jacking JEEP RENEGADE 2023 Owners Manual

5
NAVIGATION MODE — IF EQUIPPED
(UCONNECT 4C NAV ONLY) ...... ......................... 180
Operating Navigation ...... ............................. 180
Where To? . ..
..
. ............................................... 180
View Map ...................................................... 191
Infor m
ation . ..
..
. ............................................. 199
Emergency ..... . .............................................. 200
Map Updates . ..
. .
. .......................................... 200
SiriusXM® Travel Link ..... . ............................ 201
SiriusXM® Traffic Plus ..... . ........................... 201
CONNECTED VEHICLE SERVICES —
IF EQUIPPED ..... .
.................................................. 202
Is My Vehicle Connected?...... ....................... 202
Introduction To Connected Vehicle
Services . ........................................................ 202
Getti
ng Started With Connected Vehicle
Services . ........................................................ 203
Using
SiriusXM Guardian™ . ..
..
. .................... 205
Manage My SiriusXM Guardian™ Account .. 215
C O
NNECTED SERVICES FAQS . ..
..
. ..................... 215
Connected Services SOS FAQs —
If Equipped ..... .
.............................................. 215
Connected Services Remote Door Lock/
Unlock FAQs . .....
............................................ 215
Connected Services Roadside Assistance
FAQs . ............................................................. 216
Connec
ted Services Send & Go FAQs —
If Equipped . .....
.............................................. 216 Connected Services Vehicle Finder FAQs ... 21
6
C
onnected Services Stolen Vehicle
Assistance FAQs — If Equipped . .....
............. 217
Connected Services Remote Vehicle Start
FAQs . ............................................................. 217
Connec
ted Services Remote Horn & Lights
FAQs . .............................................................. 217
Connec
ted Services Account
FAQs — If Equipped . .....
................................. 218
Data Collection & Privacy ..... . ....................... 220
RADIO OPERATION AND MOBILE PHONES . ..
..
2 20
Regulatory And Safety Information ...... ........ 220
SAFETY
SAFETY FEATURES .............................................. 221
Anti-Lock Brake System (ABS) ...... ............... 221
Electronic Brake Control (EBC) System . ..
..
. . 222
AUXILIARY DRIVING SYSTEMS ..... . ................... 228
Blind Spot Monitoring (BSM) —
If Equipped..... .
............................................... 228
Forward Collision Warning (FCW) With
Mitigation Operation — If Equipped . .....
....... 232
Tire Pressure Monitoring System (TPMS) .... 2 3 5
OCCUPANT RESTRAINT SYSTEMS . ..
..
. ............. 240
Occupant Restraint Systems ...... .................. 240
Important Safety Precautions . ..
..
. ................ 240
Seat Belt Systems ..... . ................................... 241
Supplemental Restraint Systems (SRS) ..... . 246
Child Restraints . ..
..
. ...................................... 255 SAFETY TIPS .....
.
................................................... 265
Transporting Passengers...... ........................ 265
Transporting Pets ..... . .................................... 265
Connected Vehicles . ..
..
. ................................ 265
Safety Checks You Should Make Inside The
Vehicle . ......................................................... 265
Period
ic Safety Checks You Should Make
Outside The Vehicle . .....
................................ 267
Exhaust Gas ..... . ............................................ 267
Carbon Monoxide Warnings ..... . ................... 267
IN CASE OF EMERGENCY
HAZARD WARNING FLASHERS ......................... 268
ASSIST AND SOS SYSTEM — IF EQUIPPED ...... 268
JACKING AND TIRE CHANGING ...... .................. 271
Preparations For Jacking ...... ....................... 271
Jack Location/Spare Tire Stowage ..... . ....... 272
Jacking Instructions ..... . ................................ 273
TIRE SERVICE KIT — IF EQUIPPED . ..
..
. ............... 276
Tire Service Kit Storage ...... .......................... 276
Tire Service Kit Components And
Operation . ...................................................... 276
Tire
Service Kit Usage Precautions ..... . ........ 277
Replacing The Sealant . ..
..
. ............................ 278
JUMP STARTING ..... . ............................................ 278
Preparations For Jump Start ...... .................. 278
Jump Starting Procedure ..... . ........................ 279

