Lexus GX460 2013 Specifications /

81
GX460_QG_U (OM60J68U)
Safety Connect(If Equipped)
■ System components
Microphone
LED light indicators
“SOS” button
■Services
Subscribers have the following Safety Connect services available:
● Automatic Collision Notification*
In case of either airbag deployment or seve re rear-end collision, the system is designed
to automatically call the response center. Th e responding agent receives the vehicle’s
location and attempts to speak with the vehicle occupants to assess the level of emer-
gency. If the occupants are unable to communicate, the agent automatically treats the
call as an emergency, contacts the nearest emergency services provider to describe the
situation, and requests that assistance be sent to the location.
*: U.S. Patent No. 7,508,298 B2
● Stolen Vehicle Location
If your vehicle is stolen, Safety Connect can work with local authorities to assist them in
locating and recovering the vehicle. After fi ling a police report, call the Safety Connect
response center at 1-800-25-LEXUS (1- 800-255-3987) and follow the prompts for
Safety Connect to initiate this service.
In addition to assisting law enforcement with recovery of a stolen vehicle, Safety-Con-
nect-equipped vehicle location data may, un der certain circumstances, be shared with
third parties to locate your vehicle. Further information is available at Lexus.com.
Safety Connect is a subscription-based telematics service that uses Global Positioning
System (GPS) data and embedded cellular te chnology to provide safety and security
features to subscribers. Safety Connect is supported by Lexus’ designated response
center, which operates 24 hours per day, 7 days per week.
Safety Connect service is available by subscription on select, telematics hardware-
equipped vehicles.

82
GX460_QG_U (OM60J68U)
●Emergency Assistance Button (SOS)
In the event of an emergency on the road, push the “SOS” button to reach the Safety
Connect response center. The answering agen t will determine your vehicle’s location,
assess the emergency, and dispatch the necessary assistance required. If you accidentally press the “SOS” button, tell the response-center agent that you are
not experiencing an emergency.
● Roadside Assistance
Subscribers can press the “SOS” button to reach a Safety Connect response-center
agent, who can help with a wide range of needs, such as: towing, flat tire, fuel delivery, etc.
For a description of the Roadsi de Assistance services and their limitations, please see the
Safety Connect Terms and Conditions, which are available at Lexus.com.
■ Subscription
After you have signed the Telematics Subscription Service Agreement and are enrolled,
you can begin receiving services.
A variety of subscription terms is available for purchase. Contact your Lexus dealer, call
1-800-25-LEXUS (1-800-255-3987) or push the “SOS” button in your vehicle for fur-
ther subscription details.

83
GX460_QG_U (OM60J68U)
Lexus Enform with Safety Connect
(If Equipped)
For details, refer to the “Owner’s Manual” and “Navigation System Owner’s Manual”.
■Services
With an active Lexus Enform subscription, the following features are available:
● Safety Connect features ( P. 8 1 )
• Automatic collision notification*
1
• Stolen vehicle location
• Emergency assistance button (SOS)
• Roadside assistance
● Destination Assist
Destination Assist provides you with live assistance for finding destinations via the Lexus
Enform response center. You can request either a specific business, address, or ask for
help locating your desired destination by ca tegory, such as restaurants, gas stations,
shopping centers or other points of interest (POI).
After you tell the agent your choice of destination, its coordinates are sent wirelessly to
your vehicle’s navigation system.
● eDestination
With the eDestination feature, you can go online, via the Lexus.com owner’s Web site, to
select and organize destinations of your choice and then wirelessly send them to your
vehicle’s navigation system.
You can store up to 200 locations online to access and update at any time.
Your locations can be organized into up to 20 personalized folders.
You must first go online at www. lexus.com and go to the “Owners” section where you will
need to register and log in. After this, you can create your personalized folders contain-
ing the locations you wish to send to your vehicle. (See Lexus Enform Guide for more
information.)
Lexus Enform and Safety Connect are subscription-based telematics services that use
Global Positioning System (GPS) data , embedded cellular technology an XM
® satellite
data services to provide safety and security as well as convenience features to subscrib-
ers.
Lexus Enform and Safety Connect servic es are supported by Lexus’ designated
response center, which operates 24 hours per day, 7 days per week.
Lexus Enform service is available by subs cription on select, telematics hardware-
equipped vehicles.

