (3.7L).... 8Wa-80-79
Oxygen Sensor 2/2 Downstream (3.7L) . . 8Wa-80-79
Passenger Airbag................... 8Wa-80-79
Passenger Seat Belt Switch........... 8Wa-80-80
Power Mirror Switch (Except Base)..... 8Wa-80-80
Power Outlet...................... 8Wa-80-80
Power Steering Pressure Switch....... 8Wa-80-80
Power Window Master Switch
(Midline/Highline)................ 8Wa-80-81
Powertrain Control Module-C1 (2.4L) . . . 8Wa-80-81
Powertrain Control Module-C1 (3.7L) . . . 8Wa-80-82
Powertrain Control Module-C2 (Gas) . . . 8Wa-80-82
Powertrain Control Module-C3 (Gas) . . . 8Wa-80-83
Radiator Fan Motor................. 8Wa-80-84
Radiator Fan Relay................. 8Wa-80-84
Radio C1......................... 8Wa-80-84
Radio C2......................... 8Wa-80-85
Radio C3......................... 8Wa-80-85
Radio Choke (Premium)............. 8Wa-80-85
Rear Power Outlet.................. 8Wa-80-85
Rear Power Window Switch
(Midline/Highline)................ 8Wa-80-86
Rear Wheel Speed Sensor............ 8Wa-80-86Component Page
Rear Wiper Motor.................. 8Wa-80-86
Red Brake Warning Indicator Switch . . . 8Wa-80-86
Remote Keyless Entry Module
(Except Base)................... 8Wa-80-86
Right Courtesy Lamp............... 8Wa-80-87
Right Curtain Airbag................ 8Wa-80-87
Right Cylinder Lock Switch
(Except Base)................... 8Wa-80-87
Right Door Lock Switch (Except Base) . . 8Wa-80-87
Right Fog Lamp................... 8Wa-80-87
Right Front Door Ajar Switch (Base).... 8Wa-80-88
Right Front Door Lock Motor/Ajar Switch
(Except Base)................... 8Wa-80-88
Right Front Door Speaker (Base)...... 8Wa-80-88
Right Front Door Speaker (Premium) . . . 8Wa-80-88
Right Front Impact Sensor........... 8Wa-80-88
Right Front Park/ Turn Signal Lamp . . . 8Wa-80-89
Right Front Power Window Motor
(Midline/Highline)................ 8Wa-80-89
Right Front Wheel Speed Sensor (ABS) . 8Wa-80-89
Right Headlamp (Built-Up-Export)..... 8Wa-80-89
Right Headlamp (Except Built-Up-Export). 8Wa-80-89
Right Heated Seat Assembly (Highline) . 8Wa-80-90
Right Heated Seat Switch (Highline) . . . 8Wa-80-90
Right Instrument Panel Speaker....... 8Wa-80-90
Right Leveling Motor (Built-Up-Export) . 8Wa-80-90
Right Position Lamp (Built-Up-Export) . . 8Wa-80-91
Right Power Mirror (Except Base)...... 8Wa-80-91
Right Power Seat Motors
(Midline/Highline)................ 8Wa-80-91
Right Power Seat Switch
(Midline/Highline)................ 8Wa-80-91
Right Rear Door Ajar Switch (Base).... 8Wa-80-92
Right Rear Door Lock Motor/Ajar Switch
(Except Base)................... 8Wa-80-92
Right Rear Door Speaker............ 8Wa-80-92
Right Rear Power Window Motor
(Midline/Highline)................ 8Wa-80-92
Right Remote Radio Switch (Premium) . . 8Wa-80-92
Right Side Impact Airbag Control Module
