4816-4. Other interior features
6
Interior features
NX300h_U_OM78007U Important! Read this informatio n before using Safety Connect.■
Exposure to radio frequency signals
The Safety Connect system installed in your vehicle is a low-power radio
transmitter and receiver. It receives and also sends out radio frequency (RF)
signals.
In August 1996, the Federal Communications Commission (FCC) adopted
RF exposure guidelines with safety levels for mobile wireless phones. Those
guidelines are consistent with the safe ty standards previously set by the fol-
lowing U.S. and international standards bodies. ●
ANSI (American National Stan dards Institute) C95.1 [1992]●
NCRP (National Council on Radiation Protection and Measurement)
Report 86 [1986] ●
ICNIRP (International Commission on Non-Ionizing Radiation Protection)
[1996]
Those standards were based on comprehensive and periodic evaluations of
the relevant scientific literature. Over 120 scientists, engineers, and physi-
cians from universities, and governme nt health agencies and industries
reviewed the available body of research to develop the ANSI Standard
(C95.1).
The design of Safety Connect complies wi th the FCC guidelines in addition to
those standards. ■
Certification for Lexus En form with Safety Connect
FCC ID: O6Y-CDMRF101
FCC ID: XOECDMRF101B
FCC ID: N7NGTM2
FCC WARNING:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supple-
ment C to OET65. This equipment should be installed and operated keeping the radia-
tor at least 20 cm or more away from person’s body (excluding extremities: hands, wrists,
feet and ankles).Safety information for Safety Connect

482 6-4. Other interior features
NX300h_U_OM78007U

483
7Maintenance and care
NX300h_U_OM78007U 7-1. Maintenance and care
Cleaning and protecting
the vehicle exterior.................484
Cleaning and protecting
the vehicle interior ................. 488
7-2. Maintenance
Maintenance
requirements.............................. 491
General maintena nce .............. 494
Emission inspection and
maintenance (I/M)
programs .....................................497
7-3. Do-it-yourself maintenance
Do-it-yourself service
precautions ................................ 498
Hood .............................................. 500
Positioning a floor jack .............. 501
Engine compartment ...............502
12-volt battery............................... 512
Tires ................................................... 516
Tire inflation pressure ............... 525
Wheels ........................................... 528
Air conditioning filter ...............530
Electronic key battery .............. 532
Checking and replacing
fuses ..............................................534
Light bulbs.....................................538

484 7-1. Maintenance and care
NX300h_U_OM78007UCleaning and protecting the vehicle exterior ●
Working from top to bottom, liberally apply water to the vehicle body, wheel
wells and underside of the vehicle to remove any dirt and dust. ●
Wash the vehicle body using a sponge or soft cloth, such as a chamois. ●
For hard-to-remove marks, use car wash soap and rinse thoroughly with
water. ●
Wipe away any water. ●
Wax the vehicle when the waterproof coating deteriorates. If water does not bead on a clean surface, apply wax when the vehicle body is cool.■
Self-restoring coat
The vehicle body has a self-restoring coating that is resistant to small surface scratches
caused in a car wash etc. ●
The coating lasts for 5 to 8 years after the coating has been performed. ●
The restoration time differs depending on the depth of the scratch and outside temper-
ature. The restoration time may become shor ter when the coating is warmed by apply-
ing warm water. ●
Deep scratches caused by keys or coins cannot be restored.●
Do not use wax that contain abrasives. ■
Automatic car washes ●
Before washing the vehicle:
• Fold the mirrors
• Turn off the power back door (if equipped)
Start washing from the front of the vehicle. Extend the mirrors before driving. ●
Brushes used in automatic car washes may scratch the vehicle surface and harm your
vehicle’s paint. ●
Rear spoiler may not be washable in some automatic car washes. There may also be an
increased risk of damage to vehicle. ■
High pressure car washes ●
Do not allow the nozzles of the car wash to come within close proximity of the windows. ●
Before using the car wash, check that the fuel filler door on your vehicle is closed prop-
erly.Perform the following to protect the ve hicle and maintain it in prime condi-
tion:

