GENERAL INFORMATION
03-7
General fitting instructions
Precautions against damage
To avoid damage to the vehicle when carrying out
repairs, always adhere to the following:
lAlways fit wing and seat covers before
commencing work. Avoid spilling brake fluid or
battery acid on paintwork; immediately wash off
with water if this occurs.
lDisconnect the battery earth lead before starting
work, see ELECTRICAL PRECAUTIONS.
lAlways use the recommended service tool or a
satisfactory equivalent where specified.
lProtect exposed bearing surfaces, sealing
surfaces and screw threads from damage.
Component removal
Whenever possible, clean components and
surrounding area before removal.
lBlank off openings exposed by component
removal.
lImmediately seal fuel, oil or hydraulic lines when
apertures are exposed; use plastic caps or
plugs to prevent loss of fluid and ingress of dirt.
lClose open ends of oilways exposed by
component removal with tapered hardwood
plugs or conspicuous plastic plugs.
lImmediately a component is removed, place it in
a suitable container; use a separate container
for each component and its associated parts.
lClean bench and provide marking materials,
labels, containers and locking wire before
dismantling a component.
Dismantling
Observe scrupulous cleanliness when dismantling
components, particularly when brake, fuel or
hydraulic system parts are being worked on. A
particle of dirt or a cloth fragment could cause a
serious malfunction if trapped in these systems.Use the following procedures:
lBlow out all tapped holes, crevices, oilways and
fluid passages with an air line. Ensure that any
O-rings used for sealing are correctly replaced
or renewed if disturbed during the process.
lUse marking ink to identify mating parts and
ensure correct reassembly. Do not use a centre
punch or scriber to mark parts, they could
initiate cracks or distortion in marked
components.
lWire together mating parts where necessary to
prevent accidental interchange (e.g. roller
bearing components).
lWire labels on to all parts which are to be
renewed, and to parts requiring further
inspection before being passed for reassembly;
place these parts in separate containers from
those containing parts for rebuild.
lDo not discard a part due for renewal until after
comparing it with a new part to ensure that its
correct replacement has been obtained.
Cleaning components
Always use the recommended cleaning agent or
equivalent. Ensure that adequate ventilation is
provided when volatile degreasing agents are being
used. Do not use degreasing equipment for
components containing items which could be
damaged by the use of this process.
When washing under bonnet, never direct water onto
ECM, as water ingress may occur resulting in
damage to electrical components inside.
General Inspection
All components should be inspected for wear or
damage before being reassembled.
lNever inspect a component for wear or
dimensional check unless it is absolutely clean;
a slight smear of grease can conceal an
incipient failure.
lWhen a component is to be checked
dimensionally against recommended values,
use the appropriate measuring equipment
(surface plates, micrometers, dial gauges etc.).
Ensure the measuring equipment is calibrated
and in good serviceable condition.
lReject a component if its dimensions are
outside the specified tolerances, or if it appears
to be damaged.
lA part may be refitted if its critical dimension is
exactly to its tolerance limit and it appears to be
in satisfactory condition.
lUse 'Plastigauge' 12 Type PG-1 for checking
bearing surface clearances.

