200IN AN EMERGENCY
After tyre replacement
❍Stow the space saver wheel D-fig. 10 in the space pro-
vided in the luggage compartment;
❍fit the partially open jack in its box forcing it lightly
to prevent it from vibrating when travelling;
❍put the tools back into place in the container;
❍stow the container, complete with tools, in the spare
wheel and tighten the locking device B-fig. 10;
❍reposition the boot mat correctly.
IMPORTANT Do not use inner tubes with tubeless tyres.
Check the inflation pressure of the tyres and the space-
saving wheel periodically.CHANGING A BULB
GENERAL INSTRUCTIONS
❍Before changing a bulb, check the contacts for rust-
ing;
❍burnt-out bulbs must be replaced by others of the
same type and wattage;
❍always check the alignment of the beam after chang-
ing a headlight bulb;
❍when a light is not working, check that the corre-
sponding fuse is intact before changing a bulb. For the
location of fuses, refer to the paragraph “Replacing
fuses” in this chapter.
Modifications or repairs to the electric sys-
tem that are not carried out properly or do
not take the system technical specifications
into account can cause malfunctions leading to the
risk of fire.
Various fastening bolts and space-saver
wheels, specific and differing in structural
characteristics, are used depending on the
wheel rim type (alloy or steel). Fastening bolts for
alloy rims can be identified by the presence of a per-
manent washer and a hollow side on the bolt head.
Therefore, you will need to go to a Lancia Dealer-
ship to get the correct type of fastening bolts and
space saver wheel if you change the type of wheels
fitted (alloy rims instead of steel rims, or vice
versa). Keep the bolts fitted as standard in case of
re-use of the wheels originally mounted on the car.

IN AN EMERGENCY201
4
Halogen bulbs contain gas under pressure;
if they break, glass fragments may be dis-
persed.IMPORTANT The headlight inner surface might be
slightly misted: this should not be considered irregular
rather a natural phenomenon due to low temperature and
the air humidity level. Misting will disappear as soon as
the headlights are turned on. The presence of drops in-
side the headlights indicates infiltration of water. Contact
a Lancia Dealership.
IMPORTANT When the weather is cold or damp or after
heavy rain or after washing, the surface of headlights or
rear lights, may steam up and/or form drops of conden-
sation on the inside. This is a natural phenomenon due
to the difference in temperature and humidity between the
inside and the outside of the glass which does not indicate
a fault and does not compromise the normal operation of
lighting devices. The mist disappears quickly when the
lights are turned on, starting from the centre of the dif-
fuser, extending progressively towards the edges.
When handling halogen bulbs, only touch the
metal part. If the transparent bulb is touched
with the fingers, its lighting intensity is re-
duced and life of the bulb may be compromised. In
the event of accidental contact, wipe the bulb with
a cloth moistened with alcohol and leave it to dry.
Where possible, it is advisable to have bulbs
changed at a Lancia Dealership. Proper op-
eration and orientation of the external lights
are essential for driving safety and complying
with the law.

202IN AN EMERGENCY
fig. 14L0E0084m
TYPES OF BULBS fig. 14
Various types of bulbs are fitted to your car:
A. Glass bulbs: clipped into position. Pull to remove.
B. Bayonet type bulbs: to remove this type of bulb from
its holder, press the bulb and turn it anticlockwise.
C. Tubular bulbs: release them from their contacts to re-
move.
D. Halogen bulbs: to remove the bulb, release the clip
holding the bulb in place.
E. Halogen bulbs: to remove the bulb, release the clip
holding the bulb in place.

IN AN EMERGENCY203
4
LEDs
LEDs
D1S(*)/H7
H1(*)/H7
PY 24W
LEDs
WY5W
LEDs
LEDs
W5W
H11
W16W
W16W
5L/5K
12V 5W
12V 5W
W5W–
–
D
D
B
–
A
–
–
C
E
B
B
–
C
C
A–
–
55 W
55 W
24 W
–
5 W
–
–
5 W
55 W
16 W
16 W
–
5 W
5 W
5 W
(*) Xenon gas discharge bulb
Bulbs Type Power Re. figure
Front side lights/Day lights
Rear side lights
Dipped headlamps
Main beam headlamps
Front direction indicator
Rear direction indicator
Side direction indicator
Stop
3rdbrake light
Number plate
Fog lights
Rear fog lamp
Reverse gear
Front courtesy light (white LEDs)
Rear roof light
Glove compartment/luggage
compartment courtesy light
Puddle light

