LEXUS LX570 2015 Owners Manual

7193-8. Other interior features
3
Interior features
LX570_OM_OM60L96U_(U) ■ Programming HomeLink ®
Point the remote control transmit-
ter for the device 1 to 3 in. (25 to
75 mm) from the HomeLink ®
but-
tons. Keep the HomeLink ®
indicator
light in view while programming.
Press and hold one of the
HomeLink ®
buttons and the trans-
mitter button. When the
HomeLink ®
indicator light
changes from a slow to a rapid
flash, you can release both buttons. If the HomeLink ®
indicator light
comes on but does not flash,
flashes rapidly for 2 seconds and
remains lit, the HomeLink ®
button
is already programmed. Use the
other buttons or follow the “Repro-
gramming a HomeLink ®
button”
instructions. (  P. 723)STEP 1
STEP 2

7203-8. Other interior features
LX570_OM_OM60L96U_(U) Test the HomeLink ®
operation by
pressing the newly programmed
button. If a HomeLink ®
button has been
programmed for a garage door,
check to see if the garage door
opens and closes. If the garage
door does not operate, see if your
remote control transmitter is of the
rolling code type. Press and hold
the programmed HomeLink ®
but-
ton. The remote control transmitter
is of the rolling code type if the
HomeLink ®
indicator light flashes
rapidly for 2 seconds and then
remains lit. If your transmitter is of
the rolling code type, proceed to
the heading “Programming a roll-
ing code system”.
Repeat the steps above to program another device for each of
the remaining HomeLink ®
buttons.STEP 3
STEP 4

7213-8. Other interior features
3
Interior features
LX570_OM_OM60L96U_(U) ■ Programming a rolling code system
If your device is rolling code equipped, follow the steps under the
heading “Programming HomeLink ®
” before proceeding with the
steps listed below.
Locate the learn button on th e ceiling mounted garage door
opener motor. The exact location and color of the button may
vary by brand of garage door opener motor. Refer to the operation manual supplied with the garage door opener
motor for the location of the learn button.
Press the learn button. Following this step, you have 30 se conds in which to initiate step 3
below.
Press and hold the vehicle’s programmed HomeLink ®
button for
2 seconds and release it. Repeat this step once again. The garage
door may open. If the garage door opens, the programming process is complete. If the
door does not open, press and release the button a third time. This third
press and release will complete th e programming process by opening
the garage door.
The ceiling mounted garage door op ener motor should now recognize
the HomeLink ®
signal and operate the garage door.
Repeat the steps above to prog ram another rolling code system
for any of the remaining HomeLink ®
buttons.STEP 1
STEP 2
STEP 3
STEP 4

7223-8. Other interior features
LX570_OM_OM60L96U_(U) ■ Programming an entry gate (for U .S.A. owners)/Programming all
devices in the Canadian market
Place your transmitter 1 to 3 in. (25 to 75 mm) away from the sur-
face of the HomeLink ®
.Keep the HomeLink ®
indicator light in view while programming.
Press and hold the selected HomeLink ®
button.
Repeatedly press and release (cycle) the device’s remote control
button for two seconds each until step 4 is completed.
When the indicator light on the HomeLink ®
compatible trans-
ceiver starts to flash rapidly, release the buttons.
Test the operation of the HomeLink ®
by pressing the newly pro-
grammed button. Check to see if the gate/device operates cor-
rectly.
Repeat the steps above to program another device for each of
the remaining HomeLink ®
buttons.
■ Programming other devices
To program other devices such as home security systems, home door
locks or lighting, contact yo ur Lexus dealer for assistance.
■ Reprogramming a button
The individual HomeLink ®
buttons cannot be erased but can be
reprogrammed. To reprogram a butto n, follow the “Reprogramming a
HomeLink ®
button” instructions.STEP 1
STEP 2
STEP 3
STEP 4
STEP 5
STEP 6

7233-8. Other interior features
3
Interior features
LX570_OM_OM60L96U_(U) Operating HomeLink ®
Press the appropriate HomeLink ®
button. The HomeLink ®
indicator
light should come on. The HomeLink ®
compatible transceiver in your vehicle continues to send a
signal for up to 20 seconds as long as the button is pressed.
Reprogramming a HomeLink ®
button
Press and hold the desired HomeLink ®
button. After 20 seconds, the
HomeLink ®
indicator light will start flash ing slowly. Next, while still press-
ing and holding the HomeLink ®
button, press and hold the button on the
transmitter until the HomeLink ®
indicator light changes from a slow to a
rapid flash.
Erasing the entire HomeLink ®
memory (all three programs)
Press and hold the 2 outside but-
tons for 10 seconds until the indi-
cator light flashes. If you sell your vehicle, be sure to
erase the programs stored in the
HomeLink ®
memory.