84
GX460_QG_U (OM60J68U)
●XM® Sports and Stocks*2
XM® Sports and Stocks is a service included with XM® satellite radio subscriptions for
Lexus Enform vehicles. With this service, you can receive updates via the navigation sys-
tem on your personally selected sports teams and stocks.
● XM NavWeather
TM*3
The subscription-based XM NavWeatherTM service allows the navigation system to dis-
play weather information on the map.
● XM
® NavTraffic*3
The subscription-based XM® NavTraffic service allows the navigation system to display
traffic information on the map.
The following navigation-based Lexus Enform features are available without a subscription:
● Lexus Insider
Lexus Insider is an optional service that can send audio messages, or articles, to partici-
pating owner’s vehicles via the navigation sy stem. Potential Lexus Insider subjects might
include, for example, Lexus vehicle technology tips, updates on regional Lexus events, or
audio excerpts from Lexus Magazine articles. Up to 20 articles can be stored at a time.
● Voice Command
The voice command system enables you to op erate the navigation system, audio system
and hands-free system by giving a command.
*
1: U.S. Patent No. 7,508,298 B2
*
2: Available at no extra charge with an active XM® satellite radio subscription.
*
3: Available via separate XM® subscription(s).
■ Subscription
After you have signed the Telematics Subscription Service Agreement and are enrolled,
you can begin receiving services. A variety of subscription terms is available for purchase.
Contact your Lexus dealer, call 1-800-25-LEXUS (1-800-255-3987), or push the “Desti-
nation Assist” button in your vehicl e for further subscription details. XM
® NavTraffic and
XM NavWeather
TM require separate XM® subscription(s). XM® Sports and Stocks is
available with an XM
® Satellite Radio subscription. After a 90-day free trial, you must set
up the appropriate XM
® subscription(s) to continue receiving these services.

85
GX460_QG_U (OM60J68U)
Door Locks
■Door lock switches
Locks all the doors
Unlocks all the doors
■Inside lock button
Locks the door
Unlocks the door
The front doors can be opened by pull-
ing the inside handles even if the lock
buttons are in the lock position.
The vehicle can be locked and unlocked using the entry function, wireless remote con-
trol, key or door lock switch.
For details the entry function or wireless remote control ( P.10, 11)

86
GX460_QG_U (OM60J68U)
■Rear door child-protector lock
The door cannot be open ed from inside the
vehicle when the lock is set.
Unlock
Lock
These locks can be set to prevent chil-
dren from opening the rear doors. Push
down on each rear door switch to lock
both rear doors.
Power Windows
■Power window switches
Closing
One-touch closing*
Opening
One-touch opening*
*: Pushing the switch in the opposite direc- tion will stop window travel partway.
■Window lock switch
Press the switch down to lock the passen-
ger window switches.
The indicator will come on.
Use this switch to prevent children from
accidentally opening or closing a pas-
senger window.
The passenger windows can still be
opened and closed using the power win-
dow switches on the driver’s side even if
the lock switch is on.

87
GX460_QG_U (OM60J68U)
Moon Roof
■Opening and closing
Opens the moon roof*
The moon roof stops slightly before the
fully open position to reduce wind noise.
Press the switch again to fully open the
moon roof.
Closes the moon roof*
*: Lightly press either of the moon roof switches to stop the moon roof partway.
■Tilting up and down
Tilts the moon roof up*
Tilts the moon roof down*
*: Lightly press either of the moon roof switches to stop the moon roof partway.

88
GX460_QG_U (OM60J68U)
Fuel Tank Cap
■Before refueling the vehicle
Turn the “ENGINE START STOP” switch off and ensure that all the doors and windows are
closed.
■Opening the fuel tank cap
Press the opener to open the fuel filler
door.
Turn the fuel tank cap slowly to open.
Hang the fuel tank cap on the back of the
fuel filler door.

What to do if ...
89
GX460_QG_U (OM60J68U)
List of Warning/Indicator Lights
Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous.
(U.S.A.)
(Canada)Brake system warning light
Stop the vehicle immediately.
Charging system warning light
Have the vehicle inspected immediately.
(U.S.A.)
Malfunction
indicator lamp(Blinking and
then continu- ously on)Tire pressure warning light
(Canada)
(Flashing)
“AFS OFF” indicator*1
SRS warning light
(Flashing)
Automatic High Beam
indicator*
1
(U.S.A.)
ABS warning light(Flashing)
“LDA” indicator light*1
(Canada)
(Flashing)
Cruise control indicator*1
(Comes on)
Slip indicator light
(Flashing)
Dynamic radar cruise control
indicator*
1
(Flashing)
“PCS” warning light*1
(Flashing)
Multi-terrain Select
indicator*
1
Kinetic dynamic suspension
system warning light
For further information, re fer to the Owner’s Manual.

90
What to do if ...
GX460_QG_U (OM60J68U)
Have the vehicle inspected immediately.
(Flashing)
Low speed four-wheel drive
indicator*
3(Flashing)
Center differential lock
indicator*
3
Have the malfunction repaired immediately.
Open door warning light(On the cen-ter panel)
Front passenger’s seat belt
reminder light
Low fuel level warning lightMaster warning light
a
(On the
instrument panel)Driver’s seat belt
reminder light(Illuminates
without blink- ing)Tire pressure warning light*2
See the Owner’s Manual
Turn signal indicatorVSC OFF indicator
Headlight high beam indicator
(Comes on)
Multi-terrain Select
indicator*
1
Headlight indicator (U.S.A.)Crawl Control indicator*1
Tail light indicator (Canada)Downhill assist control system
indicator*
1
Automatic High Beam
indicator*
1“2nd STRT” indicator
Fog light indicator
(Comes on)
Low speed four-wheel drive
indicator
Eco Driving Indicator Light
(Comes on)
Center differential lock
indicator
For further information, re fer to the Owner’s Manual.
