LEXUS NX300h 2015 Owners Manual

4316-1. Using the air conditio ning system and defogger
6
Interior features
NX300h_U_OM78007U ■
Adjusting the temperature setting
Press to increase the temperature and to decrease the
temperature. ■
Adjusting the fan speed setting
Press to increase the fan speed and to decrease the fan
speed.
Press the “OFF” button to turn the fan off.Control panel

432 6-1. Using the air conditioning system and defogger
NX300h_U_OM78007U ■
Change the airflow mode
To change the air outlets, press
.The air outlets used are switched
each time the button is pressed.
Air flows to the upper body.
Air flows to the upper body and
feet.
Air flows to the feet.
Air flows to the feet and the wind-
shield defogger operates.■
S-FLOW mode
Priority for airflow is given to the front seats, and the airflow and air condition-
ing for the rear seats is effectively controlled.
Press . The indicator comes on when S-FLOW mode is on.
Press again to return to the previous mode.■
Other functions ●
Switching between outside air and recirculated air modes (  P. 4 3 5 )●
Defogging the windshield (  P. 4 3 5 )●
Defogging the rear window and outside rear view mirrors (  P. 4 3 5 )1
2
3
4

4336-1. Using the air conditio ning system and defogger
6
Interior features
NX300h_U_OM78007U 
Vehicles with a Lexus Display Audio system
Adjust the left-hand side temper-
ature setting
Adjust the fan speed setting
Select to set auto mode on/off,
fan off and displaying the option
control screen (  P. 434)
Select the air flow mode
Adjust the right-hand side temperature setting
Move the Lexus Display Audio controller left/right to select the desired item
( to ).
When , or is selected:
Move the controller forward/backward or turn it left/right for adjusting.
When or is selected:
Move the controller forward/backward or turn it left/right to select a screen
button, then press the controller. 
Vehicles with a navigation system
Adjust the left-hand side temper-
ature setting
Adjust the fan speed setting
Select the air flow mode
Adjust the right-hand side tem-
perature setting
Display the option control screen
(  P. 4 3 4 )
Tu r n t h e f a n o f f
Select to set automatic mode on/off
Using the touchpad of the Remote Touch, select the button on the screen and
then activate it by pressing on or double tapping the touchpad.Control screen 1
2
3
4
5
1
1 5
2
1 2 5
3 4
1
2
3
4
5
6
7

434 6-1. Using the air conditioning system and defogger
NX300h_U_OM78007U ■
Option control screen
Select on the climate screen to display the option control screen. The
functions can be switched on and off.
Select to set cooling and de humidification function on/off
Adjust the temperature for driver and passenger seats separately (“DUAL”
mode) (  P. 4 3 5 )
Prevent ice from building up on the windshield and wiper blades
(  P. 4 3 6 )
Remove pollen from the air (Micro dust and pollen filter) (  P. 4 3 6 )■
Using the automatic mode
Press the “AUTO” button.
Adjust the temperature setting.
To stop the operation, press the “OFF” button.■
Automatic mode indicator
If the fan speed setting or air flow modes are operated, the automatic mode
indicator goes off. However, automati c mode for functions other than that
operated are maintained. 
Vehicles with a Lexus Display Audio
system 
Vehicles with a navigation system
Air conditioning controls 1
2
3
4
1
2
3

4356-1. Using the air conditio ning system and defogger
6
Interior features
NX300h_U_OM78007U ■
Adjusting the temperature for driver and passenger seats separately
(“DUAL” mode)
To turn on the “DUAL” mode, perform any of the following procedures: ●
Press the “DUAL” button. ●
Select “DUAL” on the option control screen. ●
Adjust the temperature setting of the passenger side with the passenger
side temperature adjustment button. The indicator comes on when the “DUAL” mode is on.
■
Switching between outside air and recirculated air modes
Press . The mode switches between (recirculated air mode) and (outside
air mode) modes each time the button is pressed.■
Defogging the windshield
Defoggers are used to defog the windshield and front side windows.
Press . Set to outside air mode if the recirculated air mode is used. (It may
switch automatically.)
To defog the windshield and the side windows early, turn the air flow and tempera-
ture up.
To return to the previous mode, press again when the windshield is
defogged.■
Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window and to remove raindrops, dew
and frost from the outside rear view mirrors.
Press .
The defoggers will automatically turn off after a period of time.Other functions

436 6-1. Using the air conditioning system and defogger
NX300h_U_OM78007U ■
Micro dust and pollen filter
Pollen is removed from the air and the air flows to the upper part of the body.
Select on the option control screen. When the micro dust and pollen filter is on, is displayed on the air condition-
ing control screen.
In order to prevent the windshield from fo gging up when the outside air is cold, the
dehumidification function may operate.
The pollens are filtered out even if the micro dust and pollen filter is turned off.■
Windshield wiper de-icer
This feature is used to prevent ice fr om building up on the windshield and
wiper blades.
Select on the option control screen. When the windshield wiper de-icer is on , is displayed on the air condition-
ing control screen.
The windshield wiper de-icer will automati cally turn off after a period of time.
■
Location of air outlets
The air outlets and air volume
changes according to the selected
air flow mode.Air outlets

