Lexus IS300h 2014 Navigation manual

231
3. MEDIA OPERATION
IS300h/250_Navi_EE
AUDIO/VISUAL SYSTEM
4
No.Function
AudioVideo
Select to display the audio source selection
screen.Select to display the audio source selection
screen.
Select to select a track.
•Displays cover art
•Select to display a track list.
To return to the top screen, select “Now
playing” on the list screen.

Select to display the play mode selection
screen.
To return to the top screen, select “Now
playing” on the list screen.Select to display the play mode selection
screen.
To return to the top screen, select “Now
playing” on the list screen.
Select to display the audio settings screen.
Select to set random playback.
Select to set repeat playback.
Shows progressShows progress
Select to play/pause.Select to play/pause.
Select to display the option screen.
(→235)
Select to fast forward.
Select to rewind.
Select to display full screen video.
Tune/Scroll knob:
•Turn to select a track.
•Turn to move up/down the list.Tune/Scroll knob:
•Turn to select a file.
•Turn to move up/down the list.
Press to play/pause.Press to play/pause.
•Press to select a track.
•Press and hold to fast forward/rewind.•Press to select a file.
•Press and hold to fast forward/rewind.
IS_Navi_EE_53C71E.book 231 ページ ２０１４年５月２９日　木曜日　午前１１時２２分

232
3. MEDIA OPERATION
IS300h/250_Navi_EE
•Press to select a media mode.
•While in a media mode, pressing the
“MEDIA” button changes media modes.•Press to select a media mode.
•While in a media mode, pressing the
“MEDIA” button changes media modes.
Power/Volume knob:
•Turn to adjust volume.
•Press to turn the audio system on/off.
•Press and hold to restart the audio sys-
tem.Power/Volume knob:
•Turn to adjust volume.
•Press to turn the audio system on/off.
•Press and hold to restart the audio sys-
tem.
No.Function
AudioVideo
IS_Navi_EE_53C71E.book 232 ページ ２０１４年５月２９日　木曜日　午前１１時２２分

233
3. MEDIA OPERATION
IS300h/250_Navi_EE
AUDIO/VISUAL SYSTEM
4
CAUTION
●Do not operate the player’s controls or connect the iPod while driving.
NOTICE
●Depending on the size and shape of the iPod that is connected to the system, the armrest
may not close fully. In this case, do not forcibly close the armrest as this may damage the
iPod or the terminal, etc.
●Do not leave your portable player in the car. In particular, high temperatures inside the vehi-
cle may damage the portable player.
●Do not push down on or apply unnecessary pressure to the portable player while it is con-
nected as this may damage the portable player or its terminal.
●Do not insert foreign objects into the port as this may damage the portable player or its ter-
minal.
INFORMATION
●The system can only output the sound while driving.
●When an iPod is connected using a genuine iPod cable, the iPod starts charging its battery.
●Depending on the iPod, the video sound may not be able to be heard.
●Depending on the iPod and the songs in the iPod, iPod cover art may be displayed. This
function can be changed to “On” or “Off ”. (→P.254) It may take time to display iPod cover
art, and the iPod may not be operated while the cover art display is in process.
●When an iPod is connected and the audio source is changed to iPod mode, the iPod will
resume playing from the same point it was last used.
●Depending on the iPod that is connected to the system, certain functions may not be avail-
able.
●For viewing videos from an iPod, it is necessary to set “Video sound input” to “A/V”.
(→P. 2 5 3 )
IS_Navi_EE_53C71E.book 233 ページ ２０１４年５月２９日　木曜日　午前１１時２２分

234
3. MEDIA OPERATION
IS300h/250_Navi_EE
1Select .
zEach time is selected, the mode
changes as follows:
•track repeat
→ off
1Select .
zEach time is selected, the mode
changes as follows:
• track shuffle
→ album shuffle → off
iPod AUDIO
REPEATING
The track currently being listened to can
be repeated.
INFORMATION
●When is selected, “RPT” appears
on the screen.
RANDOM ORDER
Tracks or albums can be automatically
and randomly selected.
INFORMATION
●Each time is selected, “Shuffle”/
“ALB.Shuffle” appears on the screen.
IS_Navi_EE_53C71E.book 234 ページ ２０１４年５月２９日　木曜日　午前１１時２２分

235
3. MEDIA OPERATION
IS300h/250_Navi_EE
AUDIO/VISUAL SYSTEM
41Select “Options”.
2Select the desired settings to change.iPod VIDEO
To change to iPod video mode, select
“Browse” on the iPod audio screen, then
select the “Videos” tab and select the
desired video file.
iPod VIDEO OPTIONS
No.FunctionPage
Select to change the screen
size.200
Select to display the image
quality adjustment screen.200
Select to change audio set-
tings.250
IS_Navi_EE_53C71E.book 235 ページ ２０１４年５月２９日　木曜日　午前１１時２２分