IN CASE OF EMERGENCY 271
(Continued)
LTE (voice/data) or 4G (data) network conges -
tion.
Weather.
Buildings, structures, geographic terrain, or
tunnels.
NOTE:
Your vehicle may be transmitting data as autho -
rized by the subscriber.
Never place anything on or near the vehicle’s
LTE (voice/data) or 4G (data) and GPS
antennas. You could prevent LTE (voice/data) or
4G (data) and GPS signal reception, which can
prevent your vehicle from placing an emergency
call. An operable LTE (voice/data) or 4G (data)
network connection and a GPS signal is
required for the SOS Call system to function
properly.
NOTE:
Changes or modifications not expressly approved
by th e
party responsible for compliance could void
the user's authority to operate the equipment.
Automatic SOS — If Equipped
Automatic SOS is a hands-free safety service that
c an im

mediately connect you with help in the event
that your vehicle’s airbags deploy. Please refer to
your provided radio supplement for complete
information.
JACKING AND TIRE CHANGING
PREPARATIONS FOR JACKING

1. Park the vehicle on a firm level surface as far from the edge of the roadway as possible.
Avoid icy or slippery areas.

2. Turn on the Hazard Warning Flashers.
3. A ppl

y the Electric Park Brake.
4 .
Pl
a

ce the gear selector into PARK (P)
(aut om

atic transmission) or REVERSE (R)
(manual transmission).
5. Turn the ignition to the OFF position.
WARNING!
ALWAYS obey traffic laws and pay attention to
the road. ALWAYS drive safely with your hands on
the steering wheel. You have full responsibility
and assume all risks related to the use of the
features and applications in this vehicle. Only
use the features and applications when it is safe
to do so. Failure to do so may result in an
accident involving serious injury or death.
WARNING!
Do not attempt to change a tire on the side of
the vehicle close to moving traffic. Pull far
enough off the road to avoid the danger of
being hit when operating the jack or changing
the wheel.
Being under a jacked-up vehicle is dangerous.
The vehicle could slip off the jack and fall on
you. You could be crushed. Never put any part
of your body under a vehicle that is on a jack.
If you need to get under a raised vehicle, take
it to a service center where it can be raised on
a lift.
Never start or run the engine while the vehicle
is on a jack.
The jack is designed to be used as a tool for
changing tires only. The jack should not be
used to lift the vehicle for service purposes.
The vehicle should be jacked on a firm level
surface only. Avoid ice or slippery areas.
WARNING!
Do not attempt to change a tire on the side of
the vehicle close to moving traffic. Pull far
enough off the road to avoid being hit when
operating the jack or changing the wheel.
WARNING!
7

272 IN CASE OF EMERGENCY
6. Block both the front and rear of the wheel
diagonally opposite of the jacking position. For
example, if changing the driver’s front tire,
block the passenger’s rear wheel.

Wheel Blocked Example

NOTE:
Passengers should not remain in the vehicle when
the v e
hicle is being lifted or raised.
JACK LOCATION/SPARE TIRE STOWAGE
If equipped, the jack and tools are located under
the load floor in the rear storage compartment.

1. Open the liftgate.

2. Lift

the access cover using the load floor
hand l

e.

