Lexus IS300h 2013 Owner's Manual

5669-1. Specifications
IS300h_EE(OM53B95E)
Oil viscosity (0W-20 is explained here as an example):
• The 0W in 0W-20 indicates the characteristic of the oil which allows
cold startability. Oils with a lower value before the W allow for eas-
ier starting of the engine in cold weather.
• The 20 in 0W-20 indicates the viscosity characteristic of the oil
when the oil is at high temperature. An oil with a higher viscosity
(one with a higher value) may be better suited if the vehicle is oper-
ated at high speeds, or under extreme load conditions.
How to read oil container labels:
Either or both API registered marks are added to some oil containers to
help you select the oil you should use.
API Service Symbol
Top portion: “API SERVICE SN”
means the oil quality designation
by American Petroleum Institute
(API).
Center portion: “SAE 0W-20”
means the SAE viscosity grade.
Lower portion: “Resource-
Conserving” means that the oil
has fuel-saving and environmen-
tal protection capabilities.
ILSAC Certification Mark
The International Lubricant Specification Advisory Committee (ILSAC)
Certification Mark is displayed on the front of the container.
1
2

567
9 9-1. Specifications
Vehicle specifications
IS300h_EE(OM53B95E)
Spark plug
Cooling system
Gasoline engine
Power control unit
Left-hand drive
vehiclesRight-hand drive
vehicles
Capacity8.2 L (8.7 qt.,
7.2 Imp. qt.)2.0 L (2.1 qt.,
1.8 Imp. qt.)2.2 L (2.3 qt.,
1.9 Imp. qt.)
Coolant type
Use either of the following:
• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based non-sili-
cate, non-amine, non-nitrite, and non-borate coolant
with long-life hybrid organic acid technology
Do not use plain water alone.
Ignition system
Make DENSO FK20HBR8
Gap 0.8 mm (0.031 in.)
NOTICE
Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

5689-1. Specifications
IS300h_EE(OM53B95E)
*: The fluid capacity is a reference quantity.
If replacement is necessary, contact any authorized Lexus dealer or repairer, or
another duly qualified and equipped professional.
Electrical system
12-volt battery
Open voltage at 20C
(68F):
12.5 V or higher: Fully charged
11.0 - 12.4 V: Half charged
10.9 V or lower: Discharged
(Check the voltage 20 minutes after the hybrid sys-
tem and all lights are turned off.)
Charging rates4 A — 5 A
Hybrid transmission
Fluid capacity*3.8 L (4.0 qt., 3.3 Imp. qt.)
Fluid typeToyota Genuine ATF WS
NOTICE
Hybrid transmission fluid type
Using transmission fluid other than “Toyota Genuine ATF WS” may cause
deterioration in shift quality, locking up of your transmission accompanied by
vibration, and ultimately damage the hybrid transmission of your vehicle.

569
9 9-1. Specifications
Vehicle specifications
IS300h_EE(OM53B95E)Your Lexus vehicle is filled with “Toyota Genuine Differential Gear Oil” at the
factory.
Use Lexus approved “Toyota Genuine Differential Gear Oil” or an equivalent of
matching quality to satisfy the above specification. Please contact any authorized
Lexus dealer or repairer, or another duly qualified and equipped professional for
further details.
*1: Minimum pedal clearance when depressed with a force of 500 N (51.0 kgf,
112.4 lbf) while the hybrid system is operating.
*2: Parking brake pedal travel when depressed with a force of 300 N (30.6 kgf,
67.4 lbf)
Differential
Oil capacity1.35 L (1.42 qt., 1.19 Imp. qt.)
Oil type and viscosityToyota Genuine Differential gear oil LT
75W-85 GL-5 or equivalent
Brakes
Pedal clearance*1117 mm (4.6 in.) Min.
Pedal free play1.0 — 2.0 mm (0.04 — 0.08 in.)
Parking brake pedal
travel
*27 - 10 clicks
Fluid typeSAE J1703 or FMVSS No. 116 DOT 3
Steering
Free playLess than 30 mm (1.2 in.)

5709-1. Specifications
IS300h_EE(OM53B95E)
16-inch tires
*1: 5 passengers
*2: For optimizing fuel economy, ECO tire pressure is recommended. Tire pres-
sure affects traveling comfort, road noise and steering characteristics.
Tires and wheels
Tire size205/55R16 91W
Tire inflation
pressure
(Recommended
cold tire inflation
pressure)
Vehicle speed
Front wheel
kPa (kgf/cm2
or bar, psi)
Rear wheel
kPa (kgf/cm2
or bar, psi)
More than 160 km/h
(100 mph)
250 (2.5, 36)
270 (2.7, 39)*1
250 (2.5, 36)
Normal pressure:
160 km/h (100 mph)
or less
250 (2.5, 36)
ECO pressure*2:
160 km/h (100 mph)
or less
270 (2.7, 39)270 (2.7, 39)
Wheel size16  7J
Wheel nut torque103 N•m (10.5 kgf•m, 76 ft•lbf)

