Lexus IS300h 2013 Owner's Manual

5478-2. Steps to take in an emergency
8
When trouble arises
IS300h_EE(OM53B95E)
One of the following may be the cause of the problem:
One or both of the 12-volt battery terminals may be disconnected.
The 12-volt battery may be discharged. (P. 551)
Contact any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional if the problem cannot be repaired, or if repair proce-
dures are unknown.
When the hybrid system does not start, the following steps can be used as
an interim measure to start the hybrid system if the power switch is func-
tioning normally:
Set the parking brake.
Shift the shift lever to P.
Turn the power switch to ACCESSORY mode.
Press and hold the power switch for about 15 seconds while depressing
the brake pedal firmly.
Even if the hybrid system can be started using the above steps, the system
may be malfunctioning. Have the vehicle inspected by any authorized
Lexus dealer or repairer, or another duly qualified and equipped profes-
sional.
The interior lights and headlights do not turn on, or the horn does
not sound.
Emergency start function
1
2
3
4

5488-2. Steps to take in an emergency
IS300h_EE(OM53B95E)
Set the parking brake.
Turn the power switch to ACCESSORY mode.
Depress the brake pedal.
Pry the cover up with a flathead
screwdriver or equivalent tool.
To prevent damage to the cover,
cover the tip of the screwdriver with
a rag.
Press the shift lock override but-
ton.
The shift lever can be shifted while
the button is pressed.
If the shift lever cannot be shifted from P
If the shift lever cannot be shifted with your foot on the brake pedal,
there may be a problem with the shift lock system (a system to prevent
accidental operation of the shift lever). Have the vehicle inspected by any
authorized Lexus dealer or repairer, or another duly qualified and
equipped professional immediately.
The following steps may be used as an emergency measure to ensure that
the shift lever can be shifted:
1
2
3
4
5

5498-2. Steps to take in an emergency
8
When trouble arises
IS300h_EE(OM53B95E)
Doors
Use the mechanical key (P.
131) in order to perform the fol-
lowing operations:
Locks all the doors
Closes the windows and moon
roof (turn and hold)
*
Unlocks all the doors
Opens the windows and moon roof (turn and hold)
*
*
: This setting must be customized at any authorized Lexus dealer or repairer,
or another duly qualified and equipped professional.
Trunk
Turn the mechanical key clock-
wise to open.
If the electronic key does not operate properly
If communication between the electronic key and vehicle is interrupted
(P. 151) or the electronic key cannot be used because the battery is
depleted, the smart entry & start system and wireless remote control can-
not be used. In such cases, the doors and trunk can be opened and the
hybrid system can be started by following the procedure below.
Locking and unlocking the doors, unlocking the trunk and key
linked functions
1
2
3
4

5508-2. Steps to take in an emergency
IS300h_EE(OM53B95E)
Ensure that the shift lever is in P and depress the brake pedal.
Touch the Lexus emblem side of
the electronic key to the power
switch.
When the electronic key is detected,
a buzzer sounds and the power
switch will turn to ON mode.
When the smart entry & start system
is deactivated in customization set-
ting, the power switch will turn to
ACCESSORY mode.
Firmly depress the brake pedal and check that is shown on the
multi-information display.
Press the power switch.
In the event that the hybrid system still cannot be started, contact any
authorized Lexus dealer or repairer, or another duly qualified and
equipped professional.
Stopping the hybrid system
Shift the shift lever to P and press the power switch as you normally do when
stopping the hybrid system.
Replacing the key battery
As the above procedure is a temporary measure, it is recommended that the elec-
tronic key battery be replaced immediately when the battery is depleted. (P.
472)
Alarm (if equipped)
Using the mechanical key to lock the doors will not set the alarm system.
If a door is unlocked using the mechanical key when the alarm system is set, the
alarm may be triggered.
Changing power switch modes
Release the brake pedal and press the power switch in step above.
The hybrid system does not start and modes will be changed each time the switch
is pressed. (P. 210)
When the electronic key does not work properly
Make sure that the smart entry & start system has not been deactivated in the
customization setting. If it is off, turn the function on.
(Customizable features P. 575)
Check if battery-saving mode is set. If it is set, cancel the function. (P. 150)
Starting the hybrid system
1
2
3
4
3

5518-2. Steps to take in an emergency
8
When trouble arises
IS300h_EE(OM53B95E)
If you have a set of jumper (or booster) cables and a second vehicle with a
12-volt battery, you can jump start your vehicle by following the steps
below.
Open the hood (P. 437) and
fuse box cover.
Remove the clips.
Push the tabs on either side to
detach the lock and lift the lid
off while pulling the lock
plate.
Open the exclusive jump starting
terminal cover.
If the 12-volt battery is discharged
The following procedures may be used to start the hybrid system if the
12-volt battery is discharged.
You can also call any authorized Lexus dealer or repairer, or another duly
qualified and equipped professional.
1
1
2
2

5528-2. Steps to take in an emergency
IS300h_EE(OM53B95E)
Connect the jumper cables according to the following procedure:
Connect a positive jumper cable clamp to the exclusive jump start-
ing terminal on your vehicle.
Connect the clamp on the other end of the positive cable to the posi-
tive (+) battery terminal on the second vehicle.
Connect a negative cable clamp to the negative (-) battery terminal
on the second vehicle.
Connect the clamp at the other end of the negative cable to a solid,
stationary, unpainted metallic point away from the exclusive jump
starting terminal and any moving parts, as shown in the illustration.
Start the engine of the second vehicle. Increase the engine speed
slightly and maintain at that level for approximately 5 minutes to
recharge the 12-volt battery of your vehicle.
Open and close any of the doors of your vehicle with the power switch
off.
Maintain the engine speed of the second vehicle and start the hybrid
system of your vehicle by turning the power switch to ON mode.
Make sure the “READY” indicator comes on. If the indicator does not
come on, contact any authorized Lexus dealer or repairer, or another
duly qualified and equipped professional.3
1
2
3
4
4
5
6
7

