1-7. Safety information
1
Before driving
GX460_OM_OM60J63U_(U)Fully extend the shoulder belt and
allow it to retract to put it in lock
mode. In lock mode, the belt can-
not be extended.
While pushing the child restraint
system into the rear seat, allow the
shoulder belt to retract until the
child restraint system is securely in
place.
After the shoulder belt has
retracted to a point where there is
no slack in the belt, pull the belt to
check that it cannot be extended.
If the child restraint has a top tether strap, the top tether strap
should be latched onto th
e top tether strap anchor. ( P. 164)
STEP4
STEP5
STEP6

162
1-7. Safety information
GX460_OM_OM60J63U_(U)■
Booster seat
Fold the seatback forward. Then
return the seatback and secure it
at the first lock position (most
upright position). ( P. 7 1 )
Place the child restraint system on
the seat facing the front of the vehi-
cle.
STEP1
STEP2

163
1-7. Safety information
1
Before driving
GX460_OM_OM60J63U_(U)Sit the child in the child restraint
system. Fit the seat belt to the child
restraint system according to the
manufacturer’s instructions and
insert the plate into the buckle.
Make sure that the belt is not
twisted.
Check that the shoulder belt is cor-
rectly positioned over the child’s
shoulder, and that the lap belt is as
low as possible. (
P. 8 9 )
Removing a child restraint installed with a seat belt
Push the buckle release button
and fully retract the seat belt.
STEP3

164
1-7. Safety information
GX460_OM_OM60J63U_(U)
Child restraint systems with a top tether strapSecure the child restraint using a seat belt or the LATCH anchors,
and do the following.
Move the head restraint in place at
the upmost position.
Open the anchor bracket cover,
latch the hook onto the anchor
bracket and tighten the top strap.
Make sure the top strap is securely
latched.
STEP1
STEP2

165
1-7. Safety information
1
Before driving
GX460_OM_OM60J63U_(U)
■Laws and regulations pertaining to anchorages
The LATCH system conforms to FMVSS225 or CMVSS210.2.
Child restraint systems conforming to FMVSS213 or CMVSS213 specifications
can be used.
This vehicle is designed to conform to the SAE J1819.
CAUTION
■When installing a booster seat
To prevent the belt from going into ALR lo ck mode, do not fully extend the shoulder
belt. ALR mode causes the belt to tighten only. This could cause injury or discom-
fort to the child. ( P. 9 1 )

166
1-7. Safety information
GX460_OM_OM60J63U_(U)
CAUTION
■When installing a child restraint system
Follow the directions given in the child restraint system installation manual and fix
the child restraint system securely in place.
If the child restraint system is not correctly fixed in place, the child or other passen-
gers may be seriously injured or even kill ed in the event of sudden braking or an
accident.
●If the driver’s seat interferes with the child
restraint system and prevents it from being
attached correctly, attach the child restraint
system to the right-hand second seat.
●Adjust the front passen ger seat so that it
does not interfere with the child restraint
system.
●Child restraint system installed on the third
seat should not cont act the second seat-
backs.
●Only put a forward-facing child restraint
system on the front seat when unavoidable.
When installing a forward-facing child
restraint system on the front passenger
seat, move the seat as far back as possible
even if the “AIR BAG OFF” indicator light is
illuminated. Failing to do so may result in
death or serious injury if the airbags deploy
(inflate).

167
1-7. Safety information
1
Before driving
GX460_OM_OM60J63U_(U)
CAUTION
■When installing a child restraint system
●When installing a child restraint system in the second center seat, adjust both
seatbacks at the same angle.
●When using the LATCH anchors for a child restraint system, move the seat as far
back as possible, with the seatback close to the child restraint system.
●When a booster seat is installed, always ensure that the shoulder belt is posi-
tioned across the center of the child’s shoulder. The belt should be kept away from
the child’s neck, but not so that it could fall off the child’s shoulder. Failing to do so
may result in death or serious injury in the event of an accident or sudden braking.
●Ensure that the belt and plate are securely locked and the seat belt is not twisted.
●Push and pull the child restraint system from side to side and forward to be sure it
is secure.
●After securing a child restraint system, never adjust the seat.
●Follow all installation instructions provid ed by the child restraint system manufac-
turer.
■Do not use a seat belt extender
If a seat belt extender is used when inst alling a child restraint system, the seat belt
will not securely hold the child restraint system, which could cause death or serious
injury to the child or other passengers in the event of an accident.

168
1-7. Safety information
GX460_OM_OM60J63U_(U)
CAUTION
■To correctly attach a child restraint system to the anchors
●When using the LATCH anchors, be sure that there are no foreign objects
around the anchors and that the seat belt is not caught behind the child restraint.
Make sure the child restraint system is securely attached, or it may cause death or
serious injury to the child or other pass engers in the event of a sudden stop or
accident.
●When using the left side LATCH anchors
for the child restraint system, do not sit in
the center seat.
Seat belt function may be impaired, such as
being positioned overly high or loose-fit-
ting, which may result in death or serious
injury in the event of sudden braking, sud-
den swerving or an accident.

169
1-7. Safety information
1
Before driving
GX460_OM_OM60J63U_(U)

170
