LAND ROVER DISCOVERY 1999 Owners Manual

IDENTIFICATION NUMBERS
05-4
Transfer box number
Stamped on the rear of the transfer box casing above
the bottom cover plate.
Front axle number
Stamped on the rear face of the axle tube on the LH
side.Rear axle number
Stamped on the front face of the axle tube on the LH
side.
Body number
Stamped on a label attached to the LH inner wing,
behind the headlamp.

TORQUE WRENCH SETTINGS
06-1
TORQUE WRE NCH SETTINGS
Maintenance
TORQUE DESCRIPTION METRIC IMPERIAL
Wheel nuts 140 Nm (103 lbf.ft)
V8 oil drain plug 33 Nm (24 lbf.ft)
Td5 oil drain plug 23 Nm (17 lbf.ft)
Oil filter element, tighten two thirds of a turn by hand or to - 17 Nm (13 lbf.ft)
Manual gearbox oil drain plug 50 Nm (37 lbf.ft)
Manual gearbox oil filler/level plug 30 Nm (22 lbf.ft)
Automatic gearbox oil drain plug 15 Nm (11 lbf.ft)
Automatic gearbox oil drain plug 30 Nm (22 lbf.ft)
Transfer gearbox oil drain plug 30 Nm (22 lbf.ft)
Transfer gearbox oil filler/level plug 25 Nm (18 lbf.ft)
Axle oil drain plug 64 Nm (47 lbf.ft)
Axle oil filler/level plug 10 Nm (7 lbf.ft)

TORQUE WRENCH SETTINGS
06-2
Engine Td5
TORQUE DESCRIPTION METRIC IMPERIAL
ACE pump bolts25 Nm (18 lbf.ft)
A/C compressor bolts 25 Nm (18 lbf.ft)
Alternator support bracket to cylinder head bolts 25 Nm (18 lbf.ft)
Alternator/vacuum pump oil feed pipe union 10 Nm (7 lbf.ft)
Camshaft cover to camshaft carrier bolts 10 Nm (7 lbf.ft)
Camshaft sprocket to camshaft bolts 37 Nm (27 lbf.ft)
Centrifuge cover bolts 10 Nm (7 lbf.ft)
Centrifuge oil drain pipe to sump bolts (or nuts) 10 Nm (7 lbf.ft)
Centrifuge to oil drain pipe bolts 10 Nm (7 lbf.ft)
Centrifuge to oil cooler housing bolts 25 Nm (18 lbf.ft)
CKP sensor bolt10 Nm (7 lbf.ft)
Coolant pipe bolt50 Nm (37 lbf.ft)
Connecting rod bolts, then a further 80°20 Nm (15 lbf.ft)
Crankshaft pulley bolt 460 Nm (340 lbf.ft)
Crankshaft pulley TV damper bolts 80 Nm (59 lbf.ft)
Crankshaft rear oil seal housing bolts 10 Nm (7 lbf.ft)
Cylinder head bolts initial tighten 30 Nm (22 lbf.ft)
Cylinder head bolts final tighten, then a further 90°, then a further 180° and finally a
further 45°65 Nm (48 lbf.ft)
Dipstick tube to camshaft carrier bolt 10 Nm (7 lbf.ft)
Drive plate (automatic transmission) to crankshaft bolts 115 Nm (85 lbf.ft)
EGR pipe clamp to cylinder head bolt - if fitted 25 Nm (18 lbf.ft)
EGR pipe Allen screws 10 Nm (7 lbf.ft)
Engine mounting (front) to cylinder block bolts 48 Nm (35 lbf.ft)
Engine mounting (front) to chassis nuts 85 Nm (63 lbf.ft)
Engine mounting bracket (rear, LH & RH) to gearbox bolts 85 Nm (63 lbf.ft)
Engine mounting bracket (rear, LH & RH) nuts 45 Nm (33 lbf.ft)
Flywheel to crankshaft (manual transmission) bolts, then a further 90°40 Nm (30 lbf.ft)
Front crossmember bolts 26 Nm (20 lbf.ft)
Fuel connector block bolts 25 Nm (18 lbf.ft)
Fuel cooler to inlet manifold bolts 25 Nm (18 lbf.ft)
Gearbox housing to engine bolts 50 Nm (37 lbf.ft)
Heater pipe to cylinder head bolts 25 Nm (18 lbf.ft)
Main bearing cap bolts then a further 90°33 Nm (24 lbf.ft)
Oil cooler housing to cylinder block bolts 25 Nm (18 lbf.ft)
Oil cooler pipe clip bolts 10 Nm (7 lbf.ft)
Oil filter adaptor housing to oil cooler housing bolts 25 Nm (18 lbf.ft)
Oil pick-up strainer Torx screws + 10 Nm (7 lbf.ft)
Oil pressure switch 15 Nm (11 lbf.ft)
Oil pump drive sprocket bolt + 25 Nm (18 lbf.ft)
Oil pump pressure relief valve plug + 25 Nm (18 lbf.ft)
Oil pump and stiffener assembly to cylinder block bolts 13 Nm (10 lbf.ft)
Oil sump to cylinder block bolts 25 Nm (18 lbf.ft)
Oil sump to gearbox bell housing bolts 13 Nm (10 lbf.ft)
PAS pump bracket bolts 27 Nm (20 lbf.ft)
PAS pump pulley bolts 27 Nm (20 lbf.ft)
Rocker arm adjusting screw locknuts 16 Nm (12 lbf.ft)

