1-5. Opening and closing the windows and moon roof
CT200h_OM_OM76067E_(EE)
Door lock linked window operation
The power windows can be opened and closed using the mechanical
key.
*
(P. 630)
The power windows can be opened and closed using the wireless remote
control.
* (P. 8 4)
*:These settings must be customized at any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional.
Customization
Setting (e.g. linked door lock operation) can be changed.
(Customizable features
P. 667)
CAUTION
Closing the windows
Observe the following precautions.
Failing to do so may result in death or serious injury.
Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when a window is being operated.
Do not allow children to operate the power windows.
Closing a power window on someone can cause serious injury, and in
some instances, even death.
Jam protection function
Never use any part of your body to intentionally activate the jam protec-
tion function.
The jam protection function may not work if something gets caught just
before the window fully closes.

127
1
1-5. Opening and closing the windows and moon roof
Before driving
CT200h_OM_OM76067E_(EE)
Moon roof
: If equipped
Use the overhead switches to open and close the moon roof and tilt it
up and down.
Opening and closing
Opens the moon roof
*
Push and hold “OPEN” for
more than 1 second. The
moon roof tilts up and then
opens automatically.
Closes the moon roof*
Push and hold “CLOSE” for
more than 1 second. The
moon roof closes automati-
cally to the tilt up position.
Push and hold “CLOSE”
again to fully close the moon
roof.
*: Lightly press either of the
moon roof switches to stop

128
1-5. Opening and closing the windows and moon roof
CT200h_OM_OM76067E_(EE)
The moon roof can be operated when
The “POWER” switch is in ON mode.
Operating the moon roof after turning the hybrid system off
The moon roof can be operated for approximately 43 seconds even after the
“POWER” switch is turned to ACCESSORY mode or turned off. It cannot,
however, be operated once either front door is opened.
Jam protection function
If an object is detected between the moon roof and the frame while the
moon roof is closing or tilting down, travel is stopped and the moon roof
opens slightly.
Sunshade
The sunshade can be opened and closed manually. However, the sunshade
will open automatically to slightly before the fully open position when the
moon roof is opened.
Tilting up and down
Tilts the moon roof up
*
Tilts the moon roof down*
*
: Lightly press either of the
moon roof switches to stop
the moon roof partway.

129
1-5. Opening and closing the windows and moon roof
1
Before driving
CT200h_OM_OM76067E_(EE)
When the moon roof does not close normally
Perform the following procedure:
If the moon roof closes but then re-opens slightly
Stop the vehicle.
Press and hold the “CLOSE” switch.
*1
The moon roof will close, reopen and pause for approximately 10
seconds.
*2 Then it will close again and tilt down. Finally it will be
adjusted slightly and then stop.
Check to make sure that the moon roof completely stops and then
release the switch.
If the moon roof tilts down but then tilts back up
Stop the vehicle.
Press and hold the “DOWN” switch.
*1
The moon roof will close, reopen and pause for approximately 10
seconds in the tilt up position.
*2 Then it will close again and tilt
down. Finally it will be adjusted slightly and then stop.
Check to make sure that the moon roof has completely stopped and
then release the switch.
*1: If the switch is released at the incorrect time, the procedure will have to
be performed again from the beginning.
*2: If the switch is released after the above mentioned 10 second pause,
automatic operation will be disabled. In that case, press and hold the
“CLOSE” or “DOWN” switch, and the moon roof will close, be adjusted
slightly and then stop. Check to make sure that the moon roof has com-
pletely stopped and then release the switch.
If the moon roof does not fully close even after performing the above proce-
dure correctly, have the vehicle inspected by any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional.
STEP1
STEP2
STEP3
STEP1
STEP2
STEP3

130
1-5. Opening and closing the windows and moon roof
CT200h_OM_OM76067E_(EE)
Moon roof open warning buzzer
The buzzer sounds and a message is shown on the multi-information display
in the instrument cluster when the “POWER” switch is turned off and the
driver’s door is opened with the moon roof open.
CAUTION
Opening the moon roof
Observe the following precautions.
Failing to do so may cause death or serious injury.
Do not allow any passengers to put their hands or heads outside the vehi-
cle while it is moving.
Do not sit on top of the moon roof.
Closing the moon roof
Observe the following precautions.
Failing to do so may result in death or serious injury.
Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when the moon roof is being oper-
ated.
Do not allow children to operate the moon roof.
Closing the moon roof on someone can cause death or serious injury.
Jam protection function
Never use any part of your body to intentionally activate the jam protec-
tion function.
The jam protection function may not work if something gets caught just
before the moon roof fully closes.

