11. CONNECT ENGINE WIRE TO CABIN
(a) Push in the engine wire through the cowl panel.NOTICE: Be careful not to damage the engine wire. Tape
the engine wire.
(b) Install the engine wire retainer with the 3 bolts.
(c) Connect the following connectors: (1) 2 connectors to ECM
(2) Connector to ABS & TRAC ECU
(3) 2 connectors to TRAC ECU
(4) 4 connectors to connector cassette
(5) Connector to A/C control assembly
±
1UZ±FE ENGINE ENGINE MECHANICALEG±195
WhereEverybodyKnowsYourName

(d) Install the ECM with the nut.
(e) Install the ECM protector with the 2 nuts.
(f) Install the floor carpet.
(g) Install the scuff plate.
(h) Connect the connectors.
(i) Install the lower instrument panel finish panel and glovecompartment door assembly with the 4 screws.
(j) Install the instrument panel under cover with the 2 clips.
EG±196
±
1UZ±FE ENGINE ENGINE MECHANICAL
WhereEverybodyKnowsYourName

12. INSTALL CHARCOAL CANISTER
(a) Install the charcoal canister.
(b) Connect the vacuum hose and air hose to the charcoalcanister.
13. CONNECT HOSES Connect the following hoses and ground strap:
(1) Heater water hose to water bypass hose
(2) Heater water hose to heater water valve
(3) Brake booster hose to union on air intake chamber
(4) Vacuum hose (from VSV for heater water valve) to air in-
take chamber
(5) Ground strap to bracket on body
(6) Fuel inlet hose to fuel tube
SST 09278±54012
Torque: 30 N Vm (310 kgf Vcm, 22 ft Vlbf)
HINT: Use a torque wrench with a fulcrum length of 30 cm
(11.81 in.).
(7) Fuel return hose to return pipe
14. INSTALL AIR CONDITIONING (A/C) COMPRESSOR
(a) Install the A/C compressor, compressor stay and ground cable with the nut and 3 bolts.
Torque:
49 NVm (500 kgf Vcm, 36 ft Vlbf) for bolt
29 N Vm (300 kgf Vcm, 22 ft Vlbf) for nut
(b) Connect the A/C compressor connector.
±
1UZ±FE ENGINE ENGINE MECHANICALEG±197
WhereEverybodyKnowsYourName

15. INSTALL POWER STEERING (PS) PUMP
(a) Install the PS pump with the nut and 3 bolts. Alternatelytighten the bolts and nut.
Torque:
39 NVm (400 kgf Vcm, 29 ft Vlbf) for bolt
43 N Vm (440 kgf Vcm, 32 ft Vlbf) for nut
16. INSTALL POWER STEERING (PS) RESERVOIR TANK
AND BRACKET
Install the reservoir tank and bracket assembly with the 3
bolts.
17. INSTALL POWER STEERING (PS) TUBES Install the PS tube clamp with the bolt.
18. INSTALL GENERATOR
(a) Install the generator and transmission oil cooler pipe bracket with the bolt and nut.
Torque: 37 N Vm (380 kgf Vcm, 27 ft Vlbf)
(b) Connect the generator connector.
(c) Connect the generator wire with the nut and cap.
19. INSTALL WIRE CLAMP (FOR GENERATOR) AND VSV
(FOR EVAP)
(a) Install the wire clamp to the VSV bracket.
(b) Install the VSV with the 2 bolts.
EG±198
±
1UZ±FE ENGINE ENGINE MEHANICAL
WhereEverybodyKnowsYourName

20. INSTALL POWER STEERING (PS) SOLENOID VALVECONNECTOR
21. CONNECT ENGINE WIRE CONNECTORS
22. CONNECT THEFT DETERRENT HORN CONNECTOR
23. INSTALL GROUND CABLE TO BODY
24. CONNECT IGNITER CONNECTORS
(a) Connect the 2 igniter connectors HINT: Connect the yellow taped connector to the igniter on
the rear side.
(b) Install the wire clamp.
25. INSTALL RADIATOR ASSEMBLY
(a) Install the 2 lower radiator supports to the radiator.
(b) Place the radiator assembly on the body bracket.
(c) Slightly lift the radiator, and connect the 2 oil cooler hoses (for
cooling fan) to the hose clamp on the radiator fan shroud.
±
1UZ±FE ENGINE ENGINE MECHANICALEG±199
WhereEverybodyKnowsYourName

