LEXUS LX570 2016 Owners Manual

561
LX570_OM_OM60N01U_(U)
8Vehicle specifications
8-1. SpecificationsMaintenance data (fuel, oil level, etc.)................... 562
Fuel information............................571
Tire information ............................ 574
8-2. Customization Customizable features ........... 585
8-3. Initialization Items to initialize .........................598

562
LX570_OM_OM60N01U_(U)8-1. Specifications
Maintenance data (fuel, oil level, etc.)
*1: Unladen vehicles
*2: Vehicles without roof rail
*3: Vehicles with roof rail
*4: Vehicles with 20-inch tires
*5: Vehicles with 21-inch tires
Dimensions and weights
Overall length200.0 in. (5080 mm)
Overall width78.0 in. (1980 mm)
Overall height*174.4 in. (1890 mm)*2
76 . 0 i n . ( 1 9 3 0 m m )*3
Wheelbase112.2 in. (2850 mm)
Tr e a d
Front64.8 in. (1645 mm)*4
65.0 in. (1650 mm)*5
Rear64.6 in. (1640 mm)*4
65.0 in. (1650 mm)*5
Vehicle capacity weight
(Occupants + luggage)1285 lb. (580 kg)
TWR
(trailer weight + cargo weight)7000 lb. (3175 kg)

LX570_OM_OM60N01U_(U)
5638-1. Specifications
8
Vehicle specifications
■Vehicle identification number
The vehicle identification number (VIN) is the legal identifier for your vehicle.
This is the primary identification number fo r your Lexus. It is used in register-
ing the ownership of your vehicle.
This number is stamped on the top
left of the instrument panel.
This number is also on the Certifica-
tion Label.
■Engine number
The engine number is stamped on
the engine block as shown.
Vehicle identification

564
LX570_OM_OM60N01U_(U)8-1. Specifications
*: The engine oil capacity is a reference quantity to be used when changing the engine
oil. Warm up and turn off the engine, wait more than 5 minutes, and check the oil level
on the dipstick.
Engine
Model5.7L V8 (3UR-FE)
Ty p e8-cylinder V type, 4-cycle, gasoline
Bore and stroke3.70  4.02 in. (94.0  102.0 mm)
Displacement345.6 cu.in. (5663 cm3)
Valve clearanceAutomatic adjustmentDrive belt tension
Fuel
Fuel typeUnleaded gasoline only
Octane rating91 (Research Octane Number 96) or higher
Fuel tank capacity
(Reference)24.5 gal. (93 L, 20.4 Imp.gal.)
Lubrication system
Oil capacity
(Drain and refill — reference
*)
With filter
Without filter7.9 qt. (7.5 L, 6.6 Imp.qt.)
7.5 qt. (7.1 L, 6.2 Imp.qt.)

LX570_OM_OM60N01U_(U)
5658-1. Specifications
8
Vehicle specifications
■Engine oil selection
“Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use Lexus
approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following
grade and viscosity.
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good start-
ing in cold weather.
If SAE 0W-20 is not available, SAE
5W-20 oil may be used. However, it
must be replaced with SAE 0W-20
at the next oil change.
Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of
the engine in cold weather.
• The 20 in 0W-20 indicates the viscos ity characteristic of the oil when the
oil is at high temperature. An oil with a higher viscosity (one with a higher
value) may be better suited if the vehicle is operated at high speeds, or
under extreme load conditions.
How to read oil container label:
The International Lubricant Specifi cation Advisory Committee (ILSAC) Cer-
tification Mark is added to some oil containers to help you select the oil you
should use.
Outside temperature

566
LX570_OM_OM60N01U_(U)8-1. Specifications
Cooling system
Capacity (Reference)17.1 qt. (16.2 L, 14.3 Imp.qt.)
Coolant type
Use either of the following.
• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based
non-silicate, non-amine, non-nitrite, and non-
borate coolant with long-life hybrid organic
acid technology
Do not use plain water alone.
Ignition system
Spark plug
Make
GapDENSO SK20HR11
0.043 in. (1.1 mm)
NOTICE
■Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust gap when tuning engine.
Electrical system
Battery
Open voltage at 68 F (20 C):12.6  12.8 V Fully charged
12.2  12.4 V Half charged
11.8  12.0 V Discharged
(Voltage is checked 20 minutes after the engine
and all lights ar e turned off.)
Charging rates5 A max.

