light Lexus CT200h 2011 (in English) Owners Manual

441
3
Interior features
CT200h_EE (OM76041E)
3-6. Using the storage features
List of storage features
CAUTION
Items that should not be left in the storage spaces
Do not leave glasses, lighters or spray cans in the storage spaces, as this may
cause the following when cabin temperature becomes high:
Glasses may be deformed by heat or cracked if they come into contact
with other stored items.
Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release gas,
causing a fire hazard.
Console box
Bottle holders
Auxiliary boxes
Glove box
Cup holders

449
3-7. Other interior features
3
Interior features
CT200h_EE (OM76041E)
Vanity mirrors
NOTICE
To prevent 12-volt battery discharge
Do not leave the vanity lights on for extended periods while the hybrid sys-
tem is off.
Slide the cover to open.
The light turns on when the
cover is opened.

453
3-7. Other interior features
3
Interior features
CT200h_EE (OM76041E)
Heated steering wheel
: If equipped
The heated steering wheel can be used when
The “POWER” switch is in ON mode.
Timer
The heated steering wheel will automatically turn off after about 30 min-
utes.
If the indicator light flashes
Press the button to turn the heated steering wheel off and then press the but-
ton again. If the indicator light still flashes, a malfunction may be occurring.
Turn the heated steering wheel off and have the vehicle inspected by any
authorized Lexus dealer or repairer, or another duly qualified and equipped
professional.
The heated steering wheel heats the side grips of the steering wheel.
Turns the heater on/off
The indicator light comes on
when the heater is operating.

455
3-7. Other interior features
3
Interior features
CT200h_EE (OM76041E)
Seat heaters
: If equipped
The seat heaters can be used when
The “POWER” switch is in ON mode.
When not in use
Turn the knob fully counterclockwise. The indicator light goes off.
Press the knob into the recessed position.
Pops the knob out
Turns the seat heater on
The indicator light comes on.
Adjusts the seat tempera-
ture
The further you turn the knob
clockwise, the warmer the
tb

4Maintenance and care
465
CT200h_EE (OM76041E)
4-1. Maintenance and care
Cleaning and protecting
the vehicle exterior ........ 466
Cleaning and protecting
the vehicle interior ......... 471
4-2. Maintenance
Maintenance
requirements .................. 474
4-3. Do-it-yourself maintenance
Do-it-yourself service
precautions..................... 477
Hood ................................ 481
Positioning a floor jack .... 483
Engine compartment ........ 485
12-volt battery.................. 496
Tires ................................. 503
Tire inflation pressure ...... 507
Wheels ............................. 509
Air conditioning filter ....... 511
Electronic key battery ...... 515
Checking and replacing
fuses ............................... 520
Light bulbs ....................... 534

468
4-1. Maintenance and care
CT200h_EE (OM76041E)
Outside rear view mirror rain-clearing coating
Observe the following precautions in order to retain the rain-clearing prop-
erties of the mirrors:
Clean the mirrors using a car shampoo or glass cleaner that does not con-
tain silicone or an abrasive compound, and rinse thoroughly with water.
Allow the mirrors to be exposed to direct sunlight for 1 to 2 days.
CAUTION
When washing the vehicle
Do not apply water to the inside of the engine compartment. Doing so may
cause the electrical components etc. to catch fire.
When cleaning the windshield (vehicles with rain-sensing windshield wip-
ers)
When the upper part of the windshield where the raindrop sensor is
located is touched by hand
When a wet rag or similar is held close to the raindrop sensor
If something bumps against the windshield
If you directly touch the raindrop sensor body or if something bumps into
the raindrop sensor
Precautions regarding the exhaust pipe
Exhaust gasses cause the exhaust pipe to become quite hot.
When washing the vehicle, be careful not to touch the pipe until it has
cooled sufficiently, as touching a hot exhaust pipe can cause burns.
Set the wiper switch to off.
If the wiper switch is in “AUTO”, the
wipers may operate unexpectedly in the
following situations, and may result in
hands being caught or other serious inju-
ries and cause damage to the wiper
blades.
Off

