Lexus IS300h 2013 Owner's Manual

5378-2. Steps to take in an emergency
8
When trouble arises
IS300h_EE(OM53B95E)
Connect the bottle to the com-
pressor.
As shown in the illustration, insert
the bottle vertically into the com-
pressor to connect making sure that
the claw on the bottle's neck is
hooked onto the cutout of the com-
pressor case.
Check the specified tire inflation pressure.
Tire inflation pressure is specified on the label as shown. (P. 570)
10
11
Left-hand drive vehiclesRight-hand drive vehicles

5388-2. Steps to take in an emergency
IS300h_EE(OM53B95E)
Start the hybrid system.
To inject the sealant and inflate
the tire, turn the compressor
switch on.
Inflate the tire until the specified
air pressure is reached.
The sealant will be injected and
the pressure will surge and then
gradually decrease.
The air pressure gauge will dis-
play the actual tire inflation pres-
sure about 1 minute (5 minutes at
low temperature) after the switch
is turned on.
Inflate the tire until the specified
air pressure.
• Turn the compressor switch off
and then check the tire inflation
pressure. Being careful not to
over inflate, check and repeat the
inflation procedure until the
specified tire inflation pressure is
reached.
• If the tire inflation pressure is still lower than the specified point after
inflation for 35 minutes with the switch on, the tire is too damaged to
be repaired. Turn the compressor switch off and contact any authorized
Lexus dealer or repairer, or another duly qualified and equipped pro-
fessional.
• If the tire inflation pressure exceeds the specified air pressure, let out
some air to adjust the tire inflation pressure. (P. 542, 570)12
13
14
1
2
3

5398-2. Steps to take in an emergency
8
When trouble arises
IS300h_EE(OM53B95E)
With the compressor switch off, disconnect the hose from the valve on
the tire and then pull out the power plug from the power outlet socket.
Some sealant may leak when the hose is removed.
Install the valve cap onto the valve of the emergency repaired tire.
Attach the air release cap to the
end of the hose.
If the air release cap is not attached,
the sealant may leak and the vehicle
may get dirty.
Temporarily store the bottle in the luggage compartment while it is
connected to the compressor.
To spread the liquid sealant evenly within the tire, immediately drive
safely for about 5 km (3 miles) below 80 km/h (50 mph).
After driving for about 5 km (3
miles), stop your vehicle in a safe
place on a hard, flat surface and
remove the air release cap from
the hose before reconnecting the
repair kit.
15
16
17
18
19
20

5408-2. Steps to take in an emergency
IS300h_EE(OM53B95E)
Turn the compressor switch on
and wait for an approximately 5
seconds, and then turn it off.
Check the tire inflation pressure.
If the tire inflation pressure is
under 130 kPa (1.3 kgf/cm
2 or
bar, 19 psi): The puncture cannot
be repaired. Contact any autho-
rized Lexus dealer or repairer, or
another duly qualified and
equipped professional.
If the tire inflation pressure is 130 kPa (1.3 kgf/cm
2 or bar, 19 psi) or
higher, but less than the specified air pressure: Proceed to .
If the tire inflation pressure is the specified air pressure (P. 570): Pro-
ceed to .
Turn the compressor switch on to inflate the tire until the specified air
pressure is reached. Drive for about 5 km (3 miles) and then perform
.
Attach the air release cap to the
end of the hose.
If the air release cap is not attached,
the sealant may leak and the vehicle
may get dirty.
Store the bottle in the luggage compartment while it is connected to the
compressor.
Taking precautions to avoid sudden braking, sudden acceleration and
sharp turns, drive carefully at under 80 km/h (50 mph) to the nearest
authorized Lexus dealer or repairer, or another duly qualified and
equipped professional for tire repair or replacement.
21
1
2
22
3
23
22
20
23
24
25