(d) Install the upper radiator support with the 2 bolts and screw.Install the 2 upper radiator supports.
Torque: 12 N Vm (120 kgf Vcm, 9 ft Vlbf)
(e) Connect the following hoses:
(1) 2 oil cooler hoses (for cooling fan) to pipes
(2) 2 radiator hoses
(3) 2 oil cooler hoses (for transmission) to radiator
(4) Suction hose to hydraulic pump
(5) Pressure hose to hydraulic pump
EG±200
±
1UZ±FE ENGINE ENGINE MECHANICAL
WhereEverybodyKnowsYourName

(f) Connect the ECT sensor connector (for cooling fan).
(g) Install the ECT sensor wire clamp to the radiator fan shroud.
26. INSTALL RADIATOR RESERVOIR TANK
(a) Install the reservoir tank to the reservoir tank bracket.
(b) Install the reservoir tank with the bracket and 3 bolts.
Torque: 4.9 N.m (50 kgfVcm, 43 in. Vlbf)
(c) Connect the following hoses:
(1) Reservoir hose to water inlet housing
(2) Reservoir hose to radiator
(d) Connect the coolant level sensor connector.
27. INSTALL INTAKE AIR CONNECTOR
(a) Connect the intake air connector to the throttle body.
(b) Install the hose clamp and bolt.
(c) Connect the following hoses to the intake air connector: (1) Air hose (from IAC valve)
(2) Air hose (from air control valve on PS pump)
28. CONNECT VACUUM HOSE (A) (FROM PS AIR CONTROL VALVE) TO AIR INTAKE CHAMBER
±
1UZ±FE ENGINE ENGINE MECHANICALEG±201
WhereEverybodyKnowsYourName

29. INSTALL AIR CLEANER
(a) Connect the air cleaner case to the air duct.
(b) Connect the air cleaner hose to the intake air connector.
(c) Install the air cleaner with the 3 bolts.
(d) Tighten the hose clamp bolt holding the air cleaner hose tothe intake air connector.
(e) Connect the VAF meter connector.
30. CONNECT CONTROL CABLES TO THROTTLE BODY
Connect the following cables:
(1) Accelerator cable
(2) Transmission throttle control cable
(3) Cruise control actuator cable
31. INSTALL THROTTLE BODY COVER
(a) Install the thro ttle body cover and hose clamp with the cap nut
and 2 bolts.
(b) Install the EVAP hose to the hose clamp.
32. INSTALL DRIVE BELT Install the drive belt by turning the drive belt tensioner coun-
terclockwise.
HINT: The pulley bolt for the dive belt tensioner has a left±
hand thread.
33. INSTALL BATTERY
EG±202
±
1UZ±FE ENGINE ENGINE MECHANICAL
WhereEverybodyKnowsYourName

34. FILL WITH ENGINE COOLANT
35. FILL WITH ENGINE OIL
36. START ENGINE AND CHECK FOR LEAKS
37. CHECK TRANSMISSION FLUID LEVEL
38. PERFORM ENGINE ADJUSTMENT(See Tune±Up on pages EG±9 to 34)
39. INSTALL ENGINE UNDER COVER
40. INSTALL HOOD
41. PERFORM ROAD TEST Check for abnormal noise, shock slippage, correct shift
points and smooth operation.
42. RECHECK ENGINE COOLANT AND OIL LEVELS
±
1UZ±FE ENGINE ENGINE MECHANICALEG±203
WhereEverybodyKnowsYourName

EXHAUST SYSTEM
COMPONENTS
EG24S±01
