Lexus CT200h 2012 Navigation Manual (in English)

191
1. TELEPHONE OPERATION
4
TELEPHONE
CT200h_Navi_OM76078E_(EE)
14.02.06 12:30
1Select or press the
switch on the steering wheel to start
talking with the other party.
INCOMING CALL WAITING
When a call is interrupted by a third
party while talking, this screen is dis-
played.
Select or press the
switch on the steering wheel to refuse
the call.
Each time is selected or the
switch on the steering wheel is
pressed during an interrupted call, the
party who is on hold will be
switched.
INFORMATION
If your cellular phone does not sup-
port HFP Ver. 1.5, this function can-
not be used.
The ring tone that has been set in the
“Sound settings” screen sounds when
there is an incoming call. Depending
on the type of Bluetooth
® phone, both
the navigation system and Bluetooth®
phone may sound simultaneously
when there is an incoming call. (See
“RING TONE SETTING” on page
196.)

192
1. TELEPHONE OPERATION
CT200h_Navi_OM76078E_(EE)
14.02.06 12:30
7. Bluetooth® PHONE MESSAGE FUNCTION
1Press the “MENU” button on the
Remote Touch. (See “Remote
Touch” on page 12.)
2Select “Telephone” on the “Menu”
screen.
The “Telephone” screen can be dis-
played by pressing
on the steering
wheel.
3Select “Messages”.
Depending on the type of Bluetooth®
phone being connected, it may be nec-
essary to perform additional steps on
the telephone.
When “Message transfer” is set to
“Off”, a confirmation screen will be
displayed. Select “Yes”. (See page
211.)
4Select the screen button correspond-
ing to the desired message.
Messages are displayed in the appropri-
ate connected Bluetooth® phone’s reg-
istered mail address folder. Select the
tab of the desired folder to be dis-
played.
5Messages can be checked.
Selecting “Previous” or “Next” dis-
plays the previous or next message.
Only received messages on the con-
nected Bluetooth
® phone can be dis-
played.
6Select “Play” to start reading out of
the message. Select “Stop” to stop
the function.
Select “-” or “+”, turn the Power/Vol-
ume knob, or use the volume switch on
the steering wheel to adjust the mes-
sage read out volume.
Received messages can be forward-
ed from the connected Bluetooth
®
phone, enabling checking and reply-
ing using the navigation system
(Quick reply).
CHECKING MESSAGES

193
1. TELEPHONE OPERATION
4
TELEPHONE
CT200h_Navi_OM76078E_(EE)
14.02.06 12:30
1Select “Reply”.
2Select the screen button correspond-
ing to the desired message.
3Select “Send”.
While the message is being sent, a
sending message screen is displayed.
4This screen will be displayed if mes-
sage delivery fails.
Select “Retry” to attempt to send the
message again or select “Cancel” to
cancel.
When the received message is an e-
mail and “Update read status on tele-
phone” is set to “On”, “Mark as
unread” or “Mark as read” can be
selected. Select “Mark as unread” to
mark mails that have been read on the
Bluetooth
® phone as unread. Con-
versely, select “Mark as read” to
mark mails that have not been read on
the Bluetooth
® phone as read. (See
“MESSAGE SETTINGS” on page
211.)
For SMS/MMS, selecting
or
pressing the switch on the steering
wheel
calls the sender. (See page
187.)
Select “Reply” to reply to the mes-
sage.
REPLYING (QUICK REPLY)

194
1. TELEPHONE OPERATION
CT200h_Navi_OM76078E_(EE)
14.02.06 12:30
1Reply messages can be edited while
the vehicle is parked. Select “Edit”.
2Select the screen button correspond-
ing to the desired message.
3Select “OK” when editing is com-
pleted.
4Select .
1Select “Read” to check the message.
The “Messages” screen will be dis-
played.
When “Automatic message readout” is
set to “On”, the message will be auto-
matically read out. (See “MESSAGE
SETTINGS” on page 211.)
EDITING REPLY MESSAGES
NEW MESSAGE
NOTIFICATION
If “New message incoming” and
“New message voice notification”
are set to “On”, a notification ap-
pears on the screen and a voice noti-
fication will be heard when a new
message arrives. (See “MESSAGE
SETTINGS” on page 211.)
For SMS/MMS, selecting or
pressing the switch on the steer-
ing wheel calls the sender. (See page
187.)
To check the message later, select
“Ignore” or .

195
CT200h_Navi_OM76078E_(EE)
14.02.06 12:30
4
TELEPHONE
2. SETUP
1. TELEPHONE SETTINGS
1Press the “MENU” button on the
Remote Touch.
2Select “Setup”.
3Select “Telephone”.
4Perform each setting according to
the procedures outlined on the fol-
lowing pages.
1Select “Sound settings”.
2Perform each setting according to
the procedures outlined on the fol-
lowing pages.
The phonebook can be edited. Vol-
ume, display and message settings
can also be changed.
TELEPHONE SOUND
SETTINGS
The call and ring tone volume can be
adjusted. A ring tone can be selected.

