LEXUS LX570 2015 Owners Manual

6893-6. Using the interior lights
3
Interior features
LX570_OM_OM60L96U_(U) Luggage compartment light
Off
Door position■
Illuminated entry system
The lights automatically tu rn on/off according to “ENGINE START STOP” switch
mode, the presence of the electronic ke y, whether the doors are locked/unlocked,
and whether the doors are open/closed. ■
To prevent battery discharge
If the interior lights remain on when the “ENGINE START STOP” switch is turned
off, the lights will go off automatically after 20 minutes. ■
Customization
Settings (e.g. Time pe riod before the interior lights turn off.) can be changed.
(Customizable features  P. 912) Luggage compartment light

690
LX570_OM_OM60L96U_(U) 3-7. Using the storage features
List of storage features
CAUTION■
Items that should not be left in the storage spaces
Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause
the following when cabin temperature becomes high: ●
Glasses may be deformed by heat or cracked if they come into contact with
other stored items. ●
Lighters or spray cans may explode. If they come into contact with other stored
items, the lighter may catch fire or the spray can may release gas, causing a fire
hazard.Auxiliary boxes
Card holder
Overhead console
Glove box
Bottle holders Door pockets
Cup holders
Console box
Cool box

6913-7. Using the storage features
3
Interior features
LX570_OM_OM60L96U_(U) Glove box
Open (push button)
Unlock with the mechanical key
Lock with the mechanical key■
Glove box light
The glove box light turns on when the tail lights are on. ■
Removing the separate tray
CAUTION■
While driving
Keep the glove box closed.
Injuries may result in the event of sudden braking, sudden swerving or an accident.Pull out the separate tray. Glove box

6923-7. Using the storage features
LX570_OM_OM60L96U_(U) Console box (if equipped)
Your vehicle is equipped with either a console box or cool box.
For vehicles with the co ol box, refer to page 699.
Lift the lid while pulling up the
lower lever to release the lock.
Remove the tray.STEP 1
STEP 2
CAUTION■
While driving
Keep the console box closed.
Injuries may result in the event of sudden braking, sudden swerving or an accident. Console box

6933-7. Using the storage features
3
Interior features
LX570_OM_OM60L96U_(U) Overhead console
Press the button. The overhead console is useful for
temporarily storing small items.
CAUTION■
Items unsuitable for storing
Do not store items heavier than 0.4 lb (0.2 kg).
Doing so may cause the overhead console to open and the items inside may fall out,
resulting in an accident. ■
While driving
Do not leave the overhead console open.
Items may fall out and cause injury. Overhead console

6943-7. Using the storage features
LX570_OM_OM60L96U_(U) Cup holders
Front (type A)
Press down and release the lid. You can adjust or remove the
holder inside.
Front (if equipped with type B)
Open the lower console box lid.
Rear
Pull the rear armrest down. (  P. 712)
Press the button.STEP 1
STEP 2 Cup holders

6953-7. Using the storage features
3
Interior features
LX570_OM_OM60L96U_(U) ■
Removing the holder (front cup holders type A)
CAUTION■
Items unsuitable for the cup holders
Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the hold ers in the event of an accident or sudden
braking, causing injury. If possible, cover hot drinks to prevent burns. ■
When not in use
Keep the cup holders closed.
Injuries may result in the event of sudden braking, sudden swerving or an accident.
NOTICE■
To prevent damage to the cup holders
Stow the cup holders before stowing the rear armrest. Pull up the holder. Cup holders

6963-7. Using the storage features
LX570_OM_OM60L96U_(U) Bottle holders
Front seats
Second seats
Third seats Bottle holders

6973-7. Using the storage features
3
Interior features
LX570_OM_OM60L96U_(U) Card holder
Auxiliary boxes
Front seats
Press and release the lid.NOTICE■
Items that should not be stowed in the bottle holders
Put the cap on before stowing a bottle. Do not place open bottles in the bottle hold-
ers, or glasses and paper cups containing liquid. The contents may spill and glasses
may break. Bottle holders, card ho lder and auxiliary boxes

6983-7. Using the storage features
LX570_OM_OM60L96U_(U) Second seats
Pull down the armrest.
Press the button to release the
lock.
Third seats STEP 1
STEP 2
CAUTION■
While driving
Except for the third seats: Do not leave the auxiliary box open while driving.
Items stored in it may fall out and cause de ath or serious injury in case of an acci-
dent or sudden stop. Auxiliary boxes
