Lexus IS300h 2013 Owner's Manual

397
6Interior features
IS300h_EE(OM53B95E)
6-1. Using the air conditioning
system
Automatic air conditioning
system ............................. 398
Heated steering wheel/
seat heaters/
seat ventilators ................ 409
6-2. Using the interior lights
Interior lights list ............... 411
• Interior lights ................ 412
• Personal lights............... 412
6-3. Using the storage features
List of storage features ...... 413
• Glove box ..................... 414
• Console box .................. 414
•Cup holders/
Bottle holders................ 415
Trunk features ................... 4176-4. Using the other interior
features
Other interior features....... 420
• Sun visors ..................... 420
• Vanity mirrors............... 420
• Clock ............................ 420
• Power outlet.................. 421
• Armrest ......................... 422
• Rear sunshade............... 422
• Assist grips ................... 424
• Coat hooks .................... 424

398
IS300h_EE(OM53B95E)6-1. Using the air conditioning system
Automatic air conditioning system
Air outlets and fan speed are automatically adjusted according to the
temperature setting.
Vehicles with a Lexus Display Audio system: Press the “MENU” button
on the Lexus Display Audio controller, then select “Climate” to display
the air conditioning operation screen.
For details on the Lexus Display Audio controller, refer to “Lexus Dis-
play Audio controller” on P. 318.
Vehicles with a navigation system: Press the “MENU” button on the
Remote Touch, then select “Climate” to display the air conditioning con-
trol screen.
For details on the Remote Touch, refer to the “Navigation System
Owner’s Manual”.
The illustrations below are for left-hand drive vehicles.
The button positions and shapes will differ for right-hand drive vehicles.
Also, the display and button positions will differ depending on the type
of the system.

3996-1. Using the air conditioning system
6
Interior features
IS300h_EE(OM53B95E)
With “DUAL” mode
Without “DUAL” mode
Air conditioning controls

4006-1. Using the air conditioning system
IS300h_EE(OM53B95E)
Adjusting the temperature setting
To adjust the temperature setting,
touch and slide your finger up or
down on the sensor.
The temperature setting can also
be adjusted by touching on the
sensor.
When the temperature setting is
changed, a buzzer sounds.
Fan speed setting
Press to increase the fan speed.
Press to decrease the fan speed.
Change the airflow mode
To change the airflow, press .
The air outlets used are switched each time the button is pressed.
S-FLOW mode (if equipped)
When there are no passengers in the rear seats, airflow can be directed
to the front seats only to reduce the air conditioning effect on the rear
seats.
Press .
The indicator comes on when S-FLOW mode is on.
Press again to resume airflow to the rear seats.
Other functions
Switching between outside air and recirculated air modes (P. 404)
Defogging the windshield (P. 404)
Defogging the rear window and outside rear view mirrors (P. 404)

4016-1. Using the air conditioning system
6
Interior features
IS300h_EE(OM53B95E)
With a Lexus Display Audio
Adjust the left-hand side temperature setting
Adjust the fan speed setting
Select to set auto mode on/off, fan off, blower customization (P.
405) and displaying the option control screen (P. 403)
Select the air flow mode
Adjust the right-hand side temperature setting
Adjust the temperature setting
Move the Lexus Display Audio controller left/right to select the
desired item ( to ).
When , , or is selected:
Move the controller forward/backward or turn it left/right for adjusting.
When or is selected:
Move the controller forward/backward or turn it left/right to select a
screen button, then press the controller.
Air conditioning control screen (if equipped)
(With “DUAL” mode) (Without “DUAL” mode)
1
2
3
4
5
6
1
16
21256
34

4026-1. Using the air conditioning system
IS300h_EE(OM53B95E)
With a navigation system
Adjust the left-hand side temperature setting
Adjust the fan speed setting
Changing the fan speed setting during the automatic mode operation
(P. 405)
Select the air flow mode
Adjust the right-hand side temperature setting
Display the option control screen (P. 403)
Turn the fan off
Select to set auto mode on/off
Adjust the temperature setting
To adjust or select settings, move the Remote Touch knob to select the
screen button, and then press the Remote Touch knob to enter the
selected function. (With “DUAL” mode) (Without “DUAL” mode)
1
2
3
4
5
6
7
8
9

4036-1. Using the air conditioning system
6
Interior features
IS300h_EE(OM53B95E)
Option control screen
The functions can be switched on and off.
Cooling and dehumidification
function
Adjusting the temperature for
driver and passenger seats sep-
arately (“DUAL” mode)
(if equipped) (P. 403)
Removing pollen from the air
(Pollen removal mode)
(P. 404)
Press , or select “AUTO” on the air conditioning control screen.
Adjust the temperature setting.
To stop the operation, press or select “OFF” on the air condi-
tioning control screen.
If the system is operated manually in automatic mode
If the fan speed setting or air flow modes are operated, the automatic
mode indicator goes off. However, automatic mode for functions other
than that operated are maintained.
Adjusting the temperature for driver and passenger seats separately
(“DUAL” mode) (if equipped)
To turn on the “DUAL” mode, perform any of the following proce-
dures:
Press .
Select “DUAL” on the option control screen.
Adjust the passenger’s side temperature setting.
The indicator comes on when the “DUAL” mode is on.
While in “DUAL” mode, the temperature of the rear air outlets is set at the
right-hand side temperature setting.
1
2
3
Using automatic mode
1
2
3

4046-1. Using the air conditioning system
IS300h_EE(OM53B95E)
Switching between outside air and recirculated air modes
Press to change to recirculated air mode.
Press to change to outside air mode.
The indicator above the selected button comes on.
Pollen removal mode (if equipped)
Pollen is removed from the air and the air flows to the upper part of the
body.
Select
on the option control screen.
When the pollen removal mode is on, is displayed on the air condi-
tioning control screen.
In order to prevent the windshield from fogging up when the outside air is
cold, the dehumidification function may operate.
The pollens are filtered out even if the pollen removal mode is turned off.
Defogging the windshield
Defoggers are used to defog the windshield and front side windows.
Press .
Set the outside/recirculated air mode button to outside air mode if the recir-
culated air mode is used. (It may switch automatically.)
To defog the windshield and the side windows early, turn the air flow and
temperature up.
To return to the previous mode, press again when the windshield is
defogged.
Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window, and to remove raindrops,
dew and frost from the outside rear view mirrors.
Press .
The defoggers will automatically turn off after a period of time.
Other functions

4056-1. Using the air conditioning system
6
Interior features
IS300h_EE(OM53B95E)
Windshield wiper de-icer (if equipped)
This feature is used to prevent ice from building up on the windshield
and wiper blades.
Turns on/off.
The indicator comes on when the
windshield wiper de-icer is on.
The windshield de-icer will auto-
matically turn off after a period of
time.
Blower customization (if equipped)
Fan speed setting during the automatic mode operation can be custom-
ized.
To change the fan speed setting mode, select
on the air condi-
tioning control screen.
Each time is selected, the fan speed setting mode changes as follows.
“MEDIUM”“SOFT”“FAST”“MEDIUM”

4066-1. Using the air conditioning system
IS300h_EE(OM53B95E)
Location of air outlets
The air outlets and air volume
changes according to the selected
airflow mode.
Adjusting the position of and opening and closing the air outlets
Direct air flow to the left or right, up or down
To close the vent, move the knob to the most outside position. (rear outlets
only)
Turn the knob to open or close the vent
Air outlets
FrontRear
1
2
