4. Remove the bulb from the bulb socket by pulling thebulb straight out.
5. Insert the new bulb, making sure that it is locked intoplace.
6. Reinstall the socket in to the transparent lens assembly.
7. Reinstall the cover on the outside rear view mirror, making sure it is locked into place.
Transparent Lens AssemblyBulb And Socket Assembly
1 — Bulb
2 — Bulb Socket
7
IN CASE OF EMERGENCY 329

Rear Tail Lamps
Contain the following:
•Position lights
• Stop lights
• Direction indicator
• REVERSE lights
To replace the bulbs proceed as follows:
1. Open the liftgate.
2. Using a suitable tool remove the door as shown. 3. Using a suitable tool remove fastener.
4. Disconnect the electrical connector by pushing the re-
lease.
Trim Panel Door
Rear Lamp Fastener and Electrical Connector
1 — Fastener
2 — Electrical Connector
330 IN CASE OF EMERGENCY

5. Remove the rear tail lamp, sliding it toward the outsideas shown. 6. Unscrew the screws and remove the rear tail lamp
holder.
Tail Lamp RemovalRear Lamp Assembly
1 — Mounting Screws
7
IN CASE OF EMERGENCY 331

7. Replace the bulb as necessary.
8. Insert the new bulb, making sure it is properly locked.
9. Reassemble the lamp assembly on the rear tail lamphousing, tightening the screws.
10. Reposition the rear tail lamp on the car.
11. Secure the fastener of the rear tail lamp and reconnect the electrical connector. 12. Reinstall the door making sure of its correct locked.
13. Finally close the tailgate.
Center High Mounted Stop Lamp (CHMSL)
The CHMSL is LED. For replacement see your authorized
dealer.
License Plate Lights
To replace the bulbs proceed as follows:
1. Using a suitable tool remove the license plate lens.
Rear Tail Lamp Holder
1 — Tail Light
2 — Reverse Bulb
3 — Position Light/Stop Light/Turn Signal
License Plate Light Location
332 IN CASE OF EMERGENCY

2. Remove the bulbs from the individual side contacts.
3. Insert the new bulbs, and ensure that they are properlylocked between the contacts.
4. Reinstall the license plate lens.
NOTE: If removal the license plate lens using a screw-
driver, be sure to cover the tip of the screwdriver with a
cloth so no damage is done to the lenses or the vehicle
paint.
Replacing Interior Bulbs
Front Courtesy Light
To replace the bulbs proceed as follows:
1. Using a suitable tool remove the front courtesy light as shown.
License Plate Light
Front Courtesy Light Housing
7
IN CASE OF EMERGENCY 333

2. Release the retainer clips and bulb housing as shown.
3. Replace the bulbs by pulling straight out of bulb hous-ing. 4. Insert the new bulbs, making sure that they are properly
locked.
5. Reassemble the bulb housing and courtesy light housing making sure that they are properly locked.
6. Install the front courtesy light making sure that it is properly locked.
Front Courtesy Bulb Housing
1 — Retaining Clips
2 — Bulb Housing
Front Courtesy Bulb Housing
334 IN CASE OF EMERGENCY

Dome Light Vanity Mirror
To replace the bulbs proceed as follows:
1. Lift the cover of the mirror and pull out the visor mirrorlight cover.
2. Replace the bulb, releasing it from the side contacts, and then insert the new bulb, making sure that it is properly
locked between the contacts. 3. Reinstall the visor mirror light cover making sure that it
is properly locked.
4. Finally lower the visor mirror cover to the mirror.
Dome Light Glove Compartment
To replace the bulb proceed as follows:
1. Open the glove compartment;
2. Place your fingers inside the light assembly, pull the bulb to replace it.
Visor
1 — Visor Mirror Cover
2 — Visor Mirror LightBulb Removal/Installation
7
IN CASE OF EMERGENCY 335

3. Insert the new bulb, making sure it is properly locked.
Rear Dome Light — Without Retractable Roof
To replace the bulbs proceed as follows:
1. Using a suitable tool release the lamp assembly at boththe ends.
2. Open the flap and replace the bulb. 3. Insert the new bulb, locking it between the contacts.
4. Reinstall the dome light.
Dome Light — MY SKY
To replace the bulbs proceed as follows:
1. Lower the handle in the direction shown remove the
dome light.
Rear Dome Light Housing
1 — Bulb
2 — Flap
Retractable Roof Light
336 IN CASE OF EMERGENCY

2. Replace the bulb by removing it from the side contacts.
3. Insert the new bulb, locking it between the contacts.
4. Reinstall the dome light.
Interior Cargo Lights
To replace the bulbs proceed as follows:
1. Open the luggage compartment and remove the domelight assembly.
2. Open the light cover and replace the bulb. 3. Close the light cover over the bulb.
4. Reinstall the dome light in its correct position.
WARNING!
•Before proceeding with the replacement of the lamp wait
for the exhaust pipes are cool: DANGER OF BURNS!
• Modifications or repair of the electrical system per-
formed incorrectly and without taking into account
the technical characteristics can cause malfunctions
with the risk of fire.
(Continued)
Bulb
Light Cover
7
IN CASE OF EMERGENCY 337

WARNING!(Continued)
•Halogen lamps contain gas under pressure, in the
event of breakage be careful of the projection of
fragments of glass.
• Halogen lamps must be handled by touching only
the metallic part. If the transparent bulb is in contact
with the fingers, reduces the intensity of the emitted
light and you can also affect the life of the lamp. In
case of accidental contact, rub the bulb with a cloth
dampened with alcohol and allow to dry.
FUSES
WARNING!
• When replacing a blown fuse, always use an appro-
priate replacement fuse with the same amp rating as
the original fuse. Never replace a fuse with another
fuse of higher amp rating. Never replace a blown
fuse with metal wires or any other material. Failure
to use proper fuses may result in serious personal
injury, fire and/or property damage.
(Continued)
WARNING! (Continued)
•Before replacing a fuse, make sure that the ignition is
off and that all the other services are switched off
and/or disengaged.
• If the replaced fuse blows again, contact an autho-
rized dealer.
• If a general protection fuse for safety systems (air
bag system, braking system), power unit systems
(engine system, gearbox system) or steering system
blows, contact an authorized dealer.
General Information
The fuses protect electrical systems against excessive cur-
rent.
When a device does not work, you must check the electri-
cal circuit inside the fuse for a break/melt.
Also please be aware that when using power outlets for
extended periods of time with the engine off may result in
vehicle battery discharge.
