Fuse Removal
To replace a fuse use the extractor attached to the fuse
cover (located on the inside of the engine compartment
fuse cover.
Blade Fuses
1 — Electrical Circuit
2 — Blade Fuse With Good Electrical Circuit
3 — Blade Fuse With Bad Electrical CircuitFuse Extractor Location
7
IN CASE OF EMERGENCY 339

Access To The Fuses
The fuses are grouped into four controllers located in the
engine compartment, under the instrument panel and on
the inside of the left side cargo trim panel.
Engine Compartment Fuses/Distribution Unit
The engine compartment fuse panel is located on the left
side of the engine compartment.Removing Fuse Cover and Locking Screw
Proceed as follows:
•Slowly turn the screw counterclockwise.
• Slowly release the screw.
• Remove the fuse cover by sliding it upward.
Engine Compartment Fuse Cavities
Fuse Panel & Cover Location
1 — Mounting Screw
2 — Fuse Cover
340 IN CASE OF EMERGENCY

Mounting Fuse Cover and Locking Screw
Proceed as follows:
•Properly secure the fuse cover to the box, slide com-
pletely from top to bottom.
• Fully depress the screw, using the special screwdriver
supplied.
• Slowly turn the screw clockwise.
• Release the screw.
Cavity Maxi FuseCartridge Fuse Micro Fuse Description
F01 70 Amp Tan ––Module Body Com-
puter
F02 70 Amp Tan ––Module Body Com-
puter, Rear Distribu- tion Units
Battery Fuse Cover Location
1 — Fuse Cover Tabs
2 — Fuse Cover
7
IN CASE OF EMERGENCY 341

CavityMaxi FuseCartridge Fuse Micro Fuse Description
F03 –20 Amp Blue –Controller Power
Supply Body Com- puter
F04 –30 Amp Pink –Brake Control Elec-
tronics Module
F05 70 Amp Tan ––Electric Power-
Assisted Steering
F06 20 Amp Yellow ––Engine Cooling fan
F07 40 Amp Orange –
1.4 Without A/C
50 Amp Red – 1.4
With A/C And All 2.4 Models –
–Engine Cooling fan
F08 –30 Amp Pink –Automatic Transmis-
sion, GSM
F09 ––5 Amp Tan Control Module En-
gine
F10 ––15 Amp Blue Horn
F11 ––10 Amp Red – 1.4
Engines
25 Amp Clear – 2.4 Engines Supply Secondary
Loads
342 IN CASE OF EMERGENCY

CavityMaxi FuseCartridge Fuse Micro Fuse Description
F14 ––7.5 Amp Brown Heater Blow By
F14 ––5 Amp Tan Pump Power After
Run
F15 40 Amp Orange ––Brake Control Mod-
ule Pump
F16 ––5 Amp Tan Engine Control Mod-
ule Power, AutomaticTransmission
F17 ––10 Amp Red – 1.4
Engines
15 Amp Blue – 2.4 Engines Supply Primary
Loads
F18 ––20 Amp Yellow 12V Rear Cargo Out-
let Ignition Powered
F19 ––7.5 Amp Brown Air Conditioner
Compressor
F20 ––5 Amp Tan Electronic Power
Four-Wheel Drive
F21 ––15 Amp Blue Fuel Pump
F22 ––20 Amp Yellow Power Control Mod-
ule Engine
7
IN CASE OF EMERGENCY 343

CavityMaxi FuseCartridge Fuse Micro Fuse Description
F23 ––30 Amp Green Heated Windshield –
If Equipped
F24 ––15 Amp Blue Electronic Unit Sup-
ply Automatic Trans-mission
F30 ––20 Amp Yellow
(Customer Installed) 12V Rear Cargo Out-
let Constant Battery Powered
F83 –40 Amp Green –Air Conditioning Fan
F84 ––30 Amp Green Power Supply All
Wheel Drive
F87 ––5 Amp Tan Gear Selector Auto-
matic Transmission
F88 ––7.5 Amp Brown Heated Outside Mir-
rors
F89 ––30 Amp Green Heated Rear Window
F90 ––5 Amp Tan IBS Sensor (Battery
State Of Charge)
344 IN CASE OF EMERGENCY

Body Computer Fuse Center
The controller is located at the left side of the steering
column at the bottom of the instrument panel.
For the fuse replacement see your authorized dealer.
Body Controller Fuse Cavities
7
IN CASE OF EMERGENCY 345

CavityMini FuseDescription
F31 7.5 Amp BrownFlashes/Electrical Movement Front
Seats/Fan Air Conditioning
F33 20 Amp YellowPower Window Front (Driver Side)
F34 20 Amp YellowPower Window Front (Passenger
Side)
F36 15 Amp BlueSupply Uconnect System, Air Condi-
tioning, Alarm, Power Folding Out-
side Mirrors, USB Port
F37 10 Amp RedSystem Power Forward Collision
Warning Plus, All Wheel Drive
(AWD), IPC
F38 20 Amp YellowCentral Locking
F42 7.5 Amp BrownPower Under Lock and Key
F43 20 Amp YellowBi-directional Pump Washer
F47 20 Amp YellowPower Rear Window (Driver Side)
F48 20 Amp YellowPower Rear Window (Passenger Side)
F49 7.5 Amp BrownSupply ParkSense, Spot Lights Front
Dome, Mirror, Electric Motor Retract-
able Roof, Heated Front Seats, Stabi-
lizer Battery, ESC System, ESL
F50 7.5 Amp BrownSupply Air Bag
346 IN CASE OF EMERGENCY

CavityMini FuseDescription
F51 7.5 Amp BrownAlarm Power, Front Courtesy Light,
Air Conditioning Compressor, Brake
Pedal Switch (NC), Plaque Automatic
Transmission, Compass, Rear Cam-
era, Leveling Headlights, Air Condi-
tioning
F53 7.5 Amp BrownSupply IPC/Starter Device/System
Keyless Enter-N-Go
F94 15 Amp BluePower Socket
7
IN CASE OF EMERGENCY 347

Rear Cargo Fuse/Relay Distribution Unit
To access the fuses, remove the access door from the left
rear panel of the rear cargo area.
The fuses may be contained in two units. fuse holder No. 1
is located closest to the rear of the vehicle and fuse holder
No. 2 (if equipped with trailer towing) is located closest to
the front of the vehicle.
Fuse Holder No. 1
CavityMini FuseDescription
F1 30 Amp BluePower Inverter
F2 20 Amp YellowHIFI Audio System
F3 20 Amp YellowMY SKY
F4 7.5 Amp BrownLumbar Adjustment Front Seat
(Driver Side)
Rear Cargo Fuse Cavities
1 — Fuse Holder No. 1
2 — Fuse Holder No. 2