7243-8. Other interior features
LX570_OM_OM60L96U_(U) ■
Before programming ●
Install a new battery in the remote control transmitter. ●
The battery side of the re mote control transmitter must be pointed away from
the HomeLink ®

button.■
Certification for the garage door opener
For vehicles sold in the U.S.A.
FCC ID:NZLOBIHL4
FCC ID:NZLWZLHL4
NOTE:
This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-
lowing two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
FCC WARNING:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
For vehicles sold in Canada
NOTE:
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must a ccept any interference, including interfer-
ence that may cause undesire d operation of the device.■
When support is necessary
Visit on the web at www.homelink.com or call 1-800-355-3515.

7253-8. Other interior features
3
Interior features
LX570_OM_OM60L96U_(U) CAUTION■
When programming a garage door or other remote control devices
The garage door on other devices may oper ate, so ensure people and objects are
out of danger to pr event potential harm.■
Conforming to federal safety standards
Do not use the HomeLink ®
compatible transceiver with any garage door opener
or device that lacks safety stop and reverse features as required by federal safety
standards.
This includes any garage door that cannot detect an interfering object. A door or
device without these features increases the risk of death or serious injury.

7263-8. Other interior features
LX570_OM_OM60L96U_(U) Safety Connect 
 : If equippedSafety Connect is a subscription-based telematics service that uses Global
Positioning System (GPS) data and em bedded cellular technology to pro-
vide safety and security features to subscribers. Safety Connect is sup-
ported by Lexus’ designated response center, which operates 24 hours
per day, 7 days per week.
Safety Connect service is available by subscription on select, telematics
hardware-equipped vehicles.
By using the Safety Connect service, you are agreeing to be bound by the
Telematics Subscription Service Agreement and its Terms and Condi-
tions, as in effect and amended from time to time, a current copy of which is
available at Lexus.com. All use of th e Safety Connect service is subject to
such then-applicable Terms and Conditions.
■ System components
Microphone
LED light indicators
“SOS” button

7273-8. Other interior features
3
Interior features
LX570_OM_OM60L96U_(U) ■ Services
Subscribers have the following Sa fety Connect services available:
● Automatic Collision Notification
*Helps drivers receive necessary response from emergency ser-
vice providers. (  P. 729)
* : U.S. Patent No. 7,508,298 B2
● Stolen Vehicle Location
Helps drivers in the event of vehicle theft. (  P. 730)
● Emergency Assistance Button (SOS)
Connects drivers to response-center support. (  P. 730)
● Enhanced Roadside Assistance
Provides drivers various on-road assistance. (  P. 730)
■ Subscription
After you have signed the Telemati cs Subscription Service Agree-
ment and are enrolled, you can begin receiving services.
A variety of subscription terms is available for purchase. Contact
your Lexus dealer, call 1-800- 25-LEXUS (1-800-255-3987) or
push the “SOS” button in your vehicle for further subscription
details.

7283-8. Other interior features
LX570_OM_OM60L96U_(U) ■
Safety Connect Services Information ●
Phone calls using the vehicles Bluetooth ®
technology will not be possible dur-
ing Safety Connect. ●
Safety Connect is available beginning Fall 2009 on select Lexus models. Con-
tact with the Safety Connect response center is dependent upon the telematics
device being in operative condition, ce llular connection availability, and GPS
satellite signal reception, which can limit the ability to reach the response center
or receive emergency service support. Enrollment and Telematics Subscription
Service Agreement required. A variety of subscription terms is available;
charges vary by subscription term selected. ●
Automatic Collision Notification, Emergency Assistance and Stolen Vehicle
Location will function in the United St ates, including Hawaii and Alaska, and in
Canada, and Enhanced Roadside Assistance will function in the United States
(except Hawaii) and in Canada. No Safety Connect services will function out-
side of the United States in countries other than Canada. ●
Safety Connect services are not subjec t to section 255 of the Telecommunica-
tions Act and the device is not TTY compatible.■
Languages
The Safety Connect response center will offer support in multiple languages. The
Safety Connect system will offer voice prom pts in English and Spanish. Please indi-
cate your language of choice when enrolling.■
When contacting the response center
You may be unable to contact the resp onse center if the network is busy.■
Safety Connect backup battery depletion
An exclusive backup battery is built in to assist the Automatic Collision Notification,
which is activated when impact above a certain level is applied to the vehicle, or
when the airbags operate. This batter y is a primary battery, and cannot be
recharged. The red LED indicator will flas h to indicate that the battery should be
replaced.
The backup battery will need to be replaced if the Automatic Collision Notification
operates for 60 seconds or more. For replacement, consult your Lexus dealer.