4857-1. Maintenance and care
7
Maintenance and care
NX300h_U_OM78007U ■
Note for a smart access system with push-button start ●
If the door handle becomes wet while the el ectronic key is within the effective range,
the door may lock and unlock repeatedly. Place the key in a position 6 ft. (2 m) or more
separate from the vehicle while the vehicle is being washed. (Take care to ensure that
the key is not stolen.) ●
If the electronic key is insi de the vehicle and a door handle becomes wet during a car
wash, a buzzer will sound outside the vehicle. To turn off the alarm, lock all the doors. ●
Set the electronic key to battery-saving mo de to disable the smart access system with
push-button start. (  P. 1 4 1 )■
Aluminum wheels ●
Remove any dirt immediately by using a neutral detergent. Do not use hard brushes or
abrasive cleaners. Do not use strong or harsh chemical cleaners.
Use the same mild detergent and wax as used on the paint. ●
Do not use detergent on the wheels when they are hot, for example after driving for
long distance in the hot weather. ●
Wash detergent from the wheels immediately after use. ■
Bumpers
Do not scrub with abrasive cleaners. ■
Front side windows water-repellent coatin g (vehicles with water-repellent coating)●
The following precautions can extend the effectiveness of the water-repellent coating.
• Remove any dirt, etc. from the front side windows regularly.
• Do not allow dirt and dust to accumulate on the windows for a long period.
Clean the windows with a soft, da mp cloth as soon as possible.
• Do not use wax or glass cleaners that co ntain abrasives when cleaning the windows.
• Do not use any metallic objects to remove condensation build up.●
When the water-repellent performance has become insufficient, the coating can be
repaired. Contact your Lexus dealer.

486 7-1. Maintenance and care
NX300h_U_OM78007U WA R N I N G ■
When washing the vehicle
Do not apply water to the inside of the en gine compartment. Doing so may cause the
electrical components etc. to catch fire. ■
When cleaning the windshield (vehicles with rain-sensing windshield wipers)
●
When the upper part of the windshield where the raindrop sensor is located is
touched by hand ●
When a wet rag or similar is held close to the raindrop sensor ●
If something bumps against the windshield ●
If you directly touch the raindrop sensor body or if something bumps into the raindrop
sensor ■
Precautions regarding the exhaust pipe
Exhaust gasses cause the exhaust pipe to become quite hot.
When washing the vehicle, be careful not to touch the pipe until it has cooled suffi-
ciently, as touching a hot exhaust pipe can cause burns. ■
Precautions regarding the rear bumper with Blind Spot Monitor (if equipped)
If the paint of the rear bumper is chipped or scratched, the syst em may malfunction. If
this occurs, consult your Lexus dealer.Set the wiper switch to off.
If the switch is in “AUTO”, the wipers may oper-
ate unexpectedly in the following situations,
and may result in hands being caught or other
serious injuries and cause damage to the wiper
blades.
Off

4877-1. Maintenance and care
7
Maintenance and care
NX300h_U_OM78007U NOTICE ■
To prevent paint deterioration and corrosio n on the body and components (aluminum
wheels etc.) ●
Wash the vehicle immediately in the following cases:
• After driving near the sea coast
• After driving on salted roads
• If coal tar or tree sap is present on the paint surface
• If dead insects, insect droppings or bird droppings are present on the paint surface
• After driving in an area contaminated wi th soot, oily smoke, mine dust, iron pow-
der or chemical substances
• If the vehicle becomes heavily soiled with dust or mud
• If liquids such as benzene and gaso line are spilled on the paint surface●
If the paint is chipped or scratche d, have it repaired immediately.●
To prevent the wheels from corroding, remo ve any dirt and store in a place with low
humidity when storing the wheels. ■
Cleaning the exterior lights ●
Wash carefully. Do not use organic substances or scrub with a hard brush.
This may damage the su rfaces of the lights.●
Do not apply wax to the surfaces of the lights.
Wax may cause damage to the lenses. ■
To prevent damage to the windshield wiper arms
When lifting the wiper arms away from the windshield, pull the dr iver side wiper arm
upward first, and repeat for the passenger side. When returning the wipers to their
original position, do so from the passenger side first. ■
When using an automatic car wash (vehicle s with rain-sensing windshield wipers)
Set the wiper switch to the off position.
If the wiper switch is in “AUTO”, the wipers may operate and the wiper blades may be
damaged. ■
When using a high pressure car wash ●
When washing the vehicle, do not let water of the high pressure washer hit directly or
the vicinity of the camera. Due to the shock fr om the high pressure water, it is possible
the device may not operate as normal. ●
Do not bring the nozzle tip close to followi ng parts and boots (Rubber or resin manu-
factured cover), or connectors. Parts may be damages if they come into contact with
high pressure water.
• Traction battery related parts
• Steering parts
• Suspension parts
•Brake parts

