22KNOWING YOUR CAR
Versions with Start&Stop fig. 4a
(for versions/markets, where provided)
The standard screen shows the following information:
A Date
B Gear Shift Indicator (for versions/markets where pro-
vided)
C Start&Stop function indication
DTimeE Odometer (display of distance travelled in kilometres/
miles)
F Outside temperature
G Headlamp alignment position (only with dipped
headlamps on)
H Dualdrive electric power steering indication
fig. 4aL0E1032g

1
E. Car status indications (e.g. doors open, possible ice on
road, etc.)/Start&Stop function indicator (for versions/
markets where provided)/Gear Shift Indicator (for ver-
sions/markets where provided)
F. Headlamp alignment position (only with dipped
headlamps on)
G. Outside temperature
On some versions, when the “Engine info” menu item is
selected, the display shows the turbine pressure when the
ignition is turned to the MAR position, fig. 6.
fig. 6L0E0004mfig. 5L0E1033g
RECONFIGURABLE MULTIFUNCTION
“STANDARD” DISPLAY fig. 5
The standard screen shows the following information:
A. Time
B. Date
C. Sport driving mode indication (for versions/markets
where provided)
D. Odometer (display of distance travelled in kilometres/
miles)
KNOWING YOUR CAR23

1
KNOWING YOUR CAR63
Deactivation
When the lights are switched off by the sensor, the dipped
beam headlights and side lights are switched off and the
day lights are switched on (if activated).
The sensor is not capable of detecting the presence of fog
therefore, in these circumstances, the lights have to be
turned on manually.
FRONT FOG LIGHTS WITH CORNERING LIGHTS
FUNCTION
When the dipped headlamps are on and the speed is be-
low 40 km/h, if the steering wheel rotation angle is large
or the direction indicators are on, a light (incorporated in
the fog light) will come on on the relevant side to improve
visibility at nightime. The function can be acti-
vated/deactivated via the display menu (see “Display”
paragraph in this chapter). AUTOMATIC HEADLIGHT SENSOR
(dusk sensor) fig. 27
(for versions/markets, where provided)
It detects variations in brightness outside the vehicle de-
pending on the light setting: the greater the sensitivity,
the less outside light needed to activate the exterior lights
being turned on. The sensitivity of the dusk sensor may
be adjusted, using the “Set-up menu” on the instrument
panel.
Activation
When the ring nut is turned to the AUTO position the ex-
ternal lights automatically switch on depending on the
exterior brightness.
The headlights can only be flashed with the sensor on.The daytime running lights are an alterna-
tive to the dipped beam headlights for dri-
ving during the daytime in countries where
it is compulsory to have lights on during the day,
and they are also permitted in those countries
where this not obligatory.
Daytime running lights cannot replace dipped
headlights when driving at night or through tunnels.
The use of daytime running lights is governed by
the highway code of the country in which you are
driving. Comply with legal requirements.

1
KNOWING YOUR CAR71
On the roof light, some bulbs light the car interior when
the main beam headlamps or dipped headlamps are on.
IMPORTANT The roof light in fig. 32, for some versions,
may also be in a rear central position (electric sun roof
version).
IMPORTANT Before getting out of the car, make sure
that both switches are in the middle position; when the
doors are closed, the lights switch off preventing a pos-
sible battery discharging. In any case, if the switch is left
in on position, the roof light switches off automatically
15 minutes after the engine switching off.
Courtesy light timing
To make getting in and out the vehicle easier, especially
at nighttime or in poorly lit areas, two timing logics are
available.
Timing while getting into the vehicle
The roof lights switch on according to the following
modes:
❍for around 10 seconds when the front doors are un-
locked;
❍for about 3 minutes when one of the side doors is
opened;
❍for about 10 seconds when the doors are closed.
The timed period is interrupted when the ignition is
turned to “MAR”.Timing while getting out of the vehicle
After removing the key from the ignition, the courtesy
lights switch on according to the following modes:
❍within 2 minutes of the engine being switched off for
a period of about 10 seconds;
❍when one of the side doors is opened for a period
of about 3 minutes;
❍when one of the doors is closed for a period of about
10 seconds;
❍if the fuel cut off switch operates, they remain on for
about 15 minutes, then they switch off automatically.
Door locking switches the lights off immediately (unless
the fuel cut off switch is operating).
fig. 33L0E0025m

1
KNOWING YOUR CAR103
ADJUSTING THE HEADLIGHTS WHEN ABROAD
Dipped headlights are adjusted to drive in the country
where the vehicle was originally purchased. When trav-
elling in countries with opposite driving direction, to
avoid blinding the drivers on the other side of the road,
you need to cover the headlight areas depending on the
Highway code of the country you are travelling in.
ADAPTIVE LIGHTS (AFS – Adaptive Xenon Light)
This is a system combined with Xenon headlamps which
directs the main light beam and continuously and auto-
matically adapts it to the driving conditions round
bends/when cornering. The system directs the light beam
to light up the road in the best way, taking into account
the speed of the vehicle, the bend/corner angle and the
speed of steering.Activating/deactivating the system fig. 68
The adaptive lights are automatically activated when the
vehicle is started. In this situation the LED (amber) on
button A will remain off.
Press button A to deactivate the adaptive lights (if acti-
vated); they will be deactivated and the LED on button
A will come on constantly. Press AFS button again to turn
the adaptive lights on (LED off on the button).
In the event of a system failure, an indication is provided
on the instrument panel by the flashing of warning light
f
or the symbol
fappearing on the display along with a ded-
icated message (for versions/markets where provided).
fig. 68L0E0055m