GENERAL INFORMATION
03-20
Disciplines
Switch off the ignition prior to making any connection
or disconnection in the system, to prevent electrical
surges caused by disconnecting 'live' connections
damaging electronic components.
Ensure hands and work surfaces are clean and free
of grease, swarf, etc. Grease collects dirt which can
cause electrical tracking (short-circuits) or high-
resistance contacts.
When handling printed circuit boards, treat with care
and hold by the edges only; note that some electronic
components are susceptible to body static.
Connectors should never be subjected to forced
removal or refit, especially inter-board connectors.
Damaged contacts can cause short-circuit and
open-circuit fault conditions.
Prior to commencing test, and periodically during a
test, touch a good vehicle body earth to discharge
static charge. Some electronic components are
vulnerable to the static electricity that may be
generated by the operator.
Grease for electrical connectors
Some under bonnet and under body connectors may
be protected against corrosion by the application of a
special grease during vehicle production. Should
connectors be disturbed in service, or repaired or
replaced, additional grease should be re-applied:
Part No. BAU 5811, available in 150 gm tubs.
NOTE: The use of greases other than BAU 5811
must be avoided as they can migrate into relays,
switches etc. contaminating the contacts and leading
to intermittent operation or failure.
Supplementary restraint system
precautions
General
The Supplementary Restraint System (SRS)
provides active protection for vehicle occupants in
the event of a serious collision. The system
components include airbags and pre-tensioner seat
belts which are automatically deployed when a
severe frontal crash condition is detected.
The SRS pyrotechnic components could be
potentially hazardous to the service engineer if not
handled correctly. The following guidelines are
intended to alert the service engineer to potential
sources of danger and emphasise the importance of
ensuring the integrity of SRS components fitted to
the vehicle.
In order to assure system integrity, it is essential that
the SRS system is regularly checked and maintained
so that it is ready for operation in the event of an
accident.
Where necessary, additional specific precautions are
detailed in the relevant sections of this Manual which
should be referred to prior to commencing repair
operations.
WARNING: Always follow the 'SRS Precautions'
and the correct procedures for working on SRS
components. Persons working on SRS systems
must be fully trained and have been issued with
copies of the Safety guidelines.
WARNING: It is imperative that before any work
is undertaken on the SRS system the appropriate
information is read thoroughly.
WARNING: The airbag module contains sodium
azide which is poisonous and extremely
flammable. Contact with water, acid or heavy
metals may produce harmful or explosive
compounds. Do not dismantle, incinerate or
bring into contact with electricity, before the unit
has been deployed.
WARNING: Always replace a seat belt assembly
that has withstood the strain of a severe vehicle
impact, or if the webbing shows signs of fraying.
WARNING: Always disconnect the vehicle
battery before carrying out any electric welding
on a vehicle fitted with an SRS system.
CAUTION: Do not expose an airbag module or
seat belt pre-tensioner to heat exceeding 85º C
(185º F).

MAINTENANCE
MAINTENANCE 10-11
Door Locks, Hinges, Check Straps and
Bonnet Catch
Check
1.Check operation of each door, door lock,
bonnet catch and fuel filler flap.Lubricate Front and Rear Doors
1.Open each door in turn and lubricate door
hinges and check strap using recommended
lubricant.

+ CAPACITIES, FLUIDS,
LUBRICANTS AND SEALANTS,
Lubrication.
2.Lubricate door lock, striker and private lock
using PTFE lubricant. Remove excessive
lubricant, particularly from door striker area, to
avoid customer complaint.
3.Check tightness of accessible door lock and
striker fixings.
4.Open and close door to check for smooth,
noise-free operation. Ensure door closes
securely.
5.Check for smooth operation of private lock.
Lubricate Tail Door
1.Open tail door and lubricate hinges using
recommended lubricant.

+ CAPACITIES, FLUIDS,
LUBRICANTS AND SEALANTS,
Lubrication.
2.Grease tail door check slide.
3.Lubricate rear door lock and striker using PTFE
lubricant. Remove excessive lubricant to avoid
customer complaint, particularly from door
striker area.
4.Check tightness of accessible tail door lock and
striker fixings.
Lubricate Bonnet
1.With bonnet open, lubricate hinges, striker, lock
and safety catch using a suitable lubricant.

+ CAPACITIES, FLUIDS,
LUBRICANTS AND SEALANTS,
Lubrication.
Sunroof Guide Rails, Slides and Seal
1.With sunroof open, lubricate accessible guide
rails, slides and seals. Remove any excess
lubricant to avoid contaminating roof lining and
trim.
2.Ensure sunroof closes correctly.
Sunroof Drain Tubes and Channels
1.Remove any debris from sunroof tray.
2.Ensure that all accessible sunroof drain tubes
are clear using a low pressure air line.

COOLING SYSTEM - K SERIES KV6
26-3-4 REPAIRS
Radiator assembly
$% 26.40.01
Remove
1.Disconnect battery earth lead.
2.Remove engine acoustic cover.

+ ENGINE - K SERIES KV6, REPAIRS,
Cover - engine acoustic.
3.Drain cooling system.

+ COOLING SYSTEM - K SERIES KV6,
ADJUSTMENTS, Coolant - drain and refill.
4. Models without A/C: Remove bumper
valance.