571
9 9-1. Specifications
Vehicle specifications
IS300h_EE(OM53B95E)
17-inch tires
*: 5 passengers
18-inch tires
When towing a trailer (vehicles with a towing package)
Add 20.0 kPa (0.2 kgf/cm2 or bar, 3 psi) to the recommended tire inflation pres-
sure and drive at speeds below 100 km/h (62 mph).
Tire size225/45R17 91W, 225/45RF17 91W
Tire inflation
pressure
(Recommended
cold tire inflation
pressure)Vehicle speed
Front wheel
kPa (kgf/cm2
or bar, psi)
Rear wheel
kPa (kgf/cm2
or bar, psi)
More than 160 km/h
(100 mph)
250 (2.5, 36)
270 (2.7, 39)*
250 (2.5, 36)
160 km/h (100 mph)
or less250 (2.5, 36)
Wheel size17  7 1/2J
Wheel nut torque103 N•m (10.5 kgf•m, 76 ft•lbf)
Tire size225/40R18 88Y, 255/35R18 90Y
Tire inflation
pressure
(Recommended
cold tire inflation
pressure)
250 kPa (2.5 kgf/cm2 or bar, 36 psi)
Wheel size18  8J (225/40R18), 18  8 1/2J (255/35R18)
Wheel nut torque103 N•m (10.5 kgf•m, 76 ft•lbf)

5729-1. Specifications
IS300h_EE(OM53B95E)
Light bulbs*1
Light bulbsWType
Exterior
Discharge headlights*235A
Front fog lights (except F SPORT mod-
els)*219B
Front turn signal lights21C
Rear turn signal lights21C
Back-up lights16D
Outer foot lights5D
Interior
Door courtesy lights5D
Vanity lights8D
Interior light8D
Personal lights8D
Footwell lights3.8D
Trunk light*25D
A: D4S discharge bulbs
B: H16 halogen bulbs
C: Wedge base bulbs (amber)
D: Wedge base bulbs (clear)
*1: Light bulbs not listed in this table are LED bulbs.
*2: If equipped

573
9 9-1. Specifications
Vehicle specifications
IS300h_EE(OM53B95E)
Fuel tank opening for unleaded gasoline
To help prevent incorrect fueling, your vehicle has a fuel tank opening that only
accommodates the special nozzle on unleaded fuel pumps.
If your engine knocks
Consult any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional.
You may occasionally notice light knocking for a short time while accelerating
or driving uphill. This is normal and there is no need for concern.
Fuel information
EU area:
Your vehicle must use only unleaded gasoline conforming to European
standard EN228.
For optimum engine performance, select unleaded gasoline with a
Research Octane Number of 95 or higher.
Except EU area:
Your vehicle must use only unleaded gasoline.
For optimum engine performance, select unleaded gasoline with a
Research Octane Number of 95 or higher.

5749-1. Specifications
IS300h_EE(OM53B95E)
NOTICE
Notice on fuel quality
Do not use improper fuels. If improper fuels are used, the engine will be dam-
aged.
Do not use leaded gasoline.
Leaded gasoline will cause the three-way catalytic converter to lose its effec-
tiveness and the emission control system to function improperly.
Gasoline engine (EU area): Bioethanol fuel sold under names such as “E50”
or “E85” and fuel containing a large amount of ethanol should not be used.
The use of these fuels will damage the vehicle’s fuel system. In case of any
doubt, ask any authorized Lexus dealer or repairer, or another duly qualified
and equipped professional.
Gasoline engine (except EU area): Bioethanol fuel sold under names such as
“E50” or “E85” and fuel containing a large amount of ethanol should not be
used. Your vehicle can use gasoline mixed with 10% max ethanol. The use of
fuel with more than 10% ethanol content (E10) will damage the vehicle’s fuel
system. You must ensure that refueling is carried out only from a source
where fuel specification and quality can be guaranteed. In case of any doubt,
ask any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional.

575
IS300h_EE(OM53B95E)
9
Vehicle specifications
9-2. Customization
Changing by using the Remote Touch or Lexus Display Audio control-
ler (if equipped)
Vehicles with a Remote Touch
Press the “MENU” button on the Remote Touch.
Select “Setup” on the “Menu” screen and select “Vehicle”.
Various setting can be changed. Refer to the list of settings that can be
changed for details.
Vehicles with a Lexus Display Audio controller
Press the “MENU” button on the Lexus Display Audio controller.
Select “Setup” on the “MENU” screen and select “Vehicle”.
Various setting can be changed. Refer to the list of settings that can be
changed for details.
Changing by using the meter control switches
P. 1 1 7
Customizable features
Your vehicle includes a variety of electronic features that can be person-
alized to your preferences. The settings of these features can be changed
by using the meter control switches, the Remote Touch or Lexus Display
Audio controller or at any authorized Lexus dealer or repairer, or another
duly qualified and equipped professional.
Customizing vehicle features
1
2
1
2
