Lexus IS300h 2013 Owner's Manual

4076-1. Using the air conditioning system
6
Interior features
IS300h_EE(OM53B95E)
Registering air conditioning settings to electronic keys (vehicles with driving
position memory)
Unlocking the vehicle using an electronic key and turning the power switch to
ON mode will recall that key’s registered air conditioning settings.
When the power switch is turned off, the current air conditioning settings will
automatically be registered to the electronic key that was used to unlock the
vehicle.
The system may not operate correctly if more than one electronic key is in the
vicinity or if the smart entry & start system is used to unlock a passenger door.
The doors that can recall the air conditioning setting when unlocked using the
smart entry & start system can be changed.* For details, contact any authorized
Lexus dealer or repairer, or another duly qualified and equipped professional.
*: The doors that can recall the driving position memory are changed at the same
time.
Using automatic mode
Fan speed is adjusted automatically according to the temperature setting and the
ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow
immediately after is pressed or “AUTO” is selected.
Fogging up of the windows
The windows will easily fog up when the humidity in the vehicle is high. Turning
(“A/C”) on will dehumidify the air from the outlets and defog the wind-
shield effectively.
If you turn (“A/C”) off, the windows may fog up more easily.
The windows may fog up if the recirculated air mode is used.
Outside/recirculated air mode
When driving on dusty roads such as tunnels or in heavy traffic, set the outside/
recirculated air mode button to the recirculated air mode. This is effective in
preventing outside air from entering the vehicle interior. During cooling opera-
tion, setting the recirculated air mode will also cool the vehicle interior effec-
tively.
Outside/recirculated air mode may automatically switch depending on the tem-
perature setting or the inside temperature.
Operation of the air conditioning system in Eco drive mode
In Eco drive mode, the air conditioning system is controlled as follows to priori-
tize fuel efficiency:
Engine speed and compressor operation controlled to restrict heating/cooling
capacity
Fan speed restricted when automatic mode is selected
To improve air conditioning performance, perform the following operations:
Adjust the fan speed
Turn off Eco drive mode

4086-1. Using the air conditioning system
IS300h_EE(OM53B95E)
Air conditioning odors
During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to be
emitted from the vents.
To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air mode
prior to turning the vehicle off.
• The start timing of the blower may be delayed for a short period of time
immediately after the air conditioning system is started in automatic mode.
Air conditioning filter
P. 470
Customization
Settings (e.g. A/C Auto switch operation) can be changed.
(Customizable features P. 582)
CAUTION
To prevent the windshield from fogging up
Do not use during cool air operation in extremely humid weather. The
difference between the temperature of the outside air and that of the wind-
shield can cause the outer surface of the windshield to fog up, blocking your
vision.
To prevent burns
Do not touch the rear view mirror surfaces when the outside rear view mirror
defoggers are on.
Do not touch the glass at lower part of the windshield or to the side of the
front pillars when the windshield wiper de-icer is on.
NOTICE
To prevent 12-volt battery discharge
Do not leave the air conditioning system on longer than necessary when the
hybrid system is off.
Do not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers from
defogging.

4096-1. Using the air conditioning system
6
Interior features
IS300h_EE(OM53B95E)
Turn the heated steering wheel on/
off
The indicator light comes on when
the heated steering wheel is operat-
ing.
Heated steering wheel/seat heaters/seat ventilators

: If equipped
Heated steering wheel and seat heaters heat the side grips of the steering
wheel and seats, respectively. Seat ventilators maintain good airflow by
blowing air from the seats.
CAUTION
Care should be taken to prevent injury if anyone in the following categories
comes in contact with the steering wheel and seats when the heater is on:
• Babies, small children, the elderly, the sick and the physically challenged
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping drugs,
cold remedies, etc.)
Observe the following precautions to prevent minor burns or overheating,
• Do not cover the seat with a blanket or cushion when using the seat heater.
• Do not use seat heater more than necessary.
NOTICE
Do not put heavy objects that have an uneven surface on the seat and do not
stick sharp objects (needles, nails, etc.) into the seat.
To prevent 12-volt battery discharge, do not use the functions when the hybrid
system is off.
Heated steering wheel

