LEXUS LX570 2015 Owners Manual

6813-5. Using the hands-free system (for cellular phone)
3
Interior features
LX570_OM_OM60L96U_(U) ■
Editing the “Device Name”
If you change a device name, the name registered in your cellular phone is not
changed. ■
About “Device Address”
The address peculiar to the system. It cannot be changed. If you have registered
two Bluetooth ®
phones with the same device na me and you cannot distinguish one
from the other, refer to this address. ■
“My Phone Number”:
The phone number of the Bluetooth ®
phone is displayed on the screen. Depending
on the type of phone, the phon e number may no t be displayed.■
“Profiles”:
The compatibility profile of the Bluetooth ®
device is displayed on the screen.■
“Connect Portable Player from”:
There are 2 portable player connection se ttings available; “Vehicle” and “Portable
Player”. ■
When you delete a Bluetooth ®
phone
The phonebook data will be deleted at the same time.

6823-5. Using the hands-free sy stem (for cellular phone)
LX570_OM_OM60L96U_(U) Selecting a Bluetooth ®
phone
If multiple Bluetooth ®
phones are registered, follow the procedure
below to select the Bluetooth ®
phone to be used. You can only use one
phone at a time.
Display the “Bluetooth
* ” screen. ( 
P. 673)
Touch “Connect Phone” on the “Bluetooth
* ” screen.
Choose the phone to be con-
nected. The Bluetooth ®
mark is displayed
when you connect the phone.
If a completion message is dis-
played, connection is complete.
*: Bluetooth is a registered tr ademark of Bluetooth SIG, Inc.STEP 1
STEP 2
STEP 3
■
When another Bluetooth ®
device is connected during registering or selecting a
phone ●
When another Bluetooth ®
device is connected, a confirmation message will be
displayed. If you want to disconnect it, touch “Yes”. ●
The currently connected Bluetooth ®
phone’s screen button will have a Blue-
tooth ®
mark displayed on it. If the currently connected Bluetooth ®
phone’s
screen button is touched, the Bluetooth ®
phone can be disconnected. Touch
“Yes” to disconnect.■
Connecting the phone while Bluetooth ®
audio is playing
Bluetooth ®
audio will stop temporarily.

6833-5. Using the hands-free system (for cellular phone)
3
Interior features
LX570_OM_OM60L96U_(U) Selecting a portable player
If multiple portable players are reg istered, follow the procedure below to
select the portable player phone to be used. You can only use one porta-
ble player at a time.
Display the “Bluetooth
* ” screen. ( 
P. 673)
Touch “Connect Portable Player” on the “Bluetooth
* ” screen.
Choose the portable player to be
used. The Bluetooth ®
mark is displayed
when you connect the portable
player.
If a completion message is dis-
played, connection is complete.
*: Bluetooth is a registered tr ademark of Bluetooth SIG, Inc.STEP 1
STEP 2
STEP 3
■
When another Bluetooth ®
device is connected during registering or selecting a
portable player ●
When another Bluetooth ®
device is connected, a confirmation message will be
displayed. If you want to disconnect it, touch “Yes”. ●
The currently connected portable player’s screen button will have a Bluetooth ®
mark displayed on it. If the currently connected portable player’s screen button
is touched, the portable player can be disconnected. Touc h “Yes” to discon-
nect.

6843-5. Using the hands-free sy stem (for cellular phone)
LX570_OM_OM60L96U_(U) Detailed Bluetooth ®
settings
You can confirm and change the Bluetooth ®
settings.
Page 1
Changing the device connec-
tion status
Changing the name of the con-
nected device.
Changing the passcode that
you registered your Bluetooth ®
device in the system
The address peculiar to the sys-
tem You cannot change this address. If
the same device name is displayed
on the screen of your device, refer
to it.
Page 2
The compatibility profile of the
Bluetooth ®
device
To display the screen above, follow the steps below.
Press the “SETUP” button, and touch “Bluetooth
* ” on the “Setup”
screen.
Touch “Detailed Bluetooth* S ettings” on the “Bluetooth
* ” screen.
* : Bluetooth is a registered tr ademark of Bluetooth SIG, Inc.STEP 1
STEP 2