+ EXTERIOR FITTINGS, REPAIRS,
Bumper - assembly - front - up to 04MY.
5. Models without A/C:Remove 2 bolts securing
PAS fluid cooler to armature.
6. Models without A/C: Remove 4 nuts and 4
bolts securing armature to body and remove
armature.
7. Models with A/C: Remove A/C condenser.

+ AIR CONDITIONING, REPAIRS,
Condenser.
8.Release clips and remove top and bottom
hoses.
CAUTION: Always fit plugs to open
connections to prevent contamination.
9.Release clip and remove expansion hose from
radiator.10. If fitted:Remove 2 bolts and 4 scrivets securing
LH and RH radiator baffles and remove baffles.
11.Remove radiator upper retaining pegs from
bonnet locking platform. Ease top of radiator
forward.
12.Remove 4 bolts securing fan cowl to radiator.
13.Remove 2 cowl retaining clips from radiator.
M26 0947

EXTERIOR FITTINGS
REPAIRS 76-2-7
Side rail - integral roof rack - 5 door
$% 76.11.30
Remove
1.Remove finishers from feet of side rail.
2.Remove 4 Torx screws securing side rail to roof
panel.
3.Remove side rail and 2 gaskets.
NOTE: Do not carry out further dismantling if
component is removed for access only.
4.Remove seal from each torque bolt.
5.Remove Torx bolts from side rail.
Refit
1.Fit Torx bolts and seals to replacement side rail.
2.Fit gaskets to side rail.
3.Position side rail and tighten Torx bolts to 22
Nm (16 lbf.ft).
4.Fit finishers to feet of side rail.
Bonnet
$% 76.16.01.99
Remove
1.Support bonnet in open position.
2.Fit protection covers to wings and mark hinge
outline on bonnet if bonnet is to be refitted.
3.Disconnect windscreen washer tube at elbow
joint.
4.With assistance, remove bolts securing hinges
to bonnet and remove bonnet.
Refit
1.With assistance, position bonnet to hinges. Fit
and lightly tighten bolts.
2.Connect windscreen washer tube.
3.Close bonnet. Check that bonnet is aligned to
both front wings and that gaps are equal. If
necessary, adjust bonnet alignment and/or
gaps.
4.Finally tighten hinge bolts to 9 Nm (7 lbf.ft).

EXTERIOR FITTINGS
76-2-10 REPAIRS
Bumper - assembly - front - up to 04MY
$% 76.22.72
Remove
1.Open bonnet.
2.Remove 8 screws securing wheel arch liners to
bumper, release liners from wheelarch for
access.
3.Remove 2 screws securing bumper valance to
underbelly panel brackets.
4.Remove 3 scrivets securing bumper to
armature.
5.Remove 2 bolts securing rear edge of front
bumper to inner front wing.
6.Remove 4 screws securing bumper to bonnet
locking platform.
7. NAS Models: Release side repeater,
disconnect multiplug and remove repeater.
8.With assistance carefully lift and pull forward
each side of bumper to release bumper side
mounts and clips.
CAUTION: Always protect paintwork when
removing or refitting any body trims or
bumpers.
9.Remove front number plate.
10.Remove badge from grill and discard clips.Refit
1.Fit badge to grill.
2.Fit number plate.
3.With assistance, fit bumper assembly to body.
4. NAS Models: Feed side repeater harness
through bumper, connect multiplug and fit
repeater.
5.Ensure bumper locating pegs are correctly
aligned.
6.Fit and tighten bolts securing bumper to wings.
7.Fit screws securing bumper to bonnet locking
platform.
8.Fit scrivets to armature.
9.Fit screws securing bumper to underbelly
panel.
10.Fit and align wheelarch liners and tighten
screws.
11.Close bonnet.

EXTERIOR FITTINGS
REPAIRS 76-2-11
Bumper - assembly - front - from 04MY
$% 76.22.72
Remove
1.Open bonnet.
2.Remove 8 screws securing wheel arch liners to
bumper, release liners from wheel arch for
access.
3.Remove 4 screws securing bumper valance to
underbelly panel.
4.Remove 3 scrivets securing bumper to
armature.5.Disconnect multiplugs from fog/driving lamps.
6.Remove 2 bolts securing rear edge of front
bumper to inner front wing.
7.Remove 4 screws securing bumper to bonnet
locking platform.
M76 4674

PANEL REPAIRS
REPAIRS 77-2-25
REPAIRS
Front bulkhead assembly
In this procedure, the crossmember gusset plates
are replaced in conjunction with the front bulkhead
assembly.
Remove
1.Disconnect battery earth lead.
2.Disconnect alternator.
3.Disconnect all ECUs.
4.Remove front bumper valance.

