456
3-6. Using the storage features
CT200h_OM_OM76067E_(EE)
CAUTION
Caution while driving (type A and E)
Keep the auxiliary boxes closed when not in use. In the event of sudden
braking, an accident may occur due to an occupant being struck by an open
auxiliary box or the items stored inside.
Items unsuitable for storing (type A)
Do not store items heavier than 200 g (0.44 lb.).
Doing so may cause the auxiliary box to open and the items inside may fall
out, resulting in an accident.
NOTICE
Auxiliary box (type E)
Do not leave items in the auxiliary box or on the dashboard for long periods
of time when the vehicle is in the sun.
The inside of the auxiliary box and the dashboard will become extremely
hot compared to other parts of the vehicle, and the items could be deformed
or damaged.
Auxiliary boxes

458
3-7. Other interior features
CT200h_OM_OM76067E_(EE)
Vanity mirrors
NOTICE
To prevent 12-volt battery discharge
Do not leave the vanity lights on for extended periods while the hybrid sys-
tem is off.
Slide the cover to open.
The light turns on when the
cover is opened.

460
3-7. Other interior features
CT200h_OM_OM76067E_(EE)
Power outlet
The power outlet can be used for 12 V accessories that run on less than
10 A.
Center console
Press down and release the
lid.
Open the cover.
STEP1
STEP2

461
3-7. Other interior features
3
Interior features
CT200h_OM_OM76067E_(EE)
Auxiliary box (if equipped)
Press the button.
Open the cover.
STEP1
STEP2

472
3-7. Other interior features
CT200h_OM_OM76067E_(EE)
Stowing the luggage cover
Remove the side deck boards
and open the center auxiliary
box.
Adjust the cover so that the
information label is facing up.
Fold the rear edge of the cover
over, replace the side deck
boards and close the center aux-
iliary box.
STEP1
STEP2
STEP3

487
4-2. Maintenance
4
Maintenance and care
CT200h_OM_OM76067E_(EE)
Does your vehicle need repairs?
Be on the alert for changes in performance and sounds, and visual tip-offs
that indicate service is needed. Some important clues are:
Engine missing, stumbling or pinging
Appreciable loss of power
Strange engine noises
A fluid leak under the vehicle (However, water dripping from the air
conditioning system after use is normal.)
Change in exhaust sound (This may indicate a dangerous carbon monox-
ide leak. Drive with the windows open and have the exhaust system
checked immediately.)
Flat-looking tires, excessive tire squeal when cornering, uneven tire
wear
Vehicle pulls to one side when driven straight on a level road
Strange noises related to suspension movement
Loss of brake effectiveness, spongy feeling brake pedal, pedal almost
touches the floor, vehicle pulls to one side when braking
Engine coolant temperature continually higher than normal
If you notice any of these clues, take your vehicle to any authorized Lexus
dealer or repairer, or another duly qualified and equipped professional as
soon as possible. Your vehicle may need adjustment or repair.
CAUTION
If your vehicle is not properly maintained
Improper maintenance could result in serious damage to the vehicle and
possible serious injury or death.
Handling of the 12-volt battery
12-volt battery posts, terminals and related accessories contain lead and lead
compounds which are known to cause brain damage. Wash your hands after
handling. (P. 508)

490
4-3. Do-it-yourself maintenance
CT200h_OM_OM76067E_(EE)
CAUTION
The engine compartment contains many mechanisms and fluids that may
move suddenly, become hot, or become electrically energized. To avoid death
or serious injury, observe the following precautions.
When working on the engine compartment
Make sure that the indicator on the “POWER” switch and the “READY”
indicator are both off.
Keep hands, clothing and tools away from the moving fan and engine
drive belt.
Be careful not to touch the engine, power control unit, radiator, exhaust
manifold, etc. right after driving as they may be hot. Oil and other fluids
may also be hot.
Do not leave anything that may burn easily, such as paper and rags, in the
engine compartment.
Do not smoke, cause sparks or expose an open flame to fuel. Fuel fumes
are flammable.
Take care because brake fluid can harm your hands or eyes and damage
painted surfaces. If fluid gets on your hands or in your eyes, flush the
affected area with clean water immediately.
If you still experience discomfort, consult a doctor.
When working near the electric cooling fans or radiator grille
Be sure the “POWER” switch is off.
With the “POWER” switch in ON mode, the electric cooling fans may auto-
matically start to run if the air conditioning is on and/or the coolant tempera-
ture is high. (P. 506)
Safety glasses
Wear safety glasses to prevent flying or falling material, fluid spray, etc.
from getting in your eyes.

492
4-3. Do-it-yourself maintenance
CT200h_OM_OM76067E_(EE)
Hood
Release the lock from the inside of the vehicle to open the hood.
Pull the hood release lever.
The hood will pop up
slightly.
Pull up the auxiliary catch
lever and lift the hood.
Hold the hood open by
inserting the supporting rod
into the slot.
STEP1
STEP2
STEP3

493
4-3. Do-it-yourself maintenance
4
Maintenance and care
CT200h_OM_OM76067E_(EE)
CAUTION
Pre-driving check
Check that the hood is fully closed and locked.
If the hood is not locked properly, it may open while the vehicle is in motion
and cause an accident, which may result in death or serious injury.
After installing the support rod into the slot
Make sure the rod supports the hood securely from falling down on to your
head or body.
NOTICE
When closing the hood
Be sure to return the support rod to its clip before closing the hood. Closing
the hood without returning the support rod properly could cause the hood to
bend.

508
4-3. Do-it-yourself maintenance
CT200h_OM_OM76067E_(EE)
12-volt battery
Location
The 12-volt battery is located
in the right-hand side of lug-
gage compartment.
Removing the 12-volt battery cover
Open the center and right side auxiliary boxes. (P. 470)
Remove the center auxiliary box. (P. 600)
Remove the right side auxil-
iary box.
Remove the 12-volt battery
maintenance cover.
STEP1
STEP2
STEP3
STEP4
