IS F_EE
5
3-7. Other interior features
Sun visors ........................... 330
Vanity mirrors .................... 331
Clock .................................. 332
Satellite switches ................ 333
Ashtrays ............................. 336
Cigarette lighter.................. 337
Power outlet ....................... 338
Seat heaters ........................ 339
Armrest............................... 341
Trunk storage extension ..... 342
Coat hooks.......................... 344
Floor mat ............................ 345
Trunk features .................... 3464-1. Maintenance and care
Cleaning and protecting the
vehicle exterior................. 350
Cleaning and protecting the
vehicle interior ................. 353
4-2. Maintenance
Maintenance requirements . 356
4-3. Do-it-yourself maintenance
Do-it-yourself service
precautions ....................... 359
Hood ................................... 362
Positioning a floor jack ...... 363
Engine compartment .......... 365
Tires ................................... 378
Tire inflation pressure ........ 381
Wheels................................ 383
Air conditioning filter ........ 385
Electronic key battery ........ 388
Checking and replacing
fuses ................................. 390
Light bulbs ......................... 404
4Maintenance and care

4Maintenance and care
349
IS F_EE
4-1. Maintenance and care
Cleaning and protecting
the vehicle exterior ........ 350
Cleaning and protecting
the vehicle interior ......... 353
4-2. Maintenance
Maintenance
requirements .................. 3564-3. Do-it-yourself
maintenance
Do-it-yourself service
precautions..................... 359
Hood ................................ 362
Positioning a floor jack .... 363
Engine compartment ........ 365
Tires ................................. 378
Tire inflation pressure ...... 381
Wheels ............................. 383
Air conditioning filter ...... 385
Electronic key battery ...... 388
Checking and replacing
fuses ............................... 390
Light bulbs ....................... 404

362
4-3. Do-it-yourself maintenance
IS F_EE
NOTICE
If you remove the air cleaner filter
Driving with the air cleaner filter removed may cause excessive engine wear
due to dirt in the air. Also a backfire could cause a fire in the engine com-
partment.
If the brake fluid level is low or high
It is normal for the brake fluid level to go down slightly as the brake pads
wear or when the fluid level in the accumulator is high.
If the reservoir needs frequent refilling, it may indicate a serious problem.

371
4-3. Do-it-yourself maintenance
4
Maintenance and care
IS F_EE
Engine oil consumption
The amount of engine oil consumed depends on the oil viscosity, the
quality of the oil and the way the vehicle is driven.
More oil is consumed under driving conditions such as high speeds and
frequent acceleration and deceleration.
A new engine consumes more oil.
When judging the amount of oil consumption, keep in mind that the oil
may have become diluted, making it difficult to judge the true level
accurately.
Oil consumption: Max. 1.0 L per 1000 km (1.1 qt./600 miles, 0.9 Imp.
qt./600 miles)
If your vehicle consumes more than 1.0 L (1.1 qt., 0.9 Imp. qt.) every
1000 km (600 miles), contact any authorized Lexus dealer or repairer, or
another duly qualified and equipped professional.
CAUTION
Used engine oil
Used engine oil contains potentially harmful contaminants which may
cause skin disorders such as inflammation or skin cancer, so care should
be taken to avoid prolonged and repeated contact. To remove used engine
oil from your skin, wash thoroughly with soap and water.
Dispose of used oil and filters only in a safe and acceptable manner. Do
not dispose of used oil and filters in household trash, in sewers or onto the
ground.
Call any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional, service station or auto parts store for information
concerning recycling or disposal.
Do not leave used engine oil within the reach of children.

386
4-3. Do-it-yourself maintenance
IS F_EE
Air conditioning filter

387
4-3. Do-it-yourself maintenance
4
Maintenance and care
IS F_EE
The air conditioning filter must be cleaned or changed regularly to
maintain air conditioning efficiency.
Removal method
Set the air conditioning system to recirculated mode.
(P. 228)
The air conditioning filter case cannot be removed with the
system in the outside air mode.
Turn the “ENGINE START STOP” switch to OFF.
Open the glove box. Lift and
remove the partition.
Remove the filter cover.
Remove the filter case.
STEP1
STEP2
STEP3
STEP4
STEP5

388
4-3. Do-it-yourself maintenance
IS F_EE
Checking interval
Inspect and replace the air conditioning filter according to the maintenance
schedule. In dusty areas or areas with heavy traffic flow, early replacement
may be required. (For scheduled maintenance information, please refer to
the “Lexus Service Booklet” or “Lexus Warranty Booklet”.)
If air flow from the vents decreases dramatically
The filter may be clogged. Check the filter and replace if necessary.
Cleaning method
If the filter is dirty, clean by
blowing compressed air
through the filter from the
downward side.
Hold the air gun 5 cm (2 in.)
from the filter and blow for
approximately 2 minutes at
500 kPa (5.0 kgf/cm
2 or bar,
72 psi).
If it is not available, have the
filter cleaned by any autho-
rized Lexus dealer or
repairer, or another duly
qualified and equipped pro-
fessional.
Replacement method
Remove the air conditioning
filter from the filter case and
replace it with a new one.
The “UP” marks shown on
the filter and the filter case
should be pointing up.

389
4-3. Do-it-yourself maintenance
4
Maintenance and care
IS F_EE
NOTICE
To prevent damage to the system
When using the air conditioning system, make sure that a filter is always
installed.
When cleaning the filter, do not clean the filter with water.