TORQUE WRENCH SETTINGS
06-3
+ Apply sealant, Part No. STC 50552 to threads
Rocker shaft bolts 32 Nm (24 lbf. ft)
Timing chain adjustable guide bolt 25 Nm (18 lbf.ft)
Timing chain cover bolts 27 Nm (20 lbf.ft)
Timing chain cover to cylinder block stud 7 Nm (5.2 lbf.ft)
Timing chain fixed guide Allen screw + 25 Nm (18 lbf.ft)
Timing chain cover to cylinder head nut and bolt 25 Nm (18 lbf.ft)
Timing chain fixed guide (M6) bolt 10 Nm (7 lbf.ft)
Timing chain fixed guide (M10) bolt 45 Nm (33 lbf.ft)
Timing chain lubrication jet bolt 10 Nm (7 lbf.ft)
Timing chain tensioner 45 Nm (33 lbf.ft)
Torque converter to drive plate (automatic transmission) bolts 50 Nm (37 lbf.ft)
Turbocharger heatshield bolts 10 Nm (7 lbf.ft)
Turbocharger oil feed pipe banjo bolt 25 Nm (18 lbf.ft)
Turbocharger to exhaust manifold nuts 30 Nm (22 lbf.ft)
Vacuum pump oil feed pipe to cylinder head union 10 Nm (7 lbf.ft)
Viscous fan nut45 Nm (33 lbf.ft)
Fuel spill return pipe unions - if fitted 20 Nm (15 lbf.ft)TORQUE DESCRIPTION METRIC IMPERIAL