4106-1. Using the air conditioning system
IS300h_EE(OM53B95E)
The heated steering wheel can be used when the power switch is in ON mode.
The heated steering wheel will automatically turn off after about 30 minutes.
Each time the switch is pressed, the
intensity of the seat heater changes
and the level indicator lights
(amber) light as follows:
Hi (3 segments lit)  Mid (2 seg-
ments lit)  Lo (1 segment lit) 
Off
The seat heaters can be used when the power switch is in ON mode.
Seat heater timer control: The seat heater automatically switches from
HiMidLo. The switching timing differs depending on the temperature
inside the cabin etc. when the seat heater was operated.
The seat heater timer control can be turned on and off by pressing the seat
heater switches for the driver side and front passenger side at the same time
until a buzzer sounds. The buzzer will beep once when the seat heater timer
control is turned on and twice when it is turned off.
Each time the switch is pressed, the
intensity of the seat ventilator
changes and the level indicator
lights (green) light as follows:
Hi (3 segments lit)  Mid (2 seg-
ments lit)  Lo (1 segment lit) 
Off
The seat ventilators can be used when the power switch is in ON mode.
Seat heaters
Ty p e A Ty p e B
Seat ventilators

411
IS300h_EE(OM53B95E)
6
Interior features
6-2. Using the interior lights
Interior lights list
Outer foot lights
Front interior light (P. 412)
Front personal lights (P. 412)
Inside door handle lightsRear interior light (P. 412)
Rear personal lights (P. 412)
Door courtesy lights
Footwell lights1
2
3
4
5
6
7
8

4126-2. Using the interior lights
IS300h_EE(OM53B95E)
Turns the light on/off
Turns the door position on/off
Turns the light on/off
Illuminated entry system: The lights automatically turn on/off according to
power switch mode, the presence of the electronic key, whether the doors are
locked/unlocked, and whether the doors are opened/closed.
If the interior lights remain on when the door is not fully closed and the interior
light main switch is in the door position, the lights will go off automatically
after 20 minutes.
Setting (e.g. the time elapsed before lights turn off) can be changed.
(Customizable features: P. 575)
Interior lights
1
2
Personal lights
FrontRear
NOTICE
To prevent 12-volt battery discharge, do not leave the lights on longer than neces-
sary when the hybrid system is off.

413
IS300h_EE(OM53B95E)
6
Interior features
6-3. Using the storage features
List of storage features
Glove box (P. 414)
Bottle holders (P. 415)Cup holders (if equipped)
(P. 415)
Console box (P. 414)
CAUTION
Do not leave glasses, lighters or spray cans in the storage spaces, as this may
cause the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into contact with
other stored items.
• Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release gas,
causing a fire hazard.
When driving or when the storage compartments are not in use, keep the lids
closed.
In the event of sudden braking or sudden swerving, an accident may occur
due to an occupant being struck by an open lid or the items stored inside.
1
2
3
4

4146-3. Using the storage features
IS300h_EE(OM53B95E)
Open (press the button)
Unlock with the mechanical key
Lock with the mechanical key
The glove box light turns on when the power switch is in ACCESSORY or ON
mode.
The trunk opener main switch is located in the glove box. (P. 145)
Push the knob.
Lift by hand to fully open the con-
sole box.
Glove box
1
2
3
The insert inside the glove box can be
removed.
Console box

4156-3. Using the storage features
6
Interior features
IS300h_EE(OM53B95E)
Cup holders
Bottle holders
When storing a bottle, close the cap.
The bottle may not be stored depending on its size or shape.
The rubber mats at the bottom of the front cup holders can be removed.
Cup holders/Bottle holders
FrontRear (if equipped)
To open, pull down the armrest
and press the button and release
the rear cup holder on the arm-
rest.

4166-3. Using the storage features
IS300h_EE(OM53B95E)
CAUTION
Do not place anything other than cups or aluminum cans in the cup holders
and bottle in the bottle holders. Other items may be thrown out of the holders
in the event of an accident or sudden braking, causing injury.
To prevent burns, cover hot drinks when placed in the cup holders.
NOTICE
To prevent damage to the rear cup holder, stow the cup holder before stowing
the armrest.