131
1
Before driving
CT200h_OM_OM76067E_(EE)
1-6. Refueling
Opening the fuel tank cap
Perform the following steps to open the fuel tank cap:
Before refueling the vehicle
Turn the “POWER” switch off and close all the doors and
windows.
Confirm the type of fuel. (P. 132)
Opening the fuel tank cap
Press the opener to open the
fuel filler door.
Turn the fuel tank cap slowly
to open.
Hang the fuel tank cap on the
back of the fuel filler door.
STEP1
STEP2
STEP3

132
1-6. Refueling
CT200h_OM_OM76067E_(EE)
Closing the fuel tank cap
After refueling, turn the fuel
tank cap until you hear a click.
Once the cap is released, it will
turn slightly in the opposite
direction.
When the fuel filler door cannot be opened by pressing the inside switch
Fuel types
EU area:
Unleaded gasoline conforming to European standard EN228, Research
Octane Number of 95 or higher
Except EU area:
Unleaded gasoline, Research Octane Number of 95 or higher
Fuel tank capacity
Approximately 45 L (11.9 gal., 9.9 lmp. gal.)
Use of ethanol blended gasoline in a gasoline engine
Lexus allows the use of ethanol blended gasoline where the ethanol content
is up to 10%. Make sure that the ethanol blended gasoline to be used has a
Research Octane Number that follows the above.
Remove the cover inside the luggage
compartment and pull the lever.

133
1-6. Refueling
1
Before driving
CT200h_OM_OM76067E_(EE)
CAUTION
When refueling the vehicle
Observe the following precautions while refueling the vehicle. Failure to do
so may result in death or serious injury.
After exiting the vehicle and before opening the fuel door, touch an
unpainted metal surface to discharge any static electricity. It is important
to discharge static electricity before refueling because sparks resulting
from static electricity can cause fuel vapors to ignite while refueling.
Always hold the grips on the fuel tank cap and turn it slowly to remove it.
A whooshing sound may be heard when the fuel tank cap is loosened.
Wait until the sound cannot be heard before fully removing the cap. In hot
weather, pressurized fuel may spray out of the filler neck and cause injury.
Do not allow anyone that has not discharged static electricity from their
body to come close to an open fuel tank.
Do not inhale vaporized fuel.
Fuel contains substances that are harmful if inhaled.
Do not smoke while refueling the vehicle.
Doing so may cause the fuel to ignite and cause a fire.
Do not return to the vehicle or touch any person or object that is statically
charged.
This may cause static electricity to build up, resulting in a possible igni-
tion hazard.

141
1-7. Theft deterrent system
1
Before driving
CT200h_OM_OM76067E_(EE)
Canceling the double locking system
Using the entry function: Hold the outside door handle.
Using the wireless remote control: Press .
CAUTION
Double locking system precaution
Never activate the double locking system when there are people in the vehi-
cle, because all the doors cannot be opened from inside the vehicle.

142
1-7. Theft deterrent system
CT200h_OM_OM76067E_(EE)
Alarm
: If equipped
The system sounds the alarm and flashes lights when forcible entry is
detected.
Triggering of the alarm
The alarm is triggered in the following situations when the
alarm is set:
A locked door is unlocked or opened in any way other than
using the entry function (vehicles with a smart entry & start
system) or wireless remote control.
The hood is opened.
The intrusion sensor detects something moving inside the
vehicle. (An intruder gets in the vehicle.) (if equipped)
The tilt sensor detects a change of vehicle inclination. (if
equipped)
The back door window is broken. (if equipped)
Setting the alarm system
Close the doors and hood,
and lock all the doors using
the entry function (vehicles
with a smart entry & start
system) or wireless remote
control. The system will be
set automatically after 30
seconds.
The indicator light changes
from being on to flashing