6853-5. Using the hands-free system (for cellular phone)
3
Interior features
LX570_OM_OM60L96U_(U) ■ Changing Bluetooth
* power
The Bluetooth
* device is automatically conne cted when you turn the
“ENGINE START STOP” switch to ACCESSORY or IGNITION
ON mode. You can change between “On” or “Off”.
Display the “Detailed Bluetooth
* Settings” screen. ( 
P. 682)
Touch “Bluetooth
* Power” on the “Detailed Bluetooth
* Settings”
screen.
Touch “On” or “Off”, and then
touch “Save”.
* : Bluetooth is a registered tr ademark of Bluetooth SIG, Inc.
■ Editing the device name
Display the “Detailed Bluetooth
* Settings” screen. ( 
P. 682)
Touch “Device Name” on the “Detailed Bluetooth
* Settings”
screen.
Input the device name, and touch “OK”.
Touch “Save” on the “Detailed Bluetooth
* Settings” screen.
* : Bluetooth is a registered tr ademark of Bluetooth SIG, Inc.STEP 1
STEP 2
STEP 3
STEP 1
STEP 2
STEP 3
STEP 4

6863-5. Using the hands-free sy stem (for cellular phone)
LX570_OM_OM60L96U_(U) ■ Editing the passcode
Display the “Detailed Bluetooth
* Settings” screen. ( 
P. 682)
Touch “Passcode” on the “Detailed Bluetooth
* Settings” screen.
Input a passcode, and touch “OK”.
Touch “Save” on the “Detailed Bluetooth
* Settings” screen.
* : Bluetooth is a registered tr ademark of Bluetooth SIG, Inc.
■ Bluetooth ®
device connection status display settings
When “Bluetooth
* Power” is “On” and the “ENGINE START STOP”
switch is in ACCESSORY or IGNI TION ON mode, the Bluetooth ®
phone and portable player’s connection status can be displayed.
( 
P. 683)
Display the “Detailed Bluetooth
* Settings” screen. ( 
P. 682)
Touch “Display Phone Status” or “Display Portable Player Status”
on the “Detailed Bluetooth
* Settings” screen.
Touch “On”, and then touch
“Save”.
* : Bluetooth is a registered tr ademark of Bluetooth SIG, Inc.STEP 1
STEP 2
STEP 3
STEP 4
STEP 1
STEP 2
STEP 3

6873-5. Using the hands-free system (for cellular phone)
3
Interior features
LX570_OM_OM60L96U_(U) ■
While driving
You cannot change the state of “Bluetooth
* Power” from “On” to “Off” while driv-
ing, but it can be chan ged from “Off” to “On”.■
To return to the default Bluetooth ®
settings
Touch “Default”, and then touch “Yes”.
If the state of “Bluetooth
* Power” is changed from “Off” to “On”, Bluetooth ®
con-
nection will begin.
*: Bluetooth is a registered tr ademark of Bluetooth SIG, Inc.

686
LX570_OM_OM60L96U_(U) 3-6. Using the interior lights
Interior lights list
Rear interior light (  P. 687)
Rear personal lights (  P. 688)
Inside door handle light
Shift lever light (when the “ENGINE START STOP” switch is in
ACCESSORY or IGNITION ON mode)
Front interior lights (  P. 687)
Front personal lights (  P. 688)
Footwell lights
Scuff lights (if equipped)
“ENGINE START STOP” switch light
Door courtesy light
Luggage compartment light (  P. 689)
Outer foot lights
Running board lights

6873-6. Using the interior lights
3
Interior features
LX570_OM_OM60L96U_(U) Interior lights
Front
“OFF”
Door position on/off
“ON”
Rear
Door position
On Interior lights

6883-6. Using the interior lights
LX570_OM_OM60L96U_(U) Personal lights
Front
On/off
Rear
On/off Personal lights