196
2. SETUP
CT200h_Navi_OM76078E_(EE)
14.02.06 12:30
3When all settings are completed, se-
lect “OK”.
1Select “Call volume” on the “Sound
settings” screen.
2Select “-” or “+” to adjust the call
volume.
3Select “OK”.
1Select “Ring tone volume” on the
“Sound settings” screen.
2Select “-” or “+” to adjust the ring
tone volume.
3Select “OK”.
1Select “Ring tone” on the “Sound
settings” screen.
2Select the screen button correspond-
ing to the desired ring tone.
Ring tones can be heard by selecting
the screen buttons.
3Select “OK”.
INFORMATION
The system will automatically
increase the volume when the speed
exceeds 80 km/h (50 mph).
CALL VOLUME SETTING
RING TONE VOLUME
SETTING
RING TONE SETTING

197
2. SETUP
4
TELEPHONE
CT200h_Navi_OM76078E_(EE)
14.02.06 12:30
1Select “Default” on the “Sound set-
tings” screen.
2Select “Yes”.
1Press the “MENU” button on the
Remote Touch. (See “Remote
Touch” on page 12.)
2Select “Setup” on the “Menu”
screen.
3Select “Telephone” on the “Setup”
screen.
4Select “Phonebook”.
5Perform each setting according to
the procedures outlined on the fol-
lowing pages.
1Press the “MENU” button on the
Remote Touch. (See “Remote
Touch” on page 12.)
2Select “Setup” on the “Menu”
screen.
3Select “Telephone” on the “Setup”
screen.
4Select “Phonebook” on the “Tele-
phone settings” screen.
INITIALIZING THE
SETTINGS
The settings can be initialized.
PHONEBOOK
The call history can be deleted and
phonebook and speed dial settings
can be changed.INFORMATION
Phonebook data is managed inde-
pendently for every registered tele-
phone. When one telephone is
connected, another telephone’s regis-
tered data cannot be read.
SETTING THE PHONEBOOK
The phonebook can be transferred
from a Bluetooth
® phone to the sys-
tem. The phonebook also can be add-
ed, edited and deleted.

198
2. SETUP
CT200h_Navi_OM76078E_(EE)
14.02.06 12:30
5Select “Manage contacts”.
6Perform each setting according to
the procedures outlined on the fol-
lowing pages.
THE “Contacts” SCREEN CAN
ALSO BE DISPLAYED
1Press the “MENU” button on the
Remote Touch, then select
“Telephone”.
The “Telephone” screen can be dis-
played by pressing
on the steering
wheel.
2Select “Contacts” on the “Tele-
phone” screen.
3Select “Options”.
4Select “Manage contacts”.
TRANSFERRING A TELE-
PHONE NUMBER
The telephone numbers in a
Bluetooth
® phone can be transferred
to the system. The system can man-
age up to 5 phonebooks. Up to 1000
contacts (maximum of 3 numbers per
contact) can be registered in each
phonebook.
Operation methods differ between
PBAP compatible and PBAP incom-
patible but OPP compatible
Bluetooth
® phones.
If your cellular phone is neither
PBAP nor OPP compatible, the
phonebook cannot be transferred.

199
2. SETUP
4
TELEPHONE
CT200h_Navi_OM76078E_(EE)
14.02.06 12:30
For PBAP compatible Bluetooth®
phones
1Select “Transfer contacts”.
2Select “Update phonebook”.
3Transfer the phonebook data to the
system using a Bluetooth® phone.
This operation may be unnecessary
depending on the cellular phone model.
Depending on the type of cellular
phone, OBEX authentication may be
required when transferring phonebook
data. Enter “1234” into the Bluetooth
®
phone.This screen appears while transferring.
To cancel this function, select “Can-
cel”.
If another Bluetooth
® device is con-
nected when transferring phonebook
data, depending on the telephone, the
connected Bluetooth
® device may need
to be disconnected.
PBAP compatible models automatic
data transfer setting
1Select “Transfer contacts”.
2Select “Automatic phonebook
download” to transfer the phone-
book from a connected cellular
phone.
Select “Automatically download call
history” to transfer the call history
from a connected cellular phone.
When a PBAP compatible telephone is
connected, the phone’s phonebook
data can be automatically transferred.

200
2. SETUP
CT200h_Navi_OM76078E_(EE)
14.02.06 12:30
3Select “On”.
4Select “OK”.
For PBAP incompatible but OPP
compatible Bluetooth
® phones
1Select “Transfer contacts”.
2Select “Replace contacts” or “Add
contacts”.
If the phonebook contains phonebook
data, this screen is displayed.
3Transfer the phonebook data to the
system using a Bluetooth
® phone.
Depending on the type of cellular
phone, OBEX authentication may be
required when transferring phonebook
data. Enter “1234” into the Bluetooth
®
phone.
This screen appears while transferring.
To cancel this function, select “Can-
cel”. If “Add contacts” is selected and
there is an interruption during the trans-
fer of data, the phonebook data trans-
ferred until then will be stored in the
system. This is not the case when “Can-
cel” is selected.
4When the transfer is complete, “Do-
ne” will appear on the screen. Select
“Done”.
INFORMATION
Depending on the type of Bluetooth®
phone, the registered image on the
phonebook may not appear when
phonebook data is transferred.