204IN AN EMERGENCY
REPLACING EXTERIOR BULBS
FRONT LIGHT CLUSTERS fig. 15
These contain the bulbs for the dipped beams, main
beams and direction indicators. The bulbs are arranged
as follows:
A. Main beam headlights:
B. Dipped beam headlights;
C. Direction indicators DIPPED BEAM HEADLIGHTS
With incandescent bulbs
To change the bulb, proceed as follows:
❍remove the protective cover B-fig. 15;
❍release the bulb holder clip A-fig. 16;
❍disconnect the electrical connector B;
❍remove the bulb C and replace it;
❍fit the new bulb, ensuring that the outline of the metal
part coincides with the splining on the curve of the
headlight. Then reconnect the electrical connector B
and reattach the bulb holding clip A;
❍refit the protective cover B-fig. 15.
fig. 15L0E0154mfig. 16L0E0155m

IN AN EMERGENCY205
4
With gas discharge bulbs (Xenon)
(for versions/markets where provided)
MAIN BEAM HEADLIGHTS
With incandescent bulbs
To change the bulb, proceed as follows:
❍remove the protective cover A-fig. 15;
❍release the bulb holder clip A-fig. 17;
❍disconnect the electrical connector B;
❍remove the bulb C and replace it;
❍fit the new bulb, ensuring that the outline of the metal
part coincides with the splining on the curve of the
headlight. Then reconnect the electrical connector B
and reattach the bulb holding clip A;
❍refit the protective cover A-fig. 15.
fig. 17L0E0156m
Due to the high power supply voltage, gas
discharge bulbs (Xenon) should only be re-
placed by specialised personnel: danger of
death! Go to a Lancia Dealership.
With gas discharge bulbs (Xenon)
(for versions/markets where provided)
Due to the high power supply voltage, gas
discharge bulbs (Xenon) should only be re-
placed by specialised personnel: danger of
death! Go to a Lancia Dealership.

206IN AN EMERGENCY
SIDE LIGHTS/DAY LIGHTS
The side lights/day lights are LED-based.
Contact a Lancia dealership to have these lights replaced.
DIRECTION INDICATORS
Front
To change the bulb, proceed as follows:
❍remove the protective cover C-fig. 15;
❍press down near the bulb holder locking tabs (shown
in fig. 18 by the arrows) and simultaneously pull the
unit;
❍remove the bulb A and replace it;
❍refit the protective cover C.Side
To change the bulb, proceed as follows:
❍work on the lens cover A-fig. 19 to compress catch B,
then pull the unit outwards;
❍turn the bulb holder C, anticlockwise, extract the
press-fitted bulb D and replace it;
❍refit the bulb holder C in the lens cover and turn it
clockwise;
❍refit the unit making sure that the internal clip B
clicks into place.
fig. 18L0E0157mfig. 19L0E0158m

IN AN EMERGENCY207
4
FOG LIGHTS fig. 20
(for versions/markets where provided)
To replace the bulbs in the front fog lights you must con-
tact a Lancia Dealership.
REAR LIGHT CLUSTERS
Contact a Lancia Dealership to replace the LED lights
in the rear light clusters.
REVERSING LIGHTS fig. 21
To replace the bulbs in the reversing lights you must con-
tact a Lancia Dealership.REAR FOG LIGHTS fig. 22
To replace the bulbs in the rear fog lights you must con-
tact a Lancia Dealership.
fig. 20L0E0159mfig. 22L0E0161m
fig. 21L0E0160m

208IN AN EMERGENCY
THIRD BRAKE LIGHT fig. 23
Contact a Lancia Dealership to replace the LED lights
in the third brake light.
NUMBER PLATE LIGHTS
To change the bulb proceed as follows:
❍remove the lens units A-fig. 24 by acting on the points
shown by the arrows;
❍remove the bulb B and replace it.
fig. 23L0E0162mfig. 25L0E0282m
fig. 24L0E0163m

IN AN EMERGENCY209
4
fig. 27L0E0166m
fig. 26L0E0165m
REPLACING AN INTERIOR BULB
For the type of bulb and power rating, see the “Types of
bulbs” paragraph.FRONT ROOF LIGHT
Proceed as follows to replace the bulbs:
❍remove the roof light A-fig. 26 by acting on the points
shown by the arrows;
❍open the protective flap B-fig. 27;
❍replace the bulbs C releasing them from the side con-
tacts and making sure that the new bulbs are correctly
secured between the contacts;
❍close the lid B-fig. 27 and fasten the roof light A-fig.
26 in its housing, making sure it is locked correctly.
IMPORTANT In some versions, the roof light in fig. 26
is at the back (electric sun roof version). To replace the
relevant bulbs, refer to the procedure described in para-
graph “Front roof light” in this chapter.