+ EXTERIOR FITTINGS, REPAIRS,
Bumper - assembly - front - up to 04MY.
5.Remove front bumper armature.
6.Remove radiator.

+ COOLING SYSTEM - K SERIES KV6,
REPAIRS, Radiator assembly.
7.Remove PAS fluid cooler.

+ STEERING, REPAIRS, Oil cooler -
Td4 & K1.8 models.
8.Remove LH and RH headlamps.

+ LIGHTING, REPAIRS, Headlamp
assembly - up to 04MY.
9.Release wiring to headlamps and position
aside.
10.Remove LH and RH engine bay shields.
11.Remove bumper valance LH and RH
attachment brackets.
12.Remove battery.

+ CHARGING AND STARTING,
REPAIRS, Battery.
13.Remove air intake hose.
14.Remove horn.

+ SECURITY, REPAIRS, Horn.
15.Remove windscreen washer reservoir.

+ WIPERS AND WASHERS, REPAIRS,
Reservoir - washer.
16.Remove bonnet lock.
17.Support bonnet in open position.
18.Remove bonnet stay. Repair
1.Remove existing panel(s), prepare panel joint
faces and install new panel(s) in accordance
with Panel Replacement Procedure. Punch or
drill holes in new panel for plug welding as
shown.

PANEL REPAIRS
REPAIRS 77-2-27
Bonnet locking platform
In this procedure the bonnet locking platform
reinforcement is also replaced in conjunction with the
bonnet locking platform.
Remove
1.Disconnect battery earth lead.
2.Disconnect alternator.
3.Disconnect all ECUs.
4.Remove front bumper valance.

+ EXTERIOR FITTINGS, REPAIRS,
Bumper - assembly - front - up to 04MY.
5.Remove radiator.

+ COOLING SYSTEM - K SERIES KV6,
REPAIRS, Radiator assembly.
6.Remove both headlamp assemblies.

+ LIGHTING, REPAIRS, Headlamp
assembly - up to 04MY.
7.Remove horn.

+ SECURITY, REPAIRS, Horn.
8.Remove battery.

+ CHARGING AND STARTING,
REPAIRS, Battery.
9.Remove air intake hose.
10.Remove bonnet lock.
11.Support bonnet in open position.
12.Remove bonnet stay.
Repair
1.Remove existing panel(s), prepare panel joint
faces and install new panel(s) in accordance
with Panel Replacement Procedure. Refit
1.Fit bonnet stay.
2.Fit bonnet lock.
3.Fit air intake hose.
4.Fit battery. Do not connect earth lead.

+ CHARGING AND STARTING,
REPAIRS, Battery.
5.Fit horn.

+ SECURITY, REPAIRS, Horn.
6.Fit both headlamp assemblies.

+ LIGHTING, REPAIRS, Headlamp
assembly - up to 04MY.
7.Fit radiator.

+ COOLING SYSTEM - K SERIES KV6,
REPAIRS, Radiator assembly.
8.Fit front bumper valance.

+ EXTERIOR FITTINGS, REPAIRS,
Bumper - assembly - front - up to 04MY.
9.Connect all ECUs.
10.Connect alternator.
11.Connect battery earth lead.

HEATING AND VENTILATION
80-16REPAIRS
Relay - power - positive temperature co-
efficient (PTC) - Td4 models
$% 80.20.34
Remove
1.Disconnect battery earth lead.
2.Release and open under bonnet fuse box lid.
3.Remove 3 nuts securing fuse box and release
fuse box from studs.
4.Remove fixing and release PTC power relay
bracket from studs.
5.Remove cover from PTC power relay.6.Remove cable ties securing PTC power relay.
7.Remove PTC power relay.
Refit
1.Fit PTC power relay.
2.Fit cable ties to secure PTC power relay.
3.Fit cover over PTC power relay.
4.Fit PTC power relay bracket to studs and
secure with fixing.
5.Fit fuse box to studs, fit nuts and tighten to 8
Nm (6 lbf.ft).
6.Close fuse box lid.
M80 0576
M80 0577
