Page 891 of 960

LEXUS LX570 2015  Owners Manual 8876-1. Specifications
6
Vehicle specifications
LX570_OM_OM60L96U_(U) Vehicle identification
■ Vehicle identification number
The vehicle identification number (V IN) is the legal identifier for your

Page 892 of 960

LEXUS LX570 2015  Owners Manual 8886-1. Specifications
LX570_OM_OM60L96U_(U) Engine
Fuel Model 5.7L V8 (3UR-FE)
Type 8-cylinder V type, 4-cycle, gasoline
Bore and stroke 3.70    4.02 in. (94.0    102.0 mm)
Displacement
345.6 c

Page 893 of 960

LEXUS LX570 2015  Owners Manual 8896-1. Specifications
6
Vehicle specifications
LX570_OM_OM60L96U_(U) Lubrication system
* : The engine oil capacity is a reference qu antity to be used when changing the
engine oil. Warm up and turn

Page 894 of 960

LEXUS LX570 2015  Owners Manual 8906-1. Specifications
LX570_OM_OM60L96U_(U) Oil viscosity (0W-20 is explained here as an example):
• The 0W in 0W-20 indicates the char acteristic of the oil which allows
cold startability. Oils  w

Page 895 of 960

LEXUS LX570 2015  Owners Manual 8916-1. Specifications
6
Vehicle specifications
LX570_OM_OM60L96U_(U) Cooling system
Ignition system Capacity (Reference) 17.6 qt. (16.7 L, 14.7 Imp.qt.)
Coolant type Use either of the following.
•

Page 896 of 960

LEXUS LX570 2015  Owners Manual 8926-1. Specifications
LX570_OM_OM60L96U_(U) Electrical system
Differential
Your Lexus vehicle is filled with “Toyota Ge nuine Differential Gear Oil” at the fac-
tory.
Use Lexus approved “Toyot

Page 897 of 960

LEXUS LX570 2015  Owners Manual 8936-1. Specifications
6
Vehicle specifications
LX570_OM_OM60L96U_(U) Automatic transmission
The fluid capacity is the quantity of refere nce. If replacement is necessary, contact
your Lexus dealer.
T

Page 898 of 960

LEXUS LX570 2015  Owners Manual 8946-1. Specifications
LX570_OM_OM60L96U_(U) Brakes
* 1
: Minimum pedal clearance when depressed with a force of 110 lbf (490 N, 50
kgf) while the engine is running
* 2
: Parking brake lever travel wh

Page 899 of 960

LEXUS LX570 2015  Owners Manual 8956-1. Specifications
6
Vehicle specifications
LX570_OM_OM60L96U_(U) Suspension
Tires and wheels Fluid type Suspension fluid AHC
Tire size P285/50R20 111V
Tire inflation pressure
(Recommended cold t

Page 900 of 960

LEXUS LX570 2015  Owners Manual 8966-1. Specifications
LX570_OM_OM60L96U_(U) Light bulbs
A: D4S high-intensity discharge
B: HB3 halogen bulbs
C: Wedge base bulbs
D: Single end bulbs
E: Double end bulbs Light bulbs Bulb No. W Type
Ex