5538-2. Steps to take in an emergency
8
When trouble arises
IS300h_EE(OM53B95E)
Once the hybrid system has started, remove the jumper cables in the
exact reverse order from which they were connected.
Once the hybrid system starts, have the vehicle inspected at any autho-
rized Lexus dealer or repairer, or another duly qualified and equipped
professional as soon as possible.
Starting the hybrid system when the 12-volt battery is discharged
The hybrid system cannot be started by push-starting.
To prevent 12-volt battery discharge
Turn off the headlights and the audio system while the hybrid system is off.
Turn off any unnecessary electrical components when the vehicle is running at
a low speed for an extended period, such as in heavy traffic.
Charging the 12-volt battery
The electricity stored in the 12-volt battery will discharge gradually even when
the vehicle is not in use, due to natural discharge and the draining effects of cer-
tain electrical appliances. If the vehicle is left for a long time, the 12-volt battery
may discharge, and the hybrid system may be unable to start. (The 12-volt bat-
tery recharges automatically while the hybrid system is operating.)
When recharging or replacing the 12-volt battery
For vehicles with an alarm: Make sure that the key is not inside the vehicle
when recharging or replacing the 12-volt battery. The key may be locked in the
vehicle if the alarm is activated. (P. 98)
In some cases, it may not be possible to unlock the doors using the smart entry
& start system when the 12-volt battery is discharged. Use the wireless remote
control or the mechanical key to lock or unlock the doors.
The hybrid system may not start on the first attempt after the 12-volt battery has
recharged but will start normally after the second attempt. This is not a mal-
function.
The power switch mode is memorized by the vehicle. When the 12-volt battery
is reconnected, the system will return to the mode it was in before the 12-volt
battery was discharged. Before disconnecting the 12-volt battery, turn the
power switch off.
If you are unsure what mode the power switch was in before the 12-volt battery
discharged, be especially careful when reconnecting the 12-volt battery.
8

5548-2. Steps to take in an emergency
IS300h_EE(OM53B95E)
CAUTION
Avoiding 12-volt battery fires or explosions
Observe the following precautions to prevent accidentally igniting the flamma-
ble gas that may be emitted from the 12-volt battery:
Make sure each jumper cable is connected to the correct terminal and that it is
not unintentionally in contact with any other than the intended terminal.
Do not allow the other end of the jumper cable connected to the “+” terminal
to come into contact with any other parts or metal surfaces in the area, such as
brackets or unpainted metal.
Do not allow the + and - clamps of the jumper cables to come into contact
with each other.
Do not smoke, use matches, cigarette lighters or allow open flame near the
12-volt battery.
12-volt battery precautions
The 12-volt battery contains poisonous and corrosive acidic electrolyte, while
related parts contain lead and lead compounds. Observe the following precau-
tions when handling the 12-volt battery:
When working with the 12-volt battery, always wear safety glasses and take
care not to allow any 12-volt battery fluids (acid) to come into contact with
skin, clothing or the vehicle body.
Do not lean over the 12-volt battery.
In the event that 12-volt battery fluid comes into contact with the skin or eyes,
immediately wash the affected area with water and seek medical attention.
Place a wet sponge or cloth over the affected area until medical attention can
be received.
Always wash your hands after handling the 12-volt battery support, terminals,
and other battery-related parts.
Do not allow children near the 12-volt battery.
After recharging the 12-volt battery
Have the 12-volt battery inspected at any authorized Lexus dealer or repairer,
or another duly qualified and equipped professional as soon as possible.
If the 12-volt battery is deteriorating, continued use may cause the 12-volt bat-
tery to emit a malodorous gas, which may be detrimental to the health of pas-
sengers.
When replacing the 12-volt battery
P. 4 4 9

5558-2. Steps to take in an emergency
8
When trouble arises
IS300h_EE(OM53B95E)
NOTICE
When handling jumper cables
When connecting the jumper cables, ensure that they do not become entangled
in the cooling fans or belt.
Exclusive jump starting terminal
The exclusive jump starting terminal is intended to charge the 12-volt battery
on your vehicle from another vehicle in an emergency. Do not use the exclusive
jump starting terminal to jump start another vehicle.

5568-2. Steps to take in an emergency
IS300h_EE(OM53B95E)
The needle of the engine coolant temperature gauge (P. 110) enters
the red zone or a loss of hybrid system power is experienced. (For
example, the vehicle speed does not increase.)
“Hybrid System Overheat” is shown on the multi-information display.
Steam comes out from under the hood.
If the needle of the engine coolant temperature gauge enters the red
zone
Stop the vehicle in a safe place and turn off the air conditioning sys-
tem, and then stop the hybrid system.
If you see steam:
Carefully lift the hood after the steam subsides.
If you do not see steam:
Carefully lift the hood.
After the hybrid system has
cooled down sufficiently,
inspect the hoses and radiator
core (radiator) for any leaks.
Radiator
Cooling fans
If a large amount of coolant
leaks, immediately contact any
authorized Lexus dealer or
repairer, or another duly quali-
fied and equipped professional.
If your vehicle overheats
The following may indicate that your vehicle is overheating.
Correction procedures
1
2
3
1
2