(RSIACM)...................... 8Wa-80-93
Right Side Marker Lamp
(Except Built-Up-Export)........... 8Wa-80-93
Right Side Repeater Lamp
(Built-Up-Export)................ 8Wa-80-93
Right Speed Control Switch
(Except Base)................... 8Wa-80-93
Right Tail/Stop Lamp............... 8Wa-80-93
Right Visor/Vanity Lamp (Except Base) . 8Wa-80-94
Sentry Key Immobilizer Module
(Except Base)................... 8Wa-80-94
Shifter Assembly................... 8Wa-80-94
Siren (Built-Up-Export).............. 8Wa-80-94
Speed Control Servo................ 8Wa-80-94
Sunroof Motor..................... 8Wa-80-95
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-3

BLEND DOOR ACTUATOR - WHITE 4 WAY
CAV CIRCUIT FUNCTION
1 Z12 18BK/TN GROUND
2 C35 20DG/YL MODE DOOR DRIVER (A)
3 V23 20BR/PK FUSED IGNITION SWITCH OUTPUT (RUN)
4- -
BLOWER MOTOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 C7 12BK/TN BLOWER MOTOR HIGH DRIVER
2 A111 12RD/LB BLOWER MOTOR RELAY OUTPUT
BLOWER MOTOR RESISTOR BLOCK - BLACK 10 WAY
CAV CIRCUIT FUNCTION
1 C7 12BK/TN BLOWER MOTOR HIGH DRIVER
2 C7 12BK/TN BLOWER MOTOR HIGH DRIVER
3 C6 12LB BLOWER MOTOR M2 DRIVER
4 C5 14LG BLOWER MOTOR M1 DRIVER
5 C4 14TN BLOWER MOTOR LOW DRIVER
6- -
7- -
8- -
9- -
10 - -
BODY CONTROL MODULE C1 - GRAY 26 WAY
CAV CIRCUIT FUNCTION
1 Z103 16BK/OR GROUND
2 V22 20BR/YL REAR WIPER INTERMITTENT DRIVER
3 Y98 20GY/DB INSTRUMENT CLUSTER WAKE UP SIGNAL
4 G75 20TN DRIVER DOOR AJAR SWITCH SENSE
5 G74 20TN/WT PASSENGER DOOR AJAR SWITCH SENSE
6 G70 20BR/TN (EXCEPT BASE) HOOD AJAR SWITCH SENSE
7 G78 20TN/BK TAILGATE AJAR SWITCH SENSE
8 G26 20LB KEY-IN IGNITION SWITCH SENSE
9 G80 20YL/WT FLIP-UP GLASS AJAR SWITCH SENSE
10 M3 20PK/DB REAR COURTESY LAMP CONTROL
11 V10 18BR WASHER PUMP DRIVER
12 L91 20DB/PK HAZARD LAMP CONTROL
13 V21 20DB/RD REAR WIPER ON DRIVER
14 Z231 16BK/WT SIGNAL GROUND
15 D25 18YL/VT/WT PCI BUS
KJ8W-80 CONNECTOR PIN-OUTS8Wa-80-9

IDLE AIR CONTROL MOTOR - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 K59 18VT/BK IDLE AIR CONTROL MOTOR NO. 4 DRIVER
2 K40 18BR/WT IDLE AIR CONTROL MOTOR NO. 1 DRIVER
3 K60 18YL/BK IDLE AIR CONTROL MOTOR NO. 2 DRIVER
4 K39 18GY/RD IDLE AIR CONTROL MOTOR NO. 3 DRIVER
IGNITION SWITCH - BLACK 10 WAY
CAV CIRCUIT FUNCTION
1 A1 12RD FUSED (+)
2 A21 12RD/DB IGNITION SWITCH OUTPUT (RUN-START)
3 F81 12TN IGNITION SWITCH OUTPUT (RUN-ACC)
4 A25 12DB FUSED B(+)
5 G26 20LB KEY-IN IGNITION SWITCH SENSE
6 A41 12YL IGNITION SWITCH OUTPUT (START)
7 A31 12BK/WT IGNITION SWITCH OUTPUT (RUN-ACC)
8 A22 12BK/OR IGNITION SWITCH OUTPUT (RUN)
9 A2 12PK/BK FUSED B (+)
10 Z232 16BK/LB GROUND
INPUT SPEED SENSOR (3.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 T52 18RD/BK INPUT SPEED SENSOR SIGNAL
2 T13 18DB/BK SPEED SENSOR GROUND
INSTRUMENT CLUSTER - BLACK 20 WAY
CAV CIRCUIT FUNCTION