Load Floor Handle

3. Remove the jack, wheel bolt wrench and chock s

.
Jack And Tools Location

4. Remove the fastener securing the spare tire by turni
ng it counterclockwise.

Spare Tire Fastener Removal

IN CASE OF EMERGENCY 273
(Continued)
5. Remove the spare tire.
Jack And Tools
JACKING INSTRUCTIONS

Jack Warning Label

1. Remove the spare tire, jack, and wheel bolt wrench.

2

. If equipped with wheels where the center cap covers
the wheel bolts, use the wheel bolt
wrench to pry the center cap off carefully
before raising the vehicle.
1 — Wheel Bolt Wrench
2 — Jack
3 — Emergency Funnel
4 — Wheel Chocks
5 — Screwdriver
6 — Emergency Allen KeyWARNING!
A loose tire or jack thrown forward in a collision
or hard stop could endanger the occupants of
the vehicle. Always stow the jack parts and the
spare tire in the places provided. Have the
deflated (flat) tire repaired or replaced
immediately.
WARNING!
Carefully follow these tire changing warnings to
help prevent personal injury or damage to your
vehicle:
Always park on a firm, level surface as far from
the edge of the roadway as possible before
raising the vehicle.
Turn on the Hazard Warning Flashers.
Apply the parking brake and place an auto
-
matic transmission in PARK.
Chock the wheel diagonally opposite the
wheel to be raised.
Never start or run the engine with the vehicle
on a jack.
Do not let anyone sit in the vehicle when it is
on a jack.
Do not get under the vehicle when it is on a
jack. If you need to get under a raised vehicle,
take it to a service center where it can be
raised on a lift.
Only use the jack in the positions indicated
and for lifting this vehicle during a tire change.
If working on or near a roadway, be extremely
careful of motor traffic.
To assure that spare tires, flat or inflated, are
securely stowed, spares must be stowed with
the valve stem facing the ground.
WARNING!
7

274 IN CASE OF EMERGENCY
3. Before raising the vehicle, use the wheel bolt
wrench to loosen, but not remove, the wheel
bolts on the wheel with the flat tire. Turn the
wheel bolts counterclockwise one turn while
the wheel is still on the ground.

Jacking Locations

4. Place the jack underneath the jacking location that

is closest to the flat tire. Jacking location
is indicated by a stamped arrow on the body.
Turn the jack screw clockwise to firmly engage
the jack saddle with the lift area of the sill
flange, centering the jack saddle inside the
cutout in the sill cladding.
NOTE:
Placement for the front and rear jacking locations
are c r
itical. See below images for proper jacking
locations.

Front Lifting Point
Front Jacking Location Rear Lifting Point
Rear Jacking Location

5. Raise the vehicle just enough to remove the flat

tire.
CAUTION!
Do not attempt to raise the vehicle by jacking on
locations other than those indicated in the
Jacking Instructions for this vehicle.

353
Deleting A Phone...........................................168Dimmer SwitchHeadlight.....................................................37DipsticksOil (Engine)................................................294Disabled Vehicle Towing................................283Disc Drive......................................................162Disconnecting................................................168DisposalAntifreeze (Engine Coolant).......................301Disturb...........................................................171Door Ajar..........................................................71Door Ajar Light.................................................71Door Locks......................................................24Drag & Drop...................................................149Driver Memory Presets..................................160Driver’s Seat Back Tilt..............................26, 27Driving...........................................................130
E
Electric Brake Control System.......................222Anti-Lock Brake System.............................221Electric Park Brake..........................................82Electric Parking Brake.....................................82Electrical Outlet, Auxiliary (Power Outlet).........50Electronic Roll Mitigation (ERM)....................222Electronic Speed Control (Cruise Control)........95Electronic Stability Control (ESC)...................223Electronic Throttle Control Warning Light........71
Emergency Gas Can Refueling......................280
Emergency, In Case OfHazard Warning Flasher...........................268Jacking.....................................................271Jump Starting...........................................278Overheating..............................................281Tow Hooks................................................284Towing......................................................283Emission Control System Maintenance...........78Engine...........................................................293Air Cleaner................................................296Break-In Recommendations........................82Checking Oil Level....................................294Compartment...........................................293Coolant (Antifreeze)..................................345Cooling.....................................................299Exhaust Gas Caution................................267Fails To Start...............................................80Flooded, Starting.........................................80Fuel Requirements...................................342Jump Starting...........................................278Oil...........................................295, 344, 345Oil Filler Cap.............................................293Oil Filter....................................................296Oil Selection....................................295, 344Oil Synthetic.............................................295Overheating..............................................281Starting........................................................80Enhanced Accident Response
Feature................................................252, 285
Ethanol.........................................................342
Exhaust Gas Cautions...................................267Exhaust System...................................267, 298Exterior Lighting...............................................36Exterior Lights........................................36, 267
F
Family Alerts.................................................214Filters Air Cleaner................................................296Air Conditioning...........................................48Engine Oil........................................296, 345Engine Oil Disposal...................................296FlashersHazard Warning........................................268Turn Signals................................39, 76, 267Flash-To-Pass...................................................37Flat Tire Changing.........................................271Flat Tire Stowage..........................................273Flooded Engine Starting...................................80Floor Console...................................................49Fluid Capacities............................................344Fluid Leaks....................................................267Fluid Level ChecksEngine Oil.................................................294Fluid, Brake...................................................345Fog Lights........................................................38Fold-Flat Seats.................................................26Forward Collision Warning...................228, 232Freeing A Stuck Vehicle.................................282
11