5418-2. Steps to take in an emergency
8
When trouble arises
IS300h_EE(OM53B95E)
In the following cases, the tire cannot be repaired with the emergency tire punc-
ture repair kit. Contact any authorized Lexus dealer or repairer, or another duly
qualified and equipped professional.
When the tire is damaged due to driving without sufficient air pressure
When the tire lost air pressure due to a crack or damage in the tire sidewall
When the tire is visibly separated from the wheel
When the cut or damage to the tread is 4 mm (0.16 in.) long or more
When the wheel is damaged
When two or more tires have been punctured
When there is more than one hole or cut in the damaged tire
Emergency tire puncture repair kit
The sealant has a limited lifespan. The expiry date is marked on the bottle. The
sealant should be replaced before the expiry date. Contact any authorized Lexus
dealer or repairer, or another duly qualified and equipped professional for
replacement.
The sealant stored in the emergency tire puncture repair kit can be used only
once to temporarily repair a single tire. If the sealant in the bottle and other
parts of the kit have been used and need to be purchased, contact any authorized
Lexus dealer or repairer, or another duly qualified and equipped professional.
The sealant can be used when the outside temperature is from -30C (-22F) to
60C (140F).
The kit is exclusively designed for size and type of tires originally installed on
your vehicle. Do not use it for tires that a different size than the original ones, or
for any other purposes.
If the sealant gets on your clothes, it may stain.
If the sealant adheres to a wheel or the surface of the vehicle body, the stain
may not be removable if it is not cleaned at once. Immediately wipe away the
sealant with a wet cloth.
During operation of the kit, a loud operation noise is produced. This does not
indicate a malfunction.
The valve of a tire that has been repaired
After a tire is repaired with the emergency tire puncture repair kit, the valve
should be replaced.
Note for checking the emergency tire puncture repair kit
Check the sealant expiry date occasionally.
The expiry date is shown on the bottle. Do not use sealant whose expiry date has
already passed. Otherwise, repairs conducted using the emergency tire puncture
repair kit may not be performed properly.

5428-2. Steps to take in an emergency
IS300h_EE(OM53B95E)
If the tire is inflated to more than the recommended level
Disconnect the hose from the valve.
Disconnect the hose from the valve, remove the air release cap from the hose
and then reconnect the hose.
Turn the compressor switch on and wait for several seconds, then turn it off.
Check that the air pressure indicator shows the recommended level. (P. 570)
If the air pressure is lower than the recommended level, turn the compressor
switch on again and repeat the inflation procedure until the recommended pres-
sure is reached. Install the air release cap to the end of the
hose and push the protrusion on the air
release cap into the valve to let some air
out.
CAUTION
Caution while driving
Observe the following precautions.
Failure to do so may cause an accident.
The emergency tire puncture repair kit is made exclusively for your vehicle.
Do not use it on other vehicles.
Do not use the emergency tire puncture repair kit for tires that are a different
size than the specified ones or for any other purpose. Doing so may cause the
tires to not be repaired properly.
Precautions for use of the sealant
Ingesting the sealant is hazardous to your health. If you ingest sealant, con-
sume as much water as possible, then immediately consult a doctor.
If sealant gets in eyes or adheres to skin, immediately wash it off with water.
If discomfort persists, consult a doctor.
1
2
3
4

5438-2. Steps to take in an emergency
8
When trouble arises
IS300h_EE(OM53B95E)
CAUTION
When fixing the flat tire
Stop your vehicle in a safe and flat area.
Do not touch the wheels or the area around the brakes immediately after the
vehicle has been driven.
After the vehicle has been driven, the wheels and the area around the brakes
may be extremely hot. Touching these areas with hands, feet or other body
parts may result in burns.
Connect the valve and hose securely with the tire installed on the vehicle.
If the hose is not properly connected to the valve, air leakage may occur or
sealant may be sprayed out.
If the hose comes off the valve while inflating the tire, there is a risk that the
hose will move abruptly due to air pressure.
After inflation of the tire has completed, the sealant may splatter when the
hose is disconnected or some air is let out of the tire.
Follow the operation procedure to repair the tire. If the procedure is not fol-
lowed, the sealant may spray out.
Keep back from the tire while it is being repaired, as there is a chance of it
bursting while the repair operation is being performed. If you notice any
cracks or deformation of the tire, turn off the compressor switch and stop the
repair operation immediately.
The kit may overheat if operated for a long period of time. Do not operate the
compressor continuously for more than 10 minutes.
Parts of the kit become hot during operation. Be careful handling the kit
during and after operation.
Do not attach the vehicle speed warning sticker to an area other than the one
indicated. If the sticker is attached to an area where an SRS airbag is located,
such as the pad of the steering wheel, it may prevent the SRS air bag from
operating properly.
Driving to spread the liquid sealant evenly
Drive the vehicle carefully at a low speed. Be especially careful when turning
and cornering.
If the vehicle does not drive straight or you feel a pull through the steering
wheel, stop the vehicle and check the following:
• Tire condition. The tire may have separated from the wheel.
• Tire inflation pressure. If tire inflation pressure is 130 kPa (1.3 kgf/cm
2 or
bar, 19 psi) or below, this may indicate severe tire damage.