TORQUE WRENCH SETTINGS
06-4
Engine V8
* New bolts must be fitted
+ Apply sealant, Part Number STC 50552 to threads
TORQUE DESCRIPTION METRIC IMPERIAL
Engine mounting bolts (rear, LH & RH) to gearbox bolts 85 Nm (63 lbf.ft)
Engine mounting (rear, LH & RH) nuts 45 Nm (33 lbf.ft)
Cylinder head bolts tighten, then 90°, then a further 90° * 20 Nm (15 lbf.ft)
Rocker shaft bolts 40 Nm (30 lbf.ft)
Alternator mounting bracket 40 Nm (30 lbf.ft)
Auxiliary drive belt tensioner 45 Nm (33 lbf.ft)
Engine earth lead 22 Nm (16 lbf.ft)
Rocker cover screws/bolts * 8 Nm (6 lbf.ft)
Torque converter to drive plate 50 Nm (37 lbf.ft)
A/C compressor 22 Nm (16 lbf.ft)
ACE pump 22 Nm (16 lbf.ft)
Flywheel to crankshaft 78 Nm (58 lbf.ft)
Crankshaft sensor 6 Nm (5 lbf.ft)
Crankshaft sensor cover 6 Nm (5 lbf.ft)
Spacer and hub to crankshaft - Early engines 85 Nm (63 lbf.ft)
Drive plate and clamp ring - Early engines 45 Nm (33 lbf.ft)
Drive plate to crankshaft Allen bolts - Later engines 85 Nm 63 lbf.ft)
Oil pick up strainer 10 Nm (7 lbf.ft)
Filter head adaptor 13 Nm (10 lbf.ft)
Filter head 8 Nm (6 lbf.ft)
Sump bolts 22 Nm (16 lbf.ft)
Oil pressure switch 15 Nm (11 lbf.ft)
Timing gear cover to cylinder block + 22 Nm (16 lbf.ft)
Oil cooler pipe to timing gear cover 15 Nm (11 lbf.ft)
Crankshaft pulley bolt 270 Nm (200 lbf.ft)
Coolant outlet elbow 22 Nm (16 lbf.ft)
Auxiliary housing 40 Nm (30 lbf.ft)
Jockey pulley 50 Nm (37 lbf.ft)
Camshaft gear 50 Nm (37 lbf.ft)
Rocker shaft bolts 40 Nm (30 lbf.ft)
Connecting rod bolts
Final torque - turn through 80°°20 Nm
80°(15 lbf.ft)
80°
Initial torque - all main bearing cap bolts and side bolts 13.5 Nm (10 lbf.ft)
Final torque - main bearing cap side bolts 11 to 15 45 Nm (33 lbf.ft)
Final torque - main bearing cap bolts 1 to 8 72 Nm (53 lbf.ft)
Final torque - main bearing cap bolts 9 and 10 92 Nm (68 lbf.ft)
Final torque - main bearing cap side bolts 16 to 20 45 Nm (33 lbf.ft)
Viscous fan nut 45 Nm (33 lbf.ft)
Camshaft thrust plate bolts 22 Nm (16 lbf.ft)
Secondary Air Injection adapters 33 Nm (24 lbf.ft)

TORQUE WRENCH SETTINGS
06-5
Emission control - Td5
Emission control - V8
TORQUE DESCRIPTION METRIC IMPERIAL
EGR valve pipe Allen screws 10 Nm (7 lbf.ft)
EGR valve to inlet manifold bolts 10 Nm (7 lbf.ft)
EGR intake pipe clip to cylinder head bolts - if fitted 25 Nm (18 lbf.ft)
EGR cooler to cylinder head nut and bolts - if fitted 25 Nm (18 lbf.ft)
EGR valve to flexible mounting nuts 5 Nm (3 lbf.ft)
EGR valve flexible mounting to bracket nuts 5 Nm (3 lbf.ft)
TORQUE DESCRIPTION METRIC IMPERIAL
HO
2S Sensors 45 Nm (33 lbf.ft)
SAI air manifold union nuts 25 Nm (18 lbf.ft)
Rubber mountings to SAI pump bracket 10 Nm (7 lbf.ft)
SAI control valve to manifold bolts 10 Nm (7 lbf.ft)
SAI pump to bracket nuts 10 Nm (7 lbf.ft)
SAI pump bracket to body bolt 20 Nm (15 lbf.ft)
Vacuum reservoir to mounting bracket bolt 10 Nm (7 lbf.ft)