354
Fuel...............................................................342Adding.......................................................122Additives...................................................343Clean Air....................................................342Ethanol......................................................342Gasoline....................................................342Gauge..........................................................73Materials Added........................................343Methanol...................................................342Octane Rating.................................342, 345Requirements...........................................342Specifications............................................345Fuses.............................................................303
G
Gasoline, (Fuel).............................................342Gasoline, Clean Air........................................342Gasoline, Reformulated.................................342Gauges
Fuel.............................................................73Gear Selector Override..................................281Glass Cleaning...............................................340Gross Axle Weight Rating...............................124GVWR............................................................123
H
Hazard Warning Flashers..............................268Head Restraints...............................................31Head Rests......................................................31
HeadlightsAutomatic....................................................38Automatic High Beam..................................37Cleaning...................................................338Delay...........................................................38High Beam/Low Beam Select Switch..........37Lights On Reminder.....................................38Passing........................................................37Switch..........................................................36Time Delay...................................................38Heated Mirrors.................................................36Heated Seats...................................................30High Beam/Low Beam Select (Dimmer)
Switch..............................................................37Hill Descent Control......................................226Hill Descent Control Indicator.......................226Hill Start Assist..............................................227Hitches Trailer Towing...........................................125Holder, Coin.....................................................49Hood Prop........................................................56Hood Release..................................................56
I
Ignition.............................................................17Switch..........................................................17Inside Rearview Mirror............................34, 268
Instrument Cluster.............................62, 65, 76Descriptions.................................................76Display Controls...........................................64Engine Oil Reset..........................................65Menu Items.................................................66Instrument Cluster Display...............................64Trip..............................................................69Instrument Panel Lens Cleaning...................340Interior Appearance Care..............................339Interior Lights...................................................39Intermittent Wipers (Delay Wipers)..................41InverterPower...........................................................51
J
Jack Location................................................272Jack Operation.....................................271, 273Jacking And Tire Changing............................271Jacking Instructions......................................273Jump Starting................................................278
K
Key FobArm The Alarm
.............................................20Disarm The Alarm........................................21Keyless Entry...............................................22Programming Additional Key Fobs...............16Remote Keyless Entry..................................14Key Fob Battery Service (Remote Keyless
Entry)
...............................................................15

