LEXUS NX300h 2015 Owners Manual

4516-3. Using the storage features
6
Interior features
NX300h_U_OM78007U Lift the deck board and attach the hook. (  P. 452) The following item can be
stowed.
* : The warning reflector itself is not included as an original equipment.Grocery bag hooks
NOTICE
Do not hang any object heavier than 11 lb. (5 kg) on the grocery bag hooks.
Deck under tray 
Vehicles with a compact spare tire 
Vehicles with a full-size spare tire
First-aid kit and other items
Accessories Wa r n i n g r e f l e c t o r
*1
2 3

452 6-3. Using the storage features
NX300h_U_OM78007U If the luggage cover is used: Unhook
the cords.
If the luggage cover is used: Fold up
the luggage cover.
Pull the lever upwards and open the
deck board.
Lift the deck board and remove the
hook on the backside of the deck
board.Deck board 1
2
3
4

4536-3. Using the storage features
6
Interior features
NX300h_U_OM78007U Attach the hook to the upper edge
of the back door opening as shown.
Unhook the cords.
Fold up the luggage cover. 5
When attaching the side deck board, attach it so
that the “  FRONT” mark points to the front side
of the vehicle.
WA R N I N G
If the deck boards are opened or removed, return them to their original positions
before driving. In the event of sudden brakin g, an accident may occur due to an occu-
pant being struck by the deck boards or the items stored in the deck under tray.
Stowing the luggage cover 1
2

454 6-3. Using the storage features
NX300h_U_OM78007U Pull the lever upwards and open the
deck board.
Remove the luggage cover. When the seatback for the rear seat is
collapsed to the rear, remove the cover
after the cover most upright position.
(  P. 1 4 7 )
Stow the luggage cover in the deck
under tray while lifting the deck
board. 3
4
5
WA R N I N G ●
Do not place anything on the luggage cover.
In the event of sudden braking or turn-
ing, the item may go flying and strike an occupant. This could lead to an unexpected
accident, resulting in death or serious injury. ●
Do not allow children to climb on the lugg age cover. Climbing on the luggage cover
could result in damage to the luggage cover, possibly causing death or serious injury
to the child.

4556-4. Other interior features
6
Interior features
NX300h_U_OM78007UOther interior features To set the visor in the forward posi-
tion, flip it down.
To set the visor in the side position,
flip down, unhook, and swing it to the
side.
To use the side extender, place the
visor in the side position, then slide it
backward.
If the vanity lights remain on when the power swit ch is turned off, the light will go off auto-
matically after 20 minutes.Sun visors 1
2
3
Vanity mirrors 
On the sun visors 
On the sunglass holder
Slide the cover to open. The light turns on when the cover is
opened.
Remove the lid of sunglasses holder
using the strap. (  P. 4 4 9 )There is a vanity mirror on the back
side of the lid.
NOTICE ●
To prevent damage to the vanity mirror, when the lid of sunglass holder is removed, do
not subject it to strong impacts or set heavy objects on top of it.●
To prevent 12-volt battery discharge, do not leave the vanity lights on for extended
periods while the hybrid system is off. Strap

456 6-4. Other interior features
NX300h_U_OM78007U The clock can be adjusted by pressing the buttons.
Pressing and holding will move the
clock hands backward.
Pressing and holding will move the
clock hands forward.
Please use a power supply for electronic goods that use less than 12 VDC /10 A
(power consumption of 120 W).
When using electronic goods, make sure that the power consumption of all the
connected power outlets is less than 120 W.
●
The power outlet can be used when the power switch is in ACCESSORY or ON mode.Clock 1
2
Power outlet (12 VDC) 
Inside the console box 
In the luggage compartment
Open the lid. Open the lid. ●
The notch in console box allows power cables
to be passed through even when the console
box is closed.