4376-1. Using the air conditio ning system and defogger
6
Interior features
NX300h_U_OM78007U ■
Adjusting the position of and opening and closing the air outlets
Direct air flow to the left or right, up or down
Turn the knob to open or close the vent ■
Registering air conditioning settings to elec tronic keys (vehicles with driving position
memory) ●
Unlocking the vehicle using an electronic key and turning the power switch to ON
mode will recall that key’s registered air conditioning settings. ●
When the power switch is turned off, the curr ent air conditioning settings will automati-
cally be registered to the electronic key that was used to unlock the vehicle. ●
The system may not operate correctly if more th an one electronic key is in the vicinity or
if the smart access system with push-button start is used to unlock a passenger door. ●
The doors that can recall the air conditioni ng setting when unlocked using the smart
access system with push-b utton start can be changed.
* For details, contact your Lexus
dealer.
* : The doors that can recall the driving positi on memory are changed at the same time.■
Using automatic mode
Fan speed is adjusted automatically accordin g to the temperature setting and the ambi-
ent conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately
after the “AUTO” button is pr essed or “AUTO” is selected.■
When the outside temperature exceeds 75  F (24  C) and the air conditioning system
is on ●
In order to reduce the air conditioning po wer consumption, the ai r conditioning system
may switch to recirculated air mode automatically.
This may also reduce fuel consumption. ●
Recirculated air mode is selected as a default mode when the power switch is turned to
ON mode. ●
It is possible to switch to outside air mode at any time by pressing .
Front 
Rear
1
2

438 6-1. Using the air conditioning system and defogger
NX300h_U_OM78007U ■
Fogging up of the windows ●
The windows will easily fog up when the humidity in the vehicle is high. Pressing “A/C”
button or selecting “A/C” will dehumidify th e air from the outlets and defog the wind-
shield effectively. ●
If you turn “A/C” off, the windows may fog up more easily. ●
The windows may fog up if the recirculated air mode is used. ■
Windshield fog detection function
When automatic mode is set, the humidity sensor (  P. 4 3 9 ) d e t e c t s f o g o n t h e w i n d -
shield and controls the air conditioning system to prevent fog. ■
Outside/recirculated air mode ●
When driving on dusty roads such as tunnels or in heavy traffic, set to
the recirculated air mode. This is effective in preventing outside air from entering the
vehicle interior. During cooling operation, setting the recirculated air mode will also
cool the vehicle interior effectively. ●
Outside/recirculated air mode may automati cally switch depending on the tempera-
ture setting or the inside temperature. ■
When the outside temperature is low
The dehumidification function may not operat e even when “A/C” is pressed or “A/C” is
selected. ■
Operation of the air conditioning system in Eco drive mode ●
In the Eco drive mode, the air conditioning sy stem is controlled as follows to prioritize
fuel efficiency
• Engine speed and compressor operation controlled to restrict heating/cooling
capacity
• Fan speed restricted when automatic mode is selected ●
To improve air conditioning performa nce, perform the following operations
• Adjust the fan speed
• Turn off Eco drive mode ■
Ventilation and air conditioning odors ●
To let fresh air in, set the air conditio ning system to the outside air mode.●
During use, various odors from inside and outside the vehicle may enter into and accu-
mulate in the air conditioning system. This may then cause odor to be emitted from the
vents. ●
To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air mode prior
to turning the vehicle off.
• The start timing of the blower may be dela yed for a short period of time immediately
after the air conditioning system is started in automatic mode.■
Air conditioning filter
 P. 5 3 0 ■
Customization
Settings (e.g. A/C automatic mode switch operation) can be changed.
(Customizable features:  P. 6 3 9 )

4396-1. Using the air conditio ning system and defogger
6
Interior features
NX300h_U_OM78007U WA R N I N G ■
To prevent the windshield from fogging up ●
Do not use during cool air operation in extremely humid weather. The differ-
ence between the temperature of the outside air and that of the windshield can cause
the outer surface of the windshield to fog up, blocking your vision.
■
To prevent burns ●
Do not touch the rear view mirror surfaces when the outside rear view mirror defog-
gers are on. ●
Do not touch the glass at lower part of the wi ndshield or to the si de of the front pillars
when the windshield wiper de-icer is on.
NOTICE ■
Humidity sensor
■
To prevent 12-volt battery discharge
Do not leave the air conditioning system on longer than necessary when the hybrid sys-
tem is off. ●
Do not place anything on the instrument
panel which may cover th e air outlets. Other-
wise, air flow may be obstructed, preventing
the windshield defoggers from defogging.
In order to detect fog on the windshield, a sen-
sor which monitors the temperature of the
windshield, the surround humidity, etc. is
installed. (  P. 4 3 8 )
Follow these points to avoid damaging the sen-
sor: ●
Do not disassemble the sensor ●
Do not spray the glass cleaner on the sensor
or subject it to strong impacts ●
Do not stick anything on the sensor

440 6-1. Using the air conditioning system and defogger
NX300h_U_OM78007UHeated steering wheel 
/seat heaters 
/seat ventila-
tors 
 : If equippedHeated steering wheel and seat heater s heat the side grips of the steering
wheel and seats, respectively. Seat ventilators maintain good airflow by blow-
ing air from the seats. WA R N I N G ●
Care should be taken to prevent injury if anyone in the following categories comes in
contact with the steering wheel an d seats when the heater is on:
• Babies, small children, the elderly, the sick and the physically challenged
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (s leeping drugs, cold
remedies, etc.) ●
Observe the following precautions to prevent minor burns or overheating:
• Do not cover the seat with a blanket or cushion when using the seat heater.
• Do not use seat heater more than necessary.
NOTICE ●
Do not put heavy objects that have an uneven surface on the seat and do not stick
sharp objects (needles, nails, etc.) into the seat. ●
To prevent 12-volt battery discharge, do not use the functions when the hybrid system
is off.