LX570_OM_OM60N01U_(U)
5678-1. Specifications
8
Vehicle specifications
Your Lexus vehicle is filled with “Toyota Genuine Differential Gear Oil” at the
factory.
Use Lexus approved “Toyota Genuine Differential Gear Oil” or an equivalent of
matching quality to satisfy the above specification. Please contact your Lexus
dealer for further details.
The fluid capacity is the quantity of reference. If replacement is necessary, con-
tact your Lexus dealer.
Differential
Oil capacity
Front
Rear2.01 qt. (1.90 L, 1.67 Imp.qt.)
4.44 qt. (4.20 L, 3.70 Imp.qt.)
Oil type and viscosityToyota Genuine Differential Gear Oil LT 75W-85
GL-5 or equivalent
Automatic transmission
Fluid capacity10.7 qt. (10.1 L, 8.9 Imp.qt.)
Fluid typeTo y o t a G e n u i n e AT F W S
NOTICE
■Automatic transmission fluid type
Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration
in shift quality, locking up of your transm ission accompanied by vibration, and ulti-
mately damage the transmission of your vehicle.

568
LX570_OM_OM60N01U_(U)8-1. Specifications
*: Your Lexus vehicle is filled with “Toyota Genuine Transfer Gear oil LF” at the factory.
Use Lexus approved “Toyota Genuine Transfer Gear oil LF” or an equivalent of
matching quality to satisfy the above specif ication. Please contact your Lexus dealer
for further details.
*: Minimum pedal clearance when depressed with a force of 110 lbf (490 N, 50 kgf) while the engine is running
Transfer
Oil capacity1.53 qt. (1.45 L, 1.28 Imp.qt.)
Oil type*Toyota Genuine Transfer Gear oil LF or equivalent
Recommended oil viscositySAE 75W
Brakes
Pe d a l c l e a r a n c e*4.5 in. (114 mm) Min.
Pedal free play0.04  0.24 in. (1.0  6.0 mm)
Brake pad wear limit0.04 in. (1.0 mm)
Parking brake lining wear limit0.04 in. (1.0 mm)
Fluid typeSAE J1703 or FMVSS No. 116 DOT 3
Chassis lubrication
Propeller shafts
SpiderLithium base chassis grease, NLGI No.2
Slide yoke
Molybdenum-disulfide lithium base chassis
grease, NLGI No.2 or Lithium base chassis
grease, NLGI No.2
Steering
Free playLess than 1.18 in. (30 mm)
Power steering fluid typeAutomatic transmission fluid DEXRON® II or III

LX570_OM_OM60N01U_(U)
5698-1. Specifications
8
Vehicle specifications
20-inch tires
21-inch tires
Suspension
Fluid typeSuspension fluid AHC
Tires and wheels
Ti r e s i z e285/50R20 112V
Tire inflation pressure
(Recommended cold tire
inflation pressure)
Normal drivingFront:
33 psi (230 kPa, 2.3 kgf/cm
2 or bar)
Rear:
33 psi (230 kPa, 2.3 kgf/cm
2 or bar)
Spare:
33 psi (230 kPa, 2.3 kgf/cm
2 or bar)
Trailer towing
Add 2 psi (10 kPa, 0.1 kgf/cm
2 or bar) to the rear
tires.
Wheel size20  8 1 /2J
Wheel nut torque97 ft•lbf (131 N•m, 13.4 kgf•m)
Ti r e s i z e275/50R21 113V XL
Tire inflation pressure
(Recommended cold tire
inflation pressure)
Normal driving
Front:
33 psi (230 kPa, 2.3 kgf/cm
2 or bar)
Rear:
33 psi (230 kPa, 2.3 kgf/cm
2 or bar)
Spare:
33 psi (230 kPa, 2.3 kgf/cm
2 or bar)
Trailer towing Add 6 psi (40 kPa, 0.4 kgf/cm
2 or bar) to the
rear tires.
Wheel size21 X 8 1 /2J
Wheel nut torque97 ft•lbf (131 N•m, 13.4 kgf•m)

570
LX570_OM_OM60N01U_(U)8-1. Specifications
Light bulbs
Light bulbsBulb No.WTy p e
ExteriorBack-up lights92116A
InteriorVanity lights2B
A: Wedge base bulbs
B: Double end bulbs
