JEEP RENEGADE 2018 Owner handbook (in English)

Important
Apply the plate in a highly visible point
of the vehicle, near the mounting pipe or
inside the luggage compartment.
To ensure correct operation of the
system, periodically remove all deposits
of dirt which may have accumulated on
the ball head bar and from the mounting
pipe. The lock must only be treated with
graphite.
Periodically lubricate the joints, the
sliding surfaces and the balls with grease
without resin or oil. Lubrication is also a
further corrosion protection.
if the vehicle is washed with
high-pressure jets, the ball head bar
must be removed and the dedicated plug
fitted. The ball head bar must never be
treated with high-pressure jets.
Two keys are supplied together with the
removable ball tow bar. Note down the
four-digit key number and keep it in a
safe place. This number is to be used for
ordering any duplicate keys that may be
required.
IMPORTANT To install a tow hook
contact a Jeep Dealership.
WARNING
148)The ABS with which the car is
equipped will not control the braking
system of the trailer. Particular caution is
required on slippery roads.
149)Never modify the braking system of
the vehicle to control the trailer brake.
The trailer braking system must be fully
independent of the car’s hydraulic system.
189

IN AN EMERGENCY
A punctured tyre or a burnt-out bulb?
At times, a problem may interfere with
our journey.
The pages on emergencies can help you
to deal with critical situations
independently and with calm.
In an emergency we recommend that you
call the freephone number found in the
Warranty Booklet.
It is also possible to call the national or
international universal freephone number
to search for the nearest Dealership.HAZARD WARNING LIGHTS......192
CHANGING A BULB...........193
REPLACING FUSES...........202
CHANGING A WHEEL.........209
TIREKIT..................215
JUMP STARTING.............218
FUEL CUT-OFF SYSTEM........220
AUTOMATIC TRANSMISSION GEAR
LEVER UNLOCKING..........220
TWIN CLUTCH AUTOMATIC
TRANSMISSION LEVER UNLOCK . .222
BROKEN-DOWN VEHICLE TOWING .224
TOWING THE VEHICLE.........225
191

HAZARD WARNING
LIGHTS
CONTROL
Press the button fig. 141 to switch the
lights on/off.
When the hazard warning lights are on,
the
andwarning lights flash.
IMPORTANT The use of hazard
warning lights is governed by the
highway code of the country you are
driving in: comply with legal
requirements.
Emergency braking
In the event of emergency braking the
hazard warning lights switch on
automatically as well as warning lights
andin the instrument panel.
The lights switch off automatically when
emergency braking ceases.
141J0A0954C
192
IN AN EMERGENCY

CHANGING A BULB
150) 151) 152) 153)76)
GENERAL INSTRUCTIONSBefore replacing a bulb check the
contacts for oxidation;
replace blown bulbs with others of the
same type and power;
after replacing a headlight bulb,
always check its alignment;
when a light is not working, check
that the corresponding fuse is intact
before replacing the bulb. For the
location of fuses, refer to the paragraph
“If a fuse blows” in this chapter.
IMPORTANT When the weather is cold
or damp or after heavy rain or washing,
the surface of headlights or rear lights
may steam up and/or form drops of
condensation on the inside. This is a
natural phenomenon due to the
difference in temperature and
humidity between the inside and the
outside of the glass which does not
indicate a fault and does not
compromise the normal operation of
lighting devices. The mist disappears
quickly when the lights are turned on,
starting from the centre of the diffuser,
extending progressively towards the
edges.
193

Light bulbsType Power
Front position/Daytime running lights (D.R.L.) P21/5W 21/5W
Rear side/brake lightP21W 21 W
Low/high beams (halogen)H4 60/55W
Main beam/dipped beam headlights (Xenon gas discharge) D5S 25 W
Front direction indicatorsPY21W 21 W
Rear direction indicatorsW16W 16 W
Side directional indicators (front and on the external rear voew mirror) WY5W 5 W
3rd stopLED –
Number plateW5W 5 W
Fog lightsH11 55 W
Rear fog lightW16W 16 W
Reversing lightW16W 16 W
194
IN AN EMERGENCY

Light bulbsType Power
Front ceiling lightC5W 5 W
Front ceiling light (shade flaps) C5W 5 W
Rear ceiling light (versions without sun roof) C5W 5 W
Rear ceiling lights (versions with openable roof) C5W 5 W
Luggage compartment light W5W 5 W
Glove compartment lightW5W 4 W
195

REPLACING AN EXTERNAL BULB
Front upper light group (halogen high/low
beams)
To replace the bulb, proceed as follows:
working from inside the engine
compartment, remove cover A fig. 142,
using the dedicated tab;
turn the bulb and bulb holder
assembly B fig. 143 anticlockwise and
then remove it sliding it outwards;
remove, sliding it outwards, the bulb
and bulb holder assembly C fig. 144,
disconnecting it from connector D;
install the new bulb and bulb holder
assembly, ensuring that it is locked
correctly;
then insert the bulb and bulb holder
assembly in its housing and turn it
clockwise, making sure that it is locked
correctly.
Front upper light group (Xenon gas emitting
high/low beams)
For this replacement, please refer to the
Jeep Assistance network.
Front lower light cluster
Parking light/daytime running lights
(D.R.L.) and front directional indicators
To replace the bulbs, proceed as follows:
steer the wheels completely;using the screwdriver, undo screws A
fig. 145 and remove flap B;
142J0A0260C
143J0A0261C
144J0A0414C
196
IN AN EMERGENCY

remove electrical connectors C
fig. 146;
turn anticlockwise (on the left device)
or clockwise (on the right device) and
remove the bulb and bulb holder
assemblies fig. 147: D = side
lights/daytime running lights (DRLs), E =
direction indicators;
replace the burnt bulb: to extract it,
press lightly on it (1 fig. 148 ) and at the
same time turn it counter-clockwise (2);
insert the new bulb, by pressing it
fig. 148 and turning it clockwise, making
sure that it locks correctly;
then insert the bulb and bulb holder
assemblies in their respective housings
and turn them anticlockwise (right side)
and clockwise (left side), ensuring that
they are locked correctly;
reconnect the electrical connectors;finally, refit flap B fig. 145, fully
tightening fixing screws A.
Front fog lights
To replace the bulbs, proceed as follows:
steer the wheels completely;using the screwdriver, undo screws A
fig. 149 and remove flap B;
145J0A0211C
146J0A0306C
147J0A0263C
148J0A0264C
197

using tab C fig. 150, remove electrical
connector D;
turn the light bulb and holder E
fig. 150 counter-clockwise and replace
the bulb;
insert the new bulb and holder group,
making sure it is properly blocked;
reconnect the electrical connection;finally replace flap B fig. 149,
screwing down the attachment screws A
completely.
Side turn light
Side direction indicators on door mirrors
(where provided)
For light bulb replacement, please refer
to Jeep Assistance Network.
Rear upper light group
This contains the parking lights, brake
lights and directional indicators.
To replace the bulbs, proceed as follows:
open the tailgate;with the point indicated with an
arrows, remove flap A fig. 151;
unscrew fixing device B fig. 152;disconnect the electrical connector,
working on device C;
149J0A0211C
150J0A0301C
151J0A0637C
198
IN AN EMERGENCY