4576-4. Other interior features
6
Interior features
NX300h_U_OM78007U Please use a power supply for electronic goods that use less than 120 VAC
(power consumption of 100 W).
Open the lid.
The power outlet can be used when the power switch is in ON mode.NOTICE ●
To avoid damaging the power outlet, close the power outlet lid when the power outlet
is not in use.
Foreign objects or liquids that enter the power outlet may cause a short circuit. ●
To prevent 12-volt battery discharge, do not use the power outlet longer than neces-
sary when the hybrid system is off.
Power outlet (120 VAC) (if equipped)
NOTICE ●
To avoid damaging the power outlet, close the power outlet lid when the power outlet
is not in use.
Foreign objects or liquids that enter the power outlet may cause a short circuit. ●
To prevent blown fuse, do not use a 120 VAC appliance that requires more than
100 W.
If a 120 VAC appliance that consumes more than 100 W is used, the protection cir-
cuit will cut the power supply. ●
To prevent 12-volt battery discharge, do not use the power outlet longer than neces-
sary when the hybrid system is off. ●
The following 120 VAC appliances may not operate properly even if their power con-
sumption is under 100W:
• Appliances with high initial peak wattage
• Measuring devices that process precise data
• Other appliances that require an extremely stable power supply

458 6-4. Other interior features
NX300h_U_OM78007U A portable device can be charged by ju st placing Qi standard wireless charge
compatible portable devices according to the Wireless Power Consortium, such
as smart phones and mobile batteries, etc., on the charge area.
This function cannot be used with port able devices that are larger than the
charging area. Also, depending on the portable device, it may not operate as
normal. Please read the operation manual for portable devices to be used. ■
The “Qi” symbol
The “Qi” symbol is a trademark of the Wireless Power Consortium. ■
Name for all parts
Power supply switch
Operation indicator light
Charge areaWireless charger (if equipped)
1
2
3

4596-4. Other interior features
6
Interior features
NX300h_U_OM78007U ■
Using the wireless charger
Open the console box. (  P. 4 4 7 )
Press the power supply switch of
the wireless charger. Switches on and off with each press
of the power supply switch.
When turned on, the operation indi-
cator light (green) comes on.
Even with the hybrid system off, the
on/off state of the power supply
switch is memorized.
Place the charging side of the
portable device down. When charging, the operation indi-
cator light (orange) comes on.
If charging is not occurring, try plac-
ing the portable device as close to
the center of the charging area as
possible.
When charging is complete, the
operation indicator light (green)
comes on.●
Recharging function
• When charging is complete and after a fixed time in the charge suspen-
sion state, charging restarts.
• When the portable device is moved, charging is stopped for a moment
and then it restarts. 1
2
3

460 6-4. Other interior features
NX300h_U_OM78007U ■
Lighting conditions of operation indicator light
* : Depending on the portable device, there are cases where the operation indicator
light will continue being lit up orange even after the charging is complete.●
When the operation indicator light flashes
When an error occurs, the operation in dicator light flashes an orange color.
Handle the error based on the following table.
■
The wireless charger can be operated when
The power switch is in ACCESSORY or ON mode. ■
Usable portable devices
Qi standard wireless charge standard can be used on compatible devices.
However, not all Qi standard devi ces and compatibility are guaranteed.
Starting with mobile phones and smart phones , it is aimed for low power electrically sup-
plied portable devices of no more than 5W.■
When covers and accessories are attached to portable devices
Do not charge in situations where cover an d accessories not able to handle Qi are
attached to the portable devi ce. Depending on the type of cover and accessory, it may
not be possible to charge. When charging is not performed even with the portable
device placed on the charge area, remove the cover and accessories. Operation indicator light Conditions
Tu r n i n g o f f When the Wireless charger power supply is off
Green (comes on) On Standby (charging possible state)
When charging is complete
*Orange (comes on) When placing the portable device on the charging
area (detecting the portable device)
Charging
Operation indicator light Suspected causes Handling method
Flashing repeatedly once
every second (Orange) Vehicle to charger commu-
nication failure. Contact your Lexus dealer.
Repeatedly flashes
3 times continuously
(Orange) A foreign substance is
between the portable device
and charge area. Remove the foreign sub-
stance from between por-
table device and the
charge area.
The portable device is out of
sync due to the device being
shifted from its position. Place the portable device
near the center of the
charge area.
Repeatedly flashes
4 times continuously
(Orange) Te m p e r a t u r e r i s i n g w i t h i n
the wireless charger. Stop charging at once and
start charging again after
for a while.