236
3. MEDIA OPERATION
IS300h/250_Navi_EE
5. Bluetooth® AUDIO
The Bluetooth® audio system enables users to enjoy listening to music that is played
on a portable player on the vehicle speakers via wireless communication.
This audio system supports Bluetooth
®, a wireless data system capable of playing por-
table audio music without cables. If your device does not support Bluetooth
®, the
Bluetooth® audio system will not function.
OVERVIEW
The Bluetooth® audio operation screen can be reached by the following methods:
Depending on the type of portable player connected, some functions may not be avail-
able and/or the screen may look differently than shown in this manual.
XConnecting a Bluetooth® audio device (→P.240)
XUsing the instrument panel
Press the “MEDIA” button to display the audio control screen.
XUsing the Remote Touch
Press the “MENU” button on the Remote Touch, then select “Audio” to display the au-
dio control screen.
IS_Navi_EE_53C71E.book 236 ページ ２０１４年５月２９日　木曜日　午前１１時２２分

237
3. MEDIA OPERATION
IS300h/250_Navi_EE
AUDIO/VISUAL SYSTEM
4
■CONTROL SCREEN
■CONTROL PANEL
IS_Navi_EE_53C71E.book 237 ページ ２０１４年５月２９日　木曜日　午前１１時２２分

238
3. MEDIA OPERATION
IS300h/250_Navi_EE
No.Function
Select to select an album.
Select to select a track.
Select to display the audio source selection screen.
Select to display the portable device connection screen.
•Select to display a track list.
To return to the top screen, select “Now playing” on the list screen.
•Displays Bluetooth
® device condition
Select to display the playlist screen.
To return to the top screen, select “Now playing” on the list screen.
Select to set random playback.
Select to set repeat playback.
Shows progress
Select to play.
Select to pause.
Tune/Scroll knob:
•Turn to select a track.
•Turn to move up/down the list.
Press to play/pause.
•Press to select a track.
•Press and hold to fast forward/rewind.
•Press to select a media mode.
•While in a media mode, pressing the “MEDIA” button changes media modes.
Power/Volume knob:
•Turn to adjust volume.
•Press to turn the audio system on/off.
•Press and hold to restart the audio system.
IS_Navi_EE_53C71E.book 238 ページ ２０１４年５月２９日　木曜日　午前１１時２２分

239
3. MEDIA OPERATION
IS300h/250_Navi_EE
AUDIO/VISUAL SYSTEM
4
CAUTION
●Do not operate the player’s controls or connect to the Bluetooth® audio system while driv-
ing.
●Your audio unit is fitted with Bluetooth
® antennas. People with implantable cardiac pace-
makers, cardiac resynchronization therapy-pacemakers or implantable cardioverter
defibrillators should maintain a reasonable distance between themselves and the
Bluetooth
® antennas. The radio waves may affect the operation of such devices.
●Before using Bluetooth
® devices, users of any electrical medical device other than implant-
able cardiac pacemakers, cardiac resynchronization therapy-pacemakers or implantable
cardioverter defibrillators should consult the manufacturer of the device for information
about its operation under the influence of radio waves. Radio waves could have unexpected
effects on the operation of such medical devices.
NOTICE
●Do not leave your portable player in the vehicle. In particular, high temperatures inside the
vehicle may damage the portable player.
INFORMATION
●Depending on the Bluetooth® device that is connected to the system, the music may start
playing when selecting while it is paused. Conversely, the music may pause when
selecting while it is playing.
●In the following conditions, the system may not function:
• The Bluetooth
® device is turned off.
• The Bluetooth
® device is not connected.
• The Bluetooth
® device has a low battery.
●It may take time to connect the telephone when Bluetooth
® audio is being played.
●For operating the portable player, see the instruction manual that comes with it.
●If the Bluetooth
® device is disconnected due to poor reception from the Bluetooth® net-
work when the engine switch is in ACCESSORY or IGNITION ON mode,
the system automatically reconnects the portable player.
●If the Bluetooth
® device is disconnected on purpose, such as it was turned off, this does not
happen. Reconnect the portable player manually.
●Bluetooth
® device information is registered when the Bluetooth® device is connected to
the Bluetooth® audio system. When selling or disposing of the vehicle, remove the
Bluetooth® audio information from the system. (→P. 8 2 )
IS_Navi_EE_53C71E.book 239 ページ ２０１４年５月２９日　木曜日　午前１１時２２分

240
3. MEDIA OPERATION
IS300h/250_Navi_EE
XRegistering an additional device
1Select “Connect” on the Bluetooth®
audio control screen.
2For more information: →P.58
XSelecting a registered device
1Select “Connect” on the Bluetooth®
audio control screen.
2For more information: →P.60
1Select .
zEach time is selected, the mode
changes as follows:
• track repeat
→ album repeat → off
CONNECTING A Bluetooth®
DEVICE
To use the Bluetooth® audio system, it is
necessary to register a Bluetooth
® de-
vice with the system.
LISTENING TO Bluetooth®
AUDIO
REPEATING
The track or album currently being lis-
tened to can be repeated.
INFORMATION
●Each time is selected, “RPT”/
“ALB.RPT” appears on the screen.
IS_Navi_EE_53C71E.book 240 ページ ２０１４年５月２９日　木曜日　午前１１時２２分