356
Modifications/Alterations
Vehicle........................................................10Monitor, Tire Pressure System.......................235Mopar Parts...................................................348
N
NavigationBefore Route Guidance
.............................190Map Updates.............................................200View Map...................................................191View Map — Main Menu............................191View Map — Settings.................................192View Map — Settings — Guidance..............196View Map — Settings — Map Setup...........193Where To?.................................................180Where To? — City Center...........................189Where To? — Go Home..............................188Where To? — Main Menu...........................180Where To? — Phone..................................189Where To? — Point of Interest...................185Where To? — Point on Map........................187Where To? — Trips.....................................187Navigation Mode...........................................180Navigation, Emergency..................................200Navigation, Information Menu.......................199New Vehicle Break-In Period............................82
O
Occupant Restraints.....................................240Octane Rating, Gasoline (Fuel)............342, 345Oil Change Indicator........................................65Reset...........................................................65Oil Filter, Change..........................................296Oil Filter, Selection........................................296Oil Pressure Light......................................71, 72Oil, Engine............................................295, 345Capacity....................................................344Checking...................................................294Dipstick....................................................294Disposal...................................................296Filter................................................296, 345Filter Disposal...........................................296Identification Logo....................................295Materials Added To..................................296Pressure Warning Light........................71, 72Recommendation............................295, 344Synthetic..................................................295Viscosity...................................................344Onboard Diagnostic System.............................77Operating Navigation....................................180Operating Precautions.....................................77Operator ManualOwner's Manual........................................348Outside Rearview Mirrors................................35Overheating, Engine......................................281
P
Paint Care.....................................................338Pair (Link) Uconnect Phone To A Mobile
Phone
S
.....................................................166Parking Brake..................................................82ParkSense Front And Rear..........................................105ParkSense Active Park Assist........................111Personalized Main Menu Bar........................149Pets...............................................................265Phone Mode..................................................164Placard, Tire And Loading Information..........326Point of InterestAll Points of Interest..................................186Restaurants..............................................186Spell Name...............................................186PowerBrakes......................................................341Door Locks...................................................22Inverter........................................................51Outlet (Auxiliary Electrical Outlet).................50Sunroof........................................................54Windows......................................................52Power SeatsRecline.........................................................29Pregnant Women And Seat Belts..................245Preparation For Jacking................................271Presets..........................................................160PretensionersSeat Belts
.................................................245

359
Tires...................................267, 329, 333, 337Aging (Life Of Tires)...................................331Air Pressure...............................................329Chains.......................................................335Changing...................................................271Compact Spare.........................................333General Information........................329, 333High Speed................................................330Inflation Pressure......................................329Jacking......................................................271Life Of Tires...............................................331Load Capacity............................................326Pressure Monitoring System (TPMS)..74, 235Quality Grading..........................................337Radial........................................................330Replacement.............................................332Rotation....................................................336Safety..............................................322, 329Sizes..........................................................323Snow Tires.................................................333Spare Tires......................................333, 334Spinning....................................................331Trailer Towing............................................127Tread Wear Indicators...............................331Tongue Weight/Trailer Weight.......................126Tow HooksEmergency................................................284
Towing..........................................................124Disabled Vehicle.......................................283Guide........................................................126Recreational.............................................129Weight......................................................126Trailer Sway Control (TSC).............................227Trailer Towing...............................................124Hitches.....................................................125Minimum Requirements...........................126Trailer And Tongue Weight........................126Wiring.......................................................128Trailer Towing Guide.....................................126Trailer Weight................................................126TransmissionAutomatic...........................................85, 303Fluid.........................................................345Transporting Pets..........................................265Tread Wear Indicators..................................331Turn Signals..............................................39, 76
U
UconnectPhone Call Features
.................................170Things You Should Know About Your
Uconnect Phone...................................172Uconnect Settings..............................19, 134
Uconnect Phone...................................166, 168Answer Or Ignore An Incoming Call —
Call Currently In Progress.....................171Answer Or Ignore An Incoming Call —
No Call Currently In Progress................171Bluetooth Communication Link................174Call Continuation......................................172Call Controls.............................................170Call Termination.......................................172Cancel Command.....................................166Connecting To A Particular Mobile P
hone Or Audio Device After Pairing.......168Help Command.........................................166Join Calls..................................................172Making A Phone Or Audio Device A Favorite................................................169Making A Second Call While Current Call
Is In Progress........................................172Managing Your Favorites..........................169Natural Speech.........................................166Operation..................................................165Overview...................................................164Pair (Link) Uconnect Phone To A Mobile
Phone...................................................166Pair A Bluetooth Streaming Audio
Device..................................................168
11