IN AN EMERGENCY203
4
LEDs
LEDs
D1S(*)/H7
H1(*)/H7
PY 24W
LEDs
WY5W
LEDs
LEDs
W5W
H11
W16W
W16W
5L/5K
12V 5W
12V 5W
W5W–
–
D
D
B
–
A
–
–
C
E
B
B
–
C
C
A–
–
55 W
55 W
24 W
–
5 W
–
–
5 W
55 W
16 W
16 W
–
5 W
5 W
5 W
(*) Xenon gas discharge bulb
Bulbs Type Power Re. figure
Front side lights/Day lights
Rear side lights
Dipped headlamps
Main beam headlamps
Front direction indicator
Rear direction indicator
Side direction indicator
Stop
3rdbrake light
Number plate
Fog lights
Rear fog lamp
Reverse gear
Front courtesy light (white LEDs)
Rear roof light
Glove compartment/luggage
compartment courtesy light
Puddle light

218IN AN EMERGENCY
38
38
38
38
38
38
38
38
38F43
F44
F46
F47
F48
F49
F51
F52
F5330
15
20
20
20
5
5/7.5 (*)
15
7.5
USERS FUSE AMPS FIGURE
Windscreen wiper system on steering column stalk,
bi-directional windscreen/rear window washer pump system
on steering column stalk
Cigar lighter/power socket on tunnel,
luggage compartment power socket
Sunroof motor
Driver’s front electric window
Passenger side front electric window
Hazard, right, left and centre control panels on radio/
radio-navigator (lighting), steering wheel controls (lighting)
controls on front roof light (lighting), volumetric alarm control unit,
electric sun roof system (control unit, control lighting),
rain/dusk sensor, electrochromic mirror,
heated front seat controls, AUX socket (lighting)
Cigar lighter (lighting), Cruise Control system control,
Blue&Me™ Node, Parking Sensor Node, AQS sensor,
climate control unit, door mirror adjustment,
tyre pressure monitoring system control unit, lane assistance Node,
controlled damping suspension Node, control unit on right hand gas
discharge headlight (1.4 Turbo Multi Air versions excluded)
voltage stabiliser (1.4 Turbo Multi Air versions) (*)
Rear wiper system on steering column stalk
Instrument panel, rear direction indicators
(*) Version with gas discharge headlamps.

IN AN EMERGENCY219
4
38a
38a
38a
38a
40
40
40
40
40
40
40
40
40
40
2
42
42
42
42
42
42(P038)
(P036)
(P037)
(P039)
F08
F09
F09
F10
F14
F15
F19
F30
F85
F87
F1
F2
F3
F6
F4
F4
F510
5
5
5
40
30
20
10
15
30
7.5
15
15
5
30
30
10
10
15
20
10
USERS FUSE AMPS FIGURE
Car Radio / Radio Navigator
DRLs/Left side light
DRLs/Right side light
Adaptive Headlamps Node/Control units on right
and left hand gas discharge headlights
Climate control fan
Headlight washer pump
(1.4 Turbo Jet 120 HP, 1.4 Turbo Multi Air versions)
Headlight washer pump (1.4 Turbo Jet 150 HP,
1.6 Multijet, 2.0 Multijet, 1.9 Twin Turbo Multijet versions)
Horn
Main beam headlights
PTC1 additional heater
Air conditioning compressor
Fog/cornering lights
Fuel pump
Battery charge status sensor (1.4 Turbo Multi Air version)
Right front seat adjustment node
Left front seat adjustment node
Left front seat heating
Right front seat heating
Audio Hi-Fi control unit (1.4 Turbo Multi Air version excluded)
Voltage stabiliser (1.4 Turbo Multi Air version with HI-FI option)
BASSBOX speaker
(HI-FI system, 1.4 Turbo Multi Air version excluded)

280LIST OF CONTENTS
“Dualdrive” electric
power steering ...................122
Electric windows ................. 87
Engine codes/bodywork
versions .............................254
Engine compartment
(washing) ..........................249
Engine
– identification code ..........254
– specifications ..................255
EOBD system ......................122
Exterior lights ..................... 62
Fix&Go Automatic
(device) .............................186
Flashing the headlights ....... 64
Fluids and lubricants ..........271
Fog lights ........................ 63-74
– bulb replacement ............207
Fog lights ............................ 73
– Cornering function ......... 63Follow Me Home (device) ... 65
Food compartment .............. 77
Front/rear armrest .......... 76-78
Fuel cap ..............................147
Fuel consumption ...............273
Fuel cut-off ......................... 75
Fuses (if a fuse blows) .........213
Getting to know your car .... 5
Glove box light
(bulb replacement).............212
Glove compartment ......... 76-79
GSI (Gear Shift Indicator) ... 24
Handbrake .........................175
Hazard lights ...................... 73
Headlights ..........................102
Headrests ............................ 50
Hill Holder (system) ........... 11
Dashboard .......................... 6
Dimensions .........................265
Dipped headlamps
(control) ............................ 64
– bulb replacement ............204
Direction indicators
– bulb replacement ............206
– control ............................ 64
Display ............................... 21
– display readings ............. 34
– menu items ..................... 26
Display readings ................. 34
Door locking ....................... 84
Doors .................................. 84
– child safety lock ............. 86
– emergency rear door
locking device ................. 87
DPF (particulate filter) .......148
Driving Advisor....................107
DST (Dynamic Steering
Torque) .............................104
