2214-3. Operating the lights and wipers
4
Driving
CT200h_OM_OM76102E_(EE)
WA R N I N G
Caution regarding the use of windshield wipers in “AUTO” mode (vehicles
with rain-sensing windshield wipers)
The windshield wipers may operate unexpectedly if the sensor is touched or the
windshield is subject to vibration in “AUTO” mode. Take care that your fingers
etc. do not become caught in the windshield wipers.
Caution regarding the use of washer fluid
When it is cold, do not use the washer fluid until the windshield becomes
warm. The fluid may freeze on the windshield and cause low visibility. This
may lead to an accident, resulting in death or serious injury.
NOTICE
When the windshield is dry
Do not use the wipers, as they may damage the windshield.
When the washer fluid tank is empty
Do not operate the switch continually as the washer fluid pump may overheat.
When a nozzle becomes blocked
In this case, contact any authorized Lexus dealer or repairer, or another duly
qualified and equipped professional.
Do not try to clear it with a pin or other object. The nozzle will be damaged.
To prevent 12-volt battery discharge
Do not leave the wipers on longer than necessary when the hybrid system is
off.

2224-3. Operating the lights and wipers
CT200h_OM_OM76102E_(EE)
Rear window wiper and washer
Turning the end of the lever turns on the rear window wiper and washer.
Intermittent operation
Normal operation
Washer/wiper dual opera-
tion
Washer/wiper dual opera-
tion
The rear window wiper and washer can be operated when
The power switch is in ON mode.
: If equipped
Operating the wiper lever
1
2
3
4
NOTICE
When the rear window is dry
Do not use the wiper, as it may damage the rear window.
When the washer fluid tank is empty
Do not operate the switch continually as the washer fluid pump may overheat.

223
4 4-3. Operating the lights and wipers
Driving
CT200h_OM_OM76102E_(EE)
Headlight cleaner switch
Press the switch to clean the head-
lights.
The headlight cleaners can be operated when
The power switch is in ON mode and the headlight switch is turned on.
Windshield washer linked operation
Only for the first time when the windshield washer is operated with the power
switch in ON mode and the headlights on, the headlight cleaners will operate
once.
(P. 218)
: If equipped
Washer fluid can be sprayed on the headlights.
NOTICE
When the washer fluid tank is empty
Do not press the switch continually as the washer fluid pump may overheat.

2244-4. Refueling
CT200h_OM_OM76102E_(EE)
Opening the fuel tank cap
Close all the doors and windows, and turn the power switch off.
Confirm the type of fuel.
Fuel types
EU area:
Unleaded gasoline conforming to European standard EN228, Research Octane
Number of 95 or higher
Except EU area:
Unleaded gasoline, Research octane number 95 or higher
Use of ethanol blended gasoline in a gasoline engine
Lexus allows the use of ethanol blended gasoline where the ethanol content is up
to 10%. Make sure that the ethanol blended gasoline to be used has a Research
Octane Number that follows the above.
Perform the following steps to open the fuel tank cap:
Before refueling the vehicle

2254-4. Refueling
4
Driving
CT200h_OM_OM76102E_(EE)
WA R N I N G
When refueling the vehicle
Observe the following precautions while refueling the vehicle. Failure to do so
may result in death or serious injury.
After exiting the vehicle and before opening the fuel door, touch an unpainted
metal surface to discharge any static electricity. It is important to discharge
static electricity before refueling because sparks resulting from static electric-
ity can cause fuel vapors to ignite while refueling.
Always hold the grips on the fuel tank cap and turn it slowly to remove it.
A whooshing sound may be heard when the fuel tank cap is loosened. Wait
until the sound cannot be heard before fully removing the cap. In hot weather,
pressurized fuel may spray out of the filler neck and cause injury.
Do not allow anyone that has not discharged static electricity from their body
to come close to an open fuel tank.
Do not inhale vaporized fuel.
Fuel contains substances that are harmful if inhaled.
Do not smoke while refueling the vehicle.
Doing so may cause the fuel to ignite and cause a fire.
Do not return to the vehicle or touch any person or object that is statically
charged.
This may cause static electricity to build up, resulting in a possible ignition
hazard.
When refueling
Observe the following precautions to prevent fuel overflowing from the fuel
tank:
Securely insert the fuel nozzle into the fuel filler neck.
Stop filling the tank after the fuel nozzle automatically clicks off.
Do not top off the fuel tank.
NOTICE
Refueling
Do not spill fuel during refueling.
Doing so may damage the vehicle, such as causing the emission control system
to operate abnormally or damaging fuel system components or the vehicle’s
painted surface.

