LEXUS SC400 1991 Service Repair Manual

FRONT CROSSMEMBER (ASSY)
REMOVAL
BODY PANEL REPLACEMENTRE-4
WhereEverybodyKnowsYourName

INSTALLATION
1. Temporarily install the new parts and measureeach part in accordance with the body dimen-
sion diagram.
BODY PANEL REPLACEMENTRE-5
WhereEverybodyKnowsYourName

FRONT FENDER FRONT APRON (ASSY)
REMOVAL (With the radiator upper support removed.)
Apron Fender Side Extension
1. Replace the apron fender side extension at thesame time.
BODY PANEL REPLACEMENTRE-6
WhereEverybodyKnowsYourName

INSTALLATION
1. Temporarily install the new parts and measureeach part in accordance with the body dimen-
sion diagram.
BODY PANEL REPLACEMENTRE-7
WhereEverybodyKnowsYourName

FRONT APRON TO COWL SIDE UPPER
MEMBER (ASSY)
REMOVAL (With the front fender front apron removed.)
BODY PANEL REPLACEMENTRE-8
WhereEverybodyKnowsYourName

INSTALLATION
1. Temporarily install the new parts and mea-sure each part in accordance with the body
dimension diagram. 2. Temporarily install the front fender and the
hood, and check the fit.
BODY PANEL REPLACEMENTRE-9
WhereEverybodyKnowsYourName

FRONT FENDER APRON (ASSY)
REMOVAL (With the radiator upper support removed.)
BODY PANEL REPLACEMENTRE-10
WhereEverybodyKnowsYourName

INSTALLATION
2. Temporarily install the front fender and thehood, and check the fit.
1. Temporarily install the new parts and mea-
sure each part in accordance with the body
dimension diagram.
NOTICE: Make sure each measurement is correct,
as this parts affects the front wheel alignment.
BODY PANEL REPLACEMENTRE-11
WhereEverybodyKnowsYourName

mm in.228 8.98
FRONT SIDE MEMBER NO. 2 REINFORCE-
MENT (CUT)
REMOVAL
Front Side Member
Plate
Cut and Join
Location
1. After removing the front side member plate, cut and join the parts at the location shown
above.
HINT: Leaving the front side member inner on the
vehicle, cut the reinforcement only.
BODY PANEL REPLACEMENTRE-12
WhereEverybodyKnowsYourName

INSTALLATION
Butt Weld
1. Temporarily install the new parts and mea-sure each part in accordance with the body
dimension diagram.
BODY PANEL REPLACEMENTRE-13