488 7-1. Maintenance and care
NX300h_U_OM78007UCleaning and protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth
dampened with lukewarm water. ●
Remove dirt and dust using a vacuum cleaner. ●
Wipe off any excess dirt and dust with a soft cloth dampened with diluted
detergent. Use a diluted water solution of appr oximately 5% neutral wool detergent.●
Wring out any excess water from the cloth and thoroughly wipe off all remain-
ing traces of detergent. ●
Wipe the surface with a dry, soft cloth to remove any remaining moisture.
Allow the leather to dry in a shaded and ventilated area. ●
Remove loose dirt using a vacuum cleaner. ●
Apply a mild soap solution to the synthe tic leather using a sponge or soft cloth.●
Allow the solution to soak in for a few minutes. Remove the dirt and wipe off
the solution with a clean, damp cloth.The following procedures will help protect your vehicle’s interior and keep it
in top condition:
Protecting the vehicle interior
Cleaning the leather areas
Cleaning the synthetic leather areas

4897-1. Maintenance and care
7
Maintenance and care
NX300h_U_OM78007U ■
Caring for leather areas
Lexus recommends cleaning the interior of th e vehicle at least twice a year to maintain
the quality of the vehicle’s interior. ■
Shampooing the carpets
There are several commercial foaming-type cleaners available. Use a sponge or brush to
apply the foam. Rub in overlapping circles. Do not use water. Wipe dirty surfaces and let
them dry. Excellent results are obtained by keeping the carpet as dry as possible. ■
Seat belts
Clean with mild soap and lukewarm water using a cloth or sponge. Also check the belts
periodically for excessive wear, fraying or cuts. ■
Front side windows with UV protective coating
The front side windows have UV protective coating. To prevent any damage to the UV
protective coating, observe the following: ●
If the windows are dirty, gently wipe them with a cloth soaked in water or lukewarm
water as soon as possible. ●
If the windows are very dirty, do not open and close them repeatedly.
WA R N I N G ■
Wa t e r i n t h e v e h i c l e ●
Do not splash or spill liquid in the vehicle, such as on the floor, in the hybrid battery
(traction battery) air vents, and in the luggage compartment.
Doing so may cause the hybrid battery, electrical components, etc. to malfunction or
catch fire. ●
Do not get any of the SRS components or wiring in the vehicle interior wet.
(  P. 4 2 )
An electrical malfunction may cause the airb ags to deploy or not function properly,
resulting in death or serious injury. ■
Cleaning the interior (especially instrument panel)
Do not use polish wax or polish cleaner. The instrument panel may reflect off the wind-
shield, obstructing the driver’s view and leading to an accident, resulting in death or
serious injury.

490 7-1. Maintenance and care
NX300h_U_OM78007U NOTICE ■
Cleaning detergents ●
Do not use the following types of detergent, as they may discolor the vehicle interior
or cause streaks or damage to painted surfaces:
• Non-seat portions: Organic substances su ch as benzene or gasoline, alkaline or
acidic solutions, dye, and bleach
• Seats: Alkaline or acidic solutions, such as thinner, benzene, and alcohol ●
Do not use polish wax or polish cleaner. The instrument panel’s or other interior part’s
painted surface may be damaged. ■
Preventing damage to leather surfaces
Observe the following precautions to avoid damage to and deterioration of leather
surfaces: ●
Remove any dust or dirt from leather surfaces immediately. ●
Do not expose the vehicle to direct sunlight for extended periods of time. Park the
vehicle in the shade, especially during summer. ●
Do not place items made of vinyl, plastic, or containing wax on the upholstery, as they
may stick to the leather su rface if the vehicle interior heats up significantly.■
Water on the floor
Do not wash the vehicle floor with water.
Vehicle systems such as the audio system ma y be damaged if water comes into contact
with electrical components such as the au dio system above or under the floor of the
vehicle. Water may also cause the body to rust. ■
When cleaning the inside of the windshield (vehicles with LDA [Lane Departure
Alert] or Automatic High Beam)
Be careful not to touch the camera sensor (  P. 2 7 0 ) .
If the camera is accidentally scratched or hit, LDA and Automatic High Beam may not
operate properly or may cause a malfunction. ■
Cleaning the inside of the rear window ●
Do not use glass cleaner to clean the rear window, as this may cause damage to the
rear window defogger heater wires or antenna. Use a cloth dampened with luke-
warm water to gently wipe the window cl ean. Wipe the window in strokes running
parallel to the heater wires or antenna. ●
Be careful not to scratch or damage the heater wires or antenna. ■
Cleaning the front side windows
Do not use any compound or abrasive product (e.g., glass cleaner, detergent, wax) to
clean the windows. It may damage the coating.