1 Z105 20BK/LG GROUND
2- -
3 Y98 20GY/DB INSTRUMENT CLUSTER WAKE UP SIGNAL
4- -
5 G18 20PK/BK LOW COOLANT FLUID LEVEL SENSE
6 L63 20DG/RD LEFT TURN SIGNAL
7 G9 20GY/BK PARK BRAKE SWITCH SENSE
8 G69 20BK/OR VTSS INDICATOR DRIVER
9- -
10 M1 20PK FUSED B(+)
11 L78 20DG/YL FUSED PARK LAMP RELAY OUTPUT
12 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
13 - -
14 D25 20YL/VT/RD PCI BUS
15 - -
8Wa - 80 - 64 8W-80 CONNECTOR PIN-OUTSKJ

REAR POWER WINDOW SWITCH (MIDLINE/HIGHLINE) - WHITE 10 WAY
CAV CIRCUIT FUNCTION
1 Q28 14DG/WT RIGHT REAR WINDOW DRIVER DOWN
2 Q14 14GY RIGHT REAR WINDOW DRIVER UP
3 Q24 14DG RIGHT REAR WINDOW DRIVER DOWN
4 Q18 14GY/BK RIGHT REAR WINDOW DRIVER UP
5 Q1 16YL POWER WINDOW SWITCH FEED
6 Q1 16YL POWER WINDOW SWITCH FEED
7 Q17 14DB/WT LEFT REAR WINDOW DRIVER UP
8 Q23 14RD/WT LEFT REAR WINDOW DRIVER DOWN
9 Q27 14RD/BK LEFT REAR WINDOW DRIVER DOWN
10 Q13 14DB LEFT REAR WINDOW DRIVER UP
REAR WHEEL SPEED SENSOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 B2 18YL REAR WHEEL SPEED SENSOR 12 VOLT SUPPLY
2 B1 18YL/DB REAR WHEEL SPEED SENSOR SIGNAL
REAR WIPER MOTOR - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 Z235 18BK GROUND
2 V21 20DB/RD REAR WIPER ON DRIVER
3 G80 20YL/WT FLIP-UP GLASS AJAR SWITCH SENSE
4 V22 20BR/YL REAR WIPER INTERMITTENT DRIVER
5 F70 18PK/BK FUSED B(+)
6- -
RED BRAKE WARNING INDICATOR SWITCH - GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 G11 18WT/BK RED BRAKE WARNING INDICATOR DRIVER
2 Z142 18BK/WT GROUND
REMOTE KEYLESS ENTRY MODULE (EXCEPT BASE)-6WAY
CAV CIRCUIT FUNCTION
1 Y60 RKE DATA
2 Y62 RKE SUPPLY
3 Y61 RKE PROGRAM
4 Y63 RKE GROUND
5 Y64 RKE ANTENNA (+)
6 Y65 RKE ANTENNA (-)
8Wa - 80 - 86 8W-80 CONNECTOR PIN-OUTSKJ

RIGHT VISOR/VANITY LAMP (EXCEPT BASE) - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 M1 20PK FUSED B(+)
2 M20 20BR COURTESY LAMP LOAD SHED
SENTRY KEY IMMOBILIZER MODULE (EXCEPT BASE) - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 F33 20PK/RD FUSED B(+)
2 Z11 20BK/WT GROUND
3 F1 20DB FUSED IGNITION SWITCH OUTPUT (RUN-START)
4 Z110 20BK/TN GROUND
5 D25 20YL/VT/BK PCI BUS
6- -
SHIFTER ASSEMBLY - WHITE 6 WAY
CAV CIRCUIT FUNCTION
1 E2 20OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
2 Z21 20BK/LG GROUND
3 T6 20VT/WT OVERDRIVE OFF SWITCH SENSE
4 Z21 20BK/LG GROUND
5 F22 18DB/PK FUSED IGNITION SWITCH OUTPUT (RUN)
6 K29 20WT/PK BRAKE SWITCH SENSE
SIREN (BUILT-UP-EXPORT)-3WAY
CAV CIRCUIT FUNCTION
1 Z142 18BK/WT GROUND
2 X75 18DG SIREN SIGNAL CONTROL
3 M1 18PK FUSED B(+)
SPEED CONTROL SERVO - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 V36 18TN/RD SPEED CONTROL VACUUM SOLENOID CONTROL
2 V35 18LG/RD SPEED CONTROL VENT SOLENOID CONTROL
3 V30 18DB/RD SPEED CONTROL BRAKE SWITCH OUTPUT
4 Z212 18BK/OR GROUND
8Wa - 80 - 94 8W-80 CONNECTOR PIN-OUTSKJ