TORQUE WRENCH SETTINGS
06-6
Engine management system - Td5
Engine management system - V8
+ Apply sealant, Part No. STC 50552 to threads
TORQUE DESCRIPTION METRIC IMPERIAL
ECT sensor15 Nm (11 lbf.ft)
Fuel tank cradle45 Nm (33 lbf.ft)
CKP sensor10 Nm (7 lbf.ft)
MAP and IAT sensor 10 Nm (7 lbf.ft)
Fuel cooler to inlet manifold - upper bolts 25 Nm (18 lbf.ft)
Turbocharger to exhaust manifold 30 Nm (22 lbf.ft)
Turbocharger drain pipe 10 Nm (7 lbf.ft)
Banjo bolt to oil feed pipe 25 Nm (18 lbf.ft)
Fuel temperature sensor 14 Nm (10 lbf.ft)
Pressure regulator 25 Nm (18 lbf.ft)
Glow plugs16 Nm (12 lbf.ft)
EUI clamp bolts32 Nm (24 lbf.ft)
EGR valve to exhaust manifold 10 Nm (7 lbf.ft)
EGR valve to inlet manifold 10 Nm (7 lbf.ft)
EGR clip25 Nm (18 lbf.ft)
TORQUE DESCRIPTION METRIC IMPERIAL
Spark plugs20 Nm (15 lbf.ft)
Fuel tank cradle45 Nm (33 lbf.ft)
ECT sensor +10 Nm (7 lbf.ft)
CKP sensor6 Nm (4.4 lbf.ft)
CMP sensor8 Nm (6 lbf.ft)
KS sensor22 Nm (16 lbf.ft)
Throttle body10 Nm (7 lbf.ft)
Plenum chamber22 Nm (16 lbf.ft)
Breather adaptor6 Nm (4.4 lbf.ft)
Throttle cable abutment bracket 10 Nm (7 lbf.ft)
TP sensor 2.2 Nm (1.6 lbf.ft)
IACV sensor8 Nm (6 lbf.ft)
HO
2S sensor45 Nm (33 lbf.ft)
Ignition coils8 Nm (6 lbf.ft)
Fuel rail9 Nm (7 lbf.ft)

TORQUE WRENCH SETTINGS
06-7
Cooling system
TORQUE DESCRIPTION METRIC IMPERIAL
Cylinder block drain plug 30 Nm (22 lbf.ft)
Coolant pump24 Nm (18 lbf.ft)
Coolant pump pulley 22 Nm (16 lbf.ft)
Coolant pump cover - Td5 10 Nm (7 lbf.ft)

TORQUE WRENCH SETTINGS
06-8
Manifolds and exhaust systems - Td5
Manifolds and exhaust systems - V8
TORQUE DESCRIPTION METRIC IMPERIAL
Front pipe to turbocharger 27 Nm (20 lbf.ft)
Inlet manifold25 Nm (18 lbf.ft)
Tail pipe25 Nm (18 lbf.ft)
Fuel cooler25 Nm (18 lbf.ft)
EGR valve10 Nm (7 lbf.ft)
Exhaust manifold25 Nm (18 lbf.ft)
Exhaust manifold heatshield (M6) bolts 10 Nm (7 lbf.ft)
Exhaust manifold heatshield (M8) bolts 25 Nm (18 lbf.ft)
EGR pipe Allen screws 10 Nm (7 lbf.ft)
TORQUE DESCRIPTION METRIC IMPERIAL
Intermediate pipe/silencer nuts 25 Nm (18 lbf.ft)
Inlet manifold bolts - initial tighten 10 Nm (7 lbf.ft)
Inlet manifold gasket clamp bolts 18 Nm (13 lbf.ft)
Inlet manifold bolts - final tighten 51 Nm (38 lbf ft)
Tail pipe25 Nm (18 lbf.ft)
Coolant outlet pipe 22 Nm (16 lbf.ft)
Front pipe flange nuts 30 Nm (22 lbf.ft)
Exhaust manifold55 Nm (40 lbf.ft)

TORQUE WRENCH SETTINGS
06-9
Clutch
TORQUE DESCRIPTION METRIC IMPERIAL
Clutch bleed screw 9 Nm (7 lbf.ft)
Clutch cover nuts Td5 25 Nm (18 lbf.ft)
Clutch cover bolts V8 40 Nm (30 lbf.ft)
Clutch master cylinder to pedal box 25 Nm (18 lbf.ft)
Hydraulic pipe union 18 Nm (13 lbf.ft)
Clutch release bearing pivot point bolt 8 Nm (6 lbf.ft)
Slave cylinder25 Nm (18 lbf.ft)