2264-4. Refueling
CT200h_OM_OM76102E_(EE)
Press the opener to open the fuel
filler door.
Turn the fuel tank cap slowly to
open and hang it on the back of
the fuel filler door.
When the fuel filler door cannot be opened by pressing the inside switch
Opening the fuel tank cap
1
2
Remove the cover inside the luggage com-
partment and pull the lever.

2274-4. Refueling
4
Driving
CT200h_OM_OM76102E_(EE)
After refueling, turn the fuel tank
cap until you hear a click. Once the
cap is released, it will turn slightly
in the opposite direction.
Closing the fuel tank cap
WA R N I N G
When replacing the fuel cap
Do not use anything but a genuine Lexus fuel tank cap designed for your vehi-
cle. Doing so may cause a fire or other incident which may result in death or
serious injury.

2284-5. Using the driving support systems
CT200h_OM_OM76102E_(EE)
Cruise control
Use the cruise control to maintain a set speed without depressing the
accelerator pedal.
Indicator
Display
Cruise control switch
Press the “ON-OFF” button to
activate the cruise control.
Cruise control indicator will come
on.
Press the button again to deactivate
the cruise control.
Accelerate or decelerate the vehi-
cle to the desired speed, and push
the lever down to set the speed.
“SET” will be displayed.
The vehicle speed at the moment the
lever is released becomes the set
speed.
: If equipped
Summary of functions
1
2
3
Setting the vehicle speed
1
2

2294-5. Using the driving support systems
4
Driving
CT200h_OM_OM76102E_(EE)
To change the set speed, operate the lever until the desired set speed is
obtained.
Increases the speed
Decreases the speed
Fine adjustment: Momentarily move
the lever in the desired direction.
Large adjustment: Hold the lever in
the desired direction.
The set speed will be increased or decreased as follows:
Fine adjustment: By approximately 1.6 km/h (1 mph) each time the lever is
operated
Large adjustment: The set speed can be increased or decreased continually
until the lever is released.
Pulling the lever toward you can-
cels the constant speed control.
The speed setting is also canceled
when the brakes are applied.
Pushing the lever up resumes the
constant speed control.
Resuming is available when the
vehicle speed is more than approxi-
mately 40 km/h (25 mph).
Adjusting the set speed
1
2
Canceling and resuming the constant speed control
1
2

2304-5. Using the driving support systems
CT200h_OM_OM76102E_(EE)
Cruise control can be set when
The shift position is in D.
Vehicle speed is above approximately 40 km/h (25 mph).
Accelerating after setting the vehicle speed
The vehicle can be accelerated normally. After acceleration, the set speed
resumes.
Even without canceling the cruise control, the set speed can be increased by
first accelerating the vehicle to the desired speed and then pushing the lever
down to set the new speed.
Automatic cruise control cancelation
Cruise control will stop maintaining the vehicle speed in any of the following sit-
uations.
Actual vehicle speed falls more than approximately 16 km/h (10 mph) below
the preset vehicle speed.
At this time, the memorized set speed is not retained.
Actual vehicle speed is below approximately 40km/h (25 mph).
VSC is activated.
If the warning message for the cruise control is shown on the multi-information
display
Press the “ON-OFF” button once to deactivate the system, and then press the
button again to reactivate the system.
If the cruise control speed cannot be set or if the cruise control cancels immedi-
ately after being activated, there may be a malfunction in the cruise control sys-
tem. Have the vehicle inspected by any authorized Lexus dealer or repairer, or
another duly qualified and equipped professional.
WA R N I N G
To avoid operating the cruise control by mistake
Switch the cruise control off using the “ON-OFF” button when not in use.
Situations unsuitable for cruise control
Do not use cruise control in any of the following situations.
Doing so may result in loss of control and could cause an accident resulting in
death or serious injury.
In heavy traffic
On roads with sharp bends
On winding roads
On slippery roads, such as those covered with rain, ice or snow
On steep hills
Vehicle speed may exceed the set speed when driving down a steep hill.
During emergency towing