5448-2. Steps to take in an emergency
IS300h_EE(OM53B95E)
NOTICE
When performing an emergency repair
Perform the emergency repair without removing the nail or screw that has
punctured the tread of the tire. If the object that has punctured the tire is
removed, repair by the emergency tire puncture repair kit may not be possible.
The kit is not waterproof. Make sure that the kit is not exposed to water, such
as when it is being used in the rain.
Do not put the kit directly onto dusty ground such as sand at the side of the
road. If the kit vacuums up dust etc., a malfunction may occur.
Use the kit with the top facing upward. The kit cannot work properly if it is
laid on its side.
Handling the emergency tire puncture repair kit
The compressor power source should be 12 V DC suitable for vehicle use. Do
not connect the compressor to any other source.
If gasoline splatters on the kit, the kit may deteriorate. Take care not to allow
gasoline to contact it.
Store the kit in its assigned place out of reach of children.
Do not disassemble or modify the kit. Do not subject parts such as the air
pressure indicator to impacts. This may cause a malfunction.
To avoid damage to the tire pressure warning valves and transmitters
When a tire is repaired with liquid sealants, the tire pressure warning valve and
transmitter may not operate properly. If a liquid sealant is used, contact any
authorized Lexus dealer or repairer, or another duly qualified and equipped
professional as soon as possible. Make sure to replace the tire pressure warning
valve and transmitter when replacing the tire. (P. 451)

5458-2. Steps to take in an emergency
8
When trouble arises
IS300h_EE(OM53B95E)
Run-flat tires (A “RFT” or “DSST” mark is molded on the sidewall)
Take your vehicle to the nearest
Lexus dealer or authorized tire
dealer as soon as possible if any
tire goes flat.
The vehicle can be driven for a
maximum of 300 km (186 miles)
at a speed below 60 km/h (37
mph) after the tire pressure warn-
ing light comes on. (P. 510)
In some conditions (such as at high temperatures)
You cannot continue driving for up to 300 km (186 miles).
For the detailed information on run-flat tires
See the tire warranty booklet.
If you have a flat tire (vehicles with run-flat tires)
You can continue driving a vehicle with run-flat tires even if any tire
goes flat.In this case, slow down and drive with extra caution.
NOTICE
When replacing the tires
When removing or fitting the wheels, tires or the tire pressure warning valve
and transmitter, contact any authorized Lexus dealer or repairer, or another
duly qualified and equipped professional as the tire pressure warning valve and
transmitter may be damaged if not handled correctly.
When driving over bumps
If a vehicle has a flat tire, the vehicle height will be lower than usual. Ensure
that nothing strikes the bottom of the vehicle.
To avoid damage to the tire pressure warning valves and transmitters
When a tire is repaired with liquid sealants, the tire pressure warning valve and
transmitter may not operate properly. If a liquid sealant is used, contact any
authorized Lexus dealer or repairer, or another duly qualified and equipped
professional or other qualified service shop as soon as possible. Make sure to
replace the tire pressure warning valve and transmitter when replacing the tire.
(P. 451)

5468-2. Steps to take in an emergency
IS300h_EE(OM53B95E)
One of the following may be the cause of the problem:
The electronic key may not be functioning properly. (P. 550)
There may not be sufficient fuel in the vehicle’s tank.
Refuel the vehicle.
There may be a malfunction in the immobilizer system. (P. 9 0 )
There may be a malfunction in the steering lock system.
The hybrid system may be malfunctioning due to an electrical problem
such as electronic key battery depletion or a blown fuse. However,
depending on the type of malfunction, an interim measure is available
to start the hybrid system. (P. 547)
One of the following may be the cause of the problem:
The 12-volt battery terminal connections may be loose or corroded.
The 12-volt battery may be discharged. (P. 551)
If the hybrid system will not start
Reasons for the hybrid system not starting vary depending on the situa-
tion. Check the following and perform the appropriate procedure:
The hybrid system will not start even though the correct starting
procedure is being followed. (P. 209)
The interior lights and headlights are dim, or the horn does not
sound or sounds at a low volume.