469
4-1. Maintenance and care
4
Maintenance and care
CT200h_EE (OM76041E)
NOTICE
To prevent paint deterioration and corrosion on the body and components
(aluminum wheels etc.)
Wash the vehicle immediately in the following cases:
• After driving near the sea coast
• After driving on salted roads
• If coal tar or tree sap is present on the paint surface
• If dead insects, insect droppings or bird droppings are present on the
paint surface
• After driving in an area contaminated with soot, oily smoke, mine
dust, iron powder or chemical substances
• If the vehicle becomes heavily soiled with dust or mud
• If liquids such as benzene and gasoline are spilled on the paint sur-
face
If the paint is chipped or scratched, have it repaired immediately.
To prevent the wheels from corroding, remove any dirt and store in a
place with low humidity when storing the wheels.
Cleaning the exterior lights
Wash carefully. Do not use organic substances or scrub with a hard brush.
This may damage the surfaces of the lights.
Do not apply wax to the surfaces of the lights.
Wax may cause damage to the lenses.

473
4-1. Maintenance and care
4
Maintenance and care
CT200h_EE (OM76041E)
NOTICE
Cleaning detergents
Do not use the following types of detergent, as they may discolor the vehi-
cle interior or cause streaks or damage to painted surfaces:
• Non-seat portions: Organic substances such as benzene or gasoline,
alkaline or acidic solutions, dye, and bleach
• Seats: Alkaline or acidic solutions, such as thinner, benzene, and
alcohol
Do not use polish wax or polish cleaner. The instrument panel’s or other
interior part’s painted surface may be damaged.
Preventing damage to leather surfaces
Observe the following precautions to avoid damage to and deterioration of
leather surfaces:
Remove any dust or dirt from leather surfaces immediately.
Do not expose the vehicle to direct sunlight for extended periods of time.
Park the vehicle in the shade, especially during summer.
Do not place items made of vinyl, plastic, or containing wax on the uphol-
stery, as they may stick to the leather surface if the vehicle interior heats
up significantly.
Water on the floor
Do not wash the vehicle floor with water.
Vehicle systems such as the audio system may be damaged if water comes
into contact with electrical components such as the audio system above or
under the floor of the vehicle. Water may also cause the body to rust.
Cleaning the inside of the rear window
Do not use glass cleaner to clean the rear window, as this may cause dam-
age to the rear window defogger heater wires or antenna. Use a cloth
dampened with lukewarm water to gently wipe the window clean. Wipe
the window in strokes running parallel to the heater wires or antenna.
Be careful not to scratch or damage the heater wires or antenna.

478
4-3. Do-it-yourself maintenance
CT200h_EE (OM76041E)
ItemsParts and tools
Engine oil level (P. 487)
• “Toyota Genuine Motor Oil” or
equivalent
• Rag or paper towel
• Funnel (used only for adding
engine oil)
Fuses (P. 520)• Fuse with same amperage rating
as original
Light bulbs (P. 534)
• Bulb with same number and
wattage rating as original
• Phillips-head screwdriver
• Flathead screwdriver
•Wrench
Radiator and condenser (P. 4 9 4)
Tire inflation pressure (P. 507)• Tire pressure gauge
• Compressed air source
Washer fluid (P. 495)
• Water or washer fluid contain-
ing antifreeze (for winter use)
• Funnel (used only for adding
water or washer fluid)

480
4-3. Do-it-yourself maintenance
CT200h_EE (OM76041E)
NOTICE
If you remove the air cleaner filter
Driving with the air cleaner filter removed may cause excessive engine wear
due to dirt in the air. Also, a backfire could cause a fire in the engine com-
partment.
If the fluid level is low or high
It is normal for the brake fluid level to go down slightly as the brake pads
wear or when the fluid level in the accumulator is high.
If the reservoir needs frequent refilling, it may indicate a serious problem.
