JEEP RENEGADE 2017 1.G Owners Manual

Exterior Bulbs
LampsBulb Number
Bi-Xenon HID Headlamps (Serviced At An Authorized Dealer)
Low Beam/High Beam Headlamps H13
Front Position/Daytime Running Lights (DRL) P21/5W
Front Direction Indicator Lamps PY21W
Front Fog Lamps H11
Side Indicators (Front And Side View Mirror) WY5W
Tail/Brake Lights/Turn Indicators P21W
Center High Mounted Stop Lamp (CHMSL) LED (Serviced At An Authorized Dealer)
Reverse W16W
License Plate Lamp W5W
7
IN CASE OF EMERGENCY 319

Replacing Exterior Bulbs
Headlamps
Hi/Lo Beam Light Halogen
To replace the bulbs proceed as follows:
1. Open the engine compartment and remove the head-lamp bulb cap.
2. Rotate the headlamp bulb socket counterclockwise then pull outwards. 3. Push on the locking tab on the headlamp bulb connector
and remove the bulb and socket.
Headlamp Bulb Cap
Headlamp Bulb Socket
320 IN CASE OF EMERGENCY

4. Install the new headlamp bulb making sure it is prop-erly locked.
5. Install the headlamp bulb and socket; turn it clockwise making sure it is properly locked.
WARNING!
Carry out the operation of replacing lamps only with
the engine off. Also make sure that the engine is cold,
to avoid the danger of burns.
Headlamp Bulb ConnectorHeadlamp Bulb
7
IN CASE OF EMERGENCY 321

Position Lights/Daytime Running Lights/Fog Lights
To replace the bulbs proceed as follows:
1. Turn the front wheels completely.
2. Use a suitable tool to remove the access door.
3. Remove the electrical connectors.4. Rotate in a counterclockwise direction (on the left-hand
socket) or in a clockwise direction (on the right-hand
socket) and remove the bulb and bulb socket.
Position Light/Daytime Running Light/Fog Light Access
1 — Screws
2 — Access Door
Electrical Connectors
322 IN CASE OF EMERGENCY

5. To replace the bulb gently push bulb and rotate coun-terclockwise. 6. Insert the new bulb by pushing on it and turning it
clockwise. Make sure the bulb is correctly locked in
place.
7. Install the bulb and sockets and rotate them clockwise (right side) and clockwise (left side), making sure that it
is properly locked.
8. Reconnect the electrical connectors.
Position Light/Daytime Running Light Assembly
1 — DRL Bulb Socket
2 — Turn Signal Bulb Socket
Bulb and Socket Assembly
1 — Bulb
2 — Rotate Bulb
7
IN CASE OF EMERGENCY 323

9. Reinstall the access door.
Front Fog Lights
To replace the bulbs proceed as follows:
1. Turn the front wheels completely.
2. Use a suitable tool to remove the access door.
3. By pushing the electrical connector tab remove theelectrical connector. 4. Rotate the bulb counterclockwise, and then replace the
bulb.
5. Insert the new bulb in the socket, making sure the bulb is locked into place.
6. Reconnect the electrical connector.
7. Reinstall the access door.
Position Light/Daytime Running Light/Fog Light Access
1 — Screws
2 — Access Door
Fog Light Assembly
1 — Bulb Socket
2 — Electrical Connector
3 — Bulb
324 IN CASE OF EMERGENCY

Side Indicators
Front Side Indicators
To replace the bulb proceed as follows:
1. Operating from inside the engine compartment using asuitable tool release the retaining clip. 2. Remove lamp assembly by sliding it toward the outside.
Lamp Retaining Clip
Lamp Assembly
7
IN CASE OF EMERGENCY 325

3. Remove the electrical connector by pushing the tab thendisconnect the electrical connector. 4. Rotate counterclockwise to release the bulb socket from
the lamp assembly, and remove it.
Electrical ConnectorBulb Socket
326 IN CASE OF EMERGENCY

5. Remove the bulb from the socket.
6. Insert the new bulb in the socket.
7. Reinstall the bulb and socket into the lamp assembly byturning it clockwise, making sure it is locked into place.
8. Reconnect the electrical connector.
9. Reinstall the lamp assembly on the car, making sure it is locked into place. Side Indicators on External Rear View Mirrors – (If
Equipped)
CAUTION!
The procedure is described as a guideline. For the
replacement of the lamp it is recommended that you
contact your authorized dealer.
To replace the bulb proceed as follows:
1. Remove the mirror cap on the outside rear view mirror.
Bulb
Mirror Cap
7
IN CASE OF EMERGENCY 327

2. Remove the transparent lens assembly as shown. 3. Remove the bulb socket and bulb from the transparentlens assembly by rotating the socket counterclockwise.
Removing the mirror capTransparent Lens
